Front Suspension System: Specifications Chevrolet HHR I

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Ball Joint to Control Arm Nut and Bolts	68 N.m	50 lb ft
Ball Joint to Steering Knuckle Nut
First Pass	50 N.m Reverse Nut 3/4 turn	37 lb ft Reverse Nut 3/4 turn
Second Pass	50 N.m + 30°	37 lb ft +30°
Control Arm to Front Frame Bolts	55 N.m	41 lb ft
Control Arm to Rear Frame Bolts	100 N.m + 180°	74 lb ft +180°
Frame to Chassis Bolts	100 N.m +180°	74 lb ft +180°
Intermediate Shaft Pinch Bolt	34 N.m	25 lb ft
Stabilizer Link to Strut Nut	80 N.m	59 lb ft
Stabilizer Shaft Clamp Bolt	50 N.m	37 lb ft
Stabilizer Shaft Clamp Nut	50 N.m	37 lb ft
Stabilizer Shaft Link to Stabilizer Bar Nut	80 N.m	59 lb ft
Strut Assembly to Steering Knuckle Nut	120 N.m	89 lb ft
Strut to Body Nut	20 N.m	15 lb ft
Strut Shaft Nut	70 N.m	52 lb ft
Transmission Mount Through Bolt	100 N.m	74 lb ft
Transmission Mount to Frame Bolt	50 N.m	37 lb ft
Wheel Bearing/Hub Assembly Mounting Bolts	115 N.m	85 lb ft

Scheme 1: Stabilizer Shaft Replacement

Callout	Component Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the tires and wheels. Refer to Tire and Wheel Removal and Installation . Remove the stabilizer shaft link from the stabilizer shaft. Refer to Stabilizer Shaft Link Replacement Remove the stabilizer shaft insulators from the stabilizer shaft. Refer to Stabilizer Shaft Insulator Replacement .
1	Front Stabilizer Shaft Tip: Remove the stabilizer shaft from the right side of the vehicle.

Scheme 2: Stabilizer Shaft Link Replacement

Callout	Component Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the front tire and wheel assembly. Refer to Tire and Wheel Removal and Installation .
1	Front Stabilizer Shaft Link Nut (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 80 N.m (59 lb ft) Tip: Some models maybe equipped with a washer/spacer between the stabilizer link and the shock strut. It will be necessary to transfer the washer/spacer when replacing the stabilizer shaft or the stabilizer link.
2	Front Stabilizer Shaft Link

NOTE
Refer to Fastener Notice .

Scheme 3: Stabilizer Shaft Insulator Replacement

Callout	Component Name
Preliminary Procedure: Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
1	Front Stabilizer Shaft Clamp Bolt NOTE: Refer to Fastener Notice . Tighten: 50 N.m (37 lb ft)
2	Front Stabilizer Shaft Clamp Nut Tighten: 50 N.m (37 lb ft)
3	Front Stabilizer Shaft Clamp
4	Front Stabilizer Shaft Insulator Tip: Place the cut line of the insulator facing the rear of the vehicle.

NOTE
Refer to Fastener Notice .

Scheme 4: Front Wheel Bearing and Hub Replacement

Callout	Component Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the front tire and wheel. Refer to Tire and Wheel Removal and Installation . Remove the brake rotor. Refer to Front Brake Rotor Replacement .
1	Wheel Speed Sensor Electrical Connector Tip: Push inward on the wheel drive shaft when removing the wheel bearing/hub assembly from the knuckle. This will allow the removal and installation of the wheel speed sensor electrical connector (if equipped).
3	Wheel Bearing Bearing/Hub Assembly Mounting Bolt (Qty: 3) NOTE: Refer to Fastener Notice . Tighten: 115 N.m (85 lb ft)
4	Wheel Bearing/Hub Assembly Bearing Procedure: Separate the wheel drive shaft from the steering knuckle. Refer to Wheel Drive Shaft Replacement .
5	Wheel Bearing/Hub Assembly Spacer

NOTE
Refer to Fastener Notice .

Scheme 5: Steering Knuckle Replacement

Callout	Component Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the wheel bearing and hub assembly. Refer to Front Wheel Bearing and Hub Replacement . Remove the outer tie rod end from the knuckle. Refer to Rack and Pinion Outer Tie Rod End Replacement . Remove the lower control arm from the knuckle. Refer to Lower Control Arm Replacement .
1	Bolt (Qty: 2)
2	Nut (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 120 N.m (89 lb ft)
3	Steering Knuckle Tip: Check the wheel alignment. Refer to Wheel Alignment Measurement .

NOTE
Refer to Fastener Notice .
