Cooling fan circuit for Chevrolet Malibu V (1996-2000)
Cooling fan circuit
2.4L L4
3.1L V6
BATTERY
BLK WIRE
COOL FAN 1 FUSE
COOL FAN 2 FUSE
DK BLU WIRE
DK GRN WIRE
FAN CONTROL RELAY 1
FAN CONTROL RELAY 2
GRY WIRE
HOT AT ALL TIMES
LEFT COOLING FAN MOTOR
LEFT FAN CTRL
LT BLU WIRE
MODE CONTROL RELAY
POWERTRAIN CONTROL MODULE (BELOW LEFT SIDE OF I/P, NEXT TO STEERING COLUMN)
RED WIRE
RIGHT COOLING FAN MOTOR
RIGHT FAN CTRL
UNDERHOOD JUNCTION BLOCK
WHT WIRE
