Chevrolet Malibu V (1996-2000) 904 901 902 coil pos 2-3 coil ctrl 1-4 coil ctrl Wiring diagram

1-2 SHIFT SOLENOID VALVE 2-3 SHIFT SOLENOID VALVE 904 901 902 COIL POS 2-3 COIL CTRL 1-4 COIL CTRL AUTOMATIC TRANSAXLE AUTOMATIC TRANSAXLE FLUID PRESSURE VALVE MANUAL POSITION SWITCH AUTOMATIC TRANSAXLE FLUID TEMPERATURE SENSOR AUTOMATIC TRANSAXLE INPUT SHAFT SPEED SENSOR BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CKP GND REF SIG REF LOW CKP SIG GROUND IGN CRANKSHAFT POSITION SENSOR (LEFT SIDE OF ENGINE) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF ENGINE) FUEL INJECTORS GRY WIRE IC INPUT 1-4 IC INPUT 2-3 IGNITION COILS IGNITION CONTROL MODULE (TOP REAR OF ENGINE) LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PNK 1 2 WIRE PNK WIRE PNK/BLK WIRE PPL PPL 12 13 14 15 16 17 18 PPL/WHT WIRE PRESSURE CONTROL SOLENOID VALVE RED WIRE RED/BLK WIRE TAN WIRE TO SPARK PLUGS TORQUE CONVERTER CLUTCH PWM SOLENOID VALVE VEHICLE SPEED SENSOR (REAR OF TRANSAXLE) WHT WIRE YEL WIRE YEL/BLK WIRE
