Chevrolet Malibu V (1996-2000) rear view mirror reading lamps Wiring diagram
This page shows the only wiring diagram for the component.rear view mirror reading lamps, which is found in the car Chevrolet Malibu V (1996-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear view mirror reading lamps (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY FUNCTION CONTROLLER (BELOW RIGHT SIDE OF DASH)
DOME LAMP
DOOR
GLOVE BOX LAMP/ SWITCH
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
INADVERTANT POWER CONTROL OTHER DOOR AJAR INPUT
INT LPS FUSE
INTERIOR LAMPS CONTROL BATTERY POSITIVE VOLTAGE
LEFT COURTESY LAMP
LEFT FRONT DOOR AJAR INPUT
LEFT I/P WIRING HARNESS JUNCTION BLOCK
LT BLU WIRE
LT GRN/BLK WIRE
OFF
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID RELEASE MOTOR (IN REAR COMPARTMENT LID)
REAR VIEW MIRROR READING LAMPS
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT COURTESY LAMP
RIGHT I/P WIRING HARNESS JUNCTION BLOCK
RIGHT VANITY MIRROR LAMPS
SECONDARY LATCH
UNLATCH LEFT FRONT DOOR AJAR SWITCH
UNLATCH LEFT REAR DOOR AJAR SWITCH
UNLATCH RIGHT FRONT DOOR AJAR SWITCH
UNLATCH RIGHT REAR DOOR AJAR SWITCH
WHT WIRE
Go to component -> Courtesy lamps circuit -> REAR VIEW MIRROR READING LAMPS
