Body computer — Body computer circuits Chevrolet Malibu V facelift

Components on these wiring diagrams 25

Click a component to highlight it on every diagram it appears on.

• A/C Bfc Fuse
• Alc Relay Control Fog Light Relay Control Park Lamp Sw Sig On Horn Rly Ctrl
• Ambient Light Sensor
• Body Control Module
• Brake Fluid Level Switch
• Cruise Fuse
• Door Lock Unlock Ambient Light Sensor Signal
• Driver Dr Unlock Ctrl Serial Data Spi Data Transmit Fog Light Switch Input
• Drl Relay Control
• Engine Coolant Level Switch
• Ground Splice Pack
• Ignition — Switch
• Ipc/Bfc
• Key Warning Switch
• Left Front Door Ajar Input Ignition 3 Positive Voltage
• Left I/P Junction Block
• Low Beam Headlight Input
• Low Engine Coolant Input A/C Switch Request Input
• Low Washer Solvent Input Serial Data Spi Clock All Dr Lock Ctrl
• Ppl Ignition 0 Positive Voltage Park Light Relay Ctrl
• Rear Compt Release Ctrl
• Right I/P Junction Block
• Trunk Release Circuit
• Underhood Junction Block
• Washer Fluid Level Sensor
