Interior lights — Instrument illumination circuit Chevrolet Malibu VIII
All systems — 36 systems
- Air conditioning 3
- Anti-lock brakes
- Anti-theft
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.4l vin 0
- Engine performance 2.4l vin 1
- Engine performance 2.4l vin u
- Engine performance 3.6l vin 7
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 5
- Power top/sunroof
- Power windows
- Radio 5
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 2.4l vin 0
- Transmission 2.4l vin 1
- Transmission 2.4l vin u
- Transmission 3.6l vin 7
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Components on these wiring diagrams 28
Click a component to highlight it on every diagram it appears on.
