Riding Height Adjustment: Other Chevrolet Pickup K2500

Wheel Alignment 5 illustrations

RIDE HEIGHT

  1. Proper ride height is necessary for correct wheel alignment. Ensure tires are correctly inflated, cargo compartment is empty and fuel tank is full. Bounce vehicle several times to normalize ride height.
  2. Most vehicles provide front wheel alignment specifications which allow camber and caster adjustment for a large range of ride heights. See «RIDE HEIGHT SPECIFICATIONS»(ref-61842-S23390851692001011800000) table. Ride height measurement points are shown in illustrations. (Scheme 8)- (Scheme 12).

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
ApplicationRide Height: In. (mm)
Astro & Safari
2WD3.1 ± 0.24 (80 ± 6.0)
4WD5.4 ± 0.24 (136 ± 6.0)
"C" & "K" Series
C15/353.7 ± 0.2 (95 ± 6.0)
K15/256.2 ± 0.2 (157 ± 6.0)
K355.7 ± 0.2 (145 ± 6.0)
Commercial Van & Van(1)
(1) Ride height is not adjustable.
(1)Ride height is not adjustable.

RIDE HEIGHT SPECIFICATIONS
