RIDE HEIGHT SPECIFICATIONS
Note. Corvette ride height specification is not available from manufacturer.
On "C", "G", "H", and "J" body, maximum variation between side-to-side and front-to-rear should not exceed .75" (19 mm). On "N" body, maximum variation between side-to-side should not exceed 0.24" (6 mm). On all other models, maximum variation between side-to-side and front-to-rear should not exceed .47" (12 mm).
| Application | In. (mm) |
|---|
| Dimension "A" |
| "C" & "G" Body (1) | 23.5 (597) |
| Seville | 23.62 (600) |
| Dimension "B" |
| "C" & "G" Body | 23.13 (588) |
| Seville | 23.22 (590) |
| Dimension "J" |
| "C" Body | 6.44 To 7.25 (164 To 184) |
| "G" Body | 6.69 To 7.5 (170 To 190) |
| Seville |
| Standard Suspension (KS) | 7.05 (179) |
| Touring Suspension (KY) | 6.65 (169) |
| Dimension "K" |
| "C" Body | 8.38 To 9.19 (213 To 233) |
| "G" Body | 8.63 To 9.41 (219 To 239) |
| Seville |
| Standard Suspension (KS) | 9.02 (229) |
| Touring Suspension (KY) | 8.58 (218) |
| Dimension "Z" |
| "C" & "G" Bodies | 1.19 To 2.0 (30 To 50) |
| Seville |
| Standard Suspension (KS) | 1.57 (39.88) |
| Touring Suspension (KY) | 1.18 (29.97) |
| Dimension "D" |
| "C" & "G" Bodies | 3.0 To 3.75 (79 To 96) |
| Seville |
| Standard Suspension (KS) | 3.39 (86) |
| Touring Suspension (KY) | 2.99 (76) |
| (1) (Scheme 1) |
RIDE HEIGHT SPECIFICATIONS ("C" & "G" BODIES & SEVILLE)
| Application | In. (mm) |
|---|
| Concours, DeVille & Eldorado (1) |
| Dimension "A" | 22.84 (580) |
| Dimension "B" | 22.17 (563) |
| Dimension "J" |
| Concours | 6.77 To 7.57 (172 To 192) |
| DeVille | 7.16 To 7.96 (182 To 202) |
| Eldorado | 8.26 To 9.06 (210 To 230) |
| Dimension "K" |
| Concours | 7.96 To 7.16 (162 To 182) |
| DeVille | 8.35 To 7.55 (172 To 192) |
| Eldorado | 8.03 To 8.83 (204 To 224) |
| Dimension "E" |
| Concours | 27.04 To 27.84 (687 To 707) |
| DeVille | 27.43 To 28.23 (697 To 717) |
| Eldorado | 27.75 To 28.55 (705 To 725) |
| Dimension "F" |
| Concours | 17.79 To 18.59 (452 To 472) |
| DeVille | 20.98 To 21.78 (533 To 553) |
| Eldorado | 27.51 To 28.31 (699 To 719) |
| Dimension "Z" |
| Concours | 1.25 To 2.05 (32 to 52) |
| DeVille | 1.61 To 2.41 (41 To 61) |
| Eldorado | 1.57 To 2.37 (40 To 60) |
| Dimension "D" |
| Concours | 0.7 To 1.5 (28 To 38) |
| DeVille | 1.06 To 1.86 (27 To 47) |
| Eldorado | 0.74 To 1.54 (19 To 39) |
| (1) (Scheme 2) |
RIDE HEIGHT SPECIFICATIONS ("E" & "K" BODIES - EXCEPT SEVILLE)
| Application | In. (mm) |
|---|
| 1998 Camaro & Firebird (1) |
| Dimension "A" | 16.5 (420) |
| Dimension "B" | 14.4 (367) |
| Dimension "J" | 7.6 To 8.4 (194 To 214) |
| Dimension "K" | 8.0 To 8.8 (204 To 212) |
| Dimension "D" | 4.2 To 5.0 (108 To 128) |
| Dimension "Z" |
| With 235-55 Tires | 0.8 To 1.6 (20 To 40) |
| With 245-50 Tires | 1.1 To 1.9 (27 To 47) |
| (1) (Scheme 4) |
RIDE HEIGHT SPECIFICATIONS (1998 "F" BODY)
| Application | In. (mm) |
|---|
| 1999 Camaro & Firebird (1) |
| Dimension "1" (Side Rocker Panel) | 8.0 (203) |
| Dimension "2" (Side Rocker Panel) | 8.2 (208) |
| Dimension "3" (Front Fascia) |
| Camaro | 17.0 To 17.8 (432 To 452) |
| Firebird Except Trans Am With 235/55 Tires | 13.0 To 13.8 (330 To 351) |
| Trans Am With 235/55 Tires | 15.9 To 16.7 (404 To 424) |
| Dimension "4" (Rear Fascia) |
| Camaro | 14.0 To 14.8 (356 To 376) |
| Firebird | 14.3 To 15.1 (363 To 384) |
| (1) (Scheme 5) |
RIDE HEIGHT SPECIFICATIONS (1999 "F" BODY)
| Application | In. (mm) |
|---|
| Bonneville, Eighty Eight, LeSabre, LSS & Regency (1) |
| Dimension "A" | 23.5 (597) |
| Dimension "B" | 23.5 (597) |
| Dimension "J" | 9.0 To 9.8 (229 To 249) |
| Dimension "K" | 9.3 To 10.1 (236 To 256) |
| Dimension "D" | 2.69 To 3.44 (68 To 88) |
| Dimension "Z" | 1.94 To 2.75 (50 To 70) |
| (1) (Scheme 6)and (Scheme 7). |
RIDE HEIGHT SPECIFICATIONS ("H" BODY)
| Application | In. (mm) |
|---|
| 1998 Cavalier & Sunfire (1) |
| Dimension "A" |
| Cavalier | 31.5 (800) |
| Sunfire | 32.16 (817) |
| Dimension "B" | 22.05 (560) |
| Dimension "J" | 8.77 To 957 (223 To 243) |
| Dimension "K" | 9.05 To 9.85 (230 To 250) |
| Dimension "Z" |
| With 14" Tires | 0.07 To 0.87 (2 To 22) |
| With 15" Tires | 0.15 To 0.65 (-4 To 16) |
| With 16" Tires | 0.24 To 0.56 (-6 To 14) |
| 1999 Cavalier & Sunfire |
| Dimensions "A" & "B" | (2) |
| Dimension "J" | 8.77 To 9.57 (223 To 243) |
| Dimension "K" |
| Except Convertible | 9.04 To 9.84 (230 To 250) |
| Convertible | 9.24 To 10.04 (235 To 255) |
| Dimension "Z" |
| With 14" Tires | 0.24 To 0.56 (-6 To 14) |
| With 15" Tires |
| Cavalier 2.2L 4-Door (3) | 0.4 To 0.4 (-10 To 10) |
| Cavalier 2.4L 2-Door (4) , Sunfire 2.2L 4-Door (3) & 2.4L 2-Door (4) | 0.32 To 0.48 (-8 To 18) |
| Cavalier 2.4L 4-Door (5) , Sunfire 2.4L 2 & 4-Door (5) | 0.35 To 0.45 (-9 To 11) |
| Convertible 2.2L (5) | 0.2 To 0.6 (-5 To 15) |
| Convertible 2.4L (5) | 0.12 To 0.68 (-3 To 17) |
| (1) (Scheme 3) (2) Information is not available for 1999. (3) With active suspension. (4) With ride handling suspension. (5) With soft ride suspension. |
| (2) | Information is not available for 1999. |
| (3) | With active suspension. |
| (4) | With ride handling suspension. |
| (5) | With soft ride suspension. |
RIDE HEIGHT SPECIFICATIONS ("J" BODY)
| Application | In. (mm) |
|---|
| Metro & Firefly (Canadian) (1) |
| Dimension "A" | 17.75 (450) |
| Dimension "B" | 17.75 (450) |
| Dimension "J" | 8.45 To 9.25 (215 To 235) |
| Dimension "K" | 7.85 To 8.65 (200 To 220) |
| Dimension "Z" | 1.35 To 2.10 (35 To 55) |
| (1) (Scheme 6) |
RIDE HEIGHT SPECIFICATIONS (METRO & FIREFLY (CANADIAN))
| Application | In. (mm) |
|---|
| 1998 Achieva, Grand Am & Skylark |
| Dimension "A" | 31.5 (800) |
| Dimension "B" | 21.4 (560) |
| Dimension "J" | 8.99 To 9.75 (228 To 248) |
| Dimension "K" | 9.19 To 9.95 (233 To 253) |
| Dimension "D" | (1) |
| Dimension "Z" |
| 14" Wheels |
| Achieva, Grand Am & Skylark | 0.19 To 0.94 (4.83 To 23.88) |
| 15" Wheels |
| Achieva | .063 To .69 (-1.6 To 17.53) |
| Grand Am & Skylark | 0.03 To 0.72 (-3.56 To 18.26 |
| 16" Wheels |
| Achieva & Grand Am | 0.14 To 0.61 (-3.56 To 15.5) |
| Skylark | 0.09 To 0.66 (-2.29 To 16.8) |
| 1998-99 Cutlass & Malibu, 1999 Alero & Grand Am |
| Dimension "A" | (1) |
| Dimension "B" | (1) |
| Dimension "J" | 8.96 To 971 (227 To 247) |
| Dimension "K" | 9.23 To 9.99 (234 TO 254) |
| Dimension "D" |
| 15" Wheels (Except Grand Am 4-Door) | 4.47 To 5.22 (113 To 133) |
| 15" Wheels Grand Am 4-Door | 4.38 To 5.13 (110 To 130) |
| 16" Wheels | 4.40 To 5.15 (111 To 131) |
| Dimension "Z" |
| 15" Wheels (Except Grand Am 4-Door) | 0.38 To 0.38 (-10 To 10) |
| 15" Wheels Grand Am 4-Door | 0.15 To 0.61 (-16 To 4) |
| 16" Wheels | 0.18 To 0.58 (-15 To 5) |
| (1) Information is not available. (Scheme 3)for approximate locations. |
| (1) | Information is not available. (Scheme 3)for approximate locations. |
RIGHT HEIGHT SPECIFICATIONS ("N" BODY)
| Application (2) | In. (mm) |
|---|
| Dimension "Z" |
| With P175/64R14 Tires | 6.88 To 7.68 (175 To 195) |
| With P185/64R14 Tires | 7.08 To 7.88 (180 To 200) |
| Dimension "D" |
| With P175/64R14 Tires | 9.25 To 10.05 (235 To 255) |
| With P185/64R14 Tires | 9.44 To 10.24 (240 To 260) |
| (1) 1998 specifications are not available. (2) (Scheme 8) |
| (1) | 1998 specifications are not available |
RIDE HEIGHT SPECIFICATIONS (1999 PRIZM (1) )
| Application | In. (mm) |
|---|
| Catera (1) |
| Dimension "P" | 27.3 (693) |
| Dimension "J" | 6.9 (175) |
| Dimension "K" | 6.5 (165) |
| Dimension "R" | 27.3 (693) |
| (1) (Scheme 9) |
RIDE HEIGHT SPECIFICATIONS ("V" BODY)
| Application (1) | In. (mm) |
|---|
| 1998 Lumina & Monte Carlo |
| Dimension "A" | 23.8 (605) |
| Dimension "B" | 20.7 (526) |
| Dimension "J" | 9.6 To 10.4 (244 To 264) |
| Dimension "K" | 9.8 To 10.06 (249 TO 269) |
| Dimension "Z" |
| Lumina & Monte Carlo (2) , 205/70R15 Tires; Lumina Police & Taxi (3) , 215/65R15 Tires | 2.56 To 3.36 (65 To 85) |
| Lumina LS & Police (2) , 205/70R15 Tires | 2.6 To 3.4 (66 To 86) |
| Lumina LS (3) , 225/60R16 | 2.36 To 3.16 (60 To 80) |
| Lumina , Lumina LS, (2) , 225/60R16 Tires; Monte Carlo Z34, 225/60R16 Tires & Monte Carlo LS 255/60R16 Tires, (3) | 2.32 To 3.12 (59 To 79) |
| Dimension "D" |
| Lumina & Monte Carlo (2) , 205/70R15 Tires; Lumina Police & Taxi (3) , 215/65R15 Tires | 10.3 To 11.1 (262 To 282) |
| Lumina LS & Police (2) , 205/70R15 Tires; Lumina LS (3) , 225/60R16 | 10.35 To 11.15 (263 To 283) |
| Lumina , Lumina LS (2) , 225/60R16 Tires | 10.12 To 10.92 To (257 To 277) |
| Monte Carlo Z34, 225/60R16 Tires & Monte Carlo LS 255/60R16 Tires, (3) | 10.09 To 10.89 (256 To 276) |
| 1998-99 Century & Regal; 1999 Lumina & Monte Carlo |
| Dimension "A" | 23.8 (605) |
| Dimension "B" | 20.7 (526) |
| Dimension "J" & "K" | 8.00 To 8.80 (203 To 223) 8.00 To 8.80 (203 To 223) |
| Dimension "Z" |
| Century, Lumina, Monte Carlo & Regal With 225/60R16 Tires | 1.49 To 2.29 (38 To 58) |
| Lumina & Monte Carlo With 225/70R15 Tires | 1.73 To 2.53 (45 To 65) |
| Dimension "D" |
| Century, Lumina, Monte Carlo & Regal With 225/60R16 Tires | 9.64 To 10.44 (245 To 265) |
| Lumina & Monte Carlo With 225/70R15 Tires | 9.88 To 10.68 (251 To 271) |
| Intrigue |
| Dimension "A" | 23.8 (605) |
| Dimension "B" | 20.7 (526) |
| Dimension "J" |
| 1998 | 8.00 To 8.80 (203 To 223) |
| 1999 | 8.18 To 8.98 (208 To 228) |
| Dimension "K" |
| 1998 | 8.00 To 8.80 (203 To 223) |
| 1999 | 8.38 To 9.18 (213 To 233) |
| Dimension "Z" |
| 1998 With Soft Ride Suspension | 1.68 To 2.48 (43 To 63) |
| 1998 With Firm Ride Suspension | 1.43 To 2.23 (36.3 To 56.3) |
| 1999 | 1.57 To 2.37 (40 To 60) |
| Dimension "D" |
| 1998 With Soft Ride Suspension | 9.94 To 10.74 (252.7 To 277.7) |
| 1998 With Form Ride Suspension | 9.73 To 10.53 (247.4 To 267.4) |
| 1999 | 10.15 To 10.95 (258 To 278) |
| (1) (Scheme 3)and (Scheme 10). (2) With soft ride suspension. (3) With firm ride suspension. |
| (2) | With soft ride suspension. |
| (3) | With firm ride suspension. |
RIDE HEIGHT SPECIFICATIONS ("W" BODY)
| Application | In. (mm) |
|---|
| Corvette (1) |
| Dimension "A" | 35 (889) |
| Dimension "B" | 31 (787) |
| Dimension "J" | 5.73 To 6.23 (146 To 158 |
| Dimension "K" | 5.93 To 6.43 (151 To 163) |
| Dimension "D" | 4.0 To 4.5 (102 To 114) |
| Dimension "Z" | 1.48 To 1.98 (38 To 50) |
| (1) (Scheme 11) |
RIDE HEIGHT SPECIFICATIONS ("Y" BODY)
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| "C" Body |
| Adjustment Link Cam Nut | 55 (75) |
| Strut-To-Steering Knuckle Nut | 137 (185) |
| Strut-To-Strut Body Nut | 35 (47) |
| Tie Rod End Lock Nut (Front & Rear) | 47 (64) |
| "E" & "K" Body (Except Seville) |
| Rear Toe Link Bolt | 66 (90) |
| Strut-To-Steering Knuckle Nut | 140 (184) |
| Strut-To-Strut Tower Nut | 18 (24) |
| Tie Rod End Lock Nut | 46 (63) |
| "F" Body |
| Lower Control Arm-To-Crossmember Nut | 74 (100) |
| Tie Rod End Lock Nut | 35 (47) |
| "G" Body & Seville |
| Rear Inner Adjustment Link Cam Nut |
| "G" Body | 55 (75) |
| Seville | 74 (100) |
| Strut-To-Steering Knuckle Nut |
| G" Body | 137 (185) |
| 1998 Seville | 125 (170) |
| 1999 Seville | 166 (225) |
| Strut-To-Strut Tower Nut |
| Except 1999 Seville | 35 (47) |
| 1999 Seville | 30 (40) |
| Tie Rod End Lock Nut | 47 (64) |
| "H" Body |
| Strut-To-Steering Knuckle Nut | 140 (190) |
| Strut-To-Strut Body Nut | 18 (24) |
| Tie Rod End Lock Nut (Front & Rear) | 47 (64) |
| "J" Body |
| Strut-To-Steering Knuckle Nut | 133 (180) |
| Tie Rod End Lock Nut | 55 (75) |
| Metro & Firefly (Canadian) |
| Rear Cam Bolt Nut | 59 (80) |
| Tie Rod End Lock Nut | 33 (45) |
| "N" Body |
| Strut-To-Steering Knuckle Nut | 133 (180) |
| Tie Rod End Clamp Bolt |
| 1998 Achieva, Grand Am & Skylark | 31 (42) |
| Tie Rod End Lock Nut |
| 1998 Cutlass & Malibu | (3) |
| Except 1998 Cutlass & Malibu | 50 (68) |
| Prizm |
| Tie Rod End Lock Nut | 41 (56) |
| "V" Body |
| Brake Caliper Mounting Bolts | (1) 70 (95) |
| Strut-To-Steering Knuckle Bolts | (2) 66 (90) |
| Tie Rod Adjuster Clamp Bolts | 11 (15) |
| Wheel Lug Nuts | 80 (109) |
| "W" Body |
| Century, Grand Prix & Regal |
| Rear Wheel Spindle Rod | 37 (50) |
| Tie Rod End Lock Nut | 50 (68) |
| Strut-To-Knuckle Bolts | 90 (122) |
| Intrigue, Lumina & Monte Carlo |
| Rear Rod-To-Crossmember Nuts | 111 (150) |
| Front Strut Cover Plate Nuts | 24 (33) |
| Strut-To-Knuckle Nuts | 112 (83) |
| Tie Rod End Lock Nuts | 46 (62) |
| "Y" Body |
| Front Lower Control Arm Cam Bolt Nuts | 125 (170) |
| Front Upper Control Arm Bolts | 42 (57) |
| Rear Lower Control Arm |
| Front Cam Bolt Nuts | 107 (145) |
| Rear Cam Bolt Nuts | 70 (95) |
| Front Tie Rod End Lock Nuts | 50 (68) |
| Rear Tie Rod End Lock Nuts | 44 (60) |
| (1) Tighten an additional 37 degrees. (2) Tighten an additional 53 degrees. (3) Tighten to 89 INCH lbs. (10 N.m) plus an additional 210 degrees. |
| (1) | Tighten an additional 37 degrees. |
| (2) | Tighten an additional 53 degrees. |
| (3) | Tighten to 89 INCH lbs. (10 N.m) plus an additional 210 degrees. |
| Application | Preferred | Range |
|---|
| "C" Body |
| Camber (1) |
| Front | 0.2 | 0.7 To 0.3 |
| Rear | 0.3 | 0.8 To 0.2 |
| Caster (1) | 6 | 5.5 To 6.5 |
| Toe-In (1) |
| Front | 0.2 | 0.1 To 0.5 |
| Rear | 0.2 | 0 To 0.4 |
| Toe-In (2) |
| Front | 0.1 (2.5) | 0.05 To 0.25 (-1.3 To 6.4) |
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5.1) |
| "E" & "K" Body |
| Concours, DeVille & Eldorado |
| Camber (1) |
| Front | 0 | 0.5 To 0.5 |
| Rear | 0 | 0.5 To 0.5 |
| Caster (1) | 2.3 | 1.3 To 3.3 |
| Toe-In (1) |
| Front | 0.2 | 0 To 0.4 |
| Rear | 0.2 | 0 To 0.4 |
| Toe-In (2) |
| Front | 0.1 (2.5) | 0 To 0.2 (0 To 5.0) |
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5.0) |
| Seville SLS & STS |
| Camber (1) |
| SLS |
| Front | 0.02 | 0.07 To 0.3 |
| Rear | 0.03 | 0.08 To 0.2 |
| STS |
| | | | Front | 0.2 | 0.7 To 0.3 |
| | | | Rear | 0.6 | 1.1 To -0.1 |
| Caster (1) | 6 | 5.5 To 6.5 |
| Toe-In (1) |
| Front | 0.2 | 0 To 0.4 |
| Rear | 0.2 | 0 To 0.4 |
| Toe-In (2) |
| Front | 0.1 (2.5) | 0 To 0.2 (0 To 5) |
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5) |
| "F" Body |
| Camber (1) |
| Front | 0.4 | 0.1 To 0.9 |
| Rear | 0 | 0.6 To 0.6 |
| Caster (1) | 5.0 | 4.5 To 5.5 |
| Toe-In (1) |
| Front | 0 | 0.1 To 0.1 |
| Rear | 0 | 0.15 To 0.15 |
| Toe-In (2) |
| Front | 0 | 0.2 To 0.2 (-2.5 To 2.5) |
| Rear | 0 | 0.3 To 0.3 (-4.0 To 4.0) |
| "G" Body |
| Camber (1) |
| Front | 0.2 | 0.7 To 0.3 |
| Rear | 0.3 | 0.8 To 0.2 |
| Caster (1) | 6 | 5.5 To 6.5 |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.2 | 0 To 0.4 |
| Toe-In (2) |
| Front | 0 (0) | 0.1 To 0.1 (-2.5 To 2.5) |
| Rear | 0.1 (2.5) | 0 To 0.2 (0 To 5.0) |
| "H" Body |
| Camber (1) |
| Front | 0.2 | 0.3 To 0.7 |
| Rear | 0.3 | 0.8 To 0.2 |
| Caster (1) | 3.0 | 2.5 To 3.5 |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.1 | 0.1 To 0.3 |
| Toe-In (2) |
| Front | 0.1 (2.5) | 0.1 To 0.1 (-2.5 To 2.5) |
| Rear | 0.05 (1.5) | 0.05 To 0.15 (-1.5 To 4.0) |
| "J" Body |
| Camber (1) |
| Front | 0.2 | 1.2 To 0.8 |
| Rear | 0.25 | 1.0 To 0.5 |
| Caster (1) | 4.3 | 3.3 To 5.3 |
| Toe-In (1) |
| Front | 0.1 | 0.15 To 0.35 |
| Rear | 0.2 | 0.1 To 0.5 |
| Toe-In (2) |
| Front | 0.05 (1.5) | 0.07 To 0.17 (-1.5 To 4) |
| Rear | 0.1 (2.5) | 0.05 To 0.25 (-1.5 To 6.5) |
| "N" Body |
| 1998 Achieva, Grand Am & Skylark |
| Camber (1) |
| Front | 0 | 1.0 To 1.0 |
| Rear | 0.4 | 1.15 To 0.35 |
| Caster (1) | 1.45 | 0.45 To 2.45 |
| Toe-In (1) |
| Front | 0 | 0.25 To 0.25 |
| Rear | 0.2 | 0.1 To 0.5 |
| Toe-In (2) |
| Front | 0 (0) | 0.12 To 0.12 (-3.0 To 3.0) |
| Rear | 0.1 (2.5) | 0.05 To 0.25 (-1.5 To 6.5) |
| 1998-99 Malibu & Cutlass, & 1999 Alero & Grand Am |
| Camber (1) |
| Front | 0.2 | 1.2 To 0.8 |
| Rear | 0.2 | 0.7 To 0.30 |
| Caster (1) | 4.1 | 3.1 To 5.1 |
| Toe-In (1) |
| Front | 0.1 | 0.15 To 0.35 |
| Rear | 0.06 | 0.26 To 0.14 |
| Toe-In (2) |
| Front | 0.05 (1.5) | 0.07 To 0.17 (-1.5 To 4.0) |
| Rear | 0.03 (1) | 0.13 To 0.07 (-2.5 To 2.5) |
| Metro & Firefly (Canadian) |
| Camber (1) |
| Front | 0.5 | 0.5 To 1.5 |
| Rear | 0 | 1 To 1 |
| Caster (1) | 3 | 2 To 4 |
| Toe-In (1) |
| Front | 0.16 | 0 To 0.32 |
| Rear | 0.45 | 0.3 To 0.6 |
| Toe-In (2) |
| Front | 0.08 (2) | 0 To 0.16 (0 To 4) |
| Rear | 0.23 (6) | 0.15 To 0.3 (4 To 7.5) |
| Prizm |
| Camber (1) |
| Front | 0.18 | 0.93 To 0.57 |
| Rear | 0.92 | 1.67 To -0.17 |
| Caster (1) | 1.33 | 0.58 To 2.08 |
| Toe-In (1) |
| Front | 0.1 | 0.1 To 0.3 |
| Rear | 0.4 | 0.2 To 0.6 |
| Toe-In (2) |
| Front | 0.05 (1.5) | 0.05 To 0.15 (-1.5 To 4) |
| Rear | 0.25 (5) | 0.1 To 0.3 (2.5 To 7.5) |
| "V" Body |
| Camber (1) |
| Front | 1.5 | 2.0 To -1.0 |
| Rear | 1.9 | 2.3 To -1.5 |
| Caster (1) | 4.4 | 3.9 To 4.9 |
| Toe-In (1) |
| Front | 0.1 | 0.06 To 0.26 |
| Rear | 0.1 | 0.06 To 0.26 |
| Toe-In (2) |
| Front | 0.05 (1.5) | 0.03 To 0.13 (-1.0 To 3.5) |
| Rear | 0.05 (1.5) | 0.03 To 0.13 (-1.0 To 3.5) |
| "W" Body |
| Lumina & Monte Carlo |
| With 15" Wheels |
| Camber (1) |
| Front | 0.7 | 0.2 To 1.2 |
| Rear | 0.35 | 0.85 To 0.15 |
| Caster (1) | 1.8 | 1.3 To 2.3 |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0 | 0.3 To 0.3 |
| Toe-In (2) |
| Front | 0 (0) | 0.1 To 0.1 (-2.5 To 2.5) |
| Rear | 0 (0) | 0.15 To 0.15 (-3.8 To 3.8) |
| With 16" Wheels |
| Camber (1) |
| | | | Front | 0.7 | 0.2 To 1.2 |
| | | | Rear | 0.45 | /0.95 To 0.05 |
| Caster (1) | 1.8 | 1.3 To 2.3 |
| Toe-In (1) |
| | | | Front | 0 | 0.2 To 0.2 |
| | | | Rear | 0 | 0.3 To 0.3 |
| Toe-In (2) |
| | | | Front | 0 (0) | 0.1 To 0.1 (-2.5 To 2.5) |
| | | | Rear | 0 (0) | 0.15 To 0.15 (-3.8 To 3.8) |
| Intrigue |
| Camber (1) |
| Front | 0.91 | 1.41 To -0.41 |
| Rear | 0.52 | 1.02 To -0.02 |
| Caster (1) | 3.05 | 2.55 To 3.55 |
| Toe-In (1) |
| Front | 0.1 | 0.1 To 0.3 |
| Rear | 0.05 | 0.15 To 0.25 |
| Toe-In (2) |
| Front | 0.05 (1.5) | 0.05 To 0.15 (-1.5 To 4) |
| Rear | 0.2 (1.5) | 0.07 To 0.12 (-1.5 To 3) |
| "Y" Body |
| Camber (1) |
| Front | 0.2 | 0.7 To 0.3 |
| Rear | 0.18 | 0.68 To |
| Caster (1) | 6.1 | 5.6 To 6.6 |
| Toe-In (1) |
| Front | 0.08 | 0.12 To 0.28 |
| Rear | 0.02 | 0.22 To 0.18 |
| Toe-In (2) |
| Front | 0.04 (1) | 0.06 To 0.14 (-1.5 To 3.5) |
| Rear | 0.01 (.5) | 0.11 To 0.09 (-3 To 2) |
| (1) Measurement is in degrees. (2) Measurement is in inches (mm). |
| (1) | Measurement is in degrees. |
| (2) | Measurement is in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (EXCEPT CENTURY, GRAND PRIX & REGAL)
| Operation | Service Allowable | Service Preferred |
|---|
| Front |
| Camber 15" and 16" Tires | 0.20 to 1.20 | 0.7 |
| Caster | 1.30 to 2.30 | 1.8 |
| Steering Angle | 3.50 to 3.50 | 0 |
| Toe (Total) | 0.20 to 0.20 | 0 |
| Rear |
| Camber 15" and 16" Tires | 0.65 to 0.35 | 0.15 |
| Thrust Angle | 0.15 to 0.15 | 0 |
| Toe (Total) | 0.20 to -0.40 | 0.1 |
WHEEL ALIGNMENT SPECIFICATIONS (CENTURY & REGAL)
| Operation | Service Allowable | Service Preferred |
|---|
| Front |
| Camber (Cross) | 1.40 to -0.40 | 0.90 |
| Caster (Cross) | 2.50 to 3.50 | 3.00 |
| Steering Angle | 3.50 to 3.50 | 0 |
| Toe (Total) | 0.30 to -0.10 | 0.10 |
| Rear |
| Camber (Cross) | 1.40 to -0.40 | 0.90 |
| Thrust Angle | 0.15 to 0.15 | 0 |
| Toe (Total) | 0.40 to 0.20 | 0 |
WHEEL ALIGNMENT SPECIFICATIONS (GRAND PRIX)
