Chevrolet Malibu V (1996-2000) ground defogger indicator Wiring diagram
This page shows the only wiring diagram for the component.ground defogger indicator, which is found in the car Chevrolet Malibu V (1996-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground defogger indicator (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DEFOG REQUEST DIM INPUT SOLID STATE TIMER
DEFOGGER ILLUM
DEFOGGER SWITCH
EXTERIOR LIGHTS
GROUND DEFOGGER INDICATOR
GROUND SPLICE PACK (RIGHT SIDE OF DASH)
GROUND SPLICE PACK (RIGHT SIDE OF REAR PACKAGE SHELF)
GRY WIRE
HEATER-A/C CONTROL
HOT AT ALL TIMES R DEFOG FUSE
HOT IN RUN HTR A/C IGN FUSE
IGN DEFOG INDICATOR
INTERIOR LIGHTS
LEFT I/P WIRING HARNESS JINCTION BLOCK
PPL
REAR DEFOGGER GRID
REAR DEFOGGER RELAY
RELAY CTRL
UNDERHOOD WIRING HARNESS JUNCTION BLOCK
WHT WIRE
Go to component -> Defogger circuit -> GROUND DEFOGGER INDICATOR
