Configurable Customer Control System: Other Chevrolet HHR I

Memory Modules 1 illustration ~109 words

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Reference Information

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-299596-S40031980912008092400000)
  2. «Connector Repairs»(ref-299596-S11637586662008092400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-299596-S35075552982008092400000)
  4. «Wiring Repairs»(ref-299596-S38795053442008092400000)

Scan Tool Reference

Control Module References for scan tool information

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(ref-299604-S15180354282008092400000)
  2. «Control Module References»(ref-299597-S40606836452008092400000) for Radio replacement, setup, and programming.

Scheme 2

Scheme 2: Steering Wheel Control Switch Assembly Replacement
Scheme 2: Steering Wheel Control Switch Assembly Replacement
CalloutComponent Name
NOTE: Refer to Fastener Notice Preliminary Procedure: Remove the inflatable restraint steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement .
1Bolt/Screw, Steering Wheel Switch Tip: Disconnect the Electrical Connector Tighten: 1.8 N.m (16 lb in)
2Switch Assembly, Radio, HVAC and Cruise Control Assembly
NOTE
Refer to Fastener Notice
