Chevrolet Malibu V (1996-2000) right/ left select switch left Wiring diagram
This page shows the only wiring diagram for the component.right/ left select switch left, which is found in the car Chevrolet Malibu V (1996-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right/ left select switch left (1 of 1)
+DOWN VERT +UP
+RIGHT HORZ +LEFT
BLK WIRE
BRN/BLU WIRE
DK BLU WIRE
DRIVER OUTSIDE REARVIEW MIRROR
GROUND SPLICE PACK (BELOW LEFT SIDE OF DRIVER'S SEAT)
GRY (OR WIRE
GRY WIRE
HOT AT ALL TIMES POWER MIRROR FUSE
LEFT
LEFT I/P JUNCTION BLOCK (UNDER LEFT END OF DASH)
LT BLU (OR WIRE
LT BLU WIRE
LT GRN WIRE
OFF
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
PPL/ WHT WIRE
PPL/WHT WIRE
RED/ WHT WIRE
RED/WHT WIRE
RIGHT
RIGHT/ LEFT SELECT SWITCH LEFT
WHT WIRE
