Wiring Systems and Power Management - Inline Harness Connector End Views

Scheme 340

Scheme 340: X101 I/P Harness to Engine Harness

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15326849 Service Connector: 13504588 Description: 12-Way F GT 150 Series, Sealed (BK)	Connector Part Information Harness Type: Engine OEM Connector: 15326854 Service Connector: 88986252 Description: 12-Way M GT 150 Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13327112 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1	Terminal Part Information Terminated Lead: 13576363 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 L-BU	5986	Serial Data Communication Enable (JL9)	A	0.35 L-BU	5986	Serial Data Communication Enable (JL9)
B	0.35 GY	2709	5-Volt Reference 1	B	0.35 GY/BK	2709	5-Volt Reference 1
C	0.35 D-GN	890	Fuel Tank Pressure Sensor Signal	C	0.35 D-GN	890	Fuel Tank Pressure Sensor Signal
D	0.35 TN	2759	Low Reference	D	0.35 TN	2759	Low Reference
E	0.5 OG	885	Left Rear Wheel Speed Sensor Low Reference (JL9)	E	0.5 OG	885	Left Rear Wheel Speed Sensor Low Reference (JL9)
F	0.5 TN	884	Left Rear Wheel Speed Sensor Signal (JL9)	F	0.5 TN	884	Left Rear Wheel Speed Sensor Signal (JL9)
G	0.5 WH	883	Right Rear Wheel Speed Sensor Low Reference (JL9)	G	0.5 WH	883	Right Rear Wheel Speed Sensor Low Reference (JL9)
H	0.5 BN	882	Right Rear Wheel Speed Sensor Signal (JL9)	H	0.5 BN	882	Right Rear Wheel Speed Sensor Signal (JL9)
J	0.35 GY	1056	Steering Wheel Position Sensor 12V Reference Voltage (JL4)	J	0.35 GY	1056	Steering Wheel Position Sensor 12V Reference Voltage (JL4)
K	0.35 GY/BK	1337	12-Volt Reference (JL4)	K	0.35 GY/BK	1337	12-Volt Reference (JL4)
L	0.35 TN/WH	6433	CAN Bus High Serial Data (JL4)	L	0.35 TN/WH	6433	CAN Bus High Serial Data (JL4)
M	0.35 BN	818	Vehicle Speed Signal (9C1, 9C3)	M	0.5 BN	818	Vehicle Speed Signal (9C1, 9C3)
M	0.35 L-GN/BK	6432	CAN Bus Low Serial Data (JL4)	M	0.35 OG/BK	6432	CAN Bus Low Serial Data (JL4)

X101 I/P Harness to Engine Harness Connector Terminal Identification

Scheme 341

Scheme 341: X102 Engine Harness to Fuel Injector Harness

Connector Part Information Harness Type: Engine OEM Connector: 13681771 Service Connector: 13578973 Description: 16-Way F GT 150 Series, Sealed (BK)	Connector Part Information Harness Type: Fuel Injector Jumper OEM Connector: 15326867 Service Connector: Service by Harness - See Part Catalog Description: 16-Way M 150 Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13327113 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1	Terminal Part Information Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 PK/BK	5291	Ignition 1 Voltage	A	0.5 PK	639	Ignition 1 Voltage
B	0.35 YE	410	ECT Sensor Signal	B	0.5 YE	410	ECT Sensor Signal
C	0.5 TN	1744	Fuel Injector 1 Control	C	0.5 BK	1744	Fuel Injector 1 Control
D	0.5 L-GN/BK	1745	Fuel Injector 2 Control	D	0.5 OG	1745	Fuel Injector 2 Control
E	0.5 PK/BK	1746	Fuel Injector 3 Control	E	0.5 PK/BK	1746	Fuel Injector 3 Control
F	0.5 L-BU/BK	844	Fuel Injector 4 Control	F	0.5 D-GN	844	Fuel Injector 4 Control
G	0.5 TN/WH	845	Fuel Injector 5 Control	G	0.5 BK/WH	845	Fuel Injector 5 Control
H	0.5 YE/BK	846	Fuel Injector 6 Control	H	0.5 WH	846	Fuel Injector 6 Control
J-K			Not Used	J-K			Not Used
L	0.5 TN	2761	Low Reference	L	0.5 OG/BK	469	Low Reference
M			Not Used	M			Not Used
N	0.35 D-BU	6259	5-Volt Reference 1	N	0.5 RD	812	5-Volt Reference 1
P	0.35 PK/BK	632	Low Reference	P	0.5 BK	407	Low Reference
R	0.35 BN/WH	633	CMP Sensor Signal	R	0.5 BN/WH	633	CMP Sensor Signal
S			Not Used	S			Not Used

X102 Engine Harness to Fuel Injector Harness Connector Terminal Identification

X105 Battery Harness to I/P Harness

Connector Part Information Harness Type: Battery OEM Connector: 15326679 Service Connector: 88988942 Description: 2-Way F GT 280 Series, Sealed (BK)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 15326678 Service Connector: 88987860 Description: 2-Way M GT 280 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 15304720/19 Core/Insulation Crimp: 4/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU)	Terminal Part Information Pin: A Terminated Lead: 13327134 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304731/19 Core/Insulation Crimp: E/5 Pin: B Terminated Lead: 13575443 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304732/8 Core/Insulation Crimp: A/5

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	3 BK	50	Ground	A	0.5 BK	50	Ground
B			Not Used	B	2 GY	901	Not Used

X105 Battery Harness to I/P Harness Connector Terminal Identification

Scheme 342

Scheme 342: X111 I/P Harness to Engine Harness

Scheme 343

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15326856 Service Connector: 88986261 Description: 14-Way F GT 150 Series, Sealed (BK)	Connector Part Information Harness Type: Engine OEM Connector: 15326861 Service Connector: 88986246 Description: 14-Way M GT 150 Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13327112 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1	Terminal Part Information Terminated Lead: 13576363 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 BN/WH	419	MIL Control	A	0.35 BN/WH	419	MIL Control
B	0.5 WH	17	Stop Lamp Switch Signal	B	0.5 WH	17	Stop Lamp Switch Signal
C	0.35 PU	30	Fuel Level Sensor Signal	C	0.35 PU	30	Fuel Level Sensor Signal
D	0.35 D-BU	5985	Accessory Wake Up Serial Data	D	0.35 D-BU	5985	Accessory Wake Up Serial Data
E	0.35 L-GN	5060	Low Speed GMLAN Serial Data	E			Not Used
F	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus+	F	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus+
G	0.35 TN	2501	High Speed GMLAN Serial Data Bus	G	0.35 TN	2501	High Speed GMLAN Serial Data Bus
H	0.35 D-BU	5985	Accessory Wake Up Serial Data	H	0.35 D-BU	5985	Accessory Wake Up Serial Data
J	0.35 BN	1271	Low Reference	J	0.35 BN	1271	Low Reference
K	0.35 WH/BK	1164	5-Volt Reference 2	K	0.35 WH/BK	1164	5-Volt Reference 2
L	0.35 D-BU	1161	APP Sensor 1 Signal	L	0.35 D-BU	1161	APP Sensor 1 Signal
M	0.35 PU	1272	Low Reference	M	0.35 PU	1272	Low Reference
N	0.35 TN	1274	5-Volt Reference 1	N	0.35 TN	1274	5-Volt Reference 1
P	0.35 L-BU	1162	APP Sensor 2 Signal	P	0.35 L-BU	1162	APP Sensor 2 Signal

X111 I/P Harness to Engine Harness Connector Terminal Identification

Scheme 344

Scheme 344: X120 I/P Harness to Forward Lamp Harness

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15326843 Service Connector: 15326843 Description: 10-Way F GT 150 Series, Sealed (BK)	Connector Part Information Harness Type: Forward Lamp OEM Connector: 15326847 Service Connector: 19151490 Description: 10-Way M GT 150 Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13327112 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1	Terminal Part Information Terminated Lead: 13575398 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 YE	354	Discriminating Sensor - Left - Signal	A	0.8 YE	354	Discriminating Sensor - Left - Signal
B	0.35 TN/OG	5045	Discriminating Sensor - Left - Low Reference	B	0.8 TN/OG	5045	Discriminating Sensor - Left - Low Reference
C	0.35 D-GN	1409	Discriminating Sensor - Right - Signal	C	0.8 D-GN	1409	Discriminating Sensor - Right - Signal
D	0.35 GY	5600	Discriminating Sensor - Right - Low Reference	D	0.8 GY	5600	Discriminating Sensor - Right - Low Reference
E	0.35 L-GN/BK	735	Ambient Air Temperature Sensor Signal (without U2E)	E	0.35 L-GN/BK	735	Ambient Air Temperature Sensor Signal
F	0.35 YE	61	Low Reference (without U2E)	F	0.35 YE	61	Low Reference
G	0.35 PU	5531	Hood Closed Switch Signal	G	0.35 PU	5531	Hood Closed Switch Signal (AP3)
H	0.5 D-BU/YE	6841	Rear Lamp Flasher Signal (9C1, 9C3)	H	0.8 D-BU/YE	6841	Rear Lamp Flasher Signal (9C1, 9C3)
J	0.35 TN	185	Low Washer Fluid Indicator Signal	J	0.35 TN	185	Low Washer Fluid Indicator Signal
K	0.35 PK/BK	109	Hood Ajar Switch Signal	K	0.35 PK/BK	109	Hood Ajar Switch Signal (AP3)

X120 I/P Harness to Forward Lamp Harness Connector Terminal Identification

X122 Forward Lamp Harness to Forward Lamp Harness (9C1/9C3 without 6J7)

Connector Part Information Harness Type: Forward Lamp OEM Connector: 15326829 Service Connector: 88988944 Description: 6-Way F GT 150 Series, Sealed (BK)	Connector Part Information Harness Type: Forward Lamp OEM Connector: 15326833 Service Connector: 15326833 Description: 6-Way M GT 150 Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13327112 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1	Terminal Part Information Terminated Lead: 13575398 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 BK	1250	Ground	A			Not Used
B	0.5 D-GN/WH	711	Left Headlamp High Beam Supply Voltage	B	0.5 D-GN/WH	711	Left Headlamp High Beam Supply Voltage
C	0.8 RD/WH	2940	Battery Positive Voltage	C			Not Used
D	0.5 L-GN/BK	311	Right Headlamp High Beam Supply Voltage	D	0.5 L-GN/BK	311	Right Headlamp High Beam Supply Voltage
E	0.35 D-GN/RD	6820	Exterior Lamp Flasher Signal	E			Not Used
F	0.5 D-BU/YE	6841	Rear Lamp Flasher Signal	F			Not Used

X122 Forward Lamp Harness to Forward Lamp Harness (9C1/9C3 without 6J7) Connector Terminal Identification

X123 I/P Harness to the Grille Lamp Jumper Harness (6J3)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12162144 Service Connector: 12102741 Description: 4-Way F Metri-Pack 150 Series, Sealed (BK)	Connector Part Information Harness Type: Grill Lamp Jumper OEM Connector: 12162102 Service Connector: 15305839 Description: 4-Way M Metri-Pack 150 Series, Sealed Self Lock (BK)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 12094429/J-35616-14 (GN)	Terminal Part Information Terminal/Tray: 12045773/2 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	1 L-BU	6837	Upfitter Provision	A	1 L-BU	6837	Upfitter Provision
B	1 L-GN	6836	Upfitter Provision	B	1 L-GN	6836	Upfitter Provision
C	1 GY	6838	Front Emergency Flasher Control	C	1 GY	6838	Front Emergency Flasher Control
D	1 TN	6835	Front Emergency Lamp Supply Voltage	D	1 TN	6835	Front Emergency Lamp Supply Voltage

X123 I/P Harness to the Grille Lamp Jumper Harness (6J3) Connector Terminal Identification

Scheme 345

Scheme 345: X141 Forward Lamp Harness to Left Front Headlamp Assembly Harness

Connector Part Information Harness Type: Forward Lamp OEM Connector: 13521463 Service Connector: 19178189 Description: 5-Way F GT 280 5.8 Series, Sealed (BK)	Connector Part Information Harness Type: Headlamp OEM Connector: 15326647 Service Connector: 88953360 Description: 5-Way M 280 GT Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13578915 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304719/19 Core/Insulation Crimp: E/5	Terminal Part Information Terminal/Tray: 15304731/19 Core/Insulation Crimp: C/5 Release Tool/Test Probe: 15315247/J-35616-5 (PU)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.5 PU	709	Left Park Lamp Supply Voltage	A	0.8 RD	709	Left Park Lamp Supply Voltage
B	0.5 L-BU/WH	1314	Left Front Turn Signal Lamp Supply Voltage	B	0.8 YE	1314	Left Front Turn Signal Lamp Supply Voltage
C	0.5 D-GN/WH	711	Left Headlamp High Beam Supply Voltage	C	0.8 BU	711	Left Headlamp High Beam Supply Voltage
D	0.8 YE	712	Left Headlamp Low Beam Supply Voltage	D	0.8 GN	712	Left Headlamp Low Beam Supply Voltage
E	0.8 BK	1350	Ground	E	0.8 BK	1350	Ground

X141 Forward Lamp Harness to Left Front Headlamp Assembly Harness Connector Terminal Identification

X142 Forward Lamp Harness to Right Front Headlamp Assembly Harness

Connector Part Information Harness Type: Forward Lamp OEM Connector: 13521463 Service Connector: 19178189 Description: 5-Way F GT 280 5.8 Series, Sealed (BK)	Connector Part Information Harness Type: Headlamp OEM Connector: 15326647 Service Connector: 88953360 Description: 5-Way M 280 GT Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13578915 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304719/19 Core/Insulation Crimp: E/5	Terminal Part Information Terminal/Tray: 15304731/19 Core/Insulation Crimp: C/5 Release Tool/Test Probe: 15315247/J-35616-5 (PU)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.5 BN/WH	309	Right Park Lamp Supply Voltage	A	0.8 RD	309	Right Park Lamp Supply Voltage
B	0.5 D-BU/WH	1315	Right Front Turn Signal Lamp Supply Voltage	B	0.8 YE	1315	Right Front Turn Signal Lamp Supply Voltage
C	0.5 L-GN/BK	311	Right Headlamp High Beam Supply Voltage	C	0.8 BU	311	Right Headlamp High Beam Supply Voltage
D	0.5 TN/WH	312	Right Headlamp Low Beam Supply Voltage	D	0.8 GN	312	Right Headlamp Low Beam Supply Voltage
E	0.8 BK	1250	Ground	E	0.8 BK	1250	Ground

X142 Forward Lamp Harness to Right Front Headlamp Assembly Harness Connector Terminal Identification

Scheme 346

Scheme 346: X175 Engine Harness to Transmission Harness

Connector Part Information Harness Type: Engine OEM Connector: 13603425 Service Connector: 13503284 Description: 20-Way F Micro-Pack 100W Series, Sealed (BK)	Connector Part Information Harness Type: Transmission OEM Connector: 15409446 Service Connector: Service by Harness - See Part Catalog Description: 20-Way M Micro-Pack 100W (BK)
Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-33 Diagnostic Test Probe: J-35616-6 (BN) Terminal/Tray: 12084913/5 Core/Insulation Crimp: W/W	Terminal Part Information Terminal/Tray: Non-Serviceable Core/Insulation Crimp: Non-Serviceable Release Tool/Test Probe: Non-Serviceable

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 L-GN	1222	1-2 Shift Solenoid Valve Control	A	0.5 L-GN	1222	1-2 Shift Solenoid Valve Control
B	0.35 YE/BK	1223	2-3 Shift Solenoid Valve Control	B	0.5 YE	1223	2-3 Shift Solenoid Valve Control
C	0.35 OG/BK	1228	PC Solenoid Valve High Control	C	0.5 PU	1228	PC Solenoid Valve High Control
D	0.35 L-BU/WH	1229	PC Solenoid Valve Low Control	D	0.5 L-BU	1229	PC Solenoid Valve Low Control
E	0.35 PK	1339	Ignition 1 Voltage	E	0.5 RD	839	Ignition 1 Voltage
F	0.35 TN/WH	771	Transmission Range Switch Signal A	F	0.5 RD/BK	771	Transmission Range Switch Signal A
G	0.35 YE	772	Transmission Range Switch Signal B	G	0.5 D-GN/WH	772	Transmission Range Switch Signal B
H	0.35 GY	773	Transmission Range Switch Signal C	H	0.5 YE/BK	773	Transmission Range Switch Signal C
J	0.35 WH	776	Transmission Range Switch Signal P	J	0.5 GY/WH	776	Transmission Range Switch Signal P
K	0.5 BK/WH	451	Ground	K	0.5 BK/WH	1050	Ground
L	0.35 YE/BK	1227	TFT Sensor Signal	L	0.5 BN	1227	TFT Sensor Signal
M	0.35 TN	2762	Low Reference	M	0.5 GY	452	Low Reference
N-R			Not Used	N-R			Not Used
S	0.35 OG/BK	1230	AT ISS High Signal	S	0.5 BK	1230	AT ISS High Signal
T	0.35 BN	418	TCC PWM Solenoid Valve Control	T	0.5 TN	418	TCC PWM Solenoid Valve Control
U	0.35 WH	1804	TCC Release Switch Signal	U	0.5 WH	1804	TCC Release Switch Signal
V	0.35 D-BU/WH	1231	AT ISS Low Signal	V	0.5 D-GN	1231	AT ISS Low Signal
W	0.35 OG/BK	1786	Ignition Lock Cylinder Control Actuator Signal	W	0.5 OG	1786	Ignition Lock Cylinder Control Actuator Signal

X175 Engine Harness to Transmission Harness Connector Terminal Identification

Scheme 347

Scheme 347: X200 Body Harness to I/P Harness

Scheme 348

Connector Part Information Harness Type: Body OEM Connector: 15448130 Service Connector: 89046970 Description: 40-Way F GT 150 280 Series (L-GY)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 15475870 Service Connector: 88988616 Description: 40-Way M GT 150, 280 Series (L-GY)
Terminal Part Information Pins: A1, A2, A7, B1-B9, B11, B12, C1, C2, C10-C12 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Pins: A3, D6 Terminated Lead: 13575756 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Pins: A4-A6 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A Pins: B10, C8, C9 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Pins: D3, D4 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A	Terminal Part Information Pins: A1, A2, A7, B1-B9, B11, B12, C1, C2, C10-C12 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/C Pins: A3, D6 Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: A/D Pins: A4-A6 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A Pins: B10, C8, C9 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: 2/4 Pins: D3, D4 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C

Connector Part Information Harness Type: Body OEM Connector: 15448130 Service Connector: 89046970 Description: 40-Way F GT 150 280 Series (L-GY)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15475870 Service Connector: 88988616 Description: 40-Way M GT 150, 280 Series (L-GY)

Terminal Part Information Pins: A1, A2, A7, B1-B9, B11, B12, C1, C2, C10-C12 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Pins: A3, D6 Terminated Lead: 13575756 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Pins: A4-A6 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A Pins: B10, C8, C9 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Pins: D3, D4 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A

Terminal Part Information Pins: A1, A2, A7, B1-B9, B11, B12, C1, C2, C10-C12 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/C Pins: A3, D6 Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: A/D Pins: A4-A6 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A Pins: B10, C8, C9 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: 2/4 Pins: D3, D4 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1	0.35 BARE	814	Drain Wire (U2K)	A1	0.35 BARE	814	Drain Wire (U2K)
A2	0.35 TN	707	RAP Relay Coil Supply Voltage	A2	0.35 TN	707	RAP Relay Coil Supply Voltage
A3	2 GY	120	Fuel Pump Supply Voltage	A3	2 GY	120	Fuel Pump Supply Voltage
A4	0.8 PU	709	Left Park Lamp Supply Voltage	A4	0.8 PU	709	Left Park Lamp Supply Voltage
A5	0.8 D-GN	117	Right Front Speaker Output (-) (UW6)	A5	0.8 D-GN	117	Right Front Speaker Output (-) (UW6)
A5	0.5 L-GN/BK	1948	Right Front Low Level Audio Signal (-) (U87, UQ3)	A5	0.8 D-GN	117	Right Front Low Level Audio Signal (-) (U87, UQ3)
A6	0.8 L-GN	200	Right Front Speaker Output (+) (UW6)	A6	0.8 L-GN	200	Right Front Speaker Output (+) (UW6)
A6	0.5 L-GN	512	Right Front Low Level Audio Signal (+) (U87, UQ3)	A6	0.8 L-GN	200	Right Front Low Level Audio Signal (+) (U87, UQ3)
A7	0.5 L-BU	1320	CHMSL Supply Voltage	A7	0.5 L-BU	1320	CHMSL Supply Voltage
A8	0.5 YE	643	Accessory Voltage (9C1, 9C3)	A8	0.5 YE	643	Accessory Voltage (9C1, 9C3)
B1	0.35 BN/WH	367	Left Audio Signal (+) (U2K)	B1	0.35 BN/WH	367	Left Audio Signal (+) (U2K)
B2	0.35 D-GN	7007	Left Audio Signal (-) (U2K)	B2	0.35 D-GN	7007	Left Audio Signal (-) (U2K)
B3	0.35 GY	2709	5-Volt Reference 1	B3	0.35 GY	2709	5-Volt Reference 1
B4	0.35 D-GN	890	Fuel Tank Pressure Sensor Signal	B4	0.35 D-GN	890	Fuel Tank Pressure Sensor Signal
B5	0.35 TN	2759	Low Reference	B5	0.35 TN	2759	Low Reference
B6	0.35 PU	30	Fuel Level Sensor Signal	B6	0.35 PU	30	Fuel Level Sensor Signal
B7	0.35 WH	1310	EVAP Canister Vent Solenoid Control	B7	0.35 WH	1310	EVAP Canister Vent Solenoid Control
B8			Not Used	B8			Not Used
B9	0.35 OG	5748	Radio Audio Mute Signal (U87, UQ3)	B9	0.35 OG	5748	Radio Audio Mute Signal (U87, UQ3)
B10	0.8 BN/WH	309	Right Park Lamp Supply Voltage	B10	0.8 BN/WH	309	Right Park Lamp Supply Voltage
B11	0.350YE	354	Discriminating Sensor - Left - Signal	B11	0.35 YE	354	Discriminating Sensor - Left - Signal
B12	0.35 TN/OG	5045	Discriminating Sensor - Left - Low Reference	B12	0.35 TN/OG	5045	Discriminating Sensor - Left - Low Reference
C1	0.35 GY/BK	7008	Right Audio Signal (-) (U2K)	C1	0.35 GY/BK	7008	Right Audio Signal (-) (U2K)
C2	0.35 D-GN/WH	368	Right Audio Signal (+) (U2K)	C2	0.35 D-GN/WH	368	Right Audio Signal (+) (U2K)
C3-C7			Not Used	C3-C7			Not Used
C8	0.8 L-BU	115	Right Rear Speaker Output (-) (UW6)	C8	0.8 L-BU	115	Right Rear Speaker Output (-) (UW6)
	0.5 TN	1946	Right Rear Low Level Audio Signal (-) (U87, UQ3)		0.8 L-BU	115	Right Rear Low Level Audio Signal (-) (U87, UQ3)
	0.8 L-BU	115	Right Rear Speaker Output (-) (9C1, 9C3 w/o WX7)		0.8 L-BU	115	Right Rear Speaker Output (-) (9C1, 9C3 w/o WX7)
	0.8 L-BU	115	Right Front Speaker Output (-) (9C1, 9C3, WX7)		0.8 L-BU	115	Right Front Speaker Output (-) (9C1, 9C3, WX7)
C9	0.8 D-BU	46	Right Rear Speaker Output (+) (UW6)	C9	0.8 D-BU	46	Right Rear Speaker Output (+) (UW6)
	0.5 D-BU	546	Right Rear Low Level Audio Signal (+) (U87, UQ3)		0.8 D-BU	46	Right Rear Low Level Audio Signal (+) (U87, UQ3)
	0.8 D-BU	46	Right Rear Speaker Output (+) (9C1, 9C3, w/o WX7)		0.8 D-BU	46	Right Rear Speaker Output (+) (9C1, 9C3, w/o WX7)
	0.8 D-BU	46	Right Front Speaker Output (+) (9C1, 9C3, WX7)		0.8 D-BU	46	Right Front Speaker Output (+) (9C1, 9C3, WX7)
C10	0.35 D-GN	5060	Low Speed GMLAN Serial Data	C10	0.35 D-GN	5060	Low Speed GMLAN Serial Data
C11	0.35 D-GN	1409	Discriminating Sensor - Right - Signal	C11	0.35 D-GN	1409	Discriminating Sensor - Right - Signal
C12	0.35 GY	5600	Discriminating Sensor - Right - Low Reference	C12	0.35 GY	5600	Discriminating Sensor - Right - Low Reference
D1	0.8 D-GN	19	Right Rear Stop/Turn Lamp Supply Voltage (9C1, 9C3)	D1	0.8 D-GN	19	Right Rear Stop/Turn Lamp Supply Voltage (9C1, 9C3)
D2			Not Used	D2			Not Used
D3	0.5 PK	5165	Antenna 14V Switched Supply Voltage	D3	0.35 PK	5165	Antenna 14V Switched Supply Voltage
D3	0.5 PK	5165	Antenna 14V Switched Supply Voltage (UQ3)	D3	0.35 PK	5165	Antenna 14V Switched Supply Voltage
D4	0.35 PK	1139	Ignition 1 Voltage	D4	0.35 PK	1139	Ignition 1 Voltage
D5	0.5 OG	267	Heated Mirror Element Supply Voltage (DK2)	D5	0.5 OG	267	Heated Mirror Element Supply Voltage (DK2)
D5	0.5 OG	267	Heated Mirror Element Supply Voltage (DK2)	D5	0.5 OG	267	Heated Mirror Element Supply Voltage (DK2)
D6	3 BK	293	Rear Defog Element Supply Voltage (Sedan)	D6	3 PU	293	Rear Defog Element Supply Voltage
D7-D8			Not Used	D7-D8			Not Used

X200 Body Harness to I/P Harness Connector Terminal Identification

X201 Steering Column Harness to I/P Harness

Connector Part Information Harness Type: Steering Column OEM Connector: 15326931 Service Connector: 15306309 Description: 10-Way F GT 280 Series (BK)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 15326935 Service Connector: 15306305 Description: 10-Way M GT 280 Series (BK)
Terminal Part Information Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A	Terminal Part Information Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 RD/WH	1040	Battery Positive Voltage	A	0.35 RD/WH	1040	Battery Positive Voltage
A	0.35 RD/WH	1040	Battery Positive Voltage	A	0.35 RD/WH	1040	Battery Positive Voltage
B	0.35 PU/WH	7005	LED Dimming Supply	B	0.35 PU/WH	7005	LED Dimming Supply
C	0.35 PU/WH	1630	Steering Column Key Cylinder Lock Solenoid Control (Floor Shifter)	C	0.35 PU/WH	1630	Steering Column Key Cylinder Lock Solenoid Control (Floor Shifter)
D	0.35 D-GN/WH	7158	Cruise Control Indicator Dimming Signal	D	0.35 D-GN/WH	7158	Cruise Control Indicator Dimming Signal
E	0.35 BK	1450	Ground	E	0.5 BK	1450	Ground
	0.5 BK	1450	Ground (without Floor Shifter)
	0.35 BK	1450	Ground (with Floor Shifter)
F	0.35 D-GN	5060	Low Speed GMLAN Serial Data	F	0.35 D-GN	5060	Low Speed GMLAN Serial Data
G	0.35 TN	28	Horn Relay Control	G	0.35 TN	28	Horn Relay Control
H-J			Not Used	H-J			Not Used
K	0.35 BK/WH	1551	Ground	K	0.5 BK/WH	1551	Ground

X201 Steering Column Harness to I/P Harness Connector Terminal Identification

Scheme 349

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15448130 Service Connector: 89046970 Description: 40-Way F GT 150 280 Series (L-GY)	Connector Part Information Harness Type: Body OEM Connector: 15475870 Service Connector: 88988616 Description: 40-Way M GT 150, 280 Series (L-GY)
Terminal Part Information Pins: A1, B1-B3, B6-B10, C7 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Pins: A4, A5 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Pins: A6, D3, D4 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A Pins: C5, C6 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Pins: D5, D6 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A	Terminal Part Information Pins: A1, B1-B3, B6-B10, C7 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/C Pins: A4, A5 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C Pins: A6, D3, D4 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A Pins: C5, C6 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: 2/4 Pins: D5, D6 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15448130 Service Connector: 89046970 Description: 40-Way F GT 150 280 Series (L-GY)

Connector Part Information Harness Type: Body OEM Connector: 15475870 Service Connector: 88988616 Description: 40-Way M GT 150, 280 Series (L-GY)

Terminal Part Information Pins: A1, B1-B3, B6-B10, C7 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Pins: A4, A5 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Pins: A6, D3, D4 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A Pins: C5, C6 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Pins: D5, D6 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A

Terminal Part Information Pins: A1, B1-B3, B6-B10, C7 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/C Pins: A4, A5 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C Pins: A6, D3, D4 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A Pins: C5, C6 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: 2/4 Pins: D5, D6 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1	0.35 D-GN/WH	1135	A/T Shift Lock Control Solenoid Supply Voltage (Floor Shifter)	A1	0.35 D-GN/WH	1135	A/T Shift Lock Control Solenoid Supply Voltage (Floor Shifter)
A2	0.8 YE	18	Left Rear Stop/Turn Lamp Supply Voltage (9C1/9C3)	A2	0.8 YE	18	Left Rear Stop/Turn Lamp Supply Voltage (9C1/9C3)
A3			Not Used	A3			Not Used
A4	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus +	A4	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus +
A4	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus +	A4	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus +
A5	0.35 TN	2501	High Speed GMLAN Serial Data Bus	A5	0.35 TN	2501	High Speed GMLAN Serial Data Bus
A5	0.35 TN	2501	High Speed GMLAN Serial Data Bus	A5	0.35 TN	2501	High Speed GMLAN Serial Data Bus
A6	0.8 OG	1732	Inadvertent Power Courtesy Lamp	A6	0.8 OG	1732	Inadvertent Power Courtesy Lamp
A7	0.35 BK/WH	1551	Ground (JL4)	A7	0.35 BK/WH	1551	Ground (JL4)
A8			Not Used	A8			Not Used
B1	0.35 L-BU	1405	Remote Playback Device Audio Common Signal (without 9C1/9C3)	B1	0.35 L-BU	1405	Remote Playback Device Audio Common Signal (without 9C1/9C3)
B1	0.35 OG	5186	Left Trailer Turn Signal Lamp (with 9C1/9C3)	B1	0.35 OG	5186	Left Trailer Turn Signal Lamp (with 9C1/9C3)
B2	0.35 OG/BK	1406	Remote Playback Device Left Audio Signal (without 9C1/9C3)	B2	0.35 OG/BK	1406	Remote Playback Device Left Audio Signal (without 9C1/9C3)
B2	0.35 YE	5187	Right Trailer Turn Signal Lamp (with 9C1/9C3)	B2	0.35 YE	5187	Right Trailer Turn Signal Lamp (with 9C1/9C3)
B3	0.35 BARE	813	Drain Wire (without 9C1/9C3)	B3	0.35 BARE	813	Drain Wire (without 9C1/9C3)
B4	0.35 L-GN	6432	CAN Bus Low Serial Data (JL4)	B4	0.35 L-GN	6432	CAN Bus Low Serial Data (JL4)
B5	0.35 GY/BK	1337	12-Volt Reference (JL4)	B5	0.35 GY/BK	1337	12-Volt Reference (JL4)
B6	0.35 PU/WH	1630	Steering Column Key Cylinder Lock Solenoid Control (Shifter)	B6	0.35 PU/WH	1630	Steering Column Key Cylinder Lock Solenoid Control (Shifter)
B7	0.5 BN	882	Right Rear Wheel Speed Sensor Signal (JL9)	B7	0.5 BN	882	Right Rear Wheel Speed Sensor Signal (JL9)
B8	0.5 WH	883	Right Rear Wheel Speed Sensor Low Reference (JL9)	B8	0.5 WH	883	Right Rear Wheel Speed Sensor Low Reference (JL9)
B9	0.5 TN	884	Left Rear Wheel Speed Sensor Signal (JL9)	B9	0.5 TN	884	Left Rear Wheel Speed Sensor Signal (JL9)
B10	0.5 OG	885	Left Rear Wheel Speed Sensor Low Reference (JL9)	B10	0.5 OG	885	Left Rear Wheel Speed Sensor Low Reference (JL9)
B11-B12			Not Used	B11-B12			Not Used
C1-C3			Not Used	C1-C3			Not Used
C4	0.35 TN	6433	CAN Bus High Serial Data (JL4)	C4	0.35 TN	6433	CAN Bus High Serial Data (JL4)
C5	0.8 YE	116	Left Rear Low Level Audio Signal (-) (UQ3)	C5	0.5 BN	1999	Left Rear Low Level Audio Signal (-) (UQ3)
C5	0.8 YE	116	Left Rear Speaker Output (-) (UW6)	C5	0.8 YE	116	Left Rear Speaker Output (-) (UW6)
C6	0.8 BN	199	Left Rear Speaker Output (+) (UW6)	C6	0.8 BN	199	Left Rear Speaker Output (+) (UW6)
C6	0.8 BN	199	Left Rear Low Level Audio Signal (+) (UQ3)	C6	0.5 BN/WH	599	Left Rear Low Level Audio Signal (+) (UQ3)
C7	0.5 RD/WH	2340	Battery Positive Voltage (UE1/UG1)	C7	0.5 RD/WH	2340	Battery Positive Voltage (UE1/UG1)
C8	0.35 TN/WH	6433	CAN Bus High Serial Data (JL4)	C8	0.35 TN/WH	6433	CAN Bus High Serial Data (JL4)
C9	0.35 L-GN/BK	6432	CAN Bus Low Serial Data (JL4)	C9	0.35 L-GN/BK	6432	CAN Bus Low Serial Data (JL4)
C10-C12			Not Used	C10-C12			Not Used
D1-D2			Not Used	D1-D2			Not Used
D3	0.8 GY	118	Left Front Speaker Output (-) (UW6)	D3	0.8 GY	118	Left Front Speaker Output (-) (UW6)
D3	0.8 GY	118	Left Front Low Level Audio Signal (-) (UQ3)	D3	0.5 D-GN	1947	Left Front Low Level Audio Signal (-) (UQ3)
D4	0.8 TN	201	Left Front Speaker Output (+) (UW6)	D4	0.8 TN	201	Left Front Speaker Output (+) (UW6)
D4	0.8 TN	201	Left Front Low Level Audio Signal (+) (UQ3)	D4	0.5 TN	511	Left Front Low Level Audio Signal (+) (UQ3)
D5	0.5 YE	18	Right Rear Stop/Turn Lamp Supply Voltage (without 9C1/9C3)	D5	0.8 YE	18	Right Rear Stop/Turn Lamp Supply Voltage
	0.8 YE	18	Right Rear Stop/Turn Lamp Supply Voltage (with 9C1/9C3)
	0.8 YE	18	Right Rear Stop/Turn Lamp Supply Voltage (with 9C1/9C3)
D6	0.5 D-GN	19	Stop Lamp Supply Voltage/Stop Lamp Switch Signal (without 9C1/9C3)	D6	0.8 D-GN	19	Stop Lamp Supply Voltage/Stop Lamp Switch Signal
	0.8 D-GN	19	Stop Lamp Supply Voltage/Stop Lamp Switch Signal (with 9C1/9C3)
	0.8 D-GN	19	Stop Lamp Supply Voltage/Stop Lamp Switch Signal (with 9C1/9C3)
D7-D8			Not Used	D7-D8			Not Used

X203 I/P Harness to Body Harness Connector Terminal Identification

X208 SEO Auxiliary Harness to Body Harness (9C1, 9C3)

Connector Part Information Harness Type: Upfitter Jumper OEM Connector: 12129939 Service Connector: 12129939 Description: 2-Way F Metri-Pack 630 Series (BK)	Connector Part Information Harness Type: Body OEM Connector: 12129938 Service Connector: 12129938 Description: 2-Way M Metri-Pack 630 Series (BK)
Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 12084590/3 Core/Insulation Crimp: B/G	Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-43 (RD) Terminal/Tray: 12066493/3 Core/Insulation Crimp: B/G

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A			Not Used	A	5 L-BU	6822	Upfitter Defined Exterior Lamp Supply #1 (6F5)
B			Not Used	B	5 PK	6823	Upfitter Defined Exterior Lamp Supply #2 (6F5)

X208 SEO Auxiliary Harness to Body Harness (9C1, 9C3) Connector Terminal Identification

Scheme 350

Scheme 350: X210 I/P Harness to HVAC Harness

Connector Part Information Harness Type: Instrument Panel OEM Connector: 15326870 Service Connector: 88953160 Description: 2-Way F GT 280 Series (BK)	Connector Part Information Harness Type: HVAC Jumper OEM Connector: 15326874 Service Connector: 15306379 Description: 2-Way M GT 280 Series (BK)
Terminal Part Information Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A	Terminal Part Information Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	3 RD/BK	442	Battery Positive Voltage	A	3 RD	442	Battery Positive Voltage
B	3 BK	150	Ground	B	3 BK	150	Ground

X210 I/P Harness to HVAC Harness Connector Terminal Identification

X223 I/P Harness to I/P Harness (6J6)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminated Lead: 13575464 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 15326030/5 Core/Insulation Crimp: E/C	Terminal Part Information Terminated Lead: 13505668 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 YE	18	Left Rear Stop/Turn Lamp Supply Voltage	A	0.8 YE	18	Left Rear Stop/Turn Lamp Supply Voltage
B	0.8 D-GN	19	Right Rear Stop/Turn Lamp Supply Voltage	B	0.8 D-GN	19	Right Rear Stop/Turn Lamp Supply Voltage

X223 I/P Harness to I/P Harness (6J6) Connector Terminal Identification

Scheme 351

Scheme 351: X250 SIR Coil to the Body Harness

Connector Part Information Harness Type: SIR Coil OEM Connector: 15336479 Service Connector: 15306186 Description: 4-Way F Metri-Pack 280 Series w/Shorting Clip (YE)	Connector Part Information Harness Type: Body OEM Connector: 15336476 Service Connector: 88987998 Description: 4-Way M Metri-Pack 280 Series (YE)
Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A	Terminal Part Information Terminated Lead: 13575715 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 12034047/2 Core/Insulation Crimp: E/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1	0.5 TN	3021	Steering Wheel Module - Stage 1 - High Control	A1	0.35 TN	3021	Steering Wheel Module - Stage 1 - High Control
A2	0.5 BN	3020	Steering Wheel Module - Stage 1 - Low Control	A2	0.35 BN	3020	Steering Wheel Module - Stage 1 - Low Control
B1	0.5 WH	3023	Steering Wheel Module - Stage 2 - High Control	B1	0.35 WH	3023	Steering Wheel Module - Stage 2 - High Control
B2	0.5 PK	3022	Steering Wheel Module - Stage 2 - Low Control	B2	0.35 PK	3022	Steering Wheel Module - Stage 2 - Low Control

X250 SIR Coil to the Body Harness Connector Terminal Identification

X266 I/P Harness to I/P Harness (6J4)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047682 Service Connector: 12101850 Description: 1-Way F Metri-Pack 150 Series (BK)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047683 Service Connector: 12101828 Description: 1-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)	Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 TN	28	Horn Relay Control	A	0.35 TN	28	Horn Relay Control

X266 I/P Harness to I/P Harness (6J4) Connector Terminal Identification

Scheme 352

Scheme 352: X267 I/P Harness to I/P Harness (9C1, 9C3, without WX7)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12064766 Service Connector: 12101875 Description: 8-Way F Metri-Pack 150 Series (BU)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 12064767 Service Connector: 12085209 Description: 8-Way M Metri-Pack 150 Series (BU)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN)	Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 GY	118	Left Front Speaker Output (-)	A	0.8 GY	118	Left Front Speaker Output (-)
B	0.8 TN	201	Left Front Speaker Output (+)	B	0.8 TN	201	Left Front Speaker Output (+)
C	0.8 D-GN	117	Right Front Speaker Output (-)	C	0.8 D-GN	117	Right Front Speaker Output (-)
D	0.8 L-GN	200	Right Front Speaker Output (+)	D	0.8 L-GN	200	Right Front Speaker Output (+)
E	0.8 YE	116	Left Rear Speaker Output (-)	E	0.8 YE	116	Left Rear Speaker Output (-)
F	0.8 BN	199	Left Rear Speaker Output (+)	F	0.8 BN	199	Left Rear Speaker Output (+)
G	0.8 L-BU	115	Right Rear Speaker Output (-)	G	0.8 L-BU	115	Right Rear Speaker Output (-)
H	0.8 D-BU	46	Right Rear Speaker Output (+)	H	0.8 D-BU	46	Right Rear Speaker Output (+)

X267 I/P Harness to I/P Harness (9C1, 9C3, without WX7) Connector Terminal Identification

X268 I/P Harness to I/P Harness (9C1, 9C3, with WX7)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12064766 Service Connector: 12101875 Description: 8-Way F Metri-Pack 150 Series (BU)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 12064767 Service Connector: 12085209 Description: 8-Way M Metri-Pack 150 Series (BU)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN)	Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 GY	118	Left Front Speaker Output (-)	A	0.8 YE	116	Left Rear Speaker Output (-)
B	0.8 TN	201	Left Front Speaker Output (+)	B	0.8 BN	199	Left Rear Speaker Output (+)
C	0.8 D-GN	117	Right Front Speaker Output (-)	C	0.8 L-BU	115	Right Rear Speaker Output (-)
D	0.8 L-GN	200	Right Front Speaker Output (+)	D	0.8 D-BU	46	Right Rear Speaker Output (+)
E	0.8 YE	116	Left Rear Speaker Output (-)	E-H			Not Used
F	0.8 BN	199	Left Rear Speaker Output (+)
G	0.8 L-BU	115	Right Rear Speaker Output (-)
H	0.8 D-BU	46	Right Rear Speaker Output (+)

X268 I/P Harness to I/P Harness (9C1, 9C3, with WX7) Connector Terminal Identification

X269 I/P Harness to I/P Harness (9C1, 9C3, with WX7)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12064766 Service Connector: 12101875 Description: 8-Way F Metri-Pack 150 Series (BU)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 12064767 Service Connector: 12085209 Description: 8-Way M Metri-Pack 150 Series (BU)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN)	Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 GY	118	Left Front Speaker Output (-)	A	0.8 GY	118	Left Front Speaker Output (-)
B	0.8 TN	201	Left Front Speaker Output (+)	B	0.8 TN	201	Left Front Speaker Output (+)
C	0.8 D-GN	117	Right Front Speaker Output (-)	C	0.8 D-GN	117	Right Front Speaker Output (-)
D	0.8 L-GN	200	Right Front Speaker Output (+)	D	0.8 L-GN	200	Right Front Speaker Output (+)
E	0.8 YE	116	Left Rear Speaker Output (-)	E	0.8 YE	116	Left Rear Speaker Output (-)
F	0.8 BN	199	Left Rear Speaker Output (+)	F	0.8 BN	199	Left Rear Speaker Output (+)
G	0.8 L-BU	115	Right Rear Speaker Output (-)	G	0.8 L-BU	115	Right Rear Speaker Output (-)
H	0.8 D-BU	46	Right Rear Speaker Output (+)	H	0.8 D-BU	46	Right Rear Speaker Output (+)

X269 I/P Harness to I/P Harness (9C1, 9C3, with WX7) Connector Terminal Identification

X270 Body Harness to DVD Power Jumper Harness (SPO Accessory)

Connector Part Information Harness Type: Body OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (BK)	Connector Part Information Harness Type: SPO DVD Accessory Power OEM Connector: 15326874 Service Connector: 15306379 Description: 2-Way M GT 280 Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available	Terminal Part Information Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A

Pin	Wire	Circuit	Function	Pin	Wire	Function
A	0.35 YE	243	Accessory Voltage (KA1)	A	RD	Accessory Voltage
A	0.35 YE	243	Accessory Voltage (KA1)	A	RD	Accessory Voltage
B			Not Used	B		Not Used

X270 Body Harness to DVD Power Jumper Harness (SPO Accessory) Connector Terminal Identification

X275 SIR Coil to Steering Column Harness

Connector Part Information Harness Type: SIR Coil OEM Connector: 12047886 Service Connector: 12101822 Description: 8-Way F Metri-Pack 150 Series (BK)	Connector Part Information Harness Type: Steering Column OEM Connector: 12045688 Service Connector: 12101827 Description: 8-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available	Terminal Part Information Terminated Lead: 13575462 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 BK	1450	Ground	A	0.35 BK	1450	Ground
B	0.35 TN	28	Horn Relay Control	B	0.35 TN	28	Horn Relay Control
C	0.35 GY	1884	Cruise Control Switch Signal	C	0.35 GY	1884	Cruise Control Switch Signal
D	0.35 D-BU	1796	Steering Wheel Controls Signal	D	0.35 D-BU	1796	Steering Wheel Controls Signal
E	0.35 PU	1375	Steering Wheel Control Supply Voltage	E	0.35 PU	1375	Steering Wheel Control Supply Voltage
F	0.35 PU/WH	7005	LED Dimming Supply	F	0.35 PU/WH	7005	LED Dimming Supply
G	0.35 D-GN/WH	7158	Cruise Control Indicator Dimming Signal	G	0.35 D-GN/WH	7158	Cruise Control Indicator Dimming Signal
H			Not Used	H			Not Used

X275 SIR Coil to Steering Column Harness Connector Terminal Identification

X277 SIR Coil to Steering Wheel Harness

Connector Part Information Harness Type: SIR Coil OEM Connector: 12047886 Service Connector: 12101822 Description: 8-Way F Metri-Pack 150 Series (BK)	Connector Part Information Harness Type: Steering Wheel OEM Connector: 12045688 Service Connector: 12101827 Description: 8-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available	Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 BK	1450	Ground	A	0.35 BK	1450	Ground
B	0.35 TN	28	Horn Relay Control	B	0.35 TN	28	Horn Relay Control
C	0.35 GY	1884	Cruise Control Switch Signal	C	0.35 GY	1884	Cruise Control Switch Signal
D	0.35 D-BU	1796	Steering Wheel Controls Signal	D	0.35 D-BU	1796	Steering Wheel Controls Signal
E	0.35 PU	1375	Steering Wheel Control Supply Voltage	E	0.35 PU	1375	Steering Wheel Control Supply Voltage
F	0.35 PU/WH	7005	LED Dimming Supply	F	0.35 PU/WH	7005	LED Dimming Supply
G	0.35 D-GN/WH	7158	Cruise Control Indicator Dimming Signal	G	0.35 D-GN/WH	7158	Cruise Control Indicator Dimming Signal
H			Not Used	H			Not Used

X277 SIR Coil to Steering Wheel Harness Connector Terminal Identification

Scheme 353

Scheme 353: X278 Inflatable Restraint I/P Module Jumper Harness to the Body Harness

Connector Part Information Harness Type: Inflatable Restraint Jumper OEM Connector: 15479525 Service Connector: 19149302 Description: 4-Way F Metri-Pack 280 Series (YE)	Connector Part Information Harness Type: Body OEM Connector: 15336476 Service Connector: 88987998 Description: 4-Way M Metri-Pack 280 Series (YE)
Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A	Terminal Part Information Terminated Lead: 13575715 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 12034047/2 Core/Insulation Crimp: E/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1	0.35 YE	3025	I/P Module - Stage 1 - High Control	A1	0.35 YE	3025	I/P Module - Stage 1 - High Control
A2	0.35 OG	3024	I/P Module - Stage 1 - Low Control	A2	0.35 OG	3024	I/P Module - Stage 1 - Low Control
B1	0.35 GY	3027	I/P Module - Stage 2 - High Control	B1	0.35 GY	3027	I/P Module - Stage 2 - High Control
B2	0.35 PU	3026	I/P Module - Stage 2 - Low Control	B2	0.35 PU	3026	I/P Module - Stage 2 - Low Control

X278 Inflatable Restraint I/P Module Jumper Harness to the Body Harness Connector Terminal Identification

X297 I/P Harness to Grille Lamp Jumper Harness (9C1, 9C3, 6J3)

Connector Part Information Harness Type: Instrument Panel OEM Connector: 12064762 Service Connector: 12125665 Description: 6-Way F Metri-Pack 150 Series (GY)	Connector Part Information Harness Type: Grill Lamp Jumper OEM Connector: 12064763 Service Connector: 12101876 Description: 6-Way M Metri-Pack 150 Series (GY)
Terminal Part Information Terminated Lead: 13575464 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 15326030/5 Core/Insulation Crimp: E/C	Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Not Available Core/Insulation Crimp: Not Available

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.35 D-GN/RD	6820	Exterior Lamp Flasher Signal	A			Not Used
B	1 L-BU	6837	Siren 1 Supply	B	1 L-BU	6837	Siren 1 Supply
C	1 L-GN	6836	Siren 2 Supply	C	1 L-GN	6836	Siren 2 Supply
D	1 GY	6838	Front Emergency Flasher Control	D	1 GY	6838	Front Emergency Flasher Control
E	1 TN	6835	Front Emergency Lamp Supply Voltage	E	1 TN	6835	Front Emergency Lamp Supply Voltage
F			Not Used	F			Not Used

X297 I/P Harness to Grille Lamp Jumper Harness (9C1, 9C3, 6J3) Connector Terminal Identification

Scheme 354

Scheme 354: X311 Body Harness to Left Front Seat Harness

Connector Part Information Harness Type: Body OEM Connector: 15336205 Service Connector: 88986267 Description: 12-Way F GT Mixed (BK)	Connector Part Information Harness Type: Left Front Seat OEM Connector: 13516626 Service Connector: 88986259 Description: 12-Way M GT Mixed (BK)
Terminal Part Information Pins: A, M Terminated Lead: 13575756 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Pins: B-L Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C	Terminal Part Information Pins: A, M Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: A/D Pins: B-L Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/C

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	3 RD/WH	1140	Battery Positive Voltage (AG1, AH8)	A	3 RD/WH	1140	Battery Positive Voltage (AG1, AH8)
B	0.35 D-GN	5016	Seat Belt Switch - Left - Signal	B	0.35 D-GN	5016	Seat Belt Switch - Left - Signal
C	0.35 PK	5057	Low Reference	C	0.35 PK	5057	Low Reference
D	0.8 D-BU	2479	Passenger Heated Seat Element Supply Voltage (KA1)	D	0.8 D-BU	2479	Passenger Heated Seat Element Supply Voltage (KA1)
E	0.35 GY	2434	Passenger Heated Seat Cushion Temperature Sensor Signal (KA1)	E	0.35 GY	2434	Passenger Heated Seat Cushion Temperature Sensor Signal (KA1)
F	1 BK	550	Ground (KA1)	F	1 BK	550	Ground (KA1)
G	1 RD/WH	1440	Battery Positive Voltage (KA1)	G	1 RD/WH	1440	Battery Positive Voltage (KA1)
H			Not Used	H			Not Used
J	0.35 PK	2435	Passenger Heated Seat Cushion Temperature Sensor Low Reference (KA1)	J	0.35 PK	2435	Passenger Heated Seat Cushion Temperature Sensor Low Reference (KA1)
K	0.35 D-GN	5060	Low Speed GMLAN Serial Data (KA1)	K	0.35 D-GN	5060	Low Speed GMLAN Serial Data (KA1)
L	0.8 L-BU	2433	Passenger Heated Seat Back Element Control (KA1)	L	0.8 L-BU	2433	Passenger Heated Seat Back Element Control (KA1)
M	3 BK	550	Ground	M	3 BK	550	Ground (AG1, AH5)

X311 Body Harness to Left Front Seat Harness Connector Terminal Identification

X313 Body Harness to Right Front Seat Harness

Connector Part Information Harness Type: Body OEM Connector: 15336205 Service Connector: 88986267 Description: 12-Way F GT Mixed (BK)	Connector Part Information Harness Type: Right Front Seat OEM Connector: 13516626 Service Connector: 88986259 Description: 12-Way M GT Mixed (BK)
Terminal Part Information Pins: A, M Terminated Lead: 13575756 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Pins: B-L Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C	Terminal Part Information Pins: A, M Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: A/D Pins: B-L Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/C

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	3 RD/WH	1140	Battery Positive Voltage	A	3 RD/WH	1140	Battery Positive Voltage (AG2)
B	0.35 OG	1362	Seat Belt Switch - Right - Signal	B	0.35 OG	1362	Seat Belt Switch - Right - Signal
C	0.35 PK	2435	Passenger Heated Seat Cushion Temperature Sensor Low Reference (KA1)	C	0.35 PK	2435	Passenger Heated Seat Cushion Temperature Sensor Low Reference (KA1)
D	0.8 D-BU	2479	Passenger Heated Seat Element Supply Voltage (KA1)	D	0.8 D-BU	2479	Passenger Heated Seat Element Supply Voltage (KA1)
E	0.35 GY	2434	Passenger Heated Seat Cushion Temperature Sensor Signal (KA1)	E	0.35 GY	2434	Passenger Heated Seat Cushion Temperature Sensor Signal (KA1)
F	0.35 PK	5057	Low Reference	F	0.35 PK	5057	Low Reference
F	0.35 PK	5057	Low Reference	F	0.35 PK	5057	Low Reference
G	0.8 L-BU	2433	Passenger Heated Seat Back Element Control (KA1)	G	0.8 L-BU	2433	Passenger Heated Seat Back Element Control (KA1)
H			Not Used	H			Not Used
J	0.35 BK/WH	1751	Ground	J	0.35 BK/WH	1751	Ground
K	0.35 D-GN	5060	Low Speed GMLAN Serial Data	K	0.35 D-GN	5060	Low Speed GMLAN Serial Data
L	0.35 RD/WH	1340	Battery Positive Voltage	L	0.35 RD/WH	1340	Battery Positive Voltage
M	3 BK	750	Ground (AG2)	M	3 BK	750	Ground (AG2)

X313 Body Harness to Right Front Seat Harness Connector Terminal Identification

Scheme 355

Scheme 355: X315 Left Front Seat Harness to Body Harness

Connector Part Information Harness Type: Left Front Seat OEM Connector: 13671940 Service Connector: See Catalog Description: 4-Way F Metri-Pack 280 Series (YE)	Connector Part Information Harness Type: Body OEM Connector: 15336476 Service Connector: 88987998 Description: 4-Way M Metri-Pack 280 Series (YE)
Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A	Terminal Part Information Terminated Lead: 13575715 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 12034047/2 Core/Insulation Crimp: E/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1	0.5 YE/BK	3065	Seat Belt Buckle Pretensioner - Driver - Low Control	A1	0.5 YE	3065	Seat Belt Buckle Pretensioner - Driver - Low Control
A2	0.5 WH	3064	Seat Belt Buckle Pretensioner - Driver - High Control	A2	0.5 WH	3064	Seat Belt Buckle Pretensioner - Driver - High Control
B1	0.5 BN	2137	Left Front Side Impact Module - High Control	B1	0.5 BN	2137	Left Front Side Impact Module - High Control
B2	0.5 YE/BK	2138	Left Front Side Impact Module - Low Control	B2	0.5 YE/BK	2138	Left Front Side Impact Module - Low Control

X315 Left Front Seat Harness to Body Harness Connector Terminal Identification

X316 Right Front Seat Harness to Body Harness

Connector Part Information Harness Type: Right Front Seat OEM Connector: 13672037 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F Metri-Pack 280 Series (YE)	Connector Part Information Harness Type: Body OEM Connector: 15336476 Service Connector: 88987998 Description: 4-Way M Metri-Pack 280 Series (YE)
Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A	Terminal Part Information Terminated Lead: 13575715 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 12034047/2 Core/Insulation Crimp: E/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1	0.5 L-BU/BK	3063	Seat Belt Buckle Pretensioner - Passenger - Low Control	A1	0.5 L-BU/BK	3063	Seat Belt Buckle Pretensioner - Passenger - Low Control
A2	0.5 TN	3062	Seat Belt Buckle Pretensioner - Passenger - High Control	A2	0.5 TN	3062	Seat Belt Buckle Pretensioner - Passenger - High Control
B1	0.5 TN/WH	2135	Right Front Side Impact Module - High Control	B1	0.5 TN/WH	2135	Right Front Side Impact Module - High Control
B2	0.5 L-GN	2136	Right Front Side Impact Module - Low Control	B2	0.5 L-GN	2136	Right Front Side Impact Module - Low Control

X316 Right Front Seat Harness to Body Harness Connector Terminal Identification

X322 Body Harness to Roof Wiring Provision Harness (9C1, 9C3)

Connector Part Information Harness Type: Body OEM Connector: 12129939 Service Connector: 12129939 Description: 2-Way F Metri-Pack 630 Series (BK)	Connector Part Information Harness Type: Upfitter Jumper OEM Connector: 12129938 Service Connector: 12129938 Description: 2-Way M Metri-Pack 630 Series (BK)
Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 12084590/3 Core/Insulation Crimp: B/G	Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-43 (RD) Terminal/Tray: 12066493/3 Core/Insulation Crimp: B/G

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	5 L-BU	6822	Upfitter Defined Exterior Lamp Supply 1 (6F5)	A	5 L-BU	6822	Upfitter Defined Exterior Lamp Supply 1 (6F5)
B	5 PK	6823	Upfitter Defined Exterior Lamp Supply 2 (6F5)	B	5 PK	6823	Upfitter Defined Exterior Lamp Supply 2 (6F5)

X322 Body Harness to Roof Wiring Provision Harness (9C1, 9C3) Connector Terminal Identification

X340 Body Harness to Console Harness (without D55)

Connector Part Information Harness Type: Body OEM Connector: 15326870 Service Connector: 88953160 Description: 2-Way F GT 280 Series (BK)	Connector Part Information Harness Type: Body OEM Connector: 15326874 Service Connector: 15306379 Description: 2-Way M GT 280 Series (BK)
Terminal Part Information Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A	Terminal Part Information Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	1 RD/WH	1940	Battery Positive Voltage	A	1 RD/WH	1940	Battery Positive Voltage
B	1 BK	750	Ground	B	1 BK	750	Ground

X340 Body Harness to Console Harness (without D55) Connector Terminal Identification

X340 Console Harness to Body Harness (D55)

Connector Part Information Harness Type: Console OEM Connector: 15326870 Service Connector: 88953160 Description: 2-Way F GT 280 Series (BK)	Connector Part Information Harness Type: Body OEM Connector: 15326874 Service Connector: 15306379 Description: 2-Way M GT 280 Series (BK)
Terminal Part Information Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A	Terminal Part Information Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	1 RD/WH	1940	Battery Positive Voltage	A	1 RD/WH	1940	Battery Positive Voltage
B	1 BK	750	Ground	B	1 BK	750	Ground

X340 Console Harness to Body Harness (D55) Connector Terminal Identification

Scheme 356

Scheme 356: X360 Body Harness to I/P Harness (9C1, 9C3)

Scheme 357

Connector Part Information Harness Type: Body OEM Connector: 12160893 Service Connector: 15306159 Description: 1-Way F Metri-Pack 800 Series (BK)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 12160894 Service Connector: Service by Harness - See Part Catalog Description: 1-Way M Metri-Pack 800 Series (BK)
Terminal Part Information Terminated Lead: 13575718 Release Tool: J-38125-558 Diagnostic Test Probe: J-35616-44 (YE) Terminal/Tray: 12092445/18 Core/Insulation Crimp: Not Available	Terminal Part Information Terminal/Tray: 12146940/Not Serviced in Kit Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	8 RD/BK	702	Battery Positive Voltage	A	8 RD/BK	702	Battery Positive Voltage

X360 Body Harness to I/P Harness (9C1, 9C3) Connector Terminal Identification

X362 Body Harness to I/P Harness (9C1, 9C3)

Connector Part Information Harness Type: Body OEM Connector: 12160893 Service Connector: 15306159 Description: 1-Way F Metri-Pack 800 Series (BK)	Connector Part Information Harness Type: Instrument Panel OEM Connector: 12160894 Service Connector: Service by Harness - See Part Catalog Description: 1-Way M Metri-Pack 800 Series (BK)
Terminal Part Information Terminated Lead: 13575718 Release Tool: J-38125-558 Diagnostic Test Probe: J-35616-44 (YE) Terminal/Tray: 12092445/18 Core/Insulation Crimp: Not Available	Terminal Part Information Terminal/Tray: 12146940/Not Serviced in Kit Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	8 RD/BK	302	Battery Positive Voltage	A	8 RD/BK	302	Battery Positive Voltage

X362 Body Harness to I/P Harness (9C1, 9C3) Connector Terminal Identification

Scheme 358

Scheme 358: X371 DVD Signal Cable 3A to DVD Signal Cable 1A (SPO Accessory)

Scheme 359

Connector Part Information Harness Type: SPO Accessory Signal Cable 3A OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way F (BK) with (RD) case	Connector Part Information Harness Type: SPO Accessory Signal Cable 1A OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way M (BK) with (RD) case
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available	Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available

Pin	Wire	Function	Pin	Wire	Function
1	RD	Ignition Voltage	1	RD	Ignition Voltage
2	BK	Ground	2	BK	Ground
3	WH	Left Audio Signal (+)	3	WH	Left Audio Signal (+)
4	RD	Right Audio Signal (+)	4	RD	Right Audio Signal (+)
5	YE	DVD Video Signal (+)	5	YE	DVD Video Signal (+)
6	BK	DVD Video (-)	6	BK	DVD Video (-)

X371 DVD Signal Cable 3A to DVD Signal Cable 1A (SPO Accessory) Connector Terminal Identification

X372 DVD Signal Cable 3B to DVD Signal Cable 1B (SPO Accessory)

Connector Part Information Harness Type: SPO Accessory Signal Cable 3B OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way F (BK) with (BK) case	Connector Part Information Harness Type: SPO Accessory Signal Cable 1B OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way M (BK) with (BK) case
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available	Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available

Pin	Wire	Function	Pin	Wire	Function
1	RD	I2C Data	1	RD	I2C Data
2	BK	I2C Clock Signal	2	BK	I2C Clock Signal
3	WH	Left Audio Signal (+)	3	WH	Left Audio Signal (+)
4	RD	Right Audio Signal (+)	4	RD	Right Audio Signal (+)
5	YE	DVD Video Signal (+)	5	YE	DVD Video Signal (+)
6	BK	DVD Video (-)	6	BK	DVD Video (-)

X372 DVD Signal Cable 3B to DVD Signal Cable 1B (SPO Accessory) Connector Terminal Identification

X373 DVD Signal Cable 3A to DVD Signal Cable 2A (SPO Accessory)

Connector Part Information Harness Type: SPO Accessory Signal Cable 3A OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way F (BK) with (WH) case	Connector Part Information Harness Type: SPO Accessory Signal Cable 2A OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way M (BK) with (WH) case
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available	Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available

Pin	Wire	Function	Pin	Wire	Function
1	RD	Ignition Voltage	1	RD	Ignition Voltage
2	BK	Ground	2	BK	Ground
3	WH	Left Audio Signal (+)	3	WH	Left Audio Signal (+)
4	RD	Right Audio Signal (+)	4	RD	Right Audio Signal (+)
5	YE	DVD Video Signal (+)	5	YE	DVD Video Signal (+)
6	BK	DVD Video (-)	6	BK	DVD Video (-)

X373 DVD Signal Cable 3A to DVD Signal Cable 2A (SPO Accessory) Connector Terminal Identification

X374 DVD Signal Cable 3B to DVD Signal Cable 2B (SPO Accessory)

Connector Part Information Harness Type: SPO Accessory Signal Cable 3B OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way F (BK) with (BU) case	Connector Part Information Harness Type: SPO Accessory Signal Cable 2B OEM Connector: Not Available Service Connector: Service by Harness - See Part Catalog Description: 6-Way M (BK) with (BU) case
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available	Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available

Pin	Wire	Function	Pin	Wire	Function
1	RD	I2C Data	1	RD	I2C Data
2	BK	I2C Clock Signal	2	BK	I2C Clock Signal
3	WH	Left Audio Signal (+)	3	WH	Left Audio Signal (+)
4	RD	Right Audio Signal (+)	4	RD	Right Audio Signal (+)
5	YE	DVD Video Signal (+)	5	YE	DVD Video Signal (+)
6	BK	DVD Video (-)	6	BK	DVD Video (-)

X374 DVD Signal Cable 3B to DVD Signal Cable 2B (SPO Accessory) Connector Terminal Identification

X398 Roof Harness to Sunroof Harness (CF5)

Connector Part Information Harness Type: Headliner OEM Connector: 15326900 Service Connector: 19180278 Description: 6-Way F GT 280 Series (BK)	Connector Part Information Harness Type: Sunroof Jumper OEM Connector: 15326904 Service Connector: 88988314 Description: 6-Way M GT 280 Series (BK)
Terminal Part Information Pins: A, C-E Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Pins: B, F Terminated Lead: 13575754 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: 4/4	Terminal Part Information Pins: A, C-E Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-5 (PU) Pins: B, F Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A Release Tool/Test Probe: 15315247/J-35616-5 (PU)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.5 YE	643	Accessory Voltage	A	0.5 YE	643	Accessory Voltage
B	2 BK	550	Ground	B	1 BK	550	Ground
C	0.35 BN	100	Sunroof Switch Open Signal	C	0.5 BN	100	Sunroof Switch Open Signal
D	0.35 OG	110	Sunroof Switch Close Signal	D	0.5 OG	110	Sunroof Switch Close Signal
E	0.35 D-BU	128	Sunroof Switch Low Reference	E	0.5 D-BU	128	Sunroof Switch Low Reference
F	2 RD/WH	3440	Battery Positive Voltage	F	1 RD/WH	3440	Battery Positive Voltage

X398 Roof Harness to Sunroof Harness (CF5) Connector Terminal Identification

X401 Rear Body Harness to Left Tail Lamp Harness

Connector Part Information Harness Type: Rear Body OEM Connector: 12162144 Service Connector: 12102741 Description: 4-Way F Metri-Pack 150 Series, Sealed (BK)	Connector Part Information Harness Type: Tail Lamp OEM Connector: 12162102 Service Connector: 15305839 Description: 4-Way M Metri-Pack 150 Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13575419 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1	Terminal Part Information Terminal/Tray: 12045773/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 PU	709	Left Park Lamp Supply Voltage	A	0.5 L-GN	709	Left Park Lamp Supply Voltage
B	0.8 BK	850	Ground	B	0.5 BK	750	Ground
C	0.5 YE	18	Left Rear Stop/Turn Lamp Supply Voltage	C	0.5 YE	18	Left Rear Stop/Turn Lamp Supply Voltage
D	0.5 L-GN	24	Backup Lamp Supply Voltage	D	0.5 BN	24	Backup Lamp Supply Voltage

X401 Rear Body Harness to Left Tail Lamp Harness Connector Terminal Identification

X402 Rear Body Harness to Right Tail Lamp Harness

Connector Part Information Harness Type: Rear Body OEM Connector: 12162144 Service Connector: 12102741 Description: 4-Way F Metri-Pack 150 Series, Sealed (BK)	Connector Part Information Harness Type: Tail Lamp OEM Connector: 12162102 Service Connector: 15305839 Description: 4-Way M Metri-Pack 150 Series, Sealed (BK)
Terminal Part Information Terminated Lead: 13575419 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1	Terminal Part Information Terminal/Tray: 12045773/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-3 (GY)

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.5 BN/WH	309	Right Park Lamp Supply Voltage	A	0.5 L-GN	309	Right Park Lamp Supply Voltage
B	0.8 BK	850	Ground	B	0.5 BK	750	Ground
C	0.5 D-GN	19	Right Rear Stop/Turn Lamp Supply Voltage	C	0.5 YE	19	Right Rear Stop/Turn Lamp Supply Voltage
D	0.5 L-GN	24	Backup Lamp Supply Voltage	D	0.5 BN	24	Backup Lamp Supply Voltage

X402 Rear Body Harness to Right Tail Lamp Harness Connector Terminal Identification

Scheme 360

Scheme 360: X405 Rear Chassis Harness to Body Harness

Scheme 361

Connector Part Information Harness Type: Rear Chassis OEM Connector: 12146439 Service Connector: 15305883 Description: 4-Way F 150 Series (L-GY)

Connector Part Information Harness Type: Body OEM Connector: 15326714 Service Connector: 15305991 Description: 12-Way M Metri-Pack Mixed Series (GY)

Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-14 (GN) Connector Part Information OEM Connector: 12176335 Service Connector: 15305944 Description: 8-Way F Metri-Pack 280 Flex Lock Series (WH) Terminal Part Information Pins: A, C Terminal/Tray: 12110845/4 Core/Insulation Crimp: A/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU) Pins: B, D, F, G, H Terminal/Tray: 12110844/4 Core/Insulation Crimp: Pins B, F, G, H - E/C Core/Insulation Crimp: Pins D - E/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Terminal Part Information Pins: 1A-1D Terminated Lead: 13575462 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Pins: 3A, 3C Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 12084586/4 Core/Insulation Crimp: F/G Pins: 3B, 3D-3H Terminated Lead: 13575461 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 12020116/2 Core/Insulation Crimp: C/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.5 BN	882	Right Rear Wheel Speed Sensor Signal	1A	0.5 BN	882	Right Rear Wheel Speed Sensor Signal
B	0.5 WH	883	Right Rear Wheel Speed Sensor Low Reference	1B	0.5 WH	883	Right Rear Wheel Speed Sensor Low Reference
C	0.5 BK	884	Left Rear Wheel Speed Sensor Signal	1C	0.5 TN	884	Left Rear Wheel Speed Sensor Signal
D	0.5 RD	885	Left Rear Wheel Speed Sensor Low Reference	1D	0.5 OG	885	Left Rear Wheel Speed Sensor Low Reference
A	2 BK	750	Ground	3A	2 BK	750	Ground
B	0.35 BK/WH	510	Low Reference	3B	0.35 OG/BK	510	Low Reference
C	2 GY	120	Fuel Pump Supply Voltage	3C	2 GY	120	Fuel Pump Supply Voltage
D	0.5 PU	30	Fuel Level Sensor Signal	3D	0.35 PU	30	Fuel Level Sensor Signal
E			Not Used	3E			Not Used
F	0.35 GY/BK	416	5-Volt Reference 1	3F	0.35 GY	2709	5-Volt Reference 1
G	0.35 D-GN	890	Fuel Tank Pressure Sensor Signal	3G	0.35 D-GN	890	Fuel Tank Pressure Sensor Signal
H	0.35 TN	2759	Low Reference	3H	0.35 TN	2759	Low Reference
H	0.35 TN	2759	Low Reference	3H	0.35 OG/BK	510	Low Reference

X405 Rear Chassis Harness to Body Harness Connector Terminal Identification

X406 Body Harness to Rear Body Harness

Connector Part Information Harness Type: Body OEM Connector: 15326835 Service Connector: 88986255 Description: 8-Way F GT 150 Series, Sealed (BK)	Connector Part Information Harness Type: Rear Body OEM Connector: 15499804 Service Connector: Service by Harness - See Part Catalog Description: 8-Way M GT 150 Sealed 4.0 (BK)
Terminal Part Information Terminated Lead: 13327113 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1	Terminal Part Information Pins: B, C, G, E Terminated Lead: 13575398 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Terminated Lead: 13576364 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/1

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	1 BK	750	Ground	A	0.8 BK	850	Ground
B	0.8 YE	18	Left Rear Stop/Turn Lamp Supply Voltage	B	0.5 YE	18	Left Rear Stop/Turn Lamp Supply Voltage
C	0.8 D-GN	19	Right Rear Stop/Turn Lamp Supply Voltage	C	0.5 D-GN	19	Right Rear Stop/Turn Lamp Supply Voltage
D	0.8 PU	709	Left Park Lamp Supply Voltage	D	0.8 PU	709	Left Park Lamp Supply Voltage
E	0.8 L-GN	24	Backup Lamp Supply Voltage	E	0.5 L-GN	24	Backup Lamp Supply Voltage
F	0.8 BN/WH	309	Right Park Lamp Supply Voltage	F	0.8 BN/WH	309	Right Park Lamp Supply Voltage
G	0.8 L-GN	24	Backup Lamp Supply Voltage	G	0.5 L-GN	24	Backup Lamp Supply Voltage
H			Not Used	H			Not Used

X406 Body Harness to Rear Body Harness Connector Terminal Identification

X409 Emergency Vehicle Rear Compartment Lid Lamps Harness to Body Harness (9C1, 9C3)

Connector Part Information Harness Type: Upfitter Jumper OEM Connector: 12047662 Service Connector: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)	Connector Part Information Harness Type: Body OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminated Lead: 13575464 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 15326030/5 Core/Insulation Crimp: E/C	Terminal Part Information Terminated Lead: 13505668 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.5 L-BU	6822	Rear Compartment Lid Ajar Switch Signal (T53)	A	0.5 OG/BK	744	Rear Compartment Lid Ajar Switch Signal
B	0.8 RD/WH	1440	Battery Positive Voltage (T53)	B	0.8 RD/WH	1440	Battery Positive Voltage

X409 Emergency Vehicle Rear Compartment Lid Lamps Harness to Body Harness (9C1, 9C3) Connector Terminal Identification

Scheme 362

Scheme 362: X490 Headliner Harness to Body Harness

Scheme 363

Connector Part Information Harness Type: Headliner OEM Connector: 15304690 Service Connector: 15304690 Description: 18-Way F GT 150 280 (GY)

Connector Part Information Harness Type: Body OEM Connector: 15336467 Service Connector: 15336467 Description: 18-Way M Global Terminal/Mixed Series (GY)

Terminal Part Information Pins: A4, A6, B5 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Pins: A5 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A Pins: A7, A8, A9, B2, B7, B8, B9 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Pins: B4, B6 Terminated Lead: 13575754 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: 4/4

Terminal Part Information Pins: A4, A6, B5 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C Pins: A5 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A Pins: A7, A8, A9, B2, B7, B8, B9 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/C Pins: B4, B6 Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: C/D

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1-A3			Not Used	A1-A3			Not Used
A4	0.35 RD/WH	2340	Battery Positive Voltage (UG1)	A4	0.5 RD/WH	2340	Battery Positive Voltage (UG1)
A4	0.35 RD/WH	2340	Battery Positive Voltage (UG1)	A4	0.5 RD/WH	2340	Battery Positive Voltage (UE1)
A5	0.8 OG	1732	Inadvertent Power Courtesy Lamp	A5	0.8 OG	1732	Inadvertent Power Courtesy Lamp
A6	0.5 YE	643	Accessory Voltage (DD6, CF5)	A6	0.5 YE	643	Accessory Voltage (DD6, CF5)
A7	0.35 BARE	1489	Drain Wire (UE1)	A7	0.35 BARE	1489	Drain Wire (UE1)
A8	0.35 BN/WH	2517	Keypad Red LED Signal (UE1)	A8	0.35 BN/WH	2517	Keypad Red LED Signal (UE1)
A9	0.35 YE/BK	2516	Keypad Green LED Signal (UE1)	A9	0.35 YE/BK	2516	Keypad Green LED Signal (UE1)
B1			Not Used	B1			Not Used
B2	0.5 L-GN	24	Backup Lamp Supply Voltage (DD6)	B2	0.5 L-GN	24	Backup Lamp Supply Voltage (DD6)
B3			Not Used	B3			Not Used
B4	2 BK	550	Ground	B4	2 BK	550	Ground
B5	0.5 GY/BK	690	Courtesy Lamp Supply Voltage	B5	0.8 GY/BK	690	Courtesy Lamp Supply Voltage
B6	2 RD/WH	3440	Battery Positive Voltage (CF5)	B6	2 RD/WH	3440	Battery Positive Voltage (CF5)
B7	0.35 GY	655	Cellular Microphone Signal (UE1)	B7	0.35 GY	655	Cellular Microphone Signal (UE1)
B8	0.35 D-GN/WH	2514	Keypad Signal (UE1)	B8	0.35 D-GN/WH	2514	Keypad Signal (UE1)
B9	0.35 L-GN/BK	2515	Keypad Supply Voltage (UE1)	B9	0.35 L-GN/BK	2515	Keypad Supply Voltage (UE1)

X490 Headliner Harness to Body Harness Connector Terminal Identification

Scheme 364

Scheme 364: X500 Body Harness to Left Front Door Harness

Connector Part Information Harness Type: Body OEM Connector: 15401211 Service Connector: 88953323 Description: 40-Way F GT Mixed Series (GY)

Connector Part Information Harness Type: Left Front Door OEM Connector: 15401208 Service Connector: 88956505 Description: 40-Way M GT 150, 280 Series (GY)

Terminal Part Information Pins: A2-A7, D2, D4, D5 Terminated Lead: 13575756 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Pins: B1-B3, B5-B7, C1-C3, C5, C6, C12 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Pins B4, C4 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Pins: D6, D7 Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A

Terminal Part Information Pins: A2-A7, D2, D4, D5 Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: C/D Pins: B1-B3, B5-B7, C1-C3, C5, C6, C12 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/4 Pins B4, C4 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: 2/4 Pins: D6, D7 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1			Not Used	A1			Not Used
A2	3 YE	143	Accessory Voltage	A2	2 YE	143	Accessory Voltage
A3	3 D-BU	1307	Power Window Master Switch Lockout Signal	A3	2 D-BU	1307	Power Window Master Switch Lockout Signal
A4	3 L-BU	166	Power Window Master Switch Right Front Up Signal	A4	2 L-BU	166	Power Window Master Switch Right Front Up Signal
A5	3 TN	167	Power Window Master Switch Right Front Down Signal	A5	2 TN	167	Power Window Master Switch Right Front Down Signal
A6	3 L-GN	170	Power Window Master Switch Right Rear Up Signal	A6	2 L-GN	170	Power Window Master Switch Right Rear Up Signal
A7	3 PU	171	Power Window Master Switch Right Rear Down Signal	A7	2 PU	171	Power Window Master Switch Right Rear Down Signal
A8			Not Used	A8			Not Used
B1	0.35 TN/WH	330	Right Mirror Motor Supply Voltage	B1	0.5 TN/WH	330	Right Mirror Motor Supply Voltage
B2	0.35 OG/WH	881	Passenger Mirror Motor Right Control	B2	0.5 OG/WH	881	Passenger Mirror Motor Right Control
B3	0.5 OG	267	Heated Mirror Element Supply Voltage (DK2)	B3	0.5 OG	267	Heated Mirror Element Supply Voltage
B4	1 GY	295	Door Lock Actuator Lock Control	B4	1 GY	295	Door Lock Actuator Lock Control
B5	0.35 OG/BK	781	Driver Door Lock Switch Unlock Signal	B5	0.5 OG/BK	781	Driver Door Lock Switch Unlock Signal
B6	0.35 GY/BK	745	Left Front Door Ajar Switch Signal	B6	0.5 GY/BK	745	Left Front Door Ajar Switch Signal
B7	0.35 PU	1124	Door Lock Key Switch Unlock Signal (without 9C1, 9C3)	B7	0.5 PU	1124	Door Lock Key Switch Unlock Signal (Uplevel)
B8-B11			Not Used	B8-B11			Not Used
B12	0.35 YE	2131	Side Impact Sensing Module - Left - Voltage	B12	0.5 YE	2131	Side Impact Sensing Module - Left - Voltage
C1	0.35 PU/WH	889	Passenger Mirror Motor Down Control	C1	0.5 PU/WH	889	Passenger Mirror Motor Down Control
C2	0.5 RD/WH	840	Battery Positive Voltage	C2	0.5 RD/WH	840	Battery Positive Voltage
C3	0.5 GY	8	Instrument Panel Lamp Supply Voltage	C3	0.5 GY	8	Instrument Panel Lamp Supply Voltage
C4	1 TN	694	Driver Door Lock Actuator Unlock Control	C4	1 TN	694	Driver Door Lock Actuator Unlock Control
C5	0.35 PK/BK	780	Driver Door Lock Switch Lock Signal	C5	0.5 PK/BK	780	Driver Door Lock Switch Lock Signal
C6	0.35 TN	126	Left Front Door Open Switch Signal	C6	0.5 TN	126	Left Front Door Open Switch Signal
C7-C11			Not Used	C7-C11			Not Used
C12	0.35 WH	2132	Side Impact Sensing Module - Left - Signal	C12	0.5 WH	2132	Side Impact Sensing Module - Left - Signal
D1			Not Used	D1			Not Used
D2	3 BK	550	Ground	D2	2 BK	550	Ground
D3			Not Used	D3			Not Used
D4	3 D-GN	168	Power Window Master Switch Left Rear Up Signal	D4	2 D-GN	168	Power Window Master Switch Left Rear Up Signal
D5	3 PU	169	Power Window Master Switch Left Rear Down Signal	D5	2 PU	169	Power Window Master Switch Left Rear Down Signal
D6	0.8 GY	118	Left Front Speaker Output (-)	D6	0.5 GY	118	Left Front Speaker Output (-)
D6	0.8 YE	1956	Left Front Speaker Output (-) (UQ3)	D6	0.5 GY	118	Left Front Speaker Output (-)
D7	0.8 TN	201	Left Front Speaker Output (+)	D7	0.5 TN	201	Left Front Speaker Output (+)
D7	0.8 TN	1856	Left Front Speaker Output (+) (UQ3)	D7	0.5 TN	201	Left Front Speaker Output (+)
D8			Not Used	D8			Not Used

X500 Body Harness to Left Front Door Harness Connector Terminal Identification

Scheme 365

Scheme 365: X503 Left Front Door Harness to Left Front Door Trim Harness

Connector Part Information Harness Type: Left Front Door OEM Connector: 15401211 Service Connector: 88953323 Description: 40-Way F GT Mixed Series (GY)	Connector Part Information Harness Type: Left Front Door Trim OEM Connector: 15463191 Service Connector: 88988433 Description: 40-Way M GT 150, 280 Series (GY)
Terminal Part Information Pins: A2-A7, D2-D7 Terminated Lead: 13575756 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Pins: B1-B12, C1-C12 Terminated Lead: 13575735 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C	Terminal Part Information Pins: A2-A7, D2-D7 Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: C/D Pins: B1-B12, C1-C12 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/4

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1			Not Used	A1			Not Used
A2	2 YE	143	Accessory Voltage	A2	2 YE	143	Accessory Voltage
A3	2 D-BU	1307	Power Window Master Switch Lockout Signal	A3	2 D-BU	1307	Power Window Master Switch Lockout Signal
A4	2 L-BU	166	Power Window Master Switch Right Front Up Signal	A4	2 L-BU	166	Power Window Master Switch Right Front Up Signal
A5	2 TN	167	Power Window Master Switch Right Front Down Signal	A5	2 TN	167	Power Window Master Switch Right Front Down Signal
A6	2 L-GN	170	Power Window Master Switch Right Rear Up Signal	A6	2 L-GN	170	Power Window Master Switch Right Rear Up Signal
A7	2 PU	171	Power Window Master Switch Right Rear Down Signal	A7	2 PU	171	Power Window Master Switch Right Rear Down Signal
A8			Not Used	A8			Not Used
B1	0.5 TN/WH	330	Right Mirror Motor Supply Voltage	B1	0.5 WH	330	Right Mirror Motor Supply Voltage
B2	0.5 OG/WH	881	Passenger Mirror Motor Right Control	B2	0.5 OG/WH	881	Passenger Mirror Motor Right Control
B3-B4			Not Used	B3-B4			Not Used
B5	0.5 OG/BK	781	Driver Door Lock Switch Unlock Signal	B5	0.35 OG	781	Driver Door Lock Switch Unlock Signal
B6-B7			Not Used	B6-B7			Not Used
B8	0.5 L-GN	89	Driver Mirror Motor Down Control	B8	0.35 L-GN	89	Driver Mirror Motor Down Control
B9	0.5 TN	329	Left Mirror Motor Supply Voltage	B9	0.35 YE	329	Left Mirror Motor Supply Voltage
B10	0.5 WH	81	Driver Mirror Motor Right Control	B10	0.35 WH	81	Driver Mirror Motor Right Control
B11-B12			Not Used	B11-B12			Not Used
C1	0.5 PU/WH	889	Passenger Mirror Motor Down Control	C1	0.5 PU/WH	889	Passenger Mirror Motor Down Control
C2	0.5 RD/WH	840	Battery Positive Voltage	C2	0.35 RD/WH	840	Battery Positive Voltage
C3	0.5 GY	8	Instrument Panel Lamp Supply Voltage	C3	0.35 GY	8	Instrument Panel Lamp Supply Voltage
C4			Not Used	C4			Not Used
C5	0.5 PK/BK	780	Driver Door Lock Switch Lock Signal	C5	0.35 OG/BK	780	Driver Door Lock Switch Lock Signal
C6-C12			Not Used	C6-C12			Not Used
D1			Not Used	D1			Not Used
D2	2 BK	550	Ground	D2	2 BK	550	Ground
D3			Not Used	D3			Not Used
D4	2 D-GN	168	Power Window Master Switch Left Rear Up Signal	D4	2 D-GN	168	Power Window Master Switch Left Rear Up Signal
D5	2 PU	169	Power Window Master Switch Left Rear Down Signal	D5	2 PU	169	Power Window Master Switch Left Rear Down Signal
D6	2 BN	165	Power Window Motor Left Front Down Control	D6	2 BN	165	Power Window Motor Left Front Down Control
D7	2 D-BU	164	Power Window Motor Left Front Up Control	D7	2 D-BU	164	Power Window Motor Left Front Up Control
D8			Not Used	D8			Not Used

X503 Left Front Door Harness to Left Front Door Trim Harness Connector Terminal Identification

X600 Body Harness to Right Front Door Harness

Connector Part Information Harness Type: Body OEM Connector: 15401211 Service Connector: 88953323 Description: 40-Way F GT Mixed Series (GY)

Connector Part Information Harness Type: Right Front Door OEM Connector: 15401208 Service Connector: 88956505 Description: 40-Way M GT 150, 280 Series (GY)

Terminal Part Information Pins: A2, A4, A5 Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: A/D Pins: B1-B3, B6, C1, C6, C12 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: E/4 Pins: B4, B5, C3-C5 Terminated Lead: 13575502 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15304702/19 Core/Insulation Crimp: 2/4 Pins: D2, D6, D7 Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304722/8 Core/Insulation Crimp: E/C

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A1			Not Used	A1			Not Used
A2	3 YE/BK	143	Accessory Voltage	A2	3 YE	143	Accessory Voltage
A3			Not Used	A3			Not Used
A4	3 L-BU	166	Power Window Master Switch Right Front Up Signal	A4	3 L-BU	166	Power Window Master Switch Right Front Up Signal
A5	3 TN	167	Power Window Master Switch Right Front Down Signal	A5	3 TN	167	Power Window Master Switch Right Front Down Signal
A6-A8			Not Used	A6-A8			Not Used
B1	0.35 TN/WH	330	Right Mirror Motor Supply Voltage	B1	0.5 TN/WH	330	Right Mirror Motor Supply Voltage
B2	0.35 OG/WH	881	Passenger Mirror Motor Right Control	B2	0.5 OG/WH	881	Passenger Mirror Motor Right Control
B3	0.5 OG	267	Heated Mirror Element Supply Voltage (DK2)	B3	0.5 OG	267	Heated Mirror Element Supply Voltage
B4	1 GY	295	Door Lock Actuator Lock Control	B4	1 GY	295	Door Lock Actuator Lock Control
B5	0.35 D-BU	245	Passenger Door Lock Switch Unlock Signal	B5	1 D-BU	245	Passenger Door Lock Switch Unlock Signal
B6	0.35 TN/WH	746	Right Front Door Ajar Switch Signal	B6	0.5 TN/WH	746	Right Front Door Ajar Switch Signal
B7-B11			Not Used	B7-B11			Not Used
B12	0.35 TN	2133	Side Impact Sensing Module - Right - Voltage	B12	0.5 TN	2133	Side Impact Sensing Module - Right - Voltage
C1	0.35 PU/WH	889	Passenger Mirror Motor Down Control	C1	0.5 PU/WH	889	Passenger Mirror Motor Down Control
C2			Not Used	C2			Not Used
C3	0.5 GY	8	Instrument Panel Lamp Supply Voltage	C3	1 GY	8	Instrument Panel Lamp Supply Voltage
C4	1 TN	294	Door Lock Actuator Unlock Control	C4	1 TN	294	Door Lock Actuator Unlock Control
C5	0.35 L-BU	244	Passenger Door Lock Switch Lock Signal	C5	1 L-BU	244	Passenger Door Lock Switch Lock Signal
C6	0.35 OG	5922	Passenger Door Open Switch Signal	C6	0.5 OG	5922	Passenger Door Open Switch Signal
C7-C11			Not Used	C7-C11			Not Used
C12	0.5 D-GN	2134	Side Impact Sensing Module - Right - Signal	C12	0.5 D-GN	2134	Side Impact Sensing Module - Right - Signal
D1			Not Used	D1			Not Used
D2	0.8 BK	750	Ground	D2	0.5 BK	750	Ground
D3			Not Used	D3-D5			Not Used
D4	2 RD/WH	1140	Battery Positive Voltage (AG1, AG2)
D5			Not Used
D6	0.8 D-GN	117	Right Front Speaker Output (-) (9C1/9C3 without WX7)	D6	0.5 D-GN	117	Right Front Speaker Output (-)
	0.8 D-GN	117	Right Front Speaker Output (-) (9C1/9C3 with WX7)
	0.8 PU	1952	Right Front Speaker Output (-) (UQ3)
D7	0.8 L-GN	200	Right Front Speaker Output (+) (9C1/9C3 without WX7)	D7	0.5 L-GN	200	Right Front Speaker Output (+)
	0.8 L-GN	200	Right Front Speaker Output (+) (9C1/9C3 with WX7)
	0.8 L-GN	1852	Right Front Speaker Output (+) (UQ3)
D8			Not Used	D8			Not Used

X600 Body Harness to Right Front Door Harness Connector Terminal Identification

X604 Right Front Door Trim Harness to Right Front Door Harness

Connector Part Information Harness Type: Right Front Door OEM Connector: 15326931 Service Connector: 15306309 Description: 10-Way F GT 280 Series (BK)

Connector Part Information Harness Type: Right Front Door OEM Connector: 15326935 Service Connector: 15306305 Description: 10-Way M GT 280 Series (BK)

Terminal Part Information Pins: A-E Terminated Lead: 13575756 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Pins: F-H Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Pins: J Terminated Lead: 13575753 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A

Terminal Part Information Pins: A-E Terminated Lead: 13575510 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: A/D Pins: F, G, H, J Terminated Lead: 13575507 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304724/8 Core/Insulation Crimp: 2/A

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	3 YE	143	Accessory Voltage	A	3 YE	143	Accessory Voltage
B	3 L-BU	166	Power Window Master Switch Right Front Up Signal	B	3 L-BU	166	Power Window Master Switch Right Front Up Signal
C	3 TN	167	Power Window Master Switch Right Front Down Signal	C	3 TN	167	Power Window Master Switch Right Front Down Signal
D	3 D-BU	666	Power Window Motor Right Front Up Control	D	3 D-BU	666	Power Window Motor Right Front Up Control
E	3 BN	667	Power Window Motor Right Front Down Control	E	3 BN	667	Power Window Motor Right Front Down Control
F	0.35 D-BU	245	Passenger Door Lock Switch Unlock Signal	F	1 D-BU	245	Passenger Door Lock Switch Unlock Signal
G	0.35 L-BU	244	Passenger Door Lock Switch Lock Signal	G	1 L-BU	244	Passenger Door Lock Switch Lock Signal
H	0.35 GY	8	Instrument Panel Lamp Supply Voltage	H	1 GY	8	Instrument Panel Lamp Supply Voltage
J	0.5 BK	750	Ground	J	1 BK	750	Ground
J	0.5 BK	750	Ground	J	1 BK	750	Ground
K			Not Used	K			Not Used

X604 Right Front Door Trim Harness to Right Front Door Harness Connector Terminal Identification

Scheme 366

Scheme 366: X700 Body Harness to Left Rear Door Harness

Connector Part Information Harness Type: Body OEM Connector: 15441216 Service Connector: 89046932 Description: 9-Way F GT 150, 280 Series, Sealed (BK)	Connector Part Information Harness Type: Left Rear Door OEM Connector: 15486551 Service Connector: 88953404 Description: 9-Way M GT Mixed Series (BK)
Terminal Part Information Pins: A, B, D, E, F Terminated Lead: 13327113 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Pins: C, G, H Terminated Lead: 13578903 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304720/19 Core/Insulation Crimp: 4/5	Terminal Part Information Pins: A, B, D, E, F Terminated Lead: 13575398 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Pins: C, G, H Terminated Lead: 13575443 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304732/8 Core/Insulation Crimp: A/5

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 BK	550	Ground	A	0.5 BK	550	Ground
B	1 TN	294	Door Lock Actuator Unlock Control	B	1 TN	294	Door Lock Actuator Unlock Control
C	3 D-BU	1307	Power Window Master Switch Lockout Signal	C	3 D-BU	1307	Power Window Master Switch Lockout Signal
D	0.35 OG	5922	Passenger Door Open Switch Signal	D	0.5 OG	5922	Passenger Door Open Switch Signal
E	1 GY	295	Door Lock Actuator Lock Control	E	1 GY	295	Door Lock Actuator Lock Control
F	0.35 L-BU/BK	747	Left Rear Door Ajar Switch Signal	F	0.5 L-BU/BK	747	Left Rear Door Ajar Switch Signal
G	3 D-GN	168	Power Window Master Switch Left Rear Up Signal	G	3 D-GN	168	Power Window Master Switch Left Rear Up Signal
H	3 PU	169	Power Window Master Switch Left Rear Down Signal	H	3 PU	169	Power Window Master Switch Left Rear Down Signal
J			Not Used	J			Not Used

X700 Body Harness to Left Rear Door Harness Connector Terminal Identification

X800 Body Harness to Right Rear Door Harness

Connector Part Information Harness Type: Body OEM Connector: 15441216 Service Connector: 89046932 Description: 9-Way F GT 150, 280 Series, Sealed (BK)	Connector Part Information Harness Type: Right Rear Door OEM Connector: 15486551 Service Connector: 88953404 Description: 9-Way M GT Mixed Series (BK)
Terminal Part Information Pins: A, B, D, E, F Terminated Lead: 13327113 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Pins: C, G, H Terminated Lead: 13578903 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304720/19 Core/Insulation Crimp: 4/5	Terminal Part Information Pins: A, B, D, E, F Terminated Lead: 13575398 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Pins: C, G, H Terminated Lead: 13575443 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304732/8 Core/Insulation Crimp: A/5

Pin	Wire	Circuit	Function	Pin	Wire	Circuit	Function
A	0.8 BK	750	Ground	A	0.5 BK	750	Ground
B	1 TN	294	Door Lock Actuator Unlock Control	B	1 TN	294	Door Lock Actuator Unlock Control
C	3 D-BU	1307	Power Window Master Switch Lockout Signal	C	3 D-BU	1307	Power Window Master Switch Lockout Signal
D	0.35 OG	5922	Passenger Door Open Switch Signal	D	0.5 OG	5922	Passenger Door Open Switch Signal
E	1 GY	295	Door Lock Actuator Lock Control	E	1 GY	295	Door Lock Actuator Lock Control
F	0.35 L-GN/BK	748	Right Rear Door Ajar Switch Signal	F	0.5 L-GN/BK	748	Right Rear Door Ajar Switch Signal
G	3 L-GN	170	Power Window Master Switch Right Rear Up Signal	G	3 L-GN	170	Power Window Master Switch Right Rear Up Signal
H	3 PU	171	Power Window Master Switch Right Rear Down Signal	H	3 PU	171	Power Window Master Switch Right Rear Down Signal
J			Not Used	J			Not Used

X800 Body Harness to Right Rear Door Harness Connector Terminal Identification

Wiring Systems and Power Management - Inline Harness Connector End Views Chevrolet Impala IX

Scheme 340

Scheme 341

X105 Battery Harness to I/P Harness

Scheme 342

Scheme 343

Scheme 344

X122 Forward Lamp Harness to Forward Lamp Harness (9C1/9C3 without 6J7)

X123 I/P Harness to the Grille Lamp Jumper Harness (6J3)

Scheme 345

X142 Forward Lamp Harness to Right Front Headlamp Assembly Harness

Scheme 346

Scheme 347

Scheme 348

X201 Steering Column Harness to I/P Harness

Scheme 349

X208 SEO Auxiliary Harness to Body Harness (9C1, 9C3)

Scheme 350

X223 I/P Harness to I/P Harness (6J6)

Scheme 351

X266 I/P Harness to I/P Harness (6J4)

Scheme 352

X268 I/P Harness to I/P Harness (9C1, 9C3, with WX7)

X269 I/P Harness to I/P Harness (9C1, 9C3, with WX7)

X270 Body Harness to DVD Power Jumper Harness (SPO Accessory)

X275 SIR Coil to Steering Column Harness

X277 SIR Coil to Steering Wheel Harness

Scheme 353

X297 I/P Harness to Grille Lamp Jumper Harness (9C1, 9C3, 6J3)

Scheme 354

X313 Body Harness to Right Front Seat Harness

Scheme 355

X316 Right Front Seat Harness to Body Harness

X322 Body Harness to Roof Wiring Provision Harness (9C1, 9C3)

X340 Body Harness to Console Harness (without D55)

X340 Console Harness to Body Harness (D55)

Scheme 356

Scheme 357

X362 Body Harness to I/P Harness (9C1, 9C3)

Scheme 358

Scheme 359

X372 DVD Signal Cable 3B to DVD Signal Cable 1B (SPO Accessory)

X373 DVD Signal Cable 3A to DVD Signal Cable 2A (SPO Accessory)

X374 DVD Signal Cable 3B to DVD Signal Cable 2B (SPO Accessory)

X398 Roof Harness to Sunroof Harness (CF5)

X401 Rear Body Harness to Left Tail Lamp Harness

X402 Rear Body Harness to Right Tail Lamp Harness

Scheme 360

Scheme 361

X406 Body Harness to Rear Body Harness

X409 Emergency Vehicle Rear Compartment Lid Lamps Harness to Body Harness (9C1, 9C3)

Scheme 362

Scheme 363

Scheme 364

Scheme 365

X600 Body Harness to Right Front Door Harness

X604 Right Front Door Trim Harness to Right Front Door Harness

Scheme 366

X800 Body Harness to Right Rear Door Harness

More articles — Electrical

Login / Signup

Enter the code

You have successfully logged in!
