Chevrolet Malibu V (1996-2000) ppl data clss 2 wiring diagram
This page shows the only wiring diagram for the component.ppl data clss 2, which is found in the car Chevrolet Malibu V (1996-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ppl data clss 2 wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY FUNCTION CONTROLLER (BELOW RIGHT SIDE OF DASH)
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
ELECTRONIC BRAKE CONTROL MODULE (INSIDE LEFT FRONT FENDER)
HOT AT ALL TIMES
IPC/HVAC BATT FUSE
LEFT I/P WIRING HARNESS JUNCTION BLOCK (ON LEFT SIDE OF DASH)
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (BELOW LEFT SIDE OF DASH, NEAR STEERING COLUMN)
PPL
PPL DATA CLSS 2
SENSING DIAGNOSTIC MODULE (UNDER RIGHT FRONT SEAT)
TAN WIRE
UART DATA
Go to component -> Computer data lines -> PPL DATA CLSS 2
