Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Intermediate Steering Shaft Bolt | 34 N.m | 25 lb ft |
| Steering Column Pivot Bolt | 25 N.m | 18 lb ft |
| Steering Column Mounting Bolt | 25 N.m | 18 lb ft |
| Steering Column Trim Cover Screw | 2 N.m | 18 lb in |
| Steering Wheel Nut | 41 N.m | 30 lb ft |
Scheme 1
Scheme 1: Steering Column Disassembled View
| Callout | Component Name |
|---|
| 1 | Lower Intermediate Steering Shaft Bold |
| 2 | Intermediate Steering Shaft Assembly |
| 3 | Upper Intermediate Steering Shaft Bolt |
| 4 | Lower Steering Column Support Bracket Bolt |
| 5 | Lower Steering Column Jacket Bolt |
| 6 | Steering Column Assembly |
| 7 | Ignition / Start Switch Clamp Bolt |
| 8 | Ignition / Start Switch Clamp |
| 9 | Upper Steering Column Support Bracket Bolt |
| 10 | Turn Signal Switch Bracket Screw |
| 11 | Turn Signal Switch Bracket Screw |
| 12 | Inflatable Restraint Steering Wheel Module Coil Assembly |
| 13 | Ignition / Start Switch Screw |
| 14 | Ignition / Start Switch Assembly |
| 15 | Ignition / Start Switch Housing |
| 16 | Spring |
| 17 | Ignition Lock Cylinder Control Solenoid Screw |
| 18 | Ignition Lock Cylinder Control Solenoid Assembly |
| 19 | Steering Column Jacket Assembly |
| 20 | Steering Wheel Nut |
| 21 | Steering Wheel Assembly |
| 22 | Inflatable Restraint Steering Wheel Module Retainer |
| 23 | Steering Wheel Shroud Screw |
| 24 | Wiper / Washer Switch Assembly |
| 25 | Steering Wheel Shroud |
| 26 | Lower Trim Cover Clip |
| 27 | Upper Trim Cover |
| 28 | Cruise Control Resume Switch Assembly |
| 29 | Cruise Control Switch Assembly |
| 30 | Harness Assembly |
| 31 | Lower Trim Cover Plug |
| 32 | Lower Trim Cover Screw |
| 33 | Lower Trim Cover |
| 34 | Headlamp / Dimmer / Park / Turn Signal Switch Assembly |
