Power top/sunroof circuits for Chevrolet Malibu V (1996-2000)
Power top/sunroof circuits
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE INPUT
CLOSE OPEN
DK DK
GRN WIRE
GROUND SPLICE PACK
GRY WIRE
HOT IN RUN
HOT W/HEADLAMP SWITCH IN PARK OR HEAD
INST LPS FUSE
LIMIT SWITCHES
MOTOR OPEN MOTOR CLOSE
NCA WIRE
OPEN INPUT SWITCH GND
ORG/ WIRE
PNK WIRE
POWER SUN ROOF MOTOR ASSEMBLY
POWER SUN ROOF SWITCH
RANGE INPUT
RED WIRE
RIGHT I/P WIRING HARNESS JUNCTION BLOCK (ON RIGHT SIDE OF DASH)
SOFT STOP
SOFT STOP INPUT
SUN ROOF ASSEMBLY
SUN ROOF CONTROL MODULE
SUNROOF FUSE
VENT STOP
WHT WIRE
YEL WIRE
