Chevrolet Malibu V (1996-2000) srl data trans Wiring diagram
This page shows the only wiring diagram for the component.srl data trans, which is found in the car Chevrolet Malibu V (1996-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram srl data trans (1 of 1)
1998-00
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
ELECTRONIC BRAKE CONTROL MODULE PPL
FUSE
GROUND PACK GROUND PACK
HOT IN ACC, RUN OR START
HOT IN RUN OR START
IGNITION KEY
INSTRUMENT CLUSTER
IPC/BFC
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH,
LT BLU/BLK WIRE
PASSLOCK CYLINDER (LEFT SIDE OF DASH)
PASSLOCK GND
PASSLOCK REF V
PASSLOCK SIG
PNK IGN 1 WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (BELOW LEFT SIDE OF DASH)
PPL IGN
PPL IGN (0)
PPL PPL
PPL SERIAL DATA CLASS 2
PPL SRL DATA CLASS 2
PPL/ PPL/ PPL/
SENSING, DIAG- NOSTIC MODULE
SERIAL DATA RECEIVE
SERIAL DATA TRANS
SRL DATA RECEIVE
SRL DATA TRANS
THEFT SYSTEM IND
UNDERHOOD JUNCTION BLOCK (ON LEFT SIDE OF ENG COMPT) A/C BFC
WHT WIRE
YEL WIRE
