Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Mirror Base to Mounting Pad Screw | 2 N.m | 18 lb in |
| Outside Rearview Mirror | 10 N.m | 89 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Inside Rearview Mirror Schematics
Scheme 2
Scheme 3
Scheme 3: Mirror Component Views
| Callout | Component Name |
|---|
| 1 | Courtesy/Reading Lamps - Front, Left Reading |
| 2 | Cellular Telephone Microphone (UE1) |
| 3 | Sunroof Switch (CF5) |
| 4 | Garage Door Opener Transmitter (UG1) |
| 5 | Courtesy/Reading Lamps - Front, Right Reading |
| 6 | Dome/Reading Lamp |
| 7 | Sunroof (CF5) |
| 8 | Vanity Mirror Lamp - Right (DH6) |
| 9 | Inside Rearview Mirror |
| 10 | OnStar Keypad (UE1) |
| 11 | Vanity Mirror Lamp - Left (DH6/D74) |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Door Lock Switch - Driver |
| 2 | Outside Rearview Mirror - Driver |
| 3 | Outside Rearview Mirror - Switch |
| 4 | Speaker - LF Door Tweeter (UZ6) |
| 5 | Window Switch - Driver |
| 6 | Speaker - LF Door |
| 7 | Rear Compartment/Liftgate Release Switch |
| 8 | Window Motor - Driver |
| 9 | Door Latch Assembly - Driver |
Scheme 5
| Callout | Component Name |
|---|
| 1 | Speaker - RF Door Tweeter (UZ6) |
| 2 | Outside Rearview Mirror - Front Passenger |
| 3 | Door Lock Switch - Passenger |
| 4 | Window Switch - Passenger |
| 5 | Door Latch Assembly - Passenger |
| 6 | Window Motor - Passenger |
| 7 | Speaker - RF Door |
Scheme 6
Scheme 6: Inside Rearview Mirror Connector
| Connector Part Information OEM: 917981-2 Service: 15306351 Description: 16-Way F AMP Housing/0.040/0.070 HYBRID I/O (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15355438/20 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-12 (BU) |
Inside Rearview Mirror Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1-7 | | | Not Used |
| 8 | BK | 1050 | Ground |
| 9 | BN | 24 | Backup Lamp Supply Voltage (1SB) |
| 10 | | | Not Used |
| 11 | D-BU | 2514 | Keypad Signal (UE1) |
| 12 | BK/WH | 2515 | Keypad Supply Voltage (UE1) |
| 13 | D-BU/WH | 243 | Accessory Voltage (DD8) |
| 14 | GY | 2516 | Keypad Green LED Signal (UE1) |
| 15 | BN/WH | 2517 | Keypad Red LED Signal (UE1) |
| 16 | | | Not Used |
Inside Rearview Mirror Connector Terminal Identification
Scheme 7
Scheme 7: Outside Rearview Mirror - Driver Connector
| Connector Part Information OEM: 15422329 (D49) OEM: 13513962 (DL8) Service: 12101827 Description: 8-Way M Metri-Pack 150 Series (BK) (D49) Description: 8-Way M Metri-Pack 150 Series (NA) (DL8) |
|---|
| Terminal Part Information Pins: A-C Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY) Pins: D-E Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
Outside Rearview Mirror - Driver Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | WH | 81 | Driver Mirror Motor Right Control |
| B | L-BU | 82 | Driver Mirror Motor Left Control |
| C | L-GN | 89 | Driver Mirror Motor Down Control |
| D | WH | 606 | Driver Mirror Heating Element Supply Voltage (DL8) |
| E | BK | 1150 | Ground (DL8) |
| F-H | | | Not Used |
Outside Rearview Mirror - Driver Connector Terminal Identification
