Instrument illumination circuit for Chevrolet Malibu V (1996-2000)
Instrument illumination circuit
ASHTRAY LAMP
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CHEVROLET
DK GRN WIRE
FOG LAMP SWITCH
FROM RIGHT I/P BUSSED ELECTRICAL CENTER (DIAGRAM 1 OF 1)
GRY WIRE
HAZARD SWITCH
HEAD OFF PARK
HEATER, A/C CONTROL ASSEMBLY
HOT AT ALL TIMES PARK LPS FUSE
INST LAMPS FUSE
INSTRUMENT CLUSTER
LAMP DIMMER MODULE (ON LEFT SIDE OF DASH)
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT POWER WINDOW SWITCH
ORG/ WIRE
PANEL DIMMER SWITCH
POWER MIRROR SWITCH
POWER SUNROOF SWITCH ASSEMBLY
REAR COMPARTMENT LID RELEASE SWITCH
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT I/P WIRING HARNESS JUNCTION BLOCK
TO RIGHT I/P BUSSED ELECTRICAL CENTER (DIAGRAM 1 OF 1)
TRANSAXLE INDICATOR LAMP
TURN/ HEADLAMP/ WIPER SWITCH
WHT WIRE
WIRING HARNESS JUNCTION BLOCK
