Engine Controls and Fuel - 2.4l - Description and Operation Chevrolet Malibu VII

Engine Control Module Description

The engine control module (ECM) interacts with many emission related components and systems, and monitors the emission related components and systems for deterioration. OBD II diagnostics monitor the system performance and a diagnostic trouble code (DTC) sets if the system performance degrades.

The malfunction indicator lamp (MIL) operation and the DTC storage are dictated by the DTC type. A DTC is ranked as a Type A or Type B if the DTC is emissions related. Type C is a non-emissions related DTC.

The ECM is in the engine compartment. The ECM is the control center of the engine controls system. The ECM controls the following components

1. The fuel injection system
2. The ignition system
3. The emission control systems
4. The on-board diagnostics
5. The A/C and fan systems
6. The throttle actuation control (TAC) system

The ECM constantly monitors the information from various sensors and other inputs, and controls the systems that affect the vehicle performance and the emissions. The ECM also performs diagnostic tests on various parts of the system. The ECM can recognize operational problems and alert the driver via the MIL. When the ECM detects a malfunction, the ECM stores a DTC. The condition area is identified by the particular DTC that is set. This aids the technician in making repairs.

ECM Function

The engine control module (ECM) can supply 5 V or 12 V to the various sensors or switches. This is done through pull-up resistors to the regulated power supplies within the ECM. In some cases, even an ordinary shop voltmeter will not give an accurate reading because the resistance is too low. Therefore, a DMM with at least 10 Mohms input impedance is required in order to ensure accurate voltage readings.

The ECM controls the output circuits by controlling the ground or the power feed circuit through the transistors or a device called an output driver module.

EEPROM

The electronically erasable programmable read only memory (EEPROM) is a permanent memory that is physically part of the engine control module (ECM). The EEPROM contains program and calibration information that the ECM needs in order to control the powertrain operation.

Special equipment, as well as the correct program and calibration for the vehicle, are required in order to reprogram the ECM.

Data Link Connector (DLC)

The data link connector (DLC) is a 16-pin connector that provides the technician a means of accessing serial data for aid in the diagnosis. This connector allows the technician to use a scan tool in order to monitor the various serial data parameters, and display the DTC information. The DLC is located inside of the drivers compartment, underneath the dash.

Malfunction Indicator Lamp (MIL)

The malfunction indicator lamp (MIL) is inside of the instrument panel cluster (IPC). The MIL is controlled by the engine control module (ECM) and illuminates when the ECM detects a condition that affects the vehicle emissions.

ECM Service Precautions

The engine control module (ECM), by design, can withstand the normal current draws that are associated with the vehicle operations. However, care must be used in order to avoid overloading any of these circuits. When testing for opens or shorts, do not ground or apply voltage to any of the ECM circuits unless the diagnostic procedure instructs you to do so. These circuits should only be tested with a DMM.

Emissions Diagnosis For State I/M Programs

This OBD II equipped vehicle is designed to diagnose any conditions that could lead to excessive levels of the following emissions

1. Hydrocarbons (HC)
2. Carbon monoxide (CO)
3. Oxides of nitrogen (NOx)
4. Evaporative emission (EVAP) system losses

Should this vehicles on-board diagnostic system (ECM) detect a condition that could result in excessive emissions, the ECM turns ON the malfunction indicator lamp (MIL) and stores a DTC that is associated with the condition.

Aftermarket (Add-On) Electrical And Vacuum Equipment

Aftermarket, add-on, electrical and vacuum equipment is defined as any equipment installed on a vehicle after leaving the factory that connects to the vehicles electrical or vacuum systems. No allowances have been made in the vehicle design for this type of equipment.

Add-on electrical equipment, even when installed to these strict guidelines, may still cause the powertrain system to malfunction. This may also include equipment not connected to the vehicle electrical system, such as portable telephones and radios. Therefore, the first step in diagnosing any powertrain condition is to eliminate all of the aftermarket electrical equipment from the vehicle. After this is done, if the problem still exists, the problem may be diagnosed in the normal manner.

Electrostatic Discharge (ESD) Damage

Note. In order to prevent possible electrostatic discharge damage to the engine control module (ECM), DO NOT touch the connector pins on the ECM.

The electronic components that are used in the control systems are often designed to carry very low voltage. The electronic components are susceptible to damage caused by electrostatic discharge. Less than 100 V of static electricity can cause damage to some electronic components.

There are several ways for a person to become statically charged. The most common methods of charging are by friction and by induction. An example of charging by friction is a person sliding across a car seat.

Charging by induction occurs when a person with well insulated shoes stands near a highly charged object and momentarily touches ground. Charges of the same polarity are drained off leaving the person highly charged with the opposite polarity. Static charges can cause damage, therefore, it is important to use care when handling and testing electronic components.

Emissions Control Information Label

The underhood Vehicle Emissions Control Information Label contains important emission specifications and setting procedures. In the upper right corner is the exhaust emission information. This identifies the year, the manufacturing division of the engine, the displacement of the engine in liters, the class of the vehicle, and type of fuel metering system. There is also an illustrated emission components and vacuum hose schematic.

This label is located in the engine compartment of every General Motors vehicle. If the label has been removed, it can be ordered from GM service parts operations (GMSPO).

Underhood Inspection

Note. This inspection is very important and must be done carefully and thoroughly.

Perform a careful underhood inspection when performing any diagnostic procedure or diagnosing the cause of an emission test failure. This can often lead to repairing a condition without further steps. Use the following guidelines when performing an inspection

1. Inspect all of the vacuum hoses for correct routing, pinches, cuts, or disconnects.
2. Inspect any hoses that are difficult to see.
3. Inspect all of the wires in the engine compartment for the following conditions: Burned or chafed spots Pinched wires Contact with sharp edges Contact with hot exhaust manifolds

Scheme 69

The engine control module (ECM) is the control center for the throttle actuator control (TAC) system. The ECM determines the driver's intent based on input from the accelerator pedal position sensors, then calculates the appropriate throttle response based on the throttle position sensors. The ECM achieves throttle positioning by providing a pulse width modulated voltage to the throttle actuator motor. The throttle blade is spring loaded in both directions, and the default position is slightly open.

Normal Mode

During the operation of the TAC system, several modes, or functions, are considered normal. The following modes may be entered during normal operations

1. Minimum pedal value-At key-up, the ECM updates the learned minimum pedal value.
2. Minimum throttle position values-At key-up, the ECM updates the learned minimum throttle position value. In order to learn the minimum throttle position value, the throttle blade is moved to the Closed position.
3. Ice break mode-If the throttle blade is not able to reach a predetermined minimum throttle position, the ice break mode is entered. During the ice break mode, the ECM commands the maximum pulse width several times to the throttle actuator motor in the closing direction.
4. Minimum pedal value-At key-up, the ECM updates the learned minimum pedal value.
5. Battery saver mode-After a predetermined time without engine RPM, the ECM commands the Battery Saver mode. During the Battery Saver mode, the TAC module removes the voltage from the motor control circuits, which removes the current draw used to maintain the idle position and allows the throttle to return to the spring loaded default position.

Reduced Engine Power Mode

When the ECM detects a condition with the TAC system, the ECM may enter a reduced engine power mode. Reduced engine power may cause one or more of the following conditions

1. Acceleration limiting-The ECM will continue to use the accelerator pedal for throttle control, however, the vehicle acceleration is limited.
2. Limited throttle mode-The ECM will continue to use the accelerator pedal for throttle control, however, the maximum throttle opening is limited.
3. Throttle default mode-The ECM will turn OFF the throttle actuator motor, and the throttle will return to the spring loaded default position.
4. Forced idle mode-The ECM will perform the following actions: Limit engine speed to idle positioning the throttle position, or by controlling the fuel and spark if the throttle is turned OFF. Ignore the accelerator pedal input.
5. Engine shutdown mode-The ECM will disable fuel and de-energize the throttle actuator.

Scheme 70

Camshaft Position (CMP) Actuator System

The camshaft position (CMP) actuator system is an electro-hydraulic operated device used for a variety of engine performance and operational enhancements. These enhancements include lower emission output through exhaust gas dilution of the intake charge in the combustion chamber, a broader engine torque range, and improved fuel economy. The CMP actuator system accomplishes this by changing the angle or timing of the camshaft relative to the crankshaft position. The CMP actuator simply allows earlier or later intake and exhaust valve opening during the four stroke engine cycle. The CMP actuator cannot vary the duration of valve opening, or the valve lift.

During engine OFF, engine idling conditions, and engine shutdown, the camshaft actuator is held in the Park position. Internal to the CMP actuator assembly is a return spring and a locking pin. During non-phasing modes of the camshaft, the return spring rotates the camshaft back to the Park position, and the locking pin retains the CMP actuator sprocket to the camshaft.

CMP Actuator System Operation

The camshaft position (CMP) actuator system is controlled by the engine control module (ECM). The ECM sends a signal to a CMP actuator solenoid in order to control the amount of engine oil flow to a Cam Actuator passage. The pressurized engine oil is sent to unseat the locking pin, and to the vane and rotor assembly of the CMP actuator. There are 2 different passages for oil to flow through, a passage for cam advance and a passage for cam retard. The Cam Actuator is attached to a camshaft and is hydraulically operated in order to change the angle of the camshaft relative to crankshaft position (CKP). Engine oil pressure (EOP), viscosity, temperature and engine oil level can have an adverse affect on Cam Actuator performance.

Fuel System Overview

The fuel system is a returnless on-demand design. The fuel pressure regulator is a part of the fuel pump module, eliminating the need for a return pipe from the engine. A returnless fuel system reduces the internal temperature of the fuel tank by not returning hot fuel from the engine to the fuel tank. Reducing the internal temperature of the fuel tank results in lower evaporative emissions.

An electric turbine style fuel pump attaches to the fuel pump module inside the fuel tank. The fuel pump supplies high pressure fuel through the fuel feed pipe to the fuel injection system. The fuel pump provides fuel at a higher rate of flow than is needed by the fuel injection system. The fuel pressure regulator, a part of the fuel pump module, maintains the correct fuel pressure to the fuel injection system. The fuel pump module contains a reverse flow check valve. The check valve and the fuel pressure regulator maintain fuel pressure in the fuel feed pipe and the fuel rail in order to prevent long cranking times.

E85 Flex Fuel Description

E85 compatible vehicles no longer use an alcohol sensor to determine and adjust for alcohol content of the fuel in the tank. Instead, the vehicle calculates the alcohol content of the fuel through measured adjustments. The ethanol calculation occurs with the engine running after a refueling event has been detected via a measured change in the fuel level sensor output. The virtual flex fuel sensor, V-FFS, algorithm temporarily closes the canister purge valve for a few seconds and monitors information from the Closed Loop fuel trim system to calculate the ethanol content. This logic executes several times until the ethanol calculation is deemed to be stable. This may take several minutes under low fuel flow conditions such as idle, or a shorter time during higher fuel flow, off-idle conditions.

Air-fuel ratios and the corresponding ethanol percentage are updated following each purge-off sequence. The fuel alcohol content percentage value can be read on a scan tool.

When an E85 compatible vehicle is built, an ECM replaced, or if the learned alcohol content has been reset with a scan tool, the fuel system will need to contain ASTM gasoline with 10 percent or less ethanol content. A minimum of 11 liters (3 gallons) must be put in the tank in order for the vehicle to recognize a refueling event. It is not necessary to turn the ignition OFF in order to have the refueling event recognized; however, local safety regulations should be followed.

After the refueling event, the system registers the amount of fuel that was added, relative to the amount that was in the tank. Reading fuel trim and O2 sensor activity, the system determines if the fuel added was either ASTM gasoline or ASTM E85. Based on that determination, the system adjusts to the expected alcohol mix in the fuel tank, and then the fuel trim and O2 sensor activity fine-tunes the adjustments. The system must remain in Closed Loop in order for this adjustment to occur. Numerous short trips after switching from gasoline to E85, or E85 to gasoline, can result in driveability symptoms due to the inability of the system to adjust for fuel composition by not attaining Closed Loop operation.

Switching Between Gasoline and E85

No special precautions need to be taken when switching back and forth between gasoline and E85 other than refueling events must be 11 liters (3 gallons) or greater, and the vehicle must remain in Closed Loop long enough, usually by the time the engine has maintained full operating temperature, to calculate the composition of the new blend in the tank.

Scheme 71

The fuel tank (3) stores the fuel supply. The fuel tank is located in the rear of the vehicle. The fuel tank is held in place by 2 metal straps that attach to the frame. The fuel tank is molded from high-density polyethylene.

Fuel Fill Pipe

The fuel fill pipe has a built-in restrictor in order to prevent refueling with leaded fuel.

Fuel Filler Cap

The fuel fill pipe has a tethered fuel filler cap. A torque-limiting device prevents the cap from being over-tightened. To install the cap, turn the cap clockwise until you hear audible clicks. This indicates that the cap is correctly torqued and fully seated. A fuel filler cap that is not fully seated may cause a malfunction in the emission system.

Scheme 72

The fuel pump module consists of the following major components

1. The fill limit vent valve
2. The fuel level sensor (1)
3. The fuel tank pressure (FTP) sensor (2)
4. The fuel pump
5. The fuel strainer
6. The fuel pressure regulator

Fuel Level Sensor

The fuel level sensor consists of a float, a wire float arm, and a ceramic resistor card. The position of the float arm indicates the fuel level. The fuel level sensor contains a variable resistor which changes resistance in correspondence with the position of the float arm. The control module sends the fuel level information via the GMLAN serial data circuit to the instrument panel cluster (IPC). This information is used for the IPC fuel gauge and the low fuel warning indicator, if applicable. The control module also monitors the fuel level input for various diagnostics.

Fuel Pump

The fuel pump is mounted in the fuel pump module reservoir. The fuel pump is an electric high-pressure pump. Fuel is pumped to the fuel injection system at a specified flow and pressure. The fuel pump delivers a constant flow of fuel to the engine even during low fuel conditions and aggressive vehicle maneuvers. The control module controls the electric fuel pump operation through a fuel pump relay. The fuel pump flex pipe acts to dampen the fuel pulses and noise generated by the fuel pump.

Fuel Strainer

The fuel strainer attaches to the lower end of the fuel pump module. The fuel strainer is made of woven plastic. The functions of the fuel strainer are to filter contaminants and to wick fuel. The fuel strainer normally requires no maintenance. Fuel stoppage at this point indicates that the fuel tank contains an abnormal amount of sediment or contamination.

Scheme 73

The fuel pressure regulator (2) is contained in the fuel pump module near the fuel pump outlet. The fuel pressure regulator is a diaphragm relief valve. The diaphragm has fuel pressure on one side and regulator spring pressure on the other side. The fuel pressure regulator is not vacuum biased. Fuel pressure is controlled by a pressure balance across the regulator. The fuel system pressure is constant.

Fuel Feed Pipes

The fuel feed pipe carries fuel from the fuel tank to the fuel injection system. The fuel pipe consists of 2 sections

1. The rear fuel pipe is located from the top of the fuel tank to the chassis fuel pipe. The rear fuel pipe is constructed of nylon.
2. The chassis fuel pipe is located under the vehicle and connects the rear fuel pipe to the fuel rail. The chassis fuel pipe is constructed of galvanized aluminum with a section of flexible hose protected by a braided covering.

Nylon Fuel Pipes

Nylon pipes are constructed to withstand maximum fuel system pressure, exposure to fuel additives, and changes in temperature.

Heat resistant rubber hose or corrugated plastic conduit protect the sections of the pipes that are exposed to chafing, high temperature, or vibration.

Nylon fuel pipes are somewhat flexible and can be formed around gradual turns under the vehicle. However, if nylon fuel pipes are forced into sharp bends, the pipes kink and restrict the fuel flow. Also, once exposed to fuel, nylon pipes may become stiffer and are more likely to kink if bent too far. Take special care when working on a vehicle with nylon fuel pipes.

Quick-Connect Fittings

Quick-connect fittings provide a simplified means of installing and connecting fuel system components. The fittings consist of a unique female connector and a compatible male pipe end. O-rings, located inside the female connector, provide the fuel seal. Integral locking tabs inside the female connector hold the fittings together.

Scheme 74

The fuel rail assembly attaches to the cylinder head. The fuel rail assembly performs the following functions

1. Positions the injectors in the intake ports of the cylinder head
2. Distributes fuel evenly to the injectors
3. Integrates the fuel pulse dampener into the fuel metering system

Scheme 75

The fuel injector assembly is a solenoid device controlled by the control module that meters pressurized fuel to a single engine cylinder. The control module energizes the high-impedance, 12 ohms, injector solenoid (4) to open a normally closed ball valve (1). This allows fuel to flow into the top of the injector, past the ball valve, and through a director plate (3) at the injector outlet. The director plate has machined holes that control the fuel flow, generating a spray of finely atomized fuel at the injector tip (2). Fuel from the injector tip is directed at the intake valve, causing the fuel to become further atomized and vaporized before entering the combustion chamber. This fine atomization improves fuel economy and emissions. The fuel pressure regulator compensates for engine load by increasing fuel pressure as the engine vacuum drops.

Fuel Pulse Dampener

The fuel pulse dampener attaches inside a housing on the fuel rail assembly. The fuel pulse dampener is diaphragm-operated, with fuel pump pressure on one side and with spring pressure on the other side. The function of the dampener is to dampen the fuel pump pressure pulsations.

Fuel Metering Modes of Operation

The control module monitors voltages from several sensors in order to determine how much fuel to give the engine. The control module controls the amount of fuel delivered to the engine by changing the fuel injector pulse width. The fuel is delivered under one of several modes.

Starting Mode

When the ignition is first turned ON, the control module energizes the fuel pump relay for 2 seconds. This allows the fuel pump to build pressure in the fuel system. The control module calculates the air/fuel ratio based on inputs from the engine coolant temperature (ECT), manifold absolute pressure (MAP), mass air flow (MAF), and throttle position (TP) sensors. The system stays in starting mode until the engine speed reaches a predetermined RPM.

Clear Flood Mode

If the engine floods, clear the engine by pressing the accelerator pedal down to the floor and then crank the engine. When the throttle position (TP) sensor is at wide open throttle (WOT), the control module reduces the fuel injector pulse width in order to increase the air to fuel ratio. The control module holds this injector rate as long as the throttle stays wide open and the engine speed is below a predetermined RPM. If the throttle is not held wide open, the control module returns to the starting mode.

Run Mode

The run mode has 2 conditions called Open Loop and Closed Loop. When the engine is first started and the engine speed is above a predetermined RPM, the system begins Open Loop operation. The control module ignores the signal from the heated oxygen sensor (HO2S). The control module calculates the air/fuel ratio based on inputs from the engine coolant temperature (ECT), manifold absolute pressure (MAP), mass air flow (MAF), and throttle position (TP) sensors. The system stays in Open Loop until meeting the following conditions

1. The HO2S has varying voltage output, showing that the HO2S is hot enough to operate properly.
2. The ECT sensor is above a specified temperature.
3. A specific amount of time has elapsed after starting the engine.

Specific values for the above conditions exist for each different engine, and are stored in the electrically erasable programmable read-only memory (EEPROM). The system begins Closed Loop operation after reaching these values. In Closed Loop, the control module calculates the air/fuel ratio, injector ON time, based upon the signal from various sensors, but mainly from the HO2S. This allows the air/fuel ratio to stay very close to 14.7:1.

Acceleration Mode

When the driver pushes on the accelerator pedal, air flow into the cylinders increases rapidly. To prevent possible hesitation, the control module increases the pulse width to the injectors to provide extra fuel during acceleration. This is also known as power enrichment. The control module determines the amount of fuel required based upon the throttle position (TP), the engine coolant temperature (ECT), the manifold absolute pressure (MAP), the mass air flow (MAF), and the engine speed.

Deceleration Mode

When the driver releases the accelerator pedal, air flow into the engine is reduced. The control module monitors the corresponding changes in the throttle position (TP), the mass air flow (MAF), and the manifold absolute pressure (MAP). The control module shuts OFF fuel completely if the deceleration is very rapid, or for long periods, such as long, closed-throttle coast-down. The fuel shuts OFF in order to prevent damage to the catalytic converters.

Battery Voltage Correction Mode

When the battery voltage is low, the control module compensates for the weak spark delivered by the ignition system in the following ways

1. Increasing the amount of fuel delivered
2. Increasing the idle RPM
3. Increasing the ignition dwell time

Fuel Cutoff Mode

The control module cuts OFF fuel from the fuel injectors when the following conditions are met in order to protect the powertrain from damage and improve driveability

1. The ignition is OFF. This prevents engine run-on.
2. The ignition is ON but there is no ignition reference signal. This prevents flooding or backfiring.
3. The engine speed is too high, above red line.
4. The vehicle speed is too high, above rated tire speed.
5. During an extended, high speed, closed throttle coast down-This reduces emissions and increases engine braking.
6. During extended deceleration, in order to prevent damage to the catalytic converters

Fuel Trim

The control module controls the air/fuel metering system in order to provide the best possible combination of driveability, fuel economy, and emission control. The control module monitors the heated oxygen sensor (HO2S) signal voltage while in Closed Loop and regulates the fuel delivery by adjusting the pulse width of the injectors based on this signal. The ideal fuel trim values are around 0 percent for both short and long term fuel trim. A positive fuel trim value indicates the control module is adding fuel in order to compensate for a lean condition by increasing the pulse width. A negative fuel trim value indicates that the control module is reducing the amount of fuel in order to compensate for a rich condition by decreasing the pulse width. A change made to the fuel delivery changes the long and short term fuel trim values. The short term fuel trim values change rapidly in response to the HO2S signal voltage. These changes fine tune the engine fueling. The long term fuel trim makes coarse adjustments to fueling in order to re-center and restore control to short term fuel trim. A scan tool can be used to monitor the short and long term fuel trim values. The long term fuel trim diagnostic is based on an average of several of the long term speed load learn cells. The control module selects the cells based on the engine speed and engine load. If the control module detects an excessively lean or rich condition, the control module will set a fuel trim DTC.

Scheme 76

EVAP System Operation

The evaporative emission (EVAP) control system limits fuel vapors from escaping into the atmosphere. Fuel tank vapors are allowed to move from the fuel tank, due to pressure in the tank, through the EVAP vapor tube, into the EVAP canister. Carbon in the canister absorbs and stores the fuel vapors. Excess pressure is vented through the vent hose and EVAP canister vent solenoid valve to the atmosphere. The EVAP canister stores the fuel vapors until the engine is able to use them. At an appropriate time, the engine control module (ECM) will command the EVAP purge solenoid valve ON, allowing engine vacuum to be applied to the EVAP canister. With the normally open EVAP canister vent solenoid valve OFF, fresh air is drawn through the vent solenoid valve and the vent hose to the EVAP canister. Fresh air is drawn through the canister, pulling fuel vapors from the carbon. The air/fuel vapor mixture continues through the EVAP purge tube and EVAP purge solenoid valve into the intake manifold to be consumed during normal combustion. The control module uses several tests to determine if the EVAP system is leaking or restricted.

Purge Solenoid Valve Leak Test

If the evaporative emission (EVAP) purge solenoid valve does not seal properly fuel vapors could enter the engine at an undesired time, causing driveability concerns. The ECM tests for this by commanding the EVAP purge solenoid valve OFF and the canister vent solenoid valve ON which seals the system. With the engine running, the ECM then monitors the fuel tank pressure sensor for an increase in vacuum. The ECM will log a fault if a vacuum develops in the tank under these test conditions.

Large Leak Test

This diagnostic creates a vacuum condition in the EVAP system. When the enabling criteria has been met, the control module commands the normally open EVAP canister vent solenoid valve closed and the EVAP purge solenoid valve open, creating a vacuum in the EVAP system. The ECM then monitors the fuel tank pressure sensor voltage to verify that the system is able to reach a predetermined level of vacuum within a set amount of time. Failure to achieve the expected level of vacuum indicates the presence of a large leak in the EVAP system or a restriction in the purge path. The ECM will log a fault if it detects a weaker than expected vacuum level under these test conditions.

Canister Vent Restriction Test

If the evaporative emission (EVAP) vent system is restricted, fuel vapors will not be properly purged from the EVAP canister. The control module tests this by commanding the EVAP purge solenoid valve ON while commanding the EVAP canister vent solenoid valve OFF, and then monitoring the fuel tank pressure sensor for an increase in vacuum. If the vacuum increases more than the expected amount, in a set amount of time, a fault will be logged by the ECM.

Small Leak Test

The engine off natural vacuum diagnostic is the small-leak detection diagnostic for the evaporative emission (EVAP) system. The engine off natural vacuum diagnostic monitors the EVAP system pressure with the ignition OFF. Because of this, it may be normal for the control module to remain active for up to 40 minutes after the ignition is turned OFF. This is important to remember when performing a parasitic draw test on vehicles equipped with engine off natural vacuum.

When the vehicle is driven, the temperature rises in the tank due to heat transfer from the exhaust system. After the vehicle is parked, the temperature in the tank continues to rise for a period of time, then starts to drop. The engine off natural vacuum diagnostic relies on this temperature change, and the corresponding pressure change in a sealed system, to determine if an EVAP system leak is present.

The engine off natural vacuum diagnostic is designed to detect leaks as small as 0.51 mm (0.020 in).

EVAP System Components

The evaporative emission (EVAP) system consists of the following components

EVAP Canister Purge Solenoid Valve

The EVAP canister purge solenoid valve controls the flow of vapors from the EVAP system to the intake manifold. The purge solenoid valve opens when commanded ON by the control module. This normally closed valve is pulse width modulated (PWM) by the control module to precisely control the flow of fuel vapor to the engine. The valve will also be opened during some portions of the EVAP testing when the engine is running, allowing engine vacuum to enter the EVAP system.

Purge Tube Check Valve

Turbocharged vehicles have a check valve in the purge tube between the EVAP purge solenoid valve and the EVAP canister to prevent pressurization of the EVAP system under boost conditions. Note that the presence of this one-way check valve prevents pressure testing the EVAP system for leaks at the EVAP canister purge tube connector.

EVAP Canister

The canister is filled with carbon pellets used to absorb and store fuel vapors. Fuel vapor is stored in the canister until the control module determines that the vapor can be consumed in the normal combustion process.

Vapor Recirculation Tube

A vapor path between the fuel fill pipe and the vapor tube to the carbon canister is necessary for Vehicle Onboard Diagnostics to fully diagnose the EVAP system. It also accommodates service diagnostic procedures by allowing the entire EVAP system to be diagnosed from the either end of the system.

Fuel Tank Pressure Sensor

The fuel tank pressure sensor measures the difference between the pressure or vacuum in the fuel tank and outside air pressure. The control module provides a 5 V reference and a ground to the fuel tank pressure sensor. Depending on the vehicle, the sensor can be located in the vapor space on top of the fuel tank, in the vapor tube between the canister and the tank, or on the EVAP canister. The fuel tank pressure sensor provides a signal voltage back to the control module that can vary between 0.1-4.9 V. A high fuel tank pressure sensor voltage indicates a low fuel tank pressure or vacuum. A low fuel tank pressure sensor voltage indicates a high fuel tank pressure.

Fuel Fill Pipe Check Valve

The check valve on the fuel fill pipe is there to prevent spit-back during refueling.

EVAP Canister Vent Solenoid Valve

The EVAP vent solenoid valve controls fresh airflow into the EVAP canister. The valve is normally open. The canister vent solenoid valve is closed only during EVAP system tests performed by the ECM.

Fuel Fill Cap

The fuel fill cap is equipped with a seal and a vacuum relief valve.

Electronic Ignition System Description

The electronic ignition (EI) system produces and controls a high-energy secondary spark. This spark is used to ignite the compressed air/fuel mixture at precisely the correct time. This provides optimal performance, fuel economy, and control of exhaust emissions. This ignition system uses an individual coil for each cylinder. The ignition coils are mounted in the center of each camshaft cover with short integrated boots connecting the coils to the spark plugs. The driver modules within each ignition coil are commanded ON/OFF by the engine control module (ECM). The ECM primarily uses engine speed, the MAF sensor signal, and position information from the crankshaft position and the camshaft position sensors. This controls the sequence, dwell, and timing of the spark. The EI system consists of the following components

Crankshaft Position Sensor

The crankshaft position sensor works in conjunction with a 58 tooth reluctor wheel on the crankshaft. The engine control module (ECM) monitors the voltage frequency on the crankshaft position sensor signal circuit. As each reluctor wheel tooth rotates past the sensor, the sensor creates a digital ON/OFF pulse. This digital signal is processed by the ECM. The reluctor wheel teeth are 6 degrees apart. Having only 58 teeth leaves a 12 degree span that is uncut. This creates a signature pattern that enables the ECM to determine the crankshaft position. The ECM uses the signal to determine which pair of cylinders is approaching top dead center based on the crankshaft position signal alone. The camshaft position sensor signals are used in order to determine which of these 2 cylinders is on a firing stroke, and which is on the exhaust stroke. The ECM uses this to properly synchronize the ignition system, the fuel injectors, and the knock control. This sensor is also used in order to detect misfire.

Camshaft Position Sensor

This engine uses camshaft position sensor for each camshaft. The camshaft position sensor signals are a digital ON/OFF pulse, output 4 times per revolution of the camshaft. The camshaft position sensor does not directly affect the operation of the ignition system. The camshaft position sensor information is used by the engine control module (ECM) to determine the position of the camshaft relative to the crankshaft position. By monitoring the camshaft position and crankshaft position signals the ECM can accurately time the operation of the fuel injectors. The ECM supplies the camshaft position sensor with a 5 V reference circuit and a low reference circuit. The camshaft position sensor signals are an input to the ECM. These signals are also used to detect camshaft alignment with the crankshaft.

Knock Sensor

The knock sensor system enables the control module to control the ignition timing for the best possible performance while protecting the engine from potentially damaging levels of detonation, also known as spark knock. The knock sensor system uses one or 2 flat response 2-wire sensors. The sensor uses piezo-electric crystal technology that produces an AC voltage signal of varying amplitude and frequency based on the engine vibration or noise level. The amplitude and frequency are dependant upon the level of knock that the knock sensor detects. The control module receives the knock sensor signal through the signal circuit. The knock sensor ground is supplied by the control module through the low reference circuit.

The control module learns a minimum noise level, or background noise, at idle from the knock sensor and uses calibrated values for the rest of the RPM range. The control module uses the minimum noise level to calculate a noise channel. A normal knock sensor signal will ride within the noise channel. As engine speed and load change, the noise channel upper and lower parameters will change to accommodate the normal knock sensor signal, keeping the signal within the channel. In order to determine which cylinders are knocking, the control module only uses knock sensor signal information when each cylinder is near top dead center (TDC) of the firing stroke. If knock is present, the signal will range outside of the noise channel.

If the control module has determined that knock is present, it will retard the ignition timing to attempt to eliminate the knock. The control module will always try to work back to a zero compensation level, or no spark retard. An abnormal knock sensor signal will stay outside of the noise channel or will not be present. knock sensor diagnostics are calibrated to detect faults with the knock sensor circuitry inside the control module, the knock sensor wiring, or the knock sensor voltage output. Some diagnostics are also calibrated to detect constant noise from an outside influence such as a loose/damaged component or excessive engine mechanical noise.

Ignition Coils

Each ignition coil contains a solid state driver module as its primary element. The engine control module (ECM) signals the coil driver to initiate a firing event by applying ignition control (IC) circuit voltage for the appropriate time, or dwell. When the voltage is removed the coil fires the spark plug.

Engine Control Module (ECM)

The engine control module (ECM) controls all ignition system functions, and constantly corrects the spark timing. The ECM monitors information from various sensor inputs that may include the following components, if applicable

1. The throttle position sensor
2. The engine coolant temperature (ECT) sensor
3. The mass air flow (MAF) sensor
4. The intake air temperature (IAT) sensor
5. The vehicle speed sensor (VSS)
6. The transmission gear position or range information sensors
7. The engine knock sensors
8. Ambient pressure sensor (BARO)

Air Intake System Description

The primary function of the Air Intake System is to provide filtered air to the engine. The system uses a cleaner element mounted in a housing. The cleaner housing is remotely mounted and uses intake ducts to route the incoming air into the throttle body. The secondary function of the Air Intake System is to muffle air induction noise. This is achieved through the use of resonators attached to the air intake ducts. The resonators are tuned to the specific powertrain. The mass air flow (MAF)/intake air temperature (IAT) sensor is used to measure the temperature and the volume of the air entering the engine.

Secondary Air Injection System Description

The secondary air injection (AIR) system aids in the reduction of hydrocarbon exhaust emissions during a cold start-up. This occurs when the start-up engine coolant temperature (ECT) is between 5-50°C (41-122°F), and the intake air temperature (IAT) is between 5-60°C (41-140°F). The AIR pump operates 5-60 s after start-up.

The engine control module (ECM) activates the AIR system by simultaneously supplying grounds to the AIR pump and the AIR valve relays. This action closes the relays' internal contacts. The AIR pump and the AIR control solenoid valve/pressure sensor assembly are in turn energized, the pump runs and the control/shut-off valve opens.

The AIR pump sends pressurized fresh air into the pipes/hoses through the open control/shut-off valve, and into the exhaust manifold. The extra air accelerates the catalyst operation, helping it to reach operating temperature faster. The AIR pump remains ON for a short period of time after the control/shut-off valve is commanded OFF. When the AIR pump is commanded OFF it will not run or be activated until the next vehicle start. When the AIR system is inactive, the closed AIR control/shut-off valve prevents air/exhaust flow in either direction.

The AIR system pressure sensor is used to monitor pressure at the AIR control solenoid valve/pressure sensor assembly inlet during the commanded ON/OFF states.

The AIR system includes the following components

1. The AIR pump-The electric AIR pump supplies pressurized, filtered air to the AIR control/shut-off valve. The AIR pump is a turbine type pump that is permanently lubricated and requires no periodic maintenance.
2. The AIR solenoid-The AIR solenoids opens the AIR control/shut-off valve when the solenoid is energized by the AIR solenoid relay.
3. The AIR control solenoid valve/pressure sensor assembly-The AIR control solenoid valve/pressure sensor assembly has a solenoid mounted valve. When the valve is open by the solenoid, pressurized air from the AIR pump flows through the control solenoid valve/pressure sensor assembly and is directed into the exhaust manifold through an outlet pipe.
4. The AIR pressure sensor-The AIR pressure sensor is a part of the AIR control solenoid valve/pressure sensor assembly. The sensor is a 3-wire sensor that measures the AIR system pressure at the AIR control solenoid valve/pressure sensor assembly inlet.
5. The AIR pump relay-The AIR pump relay supplies high current and battery voltage to the AIR pump. The ECM commands the relay ON by supplying a ground to the relay control circuit.
6. The AIR valve relay-The AIR valve relay supplies high current and battery voltage to the AIR solenoid. the ECM commands the relay ON by supplying a ground to the relay control circuit.
7. The pipes and hoses-The AIR system hose carries filtered air from the engine air cleaner to the AIR pump inlet. The pipe/hoses carry the air from the AIR pump to the AIR control solenoid valve/pressure sensor assembly and on to the exhaust manifold.
8. The inlet filter-The AIR system does not have a separate inlet air filter. Filtered air is drawn from the engine air cleaner assembly.

Results of Incorrect Operation

The ECM monitors the secondary air injection (AIR) system for faults during cold start-up operation. When the system's pressure or relay circuits operations vary too far from the predicted values, a DTC will set. Diagnostics detect the following conditions

1. A partially blocked or leaking AIR system
2. A malfunctioning AIR pump
3. A malfunctioning AIR control solenoid valve/pressure sensor assembly
4. A malfunctioning AIR pressure sensor
5. A restricted exhaust system, forward of the catalytic converter
6. A malfunctioning AIR pump and AIR valve relay

The following DTCs set when an AIR system fault is detected

1. DTC P0411-An AIR system insufficient airflow fault condition has been detected.
2. DTC P0412-An AIR valve relay coil circuit fault condition has been detected.
3. DTC P0418-An AIR pump relay coil circuit fault condition has been detected.
4. DTC P2430-An AIR pressure sensor stuck in range fault condition has been detected.
5. DTC P2431-An AIR pressure sensor range/performance fault condition has been detected.
6. DTC P2432-An AIR pressure sensor signal voltage below the minimum range of the sensor fault condition has been detected.
7. DTC P2433-An AIR pressure sensor signal voltage is above the maximum range of the sensor fault condition has been detected.
8. DTC P2440-An AIR system airflow leak fault condition has been detected.
9. DTC P2444-An AIR pump stuck ON fault condition has been detected.
