Shift Interlock System: Overview Chevrolet Malibu VI facelift

Automatic Trans 4 illustrations ~327 words

Scheme 122

Scheme 122: Shift Lock Control Schematics

Scheme 123

Scheme 123: Shift Lock Control Component Views
CalloutComponent Name
1A/T Shift Lock Control Solenoid
2A/T Shift Lock Control Assembly, Connector

Scheme 124

Scheme 124: A/T Shift Lock Control Assembly Connector
Connector Part Information OEM: 15332145 Service: 15306407 Description: 8-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-2A (GY)

A/T Shift Lock Control Assembly Connector Parts Information

PinWire ColorCircuit No.Function
AGY8Instrument Panel Lamp Supply Voltage 1
BNot Used
CPK339Run/Crank Ignition 1 Voltage
DD-GN5525Tap Up/Tap Down Enable Signal
ED-GN/WH1135Brake Transmission Shift Interlock Solenoid Supply Voltage
FPU5526Tap Up/Tap Down Switch Signal
GBK1150Ground
HNot Used

A/T Shift Lock Control Assembly Connector Terminal Identification

Scheme 125

Scheme 125: Automatic Transmission Shift Lock Control Solenoid Connector
Connector Part Information OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Automatic Transmission Shift Lock Control Solenoid Connector Parts Information

PinWire ColorCircuit No.Function
ABK1150Ground
BD/GN1135A/T Shift Lock Control Solenoid Supply Voltage

Automatic Transmission Shift Lock Control Solenoid Connector Terminal Identification

Automatic Transmission Shift Lock Control Description and Operation

The automatic transmission shift lock control system is a safety device that prevents an inadvertent shift out of PARK when the engine is running. The driver must press the brake pedal before moving the shift lever out of the PARK position. The system consists of the following components

  1. The automatic transmission shift lock control solenoid
  2. The body control module (BCM)
  3. The engine control module (ECM)
  4. The transmission control module (TCM)

The BCM controls the voltage to the shift lock control solenoid through the shift lock control solenoid controlled voltage circuit. The following conditions must be met before the BCM will supply voltage to the shift lock control solenoid

  1. The ignition is in the ON position.
  2. The ECM sends an input through the GMLAN serial data to the BCM indicating the transmission is in the PARK position via the TCM.
  3. The BCM determines the brake pedal is not applied according to the (BPP) brake pedal position sensor.

Since the shift lock control solenoid is permanently grounded, the BCM supplies voltage to the automatic transmission shift lock control solenoid, mechanically locking the shift lever in the PARK position as the solenoid energizes. When the brake pedal is applied, the BCM turns the control voltage output of the shift lock control solenoid OFF, de-energizing the shift lock control solenoid. The de-energized solenoid releases the mechanical lock allowing the driver to move the shift lever out of the PARK position. When the transmission is out of the PARK position, the shift lock control solenoid remains de-energized.

During remote start operation the BCM will energize the shift lock control circuit, locking the shift lever in the PARK position.
