Fuse & Circuit Breaker Identification
- 1 - Left Headlamp, High Beam Indicator
- 2 - Right Headlamp
- 3 - Parking Lamps, Sidemarker Lamps, License Plate Lamps, Instrument Cluster Lights
- 4 - Door Lock System (If Equipped)
- 5 - Hazard Lamps, Horn
- 6 - Ignition System, Gages, Warning & Indicator Lights, Automatic Transaxle Speed Sensor
- 7 - Heater, Air Conditioning (If Equipped)
- 8 - Stoplamps
- 9 - Lighter, Radio
- 10 - Back Up Lamps, Turn Signal Lamps
- 11 - Rear Defogger (If Equipped)
- 12 - Front & Rear Wiper/Washer
Scheme 1
Scheme 1: ENGINE COMPARTMENT FUSE BOX IDENTIFICATION
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- BATT All Electrical Load
- ABS ABS System
- IG Accessory, Ignition, Windshield Wipers, Defrost/Defog, Heater, Back Up Lamps
- LAMP Tail Lamps, Stop Lamps, Hazard, Headlamps (Right & Left)
- PTC PTC Heater
- FI Fuel Injection
- RDTR Radiator Fan Motor
- A/C Air Conditioner
