Chevrolet Malibu V (1996-2000) fuel tank pressure tr switch c tr sw b eng oil level input cruise engaged Wiring diagram

776 1226 TR SWITCH D TR SW B TR SWITCH A OIL PRES SENSOR A/C CLUTCH RELAY CTRL A/C REFRIGERANT PRESSURE SENSOR (FRONT OF ENGINE COMPT) A/C SYSTEM AUTOMATIC TRANSAXLE AUTOMATIC TRANSAXLE FLUID PRESSURE VALVE MANUAL POS SWITCH AUTOMATIC TRANSAXLE FLUID TEMP SENSOR BLK WIRE BLK/WHT WIRE BLU DK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CAMSHAFT POSITION SENSOR (TOP FRONT OF ENGINE) CRUISE CONTROL SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE OIL PRESSURE SENSOR (LEFT SIDE OF ENGINE) ERLS FUSE EVAP CANV DRIVER FUEL PUMP RELAY CTRL EGR VALVE CTRL MIL CTRL FUEL INJ 4 FUEL TANK PRESSURE SENSOR (UNDER REAR OF VEHICLE) FUEL TANK PRESSURE TR SWITCH C TR SW B ENG OIL LEVEL INPUT CRUISE ENGAGED GENERATOR TERM L GRN WIRE GRY WIRE HEATED FRONT OXYGEN SENSOR (TOP REAR OF ENGINE) HEATED REAR OXYGEN SENSOR (BELOW CENTER OF VEHICLE) HOT IN RUN OR START IAC COIL A HI TACH OUT IAC COIL A LOW PC SOL HIGH PC SOL LOW IAC COIL B IAT SENSOR IGN PNK WIRE IGN VOLTAGE LEFT I/P WIRING HARNESS JUNCTION BLOCK LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MANIFOLD ABSOLUTE PRESSURE SENSOR (ATTACHED TO BRACKET ON TOP OF ENGINE) MAP SIGNAL ECT DENSOR A/C REFRIG PRES SENSOR EGR POS SIGNAL GENERATOR TERM F NCA WIRE ORG/ WIRE ORG/BLK WIRE PCM/IGN FUSE PNK WIRE PNK/BLK WIRE POSITION SENSOR (LOWER FRONT OF ENGINE) POWERTRAIN CONTROL MODULE (BELOW LEFT SIDE OF DASH) PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE SENSOR GND SENSOR GND 705 416 596 START- ING/ CHARGING SYSTEM STARTING/ CHARGING SYSTEM TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCC PWM SOL TCC PWM SOLE- NOID VALVE TCC REL SW TFT SENSOR TP SENSOR WHT WIRE YEL WIRE YEL/BLK WIRE
