Automatic Transmission - 4l60-e (m30) - Specifications Chevrolet Express G1500

Automatic Trans 1 illustration ~177 words

Fastener Tightening Specifications

Description of UsageRef No.*QtySizeSpecification
MetricEnglish
Accumulator Cover to Case581M6x1.0x658-14 N.m71-124 lb in
Accumulator Cover to Case1171M6x1.0x658-14 N.m71-124 lb in
Accumulator Cover to Case1182M6x1.0x28.08-14 N.m71-124 lb in
Accumulator Cover to Case592M6x1.0x358-14 N.m71-124 lb in
Converter Cover Bolt10 N.m89 lb in
Converter Housing to Case948M10x1.5gx4565-75 N.m48-55 lb ft
Cooler Pipe Connector9521/4-18NSPS(SPL)35-41 N.m26-30 lb ft
Detent Spring to Valve Body641M8x1.25x2020-27 N.m15-20 lb ft
Extension Housing to Case326M10x1.5x33.442-48 N.m31-35 lb ft
Extension Housing to Case (4WD Shipping)N/A4M10x1.5x33.411-23 N.m8-17 lb in
Floorshift Control Bolt10 N.m89 lb in
Flywheel to Torque Converter Bolt60 N.m44 lb ft
Forward Accumulator Cover to Valve Body3643M6x1.0x17.78-14 N.m71-124 lb in
Heat Shield to Transmission Bolt17 N.m13 lb ft
Input Speed Sensor Hole Plug to Pump Cover2481M6x1.0x17.79-11 N.m80-97 lb in
Input Speed Sensor to Pump Cover2471M6x1.0x17.79-11 N.m80-97 lb in
Line Pressure Test Hole Plug3911/8-27NPTF8-14 N.m71-124 lb in
Negative Battery Cable Bolt15 N.m11 lb ft
Oil Cooler Pipe Fitting1029/16-18UNF20 +/- 2 N.m15 lb ft
Oil Level Indicator Bolt47 N.m35 lb ft
Oil Pan to Case7616M8x1.25x19.316 N.m11.8 lb ft
Oil Pan to Transmission Case Bolt11 N.m97 lb in
Oil Passage Cover (Spacer Plate Support) to Case773M6x1.0x17.78-14 N.m71-124 lb in
Oil Passage Cover (Spacer Plate Support) to Case1151M6x1.0x19.08-14 N.m71-124 lb in
Park Lock Bracket to Case871M8x1.25x2027-34 N.m20-25 lb ft
Park/Neutral Position Switch Screw3 N.m27 lb in
Plate to Case (Shipping)N/A2M10x1.5x3527-34 N.m20-25 lb ft
Plate to Converter (Shipping)N/A1M10x1.5x2527-34 N.m20-25 lb ft
Plate to Converter (Shipping)N/A1M10x1.5x1527-34 N.m20-25 lb ft
Pressure Control Solenoid Bracket to Valve Body Bolt3641M6x1.0x17.78-14 N.m71-124 lb in
Pump Assembly to Case27M8x1.25x6026-32 N.m19-24 lb ft
Pump Cover to Pump Body2335M8x1.25x4020-27 N.m15-20 lb ft
Shift Cable Grommet Screw1.7 N.m15 lb in
Shift Control Cable Attachment20 N.m15 lb ft
Speed Sensor to Case351M6x1.0x1511-14 N.m98-124 lb in
TCC Solenoid Assembly to Case682M6x1.0x128-14 N.m71-124 lb in
Transmission Mount to Crossmember Nut55 N.m41 lb ft
Transmission Mount to Transmission Bolt50 N.m37 lb ft
Transmission Oil Cooler Pipe Fitting35-41 N.m26-30 lb ft
Transmission Oil Pan to Case Bolt9.5-13.8 N.m84-122 lb in
Transmission to Engine Bolt47 N.m35 lb ft
Valve Body to Case1203M6x1.0x54.48-14 N.m71-124 lb in
Valve Body to Case6212M6x1.0x47.58-14 N.m71-124 lb in
Valve Body to Case592M6x1.0x358-14 N.m71-124 lb in
* Reference Number refers to the callout number on the disassembled view.

Fastener Tightening Specifications

Transmission General Specifications

NameHydra-Matic 4L60-E
RPO CodesM30
Production LocationToledo, Ohio Ramos Arizpe, Mexico
Vehicle Platform (Engine/Transmission) UsageG/H
Transmission DriveLongitudinally-Mounted Rear Wheel Drive
1st Gear Ratio3.059:1
2nd Gear Ratio1.625:1
3rd Gear Ratio1.000:1
4th Gear Ratio0.696:1
Reverse2.294:1
Torque Converter Size (Diameter of Torque Converter Turbine)300 mm
Pressure TapsLine Pressure
Transmission Fluid TypeDEXRON® VI
Transmission Fluid Capacity (Approximate)300 mm Converter Dry: 11.50 l (12.1 qt)
Transmission Type: 4Four Forward Gears
Transmission Type: LLongitudinal Mount
Transmission Type: 60Product Series
Transmission Type: EElectronic Controls
Position QuadrantP, R, N,X, D, 2, 1 P, R, N,X, 3, 2, 1
Case MaterialDie Cast Aluminum
Transmission Weight Dry (Approximate)300 mm Converter 86.17 kg (190.5 lb)
Transmission Weight Wet (Approximate)300 mm Converter 98.4 kg (218.0 lb)
Maximum Trailer Towing Capacity5 448 kg (12,000 lb)
Maximum Gross Vehicle Weight (GVW)3 900 kg (8,600 lb)

Transmission General Specifications (4L60-E)

Adhesives, Fluids, Lubricants, and Sealers

ApplicationType of MaterialGM Part Number
United StatesCanada
Automatic Transmission FluidDEXRON®VI8886103719264717

Adhesives, Fluids, Lubricants, and Sealers

Fluid Capacity Specifications

ApplicationSpecification
MetricEnglish
Pan Removal4.7 liters5 quarts
Overhaul10.6 liters11 quarts
300 mm Torque Converter Approximate Fluid Capacity Dry Fill10.6 L11.2 qts

Fluid Capacity - Approximate

End Play Specifications

IdentificationWasher Thickness (mm)Washer Thickness (in)
671.87-1.970.074-0.078
682.04-2.140.080-0.084
692.21-2.310.087-0.091
702.38-2.480.094-0.098
712.55-2.650.100-0.104
722.72-2.820.107-0.111
732.89-2.990.113-0.117
743.06-3.160.120-0.124

Transmission End Play Washer Selection Chart

Low and Reverse Clutch Spacer Plate Selection

Measured DimensionSelective Plate
IdentificationThickness
28.065-27.545 mm (1.105-1.084 in)None1.684-1.829 mm (0.066-0.072 in)
28.586-28.066 mm (1.125-1.105 in)01.314-1.168 mm (0.052-0.046 in)
27.544-27.026 mm (1.084-1.064 in)12.198-2.344 mm (0.087-0.092 in)

Low and Reverse Clutch Spacer Plate Selection

Forward Clutch Backing Plate Selection

Plate ThicknessIdentification
6.92-7.07 mm (0.272-0.278 in)A
6.33-6.48 mm (0.249-0.255 in)B
5.74-5.89 mm (0.226-0.232 in)C
5.15-5.30 mm (0.203-0.208 in)D
4.56-4.71 mm (0.180-0.185 in)E
Backing Plate Travel: 0.766-1.756 mm (0.030-0.069 in)

Third and Fourth Clutch Backing Plate Selection

DimensionIdentification
5.88-5.68 mm (0.231-0.224 in)A
4.99-4.76 mm (0.196-0.187 in)B
4.10-3.90 mm (0.161-0.154 in)C
Use a backing plate which gives the correct travel. The travel should be 2.10-0.90 mm (0.083-0.035 in).

3rd and 4th Clutch Backing Plate Selection Table

Reverse Input Clutch Backing Plate Selection

Plate ThicknessIdentification
7.249-7.409 mm (0.285-0.292 in)2
6.678-6.519 mm (0.263-0.257 in)3
5.947-5.787 mm (0.234-0.228 in)4
Backing Plate Travel: 1.02-1.94 mm (0.040-0.076 in)

Reverse Input Clutch Backing Plate Selection Table

Fluid Pump Rotor and Slide Measurement

Thickness (mm)Thickness (in)
Oil Pump Rotor
17.948-17.9610.7066-0.7071
17.961-17.9740.7071-0.7076
17.974-17.9870.7076-0.7081
17.987-18.0000.7081-0.7086
18.000-18.0130.7086-0.7091
Oil Pump Slide
17.948-17.9610.7066-0.7071
17.961-17.9740.7071-0.7076
17.974-17.9870.7076-0.7081
17.987-18.0000.7081-0.7086
18.000-18.0130.7086-0.7091

Oil Pump Rotor and Slide Measurement

Torque Converter End Play Specifications

Torque Converter SizeSpecification
258 mm (10.16 in)0.1-0.5 mm (0.004-0.020 in)
280 mm (11.02 in)0.1-0.5 mm (0.004-0.020 in)
300 mm (11.81 in)0.1-0.5 mm (0.004-0.020 in)

Torque Converter End Play Check

Scheme 96

Scheme 96: 2-4 Band Servo Piston Pin Selection
Scheme 96: 2-4 Band Servo Piston Pin Selection
Pin LengthPin Identification
MmInch
65.82-66.122.59-2.601 Groove
67.23-67.532.65-2.662 Grooves
68.64-68.942.70-2.71No Groove

2-4 Servo Pin Selection

1-2 Accumulator Piston Spring Selection

One SpringTwo Springs
1CBD 1KBD 1KPD 1LPD 1SHD 1TSD1STD 1TTD

1-2 Accumulator Piston Spring Selection

Clutch & Band Application

RangeParkReverseNeutralODD21
Gear1st2nd3rd4th1st2nd3rd1st**2nd1st2nd***
1-2 Shift SolenoidON*ON*ON*ONOFFOFFONONOFFOFFONOFFONOFF
2-3 Shift SolenoidON*ON*ON*ONONOFFOFFONONOFFONONONON
2-4 BandAAAAA
Reverse Input ClutchA
Overrun ClutchAAAAA
Forward ClutchAAAAAAAAAAA
Forward Sprag Clutch AssemblyHHHHHHHHHH
3-4 ClutchAAA
Lo/Roller ClutchHHHH
Lo/Rev ClutchAAA
A = Applied H = Holding ON = The solenoid is energized. OFF = The solenoid is de-energized. *Shift Solenoid state is a function of vehicle speed and may change if the vehicle speed increases sufficiently in Park, Reverse or Neutral. However, this does not affect the operation of the transmission. **Manual Second-First gear is electronically prevented under normal operating conditions. ***Manual First-Second gear is only available above approximately 48-56 km/h (30-35 mph).

Range Reference Table

Shift Solenoid Valve State and Gear Ratio

Gear1-2 Shift Solenoid2-3 Shift SolenoidGear Ratio
1ONON3.059:1
2OFFON1.625:1
3OFFOFF1.000:1
4ONOFF0.696:1

Shift Solenoid Valve State and Gear Ratio 4L60-E/4L70-E

Shift Speed

% TPS4.3L (LU3)4.8L (LR4)5.3L (LM7)
Trans CalBCABAB
BodyGGMT600GGGG
Axle3.423.733.423.733.423.73
1-2 Upshift @ +/- 250 RPM Output Shaft Speed12486492431419431391
25613604607608607568
5011201118103810271038960
2-3 Upshift @ +/- 250 RPM Output Shaft Speed12866850764755764705
251141114099910061000940
50188018551666167716661568
3-4 Upshift @ +/- 250 RPM Output Shaft Speed12129212071078107010771000
25162615201509148815091391
50258424142547253725472370
1-2 Upshift @ Wide Open Throttle +/- 250 RPM, Output Shaft Speed152115201815181618151697
2-3 Upshift @ Wide Open Throttle +/- 250 RPM, Output Shaft Speed291526823166316231662955
3-1 Wide Open Throttle Downshift +/- 100 RPM, Output Shaft Speed133113411333130013321215
MIN TCC Apply @ 12% (RPM)158515651568157215681470

Shift Speed (4L60-E)

Transmission Internal Mode Switch Logic

Gear Selector PositionSignal ASignal BSignal CSignal P
Park (P)LOWHIHILOW
Reverse (R)LOWLOWHIHI
Neutral (N)HILOWHILOW
Drive 4 (D)HILOWLOWHI
Drive 3 (3)LOWLOWLOWLOW
Drive 2 (2)LOWHILOWHI
Drive 1 (1)HIHILOWLOW
HI = Ignition voltage LOW = 0 volts

Transmission Internal Mode Switch Logic

Line Pressure

Pressure Control Solenoid Current (Amp)Approximate Line Pressure (PSI)
2.9 L/3.7 L
0.00170-193
0.10169-192
0.20168-188
0.30156-184
0.40146-176
0.50135-166
0.60121-152
0.70103-136
0.8084-117
0.9063-96
1.0054-80
1.1054-62
4.2 L/4.3 L/4.8 L/5.3 L/6.0 L
0.00198-227
0.10197-226
0.20189-221
0.30181-216
0.40168-205
0.50154-193
0.60137-175
0.70114-156
0.8090-132
0.9064-105
1.0053-85
This test must be performed at 1200 RPM and between 100°F and 200°F.

Line Pressure (4L60-E)

Component Resistance

ComponentPass Thru PinsResistance at 20°C (68°F)Resistance at 100°C (212°F)Resistance to Ground (Case)
1-2 Shift Solenoid ValveA, E19-24 ohms24-31 ohmsGreater than 250 K ohms
2-3 Shift Solenoid ValveB, E19-24 ohms24-31 ohmsGreater than 250 K ohms
TCC Solenoid ValveT, E21-26 ohms26-33 ohmsGreater than 250 K ohms
TCC PWM Solenoid ValveU, E10-13 ohms13-15 ohmsGreater than 250 K ohms
Pressure Control Solenoid ValveC, D3-5 ohms4-7 ohmsGreater than 250 K ohms
Vehicle Speed SensorA, B VSS CONN1377-2220 ohms1800-3355 ohmsGreater than 10 M ohms

Component Resistance
