Shift interlock circuit for Chevrolet Malibu V (1996-2000)
Shift interlock circuit
1995 VFTC
BLK WIRE
BRAKE SWITCH (OPEN WITH BRAKE PEDAL DEPRESSED) (ON BRAKE PEDAL SUPPORT)
BRAKE TRANSAXLE SHIFT INTERLOCK (BTSI) SOLENOID (UNDER CENTER CONSOLE)
DK GRN/WHT WIRE
GROUND SPLICE PACK (RIGHT SIDE OF DASH)
HOT IN RUN OR START
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH,
LT GRN WIRE
NSBU FUSE
PARK/ NEUTRAL POSITION SWITCH (ON SIDE OF
PNK WIRE
TRANSAXLE
UNDERHOOD JUNCTION BLOCK
