Trunk release circuit for Chevrolet Malibu V (1996-2000)
Trunk release circuit
BLK WIRE
BLK/WHT WIRE
GROUND SPLICE PACK
GRY WIRE
HOT AT ALL TIMES
LEFT I/P WIRING HARNESS JUNCTION BLOCK (LEFT SIDE OF DASH)
ORG/ WIRE
REAR COMPART- MENT LID RELEASE MOTOR (REAR COMPART- MENT)
REAR COMPART- MENT LID RELEASE SWITCH (BELOW LEFT SIDE OF DASH)
REAR COMPARTMENT LID RELEASE RELAY
REMOTE CON- TROL DOOR LOCK RECEIVER (REAR PACKAGE SHELF)
TRANS- AXLE RANGE SWITCH (SIDE OF TRANSAXLE)
TRUNK REL/FRA FUSE
W/ RKE
W/O RKE W/ RKE
WHT WIRE
YEL WIRE
