BELT TENSION
| Application | Tension - Lbs. (kg) |
|---|
| All Models | (1) |
| (1) Serpentine belt tension is maintained automatically by a spring-tensioned idler pulley. No adjustment is necessary. |
| (1) | Serpentine belt tension is maintained automatically by a spring-tensioned idler pulley. No adjustment is necessary. |
ENGINE COMPRESSION
| Application | Compression Ratio |
|---|
| 4.3L VIN Z | 9.05:1 |
| 5.0L (VIN H) | 9.1:1 |
| 5.7L (VIN K) | (1) 9.1:1 |
| 7.4L (VIN N) | 7.9:1 |
| (1) Compression ratio is 8.3:1 for vehicles with GVW greater than 8500 lbs. |
| (1) | Compression ratio is 8.3:1 for vehicles with GVW greater than 8500 lbs. |
COMPRESSION SPECIFICATIONS
VALVE CLEARANCE
Note. All models are equipped with hydraulic lifters. No adjustments are required.
IGNITION COIL
| Application | Ohms |
|---|
| All Models | 500-1500 |
HIGH TENSION WIRE RESISTANCE
| Application | Ohms |
|---|
| All Models | 30,000 Maximum |
HIGH TENSION WIRE RESISTANCE
SPARK PLUGS
| Application | AC |
|---|
| 4.3L VIN Z | CR43TSM |
| 5.0L (VIN H), 5.7L (VIN K) & 7.4L (VIN N) | CR43TS |
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|
| 4.3L VIN Z | .045 (1.14) | 11 (15) |
| 5.0L (VIN H) | .035 (0.89) | 11 (15) |
| 5.7L (VIN K) | .035 (0.89) | 11 (15) |
| 7.4L (VIN N) | .035 (0.89) | 11 (15) |
SPARK PLUG SPECIFICATIONS
FIRING ORDER & TIMING MARKS
Note. For firing order and timing marks, see appropriate illustration. (Scheme 1)& 2.
Firing Order & Timing Marks (4.3L). Scheme 1
Scheme 1: Firing Order & Timing Marks (4.3L)
Firing Order & Timing Marks (5.0L, 5.7L & 7.4L). Scheme 2
Scheme 2: Firing Order & Timing Marks (5.0L, 5.7L & 7.4L)
IGNITION TIMING
Note. For timing adjustment procedures, see appropriate ADJUSTMENTS - GASOLINE article in the ENGINE PERFORMANCE section.
| Application | (1) Man. Trans. | (2) Auto. Trans. |
|---|
| 4.3L (VIN Z) | 0 @ Idle | 0 @ Idle |
| 5.0L (VIN H) | 0 @ Idle | 0 @ Idle |
| 5.7L (VIN K) | 0 @ Idle | 0 @ Idle |
| 7.4L (VIN N) | 4 @ Idle | 4 @ Idle |
| (1) With transmission in Neutral. (2) With transmission in Neutral or Park. |
| (1) | With transmission in Neutral. |
| (2) | With transmission in Neutral or Park. |
IGNITION TIMING (Degrees BTDC @ RPM)
FUEL PUMP
| Application | Psi (kg/cm 2 ) |
|---|
| 4.3L (VIN Z), 5.0L (VIN H) & 5.7L (VIN K) | 9-13 (.63-.91) |
| 7.4L (VIN N) | 26-32 (1.83-2.25) |
INJECTOR RESISTANCE
| Application | Ohms |
|---|
| All Models | 1.3 |
| (1) Injector resistance specification is at 140°F (60°C). |
| (1) | Injector resistance specification is at 140°F (60°C). |
INJECTOR RESISTANCE SPECIFICATIONS (1)
IDLE SPEED & MIXTURE
Note. Idle mixture on fuel injected models is controlled by Electronic Control Module (ECM) and is not adjustable. Controlled idle speed and IAC count can be checked using scan tester. See CONTROLLED IDLE SPEED & IAC COUNT table.
| Application | Idle RPM | (1) IAC Counts |
|---|
| 4.3L TBI |
| "C" & "K" Series |
| Auto. Trans. (2) (4) | 537 | 5-30 |
| Auto. Trans. (2) (4) | 650 | 20-35 |
| Man. Trans. (3) | 550 | 2-20 |
| 5.0L TBI |
| "C" & "K" Series |
| Auto. Trans. (2) | 500 | 5-30 |
| Man. Trans. (3) | 600 | 5-30 |
| 5.7L TBI |
| "C" & "K" Series |
| Under 8500 GVW |
| Auto. Trans. (2) | 550 | 5-30 |
| Man. Trans. (3) | 660 | 5-30 |
| Over 8500 GVW |
| Auto. Trans. (2) | 550 | 5-30 |
| Man. Trans. (3) | 600 | 5-30 |
| 7.4L TBI |
| "G" & "P" Series |
| Auto. Trans. (2) | 750 | 5-30 |
| Man. Trans. (3) | 800 | 5-30 |
| (1) Add 2 counts for engines with less than 500 miles. On 4.3L and V8 engines, add 2 counts for every 1000 ft. above sea level. (2) Automatic transmission in Drive. (3) Manual transmission in Neutral. Tech 1 scan tester will display "RDL" with transmission in Neutral. (4) Calibration identification is not given by manufacturer. IAC count and actual RPM should correspond to one of these calibrations. |
| (1) | Add 2 counts for engines with less than 500 miles. On 4.3L and V8 engines, add 2 counts for every 1000 ft. above sea level. |
| (2) | Automatic transmission in Drive. |
| (3) | Manual transmission in Neutral. Tech 1 scan tester will display "RDL" with transmission in Neutral. |
| (4) | Calibration identification is not given by manufacturer. IAC count and actual RPM should correspond to one of these calibrations. |
CONTROLLED IDLE SPEED & IAC COUNT
MINIMUM IDLE SPEED
Note. Minimum idle speed adjustment can only be performed on 7.4L engines. For minimum idle speed adjustment procedures, see ADJUSTMENTS - GASOLINE article in the ENGINE PERFORMANCE section.
