Wiring Systems and Power Management - Component Locator - Powertrain Component Views Chevrolet Express G3500

Scheme 9

Scheme 9: Oxygen Sensors (LC8, L20, or L96)
Items
1: X128 (L20, L96 or LC8)
2: B52E Heated Oxygen Sensor - Bank 2 Sensor 1 (LU3, L20, LMF, L96 or LC8)
3: B52D Heated Oxygen Sensor - Bank 1 Sensor 2 (LU3, L20, LMF, L96 or LC8)
4: B52F Heated Oxygen Sensor - Bank 2 Sensor 2 (LU3, L20, LMF, L96 or LC8)
5: B52C Heated Oxygen Sensor - Bank 1 Sensor 1 (LU3, L20, LMF, L96 or LC8)

Scheme 10

Scheme 10: Lower Right of the Engine (LU3)
Items
1: B68A Knock Sensor 1

Scheme 11

Scheme 11: Upper Engine (LGH)
Items
1: B75B Mass Air Flow/Intake Air Temperature Sensor
2: Q38 Throttle Body (LU3, L20, LMF, L96 or LC8)
3: Q20 Intake Air Flow Valve
4: E24 Intake Air Heater (LGH)
5: B74 Manifold Absolute Pressure Sensor
6: Q41 Turbocharger Vane Position Control Solenoid Valve (LGH)
7: B112 Turbocharger Vane Position Sensor (LGH)
9: X111
10: X110 (LGH)

Scheme 12

Scheme 12: Right Side of the Engine (LU3)
Items
1: Q7 Fuel Injector Fuel Meter Body (LU3)
2: G13 Generator
3: K35 Ignition Coil Module (LU3)
4: Q12 Evaporative Emission Purge Solenoid Valve (LU3, L20, LMF, L96 or LC8)
5: B74 Manifold Absolute Pressure Sensor

Scheme 13

Scheme 13: Engine Components (LGH)
Items
1: B75B Mass Air Flow/Intake Air Temperature Sensor
2: K20 Engine Control Module (ECM)
3: B1 A/C Refrigerant Pressure Sensor (C60)
4: P13 Horn Assembly
5: X50A Fuse Block - Underhood

Scheme 14

Scheme 14: Front of the Engine Components (LC8, LMF, L20, or L96)
Items
1: Q38 Throttle Body (LU3, L20, LMF, L96 or LC8)
2: B74 Manifold Absolute Pressure Sensor
3: Q12 Evaporative Emission Purge Solenoid Valve (LU3, L20, LMF, L96 or LC8)
4: B68B Knock Sensor 2
5: B34 Engine Coolant Temperature Sensor
6: B23 Camshaft Position Sensor
7: G13 Generator

Scheme 15

Scheme 15: Left Front of Engine Components (LGH)
Items
1: Q20 Intake Air Flow Valve
2: E24 Intake Air Heater (LGH)
3: Q2 A/C Compressor Clutch
4: Q14 Exhaust Gas Recirculation Valve (LGH)
5: B112 Turbocharger Vane Position Sensor (LGH)
6: B193A Charge Air Cooler Inlet Temperature Sensor (LGH)
7: B130A Exhaust Gas Recirculation Temperature Sensor 1 (LGH)
8: B215 Fuel Filter Pressure Switch (LGH)
9: B195A Nitrogen Oxides Sensor 1 (LGH)
10: B48B Fuel Temperature Sensor 2 (LGH)
11: B47B Fuel Rail Pressure Sensor
12: K34 Glow Plug Control Module (LGH)
13: Q17H Fuel Injector 8
14: Q17F Fuel Injector 6
15: E12H Glow Plug 8 (LGH)
16: E12F Glow Plug 6 (LGH)
17: Q17D Fuel Injector 4
18: E12D Glow Plug 4 (LGH)
19: B37B Engine Oil Pressure Sensor
20: B35 Engine Oil Level Switch (LGH)
21: E12B Glow Plug 2 (LGH)
22: Q17B Fuel Injector 2
23: G13 Generator

Scheme 16

Scheme 16: Right Side of the Engine Components (LC8, LMF, L20, or L96)
Items
1: T8H Ignition Coil 8 (L20, LMF, L96 or LC8)
2: T8F Ignition Coil 6 (L20, LMF, L96 or LC8)
3: T8D Ignition Coil 4 (L20, LMF, L96 or LC8)
4: B74 Manifold Absolute Pressure Sensor
5: Q38 Throttle Body (LU3, L20, LMF, L96 or LC8)
6: T8B Ignition Coil 2 (L20, LMF, L96 or LC8)
7: B68A Knock Sensor 1
8: B26 Crankshaft Position Sensor
9: M64 Starter Motor
10: B37B Engine Oil Pressure Sensor

Scheme 17

Scheme 17: Rear of the Engine (LU3 or LMF)
Items
1: B52C Heated Oxygen Sensor - Bank 1 Sensor 1 (LU3, L20, LMF, L96 or LC8)
2: B52E Heated Oxygen Sensor - Bank 2 Sensor 1 (LU3, L20, LMF, L96 or LC8)
3: B52F Heated Oxygen Sensor - Bank 2 Sensor 2 (LU3, L20, LMF, L96 or LC8)
4: B52D Heated Oxygen Sensor - Bank 1 Sensor 2 (LU3, L20, LMF, L96 or LC8)
5: B81 Park/Neutral Position Switch (M30)

Scheme 18

Scheme 18: Automatic Transmission Internal Electronic Components (MYD)
CalloutComponent Name
1Control Solenoid Valve Assembly
2Automatic Transmission Input and Output Speed Sensors Assembly
3Automatic Transmission Internal Mode Switch (IMS)

Scheme 19

Scheme 19: Left Rear of the Engine (LU3)
Items
1: B34 Engine Coolant Temperature Sensor

Scheme 20

Scheme 20: Right Side of the Engine (LC8, LMF, L20, or L96)
Items
1: B26 Crankshaft Position Sensor
2: Q2 A/C Compressor Clutch
3: M64 Starter Motor

Scheme 21

Scheme 21: Lower Right of the Engine (LC8, LMF, L20, or L96)
Items
1: B68A Knock Sensor 1

Scheme 22

Scheme 22: Upper Right Side of the Engine (LC8, LMF, L20, or L96)
Items
1: Q17H Fuel Injector 8
2: Q17F Fuel Injector 6
3: Q17D Fuel Injector 4
4: Q17B Fuel Injector 2
5: T8B Ignition Coil 2 (L20, LMF, L96 or LC8)
6: T8D Ignition Coil 4 (L20, LMF, L96 or LC8)
7: T8F Ignition Coil 6 (L20, LMF, L96 or LC8)
8: X127 (L20, LMF, L96 or LC8)
9: T8H Ignition Coil 8 (L20, LMF, L96 or LC8)

Scheme 23

Scheme 23: Front of the Engine (LU3)
Items
1: G13 Generator
2: Q2 A/C Compressor Clutch
3: B26 Crankshaft Position Sensor

Scheme 24

Scheme 24: Upper Left Side of the Engine (LC8, LMF, L20, or L96)
CalloutComponent Name
1Fuel Injector 1 Connector
2Fuel Injector 3 Connector
3Fuel Injector 5 Connector
4J101
5J102
6Fuel Injector 7 Connector
7Ignition Coil 7 Connector
8Ignition Coil 5 Connector
9X126
10Ignition Coil 3 Connector
11Engine Coolant Temperature (ECT) Sensor Connector
12Ignition Coil 1 Connector

Scheme 25

Scheme 25: Right Front of Engine Components (LGH)
Items
1: Q17G Fuel Injector 7
2: Q17E Fuel Injector 5
3: Q67 Exhaust Aftertreatment Fuel Injector (LGH)
4: B131A Exhaust Temperature Sensor 1 (LGH)
5: Q17A Fuel Injector 1
6: Q41 Turbocharger Vane Position Control Solenoid Valve (LGH)
7: B130B Exhaust Gas Recirculation Temperature Sensor 2 (LGH)
8: G13 Generator
9: B74 Manifold Absolute Pressure Sensor
10: B23 Camshaft Position Sensor
11: B26 Crankshaft Position Sensor
12: E12A Glow Plug 1 (LGH)
13: E12C Glow Plug 3 (LGH)
14: M64 Starter Motor
15: E12E Glow Plug 5 (LGH)
16: E12G Glow Plug 7 (LGH)
17: Q17C Fuel Injector 3

Scheme 26

Scheme 26: Top Rear of the Engine (LGH)
Items
1: B47B Fuel Rail Pressure Sensor
2: X112 (LGH)

Scheme 27

Scheme 27: Automatic Transmission Internal Electronic Components (M30)
Items
1: Q39A Torque Converter Clutch Pressure Control Solenoid Valve (M30)
2: B14C Transmission Input Shaft Speed Sensor (M30)
3: B14A Transmission Output Shaft Speed Sensor (M30)
4: Q1B 2-3 Shift Solenoid Valve (M30)
5: Q1A 1-2 Shift Solenoid Valve (M30)
6: B13 Transmission Fluid Temperature Sensor (M30)
7: Q27 Pressure Control Solenoid Valve (M30)
8: Q39A Torque Converter Clutch Pressure Control Solenoid Valve (M30)

Scheme 28

Scheme 28: Left Front Side of the Engine Components (LC8, LMF, L20, or L96)
Items
1: Q6 Camshaft Position Actuator Solenoid Valve (L96 or LC8)
2: B23 Camshaft Position Sensor

Scheme 29

Scheme 29: Top of the Engine (LC8, LMF, L20, or L96)
CalloutComponent Name
1Manifold Absolute Pressure (MAP) Sensor Connector
2J102
3J101
4Evaporative Emission (EVAP) Canister Purge Solenoid Valve
5Throttle Body

Scheme 30

Scheme 30: Top of the Engine Components (LGH)
Items
1: Q18A Fuel Pressure Regulator 1 (LGH)
2: B34 Engine Coolant Temperature Sensor
3: B48A Fuel Temperature Sensor 1 (LGH)
4: Q18B Fuel Pressure Regulator 2 (LGH)
