Chevrolet Malibu V (1996-2000) lf spd sensor rf spd sensor lr spd sensor rr spd sensor serial data battery Wiring diagram
This page shows the only wiring diagram for the component.lf spd sensor rf spd sensor lr spd sensor rr spd sensor serial data battery, which is found in the car Chevrolet Malibu V (1996-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf spd sensor rf spd sensor lr spd sensor rr spd sensor serial data battery (1 of 1)
ABS ACTUATOR MOTOR ASSEMBLY (LEFT FRONT OF ENGINE COMPT)
ABS IND.
BLK WIRE
BLK/WHT WIRE
BODY FUNCTION CONTROLLER (BELOW RIGHT SIDE OF DASH)
BRAKE FLUID LEVEL SWITCH (REAR OF ENGINE COMPT)
BRAKE IND. IND. CTRL
BRAKE SWITCH (BRAKE PEDAL SUPPORT)
BRN WIRE
DATA LINE
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (INSIDE LEFT FRONT FENDER)
ELECTRONIC BRAKE CONTROL RELAY
EVO/ ABS SOL FUSE
FUSE BLOCK
HOT AT ALL TIMES
HOT IN RUN OR START
ICC BAT FUSE
ICC FUSE
ICC IGN FUSE
IGN
INSTRUMENT CLUSTER
LEFT FRONT ABS SOLENOID (LEFT FRONT CORNER OF ENGINE COMPT)
LEFT FRONT MOTOR
LEFT FRONT WHEEL SPEED SENSOR
LEFT I/P WIRING HARNESS JUNCTION BLOCK
LEFT REAR WHEEL SPEED SENSOR
LF SPD SENSOR RF SPD SENSOR LR SPD SENSOR RR SPD SENSOR SERIAL DATA BATTERY
LT BLU WIRE
LT BLU/BLK WIRE
MICROPROCESSOR
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (LEFT SIDE OF DASH)
PPL
PPL 1282 1283 1633 251 1285
REAR MOTOR
RED WIRE
RIGHT FRONT ABS SOLENOID (RIGHT FRONT CORNER OF ENGINE COMPT)
RIGHT FRONT MOTOR
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
STOP LAMP FEED
STOP LPS FUSE
TAN WIRE
UNDERHOOD BUSSED ELECTRICAL CENTER
UNDERHOOD WIRING HARNESS JUNCTION BLOCK
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brake circuits -> LF SPD SENSOR RF SPD SENSOR LR SPD SENSOR RR SPD SENSOR SERIAL DATA BATTERY
