A/c System General Servicing: Other Chevrolet Pickup C1500

HANDLING/SAFETY PRECAUTIONS

1. Always work in a well-ventilated, clean area. Refrigerant (R-12 or R-134a) is colorless and invisible as a gas. Refrigerant is heavier than oxygen and will displace oxygen in a confined area. Avoid breathing refrigerant vapors. Exposure may irritate eyes, nose and throat.
2. The system's high pressure can cause severe injury to eyes and skin if a hose were to burst. Always wear eye protection when working around A/C system and refrigerant. If necessary, wear rubber gloves or other protective clothing.
3. Refrigerant evaporates quickly when exposed to atmosphere, freezing anything it contacts. If liquid refrigerant contacts eyes or skin (frostbite), DO NOT rub eyes or skin. Immediately flush affected area with cool water for 15 minutes and consult a doctor or hospital.
4. Never use R-134a in combination with compressed air for leak testing. Pressurized R-134a in the presence of oxygen (air concentrations greater than 60 percent by volume) may form a combustible mixture. DO NOT introduce compressed air into R-134a containers (full or empty), A/C system components, or service equipment.
5. DO NOT expose A/C system components to high temperatures (steam cleaning for example) as excessive heat will cause refrigerant/system pressure to increase. Never expose refrigerant directly to open flame. If refrigerant needs to be warmed, place bottom of refrigerant tank in warm water. Water temperature MUST NOT exceed 125°F (52°C).
6. Use care when handling refrigerant containers. DO NOT drop, strike, puncture, or incinerate containers. Use Department Of Transportation (DOT) approved (DOT 4BW or DOT 4BA) refrigerant containers.
7. Never overfill refrigerant containers. The safe filling level of a refrigerant container MUST NOT exceed 60% of the container's gross weight rating. Store refrigerant containers below 125°F (52°C).
8. Freon (R-12) will be sold and stored in White colored containers, while R-134a refrigerant will be sold and stored in 30 or 50 pound Light Blue containers.
9. Refrigerant R-12 and R-134a must never be mixed, as they and their desiccants and lubricants are not compatible. If the refrigerants are mixed, system cross-contamination or A/C system component failure may occur. Always use separate servicing and refrigerant recovery/recycling equipment.
10. Read and follow equipment manufacturer's instructions for all service equipment to be used. The Material Safety Data Sheet (MSDS), provided by refrigerant manufacturer/suppliers, contains valuable information regarding the safe handling of R-12 or R-134a refrigerants.

IDENTIFYING R-134a SYSTEMS & COMPONENTS

To prevent refrigerant cross-contamination, use following methods to identify R-134a based systems and components.

Fittings & "O" Rings

All R-134a based A/C systems use 1/2" - 16 ACME threaded fittings (identifiable by square threads) and quick-connect service couplings.

REFRIGERANT OILS

Refrigerant R-12 based systems use mineral oil, while R-134a systems use synthetic/Polyalkylene Glycol (PAG) oils. Using a mineral oil based lubricant with R-134a will result in A/C compressor failure due to lack of proper lubrication.

Use only specified oil for the appropriate system and A/C compressor. Always check the underhood A/C specification label or A/C compressor label before adding refrigerant oil to A/C compressor/system. The following R-134a refrigerant oils are currently available.

GM

Use PAG Refrigerant Oil (Part No. 12345923).

Note. Synthetic/PAG oils absorb moisture very rapidly, 2.3-5.6% by weight, as compared to a mineral oil absorption rate of .005% by weight.

SERVICE EQUIPMENT

Note. Ensure "O" rings are designed for use with specified refrigerant. Deterioration of "O" rings and system contamination will result if incorrect "O" rings are used.

Because R-134a is not interchangeable with R-12, separate sets of hoses, gauges and recovery/recycling equipment are required to service vehicles. This is necessary to avoid cross-contamination and damaging system.

All equipment used to service systems using R-134a must meet SAE standard J1991. The service hoses on the manifold gauge set must have manual (turn wheel) or automatic back-flow valves at the service port connector ends. This will prevent refrigerant from being released into the atmosphere.

For identification purposes, R-134a service hoses must have a Black stripe along their length and be clearly labeled SAE J2196/R-134a. The low pressure test hose is Blue with a Black stripe. The high pressure test hose is Red with a Black stripe. The center test hose is Yellow with a Black stripe.

Note. Refrigerant R-12 service hoses will ONLY be labeled SAE J2196.

R-134a manifold gauge sets can be identified by one or all of the following

1. Labeled FOR USE WITH R-134a on set
2. Labeled HFC-134 or R-134a on gauge face
3. Light Blue color on gauge face

In addition, pressure/temperature scales on R-134a gauge sets are different from R-12 manifold gauge sets.

SIGHT GLASS INDICATOR

Note. Sight glass indicator conditions listed are for R-12 systems. Information for R-134a systems is not available.

Not all systems use a sight glass. If used, a sight glass may be mounted in receiver-drier (accumulator) or in discharge line. Refrigerant's condition can be visually checked while passing through sight glass. The following are possible conditions of sight glass indicator, which may help in the diagnosis of problems. (Scheme 11)

Clear Sight Glass

A clear sight glass indicates refrigerant level is correct or is excessively low for system circulation. Sight glass may be clear, but system may contain excessive refrigerant. This must be verified by test gauge readings.

Bubbly/Foamy Sight Glass

A bubbly or foamy sight glass indicates system is low on refrigerant, and air has probably entered system. However, if only occasional bubbles are noticed, during clutch cycling or system start-up, this may be a normal condition.

Oil Streaked Sight Glass

If oil streaks appear on sight glass, a lack of refrigerant may be indicated, and the system's compressor oil is circulating through the system.

Cloudy Sight Glass

A cloudy sight glass indicates desiccant contained in receiver-drier or accumulator has broken down and is being circulated through system.

Sight glass readings are not positive identification of a problem. Readings should be relied upon only when other system symptoms exist.

Identifying Sight Glass Indicator Conditions. Scheme 11

STEM-TYPE VALVES

This manually operated service valve has adjustable stem located under a protective cap. Valve stem must be manually positioned when making gauge connections and/or reading system pressure on the gauges. (Scheme 12)

Identifying Stem-Type Service Valve Positions. Scheme 12

Back-Seated (Operating) Position

This is the normal operating position, which is also used for connecting and disconnecting manifold gauge set. Stem is turned fully outward to seal the service gauge port.

SCHRADER-TYPE VALVES

Note. Although similar in construction and operation to a tire valve, NEVER replace a Schrader-type valve with a tire valve.

Schrader valve is similar in construction and operation to a tire valve. When a test gauge hose is attached (hose has built-in valve core depressor), Schrader stem is pushed inward to the open position and allows system pressure to reach the gauge.

If test hose being used does not have a built-in core depressor, an adapter must be used. Never attach hoses or adapters to a Schrader valve unless it is first connected to manifold gauge set.

SPECIAL VALVE CONNECTORS

All vehicles with R-134a refrigerant use quick-disconnect service valves. To help prevent installing hoses and other parts used on R-12 systems, all fittings on R-134a systems use 1/2"-16 ACME threads.

On some General Motors models, thread size on high-side service valve (3/8-24 threads) is different from thread size on low-side service valve (7/16-20 threads). Special adapters are required to make this connection. These adapters are available in 45-degree and 90-degree angles in addition to straight fixed and flexible adapters.

MANIFOLD GAUGE SET

A manifold gauge set is used to determine system's high-side and low-side pressures, correct refrigerant charge, system diagnosis and operating efficiency. High (discharge) and low (suction) pressures must be compared to determine system operation. Manifold gauge sets for the two refrigerant types are basically the same. The fittings at the ends of the hoses are different to ensure connection only to a system using the type of refrigerant specified for that manifold gauge set.

Low-Side Gauge

The low-side gauge, which may have a Blue identifying feature, is used to measure low-side (suction) pressure. Low-side gauge is also called a compound gauge because it can measure pressure and vacuum. Pressure scale ranges from 0 to 150 psi; vacuum scale ranges from 0 to 30 in. Hg.

High-Side Gauge

The high-side gauge, which may have a Red identifying feature, is used to measure high-side (discharge) pressure. Gauge scale ranges from 0 to 500 psi.

1. Put on safety goggles, and cover vehicle's fender. Remove protective caps from Schrader valves. Do this slowly to check for leaky valves. CAUTION: Ensure hand valves on manifold gauge set are closed before connecting test hoses to Schrader valves.
2. Ensure service hoses are equipped with valve core depressor to match Schrader valve. Special adapters are required if service hoses do not have built-in core depressor. Ensure both manifold gauge hand valves are closed.
3. Connect low-side service hose to low-side (suction) service valve, and finger tighten connections. Connect high-side service hose to high-side (discharge) service valve, and finger tighten connections.

1. Put on safety goggles, and cover vehicle's fender. Place valves in back-seated position. Remove protective caps from service valves. Do this slowly to check for leaky valves. CAUTION: Ensure hand valves on manifold gauge set are closed before turning service valve to mid-position.
2. Attach low-side service hose to low-side (suction) service valve. Connect high-side service hose to high-side (discharge) service valve. Finger-tighten both connections.

Note. After test gauges are installed, test hoses must be purged of all air before proceeding with testing.

STABILIZING A/C SYSTEM

1. Once manifold gauge set is attached to system and test hoses have been purged (if required), system is ready for testing. Place all test hoses, gauge set and other equipment away from all moving parts of engine.
2. Start engine, and turn A/C controls to maximum cooling position. Set blower fan on high speed. Open doors and/or windows, and operate system for 5-10 minutes. System should now be stabilized and ready for test readings.

PRESSURE GAUGE INDICATIONS

Note. Pressure gauge indications are for R-12 systems only. Information for R-134a systems is not available from manufacturers.

The following typical pressure gauge indications represent conditions that may be encountered during system servicing. see scheme 6- see scheme 12. Temperature and humidity, as well as other factors, affect pressure gauge readings. Pressure gauge indications should be used only as a guide.

Correction

1. Discharge refrigerant from system.
2. Replace receiver-drier, accumulator or desiccant bag.
3. Evacuate system with vacuum pump.
4. Charge system with R-12.
5. Operate system and check performance.

1. Stop vehicle engine and turn air conditioner "OFF".
2. Remove and discard old clutch cycling switch, install a new switch of same type.
3. Operate system and check performance.

MISADJUSTED THERMOSTATIC SWITCH GAUGE READINGS

See DEFECTIVE CLUTCH CYCLING SWITCH PRESSURE GAUGE READINGS below.

Correction With Thermostatic Switch

Note. If no adjusting screw is provided, the switch is nonadjustable and must be replaced.

1. Stop engine and turn air conditioner off.
2. Remove components necessary to gain access to thermostatic adjustment screw.
3. Make certain that all wiring is positioned so that no short-circuiting can occur. Connect battery cable so that engine can be operated while making switch adjustment. Adjust thermostatic switch.

Note. A pressure sensing switch is used on most late General Motors models with accumulator-type systems. It performs the same function as thermostatic switch.

Correction With Clutch Cycling Switch

Note. Switch is non adjustable and is mounted on a Schrader valve fitting. Therefore, no system discharge is required.

1. Stop engine and turn air conditioner off.
2. Detach electrical connector from pressure sensing switch at accumulator.
3. Remove pressure sensing switch, and install a new switch.

1. Leak test system.
2. Discharge refrigerant from system if necessary to replace units or lines.
3. Repair leaks.
4. Check compressor oil level. System may have lost oil due to leakage.
5. Evacuate system using vacuum pump.
6. Charge system with R-12.
7. Operate system and check performance.

1. If compressor operation is stopped due to a pressure sensing switch, by-pass switch with jumper wire until testing and correction are complete.
2. Add a partial refrigerant charge (to at least 50 percent system capacity), then make thorough leak test.
3. Discharge refrigerant from system.
4. Check compressor oil level. System may have lost oil due to leakage.
5. Evacuate system using vacuum pump.
6. Charge system with R-12.
7. Operate system and check performance.

1. Evacuate system using vacuum pump.
2. Charge system with R-12.
3. Operate system and check performance.

1. Evacuate system using vacuum pump.
2. Replace orifice tube.
3. Charge system with R-12.
4. Operate system and check performance.

1. If expansion valve test indicates valve operation is satisfactory, proceed as follows: Clean contact surface of evaporator outlet pipe and temperature sensing bulb, then clamp bulb securely in contact with pipe and recover with proper insulation tape. Operate system and check performance.
2. If expansion valve test indicates valve is defective, proceed as follows: Discharge system. Replace expansion valve, making sure all contacts are clean and secure. Evacuate system using vacuum pump, then charge system with R-12. Operate system and check performance.

1. Isolate compressor (if equipped with stem-type service valves) or discharge entire system.
2. Remove compressor cylinder head and inspect compressor. Replace reed valve plate assembly if necessary. Install cylinder head using NEW gasket.
3. Check compressor oil level.
4. Replace receiver-drier, desiccant or accumulator if: System previously opened. System operated two or more seasons with present unit. Compressor inspection revealed desiccant particles (very fine golden or brown particles).
5. Using vacuum pump, evacuate compressor or entire system (depending on procedure used in step 1).
6. Charge system with R-12.
7. Operate system and check performance.

1. Check electric cooling fan operation.
2. Inspect condenser for clogged air passages, bug screen, or other obstructions preventing airflow through condenser.
3. Inspect condenser mounting for proper radiator clearance. Inspect clutch type fan for proper operation. Inspect radiator pressure cap for correct type and proper operation.

After making above corrections, operate system and check performance. If condition is not corrected

1. Inspect system for overcharge of refrigerant and correct as follows: Discharge refrigerant until stream of bubbles appears in sight glass and both high and low gauge readings drop below normal. Add R-12 until bubbles disappear and pressures are normal, then add an additional 1/4-1/2 lb. of refrigerant.
2. Operate system and check performance. If Gauge Readings Still Too High Discharge system, and remove and inspect condenser to ensure free passage of refrigerant or replace condenser. Replace receiver-drier, desiccant bag or accumulator. Evacuate system using vacuum pump. Charge system with R-12. Operate system and check performance.

REFRIGERANT RECOVERY/RECYCLING

Note. The use of recovery/recycling equipment is required by law.

Refrigerant recovery/recycling equipment is used to remove refrigerant from vehicle's A/C system without polluting atmosphere. To remove and recycle refrigerant, ALWAYS follow instructions provided with the refrigerant/recovery equipment being used.

The removed refrigerant is filtered, dried and stored in a tank within the recovery/recycling equipment until it is ready to be pumped back into the vehicle's A/C system.

Note. Separate sets of hoses, gauges and refrigerant recovery/recycling equipment MUST be used for R-12 and R-134a based systems. DO NOT mix R-12 and R-134a refrigerants, as their refrigerant oils and desiccants are NOT compatible.

GENERAL MOTORS

1. Close both valves on manifold gauge set. Connect manifold gauge set to high-side and low-side service valves. See «SERVICE VALVE LOCATIONS»(ref-40115-S03404477502001080200000) under SYSTEM SERVICE VALVES.
2. Connect center hose on manifold gauge set to inlet port on Refrigerant Recovery/Recycling Equipment (J-38100-B). Start engine. Turn A/C on for about 2 minutes. NOTE: Operating A/C for 2 minutes will warm the refrigerant so refrigerant recovery/recycling equipment can recover more refrigerant from the system.
3. Shut engine off. Open both valves on manifold gauge set. Simultaneously open both valves on refrigerant recovery/recycling equipment storage tank.
4. Plug refrigerant recovery/recycling equipment in and turn power switch on. Depress compressor START switch, and ensure the compressor ON light is activated.
5. The refrigerant recovery/recycling equipment will shut off when a vacuum reading of 17 in. Hg is obtained on manifold gauge set. Manifold gauge vacuum reading should remain at 17 in. Hg for at least 2 minutes.
6. If vacuum reading is greater than zero, some refrigerant still remains in the vehicle's A/C system. Depress compressor START switch, and operate refrigerant recovery/recycling equipment through another cycle.
7. Once refrigerant is recovered, open accumulator pressure valve on the refrigerant recovery/recycling equipment for 15 seconds. This will pressurize the oil separator so refrigerant oil can be drained.
8. Open oil drain valve on the refrigerant recovery/recycling equipment, and drain refrigerant oil into a container. Measure exact amount of oil to be added when system is put back in service.

DISCHARGING A/C SYSTEM

Note. When discharging refrigerant from A/C system, use refrigerant recovery/recycling equipment to prevent refrigerant from entering the atmosphere. The use of recovery/recycling equipment is required by law.

Manufacturer does not provide procedures for discharging A/C system. Discharge A/C system using approved refrigerant recovery/recycling equipment. Follow refrigerant recovery procedures outlined under REFRIGERANT RECOVERY/RECYCLING .

1. Manufacturer does not recommend flushing A/C system. If system is contaminated, discharge system and install a liquid line filter between condenser and evaporator.
2. Filter may be an integral part of the line, or line may need to be cut and filter installed (non-integral type). Filters may or may not contain orifice. (Scheme 13)
3. Filter with orifice is installed on low pressure side of orifice tube. Remove original orifice tube if installing filter with orifice. Filter without orifice must be installed on high pressure side of orifice tube.
4. To install liquid line filter, discharge A/C system, and remove liquid line. Using a tubing cutter, cut section from liquid line to allow installation of liquid line filter. Clean all burrs, and smooth surfaces.
5. Install nut over the line. Install ferrule on line with small end toward nut. DO NOT install "O" ring at this time.
6. Push line into fitting until it bottoms on filter assembly. Tighten nuts on each joint to 11 ft. lbs. (15 N.m). Disassemble joint assembly.
7. Lubricate NEW "O" rings with refrigerant oil and install them on the lines. Install filter assembly. Ensure arrow on filter indicates proper flow of refrigerant. Tighten nuts to 11 ft. lbs. (15 N.m). Evacuate and charge system. Check system for leaks.

Scheme 13

R-12

1. Close both valves on manifold gauge set. Connect low-side gauge hose to low-side service valve. See «SERVICE VALVE LOCATIONS»(ref-40115-S03404477502001080200000) under SYSTEM SERVICE VALVES. Connect high-side gauge hose to evacuation pump and center hose to R-12 drum. Ensure valve on R-12 drum is closed.
2. Fully open both valves on manifold gauge set. Start evacuation pump, and operate it until vacuum reading is at least 28-29 in. Hg on low side. If specified reading cannot be reached, A/C system or gauge set leaks or evacuation pump is defective. Repair or replace components as necessary.
3. Continue operating evacuation pump for 5 minutes after reaching 28-29 in. Hg. Close both valves on manifold gauge set. Stop evacuation pump. Observe low-side gauge. Any loss of vacuum indicates a system or gauge leak.
4. If leak is indicated, charge system with 8 ounces of R-12, and perform leak testing procedure. See LEAK TESTING. Repair any leaks, and repeat evacuation procedures.

R-134a

Information is not available.

CHARGING A/C SYSTEM

Note. Manufacturer does not recommend using one-pound cans. Using a charging station will allow precise measurement of refrigerant charge. Refer to the appropriate REFRIGERANT OIL & REFRIGERANT SPECIFICATIONS at the end of this article for system capacities.

Note. DO NOT connect high-side gauge hose to high-side service port. Perform A/C charging service through low side only.

1. System must be evacuated before charging. With manifold gauge set attached from evacuation procedure, start engine, but DO NOT turn on A/C. With gauges and refrigerant drum (inverted for liquid charging) connected from evacuation procedure, open low-side gauge valve on manifold gauge set. Allow 16 ounces of refrigerant to enter system.
2. When 16 ounces of refrigerant have entered system, turn A/C system to normal operating position with blower fan on high speed. Continue charging (liquid charging) until proper amount of refrigerant has entered system.
3. Close refrigerant drum valve, and continue running A/C system for 30 seconds to clear lines and gauges. Turn off valve on manifold gauge set. With engine running, disconnect low-side hose, and install service valve cap at accumulator. Perform leak test procedure. See LEAK TESTING.

BODY DESIGNATIONS

BODY DESIGNATIONS

BODY DESIGNATIONS (GENERAL MOTORS LIGHT TRUCKS & VANS)
