Contents Section: Electrical Component Locations All sections

Electrical Component Locator Chevrolet Malibu V рестайлинг

BUZZERS, RELAYS & TIMERS

ComponentLocation
A/C Compressor Clutch RelayOn underhood junction block.
Automatic Lamp Control RelayOn underhood junction block.
Blower Motor RelayOn underhood junction block.
Cooling Fan Mode RelayOn underhood junction block.
Daytime Running Lamps (DRL) RelayOn underhood junction block.
Door Lock RelayOn left I/P junction block.
Door Unlock RelayOn left I/P junction block.
Electronic Brake Control (ABS) RelayIntegral to electronic brake control module.
Fan Control Relay No. 1On underhood junction block.
Fan Control Relay No. 2On underhood junction block.
Fog Lamps RelayOn right I/P junction block.
Fuel Pump RelayOn underhood junction block.
Horn RelayOn underhood junction block.
Park Lamp RelayOn underhood junction block.
Rear Compartment Lid Release RelayOn left I/P junction block.
Rear Defogger RelayOn underhood junction block.

BUZZERS, RELAYS & TIMERS LOCATION

CIRCUIT PROTECTION DEVICES

ComponentLocation
Left I/P Junction BlockOn left end of dash.
Power Seats Circuit BreakerOn left I/P junction block.
Power Windows Circuit BreakerOn right I/P junction block.
Right I/P Junction BlockOn right end of dash. (Scheme 4)
Underhood Junction BlockOn left side of engine compartment.

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

ComponentLocation
Body Control Module (BCM)Below right side of dash, near blower motor. (Scheme 4)
Brake Pressure Modulator Valve (BPMV)At lower left front of engine compartment.
Cruise Control ModuleOn right side of engine compartment. (Scheme 3)
Electronic Brake Control Module (EBCM)Inside left front fender.
Fuel Tank ModuleUnder rear of vehicle, at fuel tank.
Ignition Control ModuleOn top right side of engine.
Inflatable Restraint Sensing & Diagnostic ModuleUnder right front seat.
Lamp Dimmer ModuleOn left side of dash.
Powertrain Control Module (PCM)Below left side of dash, near steering column. (Scheme 2)
Remote Control Door Lock ReceiverOn rear package shelf.

CONTROL UNITS LOCATION

MOTORS

ComponentLocation
Air Temperature ActuatorOn top right side of dash.
Blower MotorBelow right side of dash. (Scheme 4)
Cooling Fan Motor (Left/Right)On front of engine compartment.
Forward-Back MotorUnder left front seat.
Front Height MotorUnder left front seat.
Rear Compartment Lid Release MotorOn rear compartment lid.
Rear Height MotorUnder left front seat.
Starter MotorOn lower left side of engine.
Sun Roof AssemblyOn headliner.
Washer MotorBetween washer solvent reservoir & frame rail.
Wiper Motor AssemblyOn left rear of engine compartment.

MOTORS LOCATION

SENDING UNITS & SENSORS

ComponentLocation
A/C Refrigerant Pressure SensorOn front of engine compartment.
Ambient Lamp SensorOn top of dash trim pad.
Camshaft Position (CMP) SensorOn front of engine. (Scheme 1)
Crankshaft Position (CKP) Sensor (7X)On lower right side of engine. (Scheme 1)
Crankshaft Position (CKP) Sensor (24X)On lower front of engine.
Engine Coolant Temperature (ECT) SensorOn top rear of engine.
Engine Oil Pressure SensorOn left side of engine.
Fuel Tank Pressure SensorUnder rear of vehicle.
Intake Air Temperature (IAT) SensorIn air intake duct, near throttle body.
Knock SensorOn lower left side of engine.
Manifold Absolute Pressure (MAP) SensorAttached to bracket, on top of engine.
Mass Airflow (MAF) SensorOn air intake duct assembly.
Passenger Safing SensorOn right end of dash. (Scheme 4)
Passlock SensorNear ignition cylinder.
Post Converter Heated Oxygen Sensor (HO2S 2)At rear of catalytic converter.
Pre-Converter Oxygen Sensor (O2S)On exhaust manifold.
Throttle Position (TP) SensorOn top rear of engine.
Vehicle Speed Sensor (VSS)On rear of engine/transaxle.
Washer Solvent Level SensorInside of left front fender.
Wheel Speed Sensor (4)On respective wheel hub.

SENDING UNITS & SENSORS LOCATION

SOLENOIDS & SOLENOID VALVES

ComponentLocation
ABS SolenoidsIntegral to brake pressure modulator valve.
AIR Solenoid ValveOn engine.
Evaporative Emission Canister Purge ValveOn top right rear of engine.
Evaporative Emission Canister Vent SolenoidUnder rear of vehicle.
Exhaust Gas Recirculation (EGR) ValveOn top rear of engine. (Scheme 1)
Fuel InjectorsOn top of engine.
Idle Air Control (IAC) ValveOn top center rear of engine. (Scheme 1)
Starter SolenoidOn lower left side of engine, on starter motor.

SOLENOIDS & SOLENOID VALVES LOCATION

SWITCHES

ComponentLocation
Brake Fluid Level SwitchOn brake master cylinder reservoir.
Brake SwitchOn brake pedal support.
Cruise Control Brake SwitchOn brake pedal support.
Engine Coolant Level SwitchOn engine coolant surge tank.
Engine Oil Level SwitchOn engine oil pan.
Park Brake SwitchOn park brake assembly.
Park/Neutral Position SwitchOn side of transaxle.
Rear Compartment Lid Release SwitchBelow left side of dash.
Seat Belt SwitchIn driver's seat belt assembly.
Transaxle Range SwitchOn side of transaxle.

SWITCHES LOCATION

MISCELLANEOUS

ComponentLocation
A/C Compressor ClutchOn lower left front of engine.
A/C Compressor Clutch DiodeIn underhood junction block.
Auxiliary Power OutletOn right side of ashtray.
Blower Resistor AssemblyBelow right side of dash. (Scheme 4)
Data Link Connector (DLC)Below left side of dash, near steering column. (Scheme 2)
DRL ResistorOn rear of front impact bar.
GeneratorOn top front of engine.
Horn AssemblyInside right front fender.
SIR Coil AssemblyOn top of steering column.

MISCELLANEOUS LOCATION

CONNECTORS

ComponentLocation
C101 (Black, 10 Pin)On left side of engine compartment, in junction block.
C102 (20 Pin)On left side of engine.
C120 (2 Pin)On top rear of engine.
C130 (Black, 16 Pin)On top rear of engine.
C200 (Black, 18 Pin)Below left side of dash, near steering column.
C300 (White, 10 Pin)Below left side of dash, near steering column.
C301 (Black, 3 Pin)In headliner.
C306 (Black, 2 Pin)In left side of passenger compartment.
C400 (Natural, 8 Pin)In left rear of passenger compartment.
C413 (16 Pin)Under rear of vehicle.
C500 (Gray, 18 Pin)In left front corner of passenger compartment.
C501 (Black, 18 Pin)In left front corner of passenger compartment, behind trim panel.
C600 (Black, 18 Pin)In right front corner of passenger compartment, behind trim panel.
C700 (Black, 7 Pin)In left side of passenger compartment.
C800 (Black, 7 Pin)In right side of passenger compartment.

CONNECTORS LOCATION

GROUNDS

ComponentLocation
G101On left side of engine compartment.
G102On front of engine, near starter.
G103On left side of engine.
G104On left side of engine compartment.
G105On left side of engine compartment.
G201On left side of dash.
G202On left side of dash, near junction block.
G203On right side of dash. (Scheme 4)
G204On right side of dash. (Scheme 4)
G301On left side of passenger compartment, at rocker panel.
G302On right side of passenger compartment, at rocker panel.
G401On left side of passenger compartment, on rear package shelf.
G402On right side of passenger compartment, on rear package shelf.

GROUNDS LOCATION

SPLICES

ComponentLocation
S101In injector harness, 16 cm from C130.
S102In engine harness, 15 cm from P100.
S103In engine harness, 15 cm from P100.
S104In engine harness, 15 cm from P100.
S105In engine harness, 15 cm from P100.
S205Below dash, on right side of steering column.
S301Under right front seat.

SPLICES LOCATION

COMPONENT LOCATION GRAPHICS

Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.

Scheme 1

Scheme 1: COMPONENT LOCATION GRAPHICS

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4
