Accessory Power Socket: Overview Chevrolet Malibu VI facelift

Body Electrical 5 illustrations

Scheme 1

Scheme 1: Cigar Lighter/Power Outlet Schematics
Scheme 1: Cigar Lighter/Power Outlet Schematics

Scheme 2

Scheme 2: Power Outlet Component Views
Scheme 2: Power Outlet Component Views
CalloutComponent Name
1C214
2Cigar Lighter
3Traction Control Switch (NW7/NW9) or Auxiliary Power Outlet - Front (w/o NW7/NW9)

Scheme 3

Scheme 3
Scheme 3
CalloutComponent Name
1Auxiliary Power Outlet - Console (w/NW7, NW9)

Scheme 4

Scheme 4
Scheme 4
CalloutComponent Name
1Auxiliary Power Outlet - Rear
2Cargo Lamp
3Fuse Block - Rear

Scheme 5

Scheme 5: Auxiliary Power Outlet - Console (NW7/NW9) Connector
Scheme 5: Auxiliary Power Outlet - Console (NW7/NW9) Connector
Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (M-GY)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Auxiliary Power Outlet - Console (NW7/NW9) Connector Parts Information

PinWire ColorCircuit No.Function
ARD/WH40Battery Positive Voltage
BNot Used
CBK1150Ground

Auxiliary Power Outlet - Console (NW7/NW9) Connector Terminal Identification
