SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10-Cyl. |
| Compressor Belt Deflection (1) | 9/32-3/8" (7-9 mm) |
| System Oil Capacity (2) | 3.4 ozs. |
| Refrigerant (R-134a) Capacity | 19.4-21.1 ozs. |
| System Operating Pressure (3) |
| High Side | 185-228 psi (13.0-16.0 kg/cm 2 ) |
| Low Side | 29.9-46.9 psi (2.1-3.3 kg/cm 2 ) |
| (1) Specification is with 22 lbs. (9.9 kg) of force applied midway on longest span of belt. (2) Use Polyalkylene Glycol (PAG) oil. (3) Specification is with ambient temperature at 80°F (27°C), relative humidity at 50-70 percent and engine speed at idle RPM. |
| (1) | Specification is with 22 lbs. (9.9 kg) of force applied midway on longest span of belt. |
| (2) | Use Polyalkylene Glycol (PAG) oil. |
| (3) | Specification is with ambient temperature at 80°F (27°C), relative humidity at 50-70 percent and engine speed at idle RPM. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bracket Bolt |
| Front | 47-50 (64-68) |
| Right | 25-29 (34-39) |
| Compressor Mounting Bolt | 16-20 (22-27) |
| Condenser Outlet Pipe Fitting Nut | 26 (35) |
| Evaporator Inlet Pipe Fitting Nut | 26 (35) |
| Idler Pulley Lock Nut | 32-36 (44-49) |
| Receiver-Drier-To-Evaporator Inlet Pipe Fitting Nut | 26 (35) |
| INCH Lbs. (N.m) |
| Battery Terminal | 49 (5.5) |
| Compressor Discharge Pipe Fitting | 87 (9.8) |
| Condenser Inlet Pipe Fitting Nut | 87 (9.8) |
| Hood Latch Assembly Mounting Bolt | 62 (7) |
Manual A/C-Heater System Wiring Diagram (Metro & Firefly (Canadian)). Scheme 1
Scheme 1: Manual A/C-Heater System Wiring Diagram (Metro & Firefly (Canadian))
