Interior Trim and Interior Paneling Chevrolet Equinox II

Exterior/interior Trim 25 illustrations ~255 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Cargo Tie Down Loop Fastener13 N.m9 lb ft
Center Pillar Upper Trim Panel Fastener2 N.m18 lb in
Coat Hook Fastener3.3 N.m29 lb in
Front Side Door Inside Handle Fastener2.5 N.m22 lb in
Front Side Door Pull Handle Fastener2.5 N.m22 lb in
Liftgate Lower Trim Finish Panel Fastener2 N.m18 lb in
Quarter Window Trim Finish Panel Fastener3 N.m27 lb in
Rear Side Door Inside Handle Fastener2.5 N.m22 lb in
Rear Side Door Pull Handle Fastener3 N.m27 lb in
Roof Rail Front Assist Handle Fastener6 N.m53 lb in
Roof Rail Rear Assist Handle Fastener6 N.m53 lb in
Sunshade Support Fastener3 N.m27 lb in
Sunshade Fastener3 N.m27 lb in

Fastener Tightening Specifications

Scheme 30

Scheme 30: Front Side Door Accessory Switch Mount Plate Replacement
Scheme 30: Front Side Door Accessory Switch Mount Plate Replacement
CalloutComponent Name
1Front Side Door Accessory Switch Mount Plate Procedure Disconnect the electrical connector from the switch assembly. Transfer parts as necessary.

Front Side Door Accessory Switch Mount Plate Replacement

Scheme 31

Scheme 31: Rear Side Door Accessory Switch Mount Plate Replacement
Scheme 31: Rear Side Door Accessory Switch Mount Plate Replacement
CalloutComponent Name
1Rear Side Door Accessory Switch Mount Plate Procedure Starting at the rear of the accessory switch mount plate, use a small flat bladed tool to release the accessory switch mount plate from the door trim. Disconnect the electrical connector. When replacing the accessory switch mount plate, transfer all necessary components.

Rear Side Door Accessory Switch Mount Plate Replacement

Scheme 32

Scheme 32: Front Side Door Trim Panel Replacement
Scheme 32: Front Side Door Trim Panel Replacement
CalloutComponent Name
1Front Side Door Inside Handle Bolt Finish Cap TIP: Pull handle back to remove cap. Use suitable tool to unsnap.
2Front Side Door Inside Handle Fastener CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
3Front Side Door Pull Handle Cover
4Front Side Door Pull Handle Fastener (Qty: 2) Tighten 2.5 N.m (22 lb in)
5Front Side Door Trim Panel Assembly Procedure Use a door trim tool, or equivalent, to aid in the removal of the door trim panel. Disconnect the inside handle release cable from the trim panel. Disconnect electrical connectors.
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Panel Replacement

Scheme 33

Scheme 33: Front Side Door Garnish Molding Replacement
Scheme 33: Front Side Door Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement .
1Front Side Door Garnish Molding Retainer Procedure Use a door trim panel removal tool or equivalent to aid in the removal of the retainers.
2Front Side Door Garnish Molding Procedure Pull outward starting at the front and moving slowly rearward to remove the molding.

Front Side Door Garnish Molding Replacement

Scheme 34

Scheme 34: Rear Side Door Trim Panel Replacement
Scheme 34: Rear Side Door Trim Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear door accessory switch mount plate. Refer to Rear Side Door Accessory Switch Mount Plate Replacement .
1Rear Side Door Inside Handle Bolt Cap Procedure Pull the handle back to remove the cap. Use a suitable tool to unsnap.
2Rear Side Door Inside Handle Fastener CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
3Rear Side Door Pull Handle Fastener (Qty: 2) Tighten 3 N.m (27 lb in)
4Rear Side Door Trim Panel Assembly Procedure Use a door trim panel removal tool or equivalent to aid in the removal of the retainer. Pull upwards on the door lock retainer cable to disengage. Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Rear Side Door Trim Panel Replacement

Scheme 35

Scheme 35: Rear Side Door Garnish Molding Replacement
Scheme 35: Rear Side Door Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear side door trim panel. Refer to Rear Side Door Trim Panel Replacement .
1Rear Side Door Garnish Molding Retainer Procedure Use a door trim panel removal tool or equivalent to aid in the removal of the retainers.
2Rear Side Door Garnish Molding Procedure Pull outward starting at the front and moving slowly rearward to remove the molding.

Rear Side Door Garnish Molding Replacement

Scheme 36

Scheme 36: Body Hinge Pillar Trim Panel Replacement
Scheme 36: Body Hinge Pillar Trim Panel Replacement
CalloutComponent Name
1Body Hinge Pillar Trim Panel Assembly Procedure Reposition the front floor panel carpet as needed.

Body Hinge Pillar Trim Panel Replacement

Scheme 37

Scheme 37: Front Side Door Sill Trim Plate Replacement
Scheme 37: Front Side Door Sill Trim Plate Replacement
CalloutComponent Name
1Front Side Door Sill Trim Plate Assembly
2Front Side Door Sill Trim Plate Assembly Clip (Qty: 3) Procedure Use a flat-bladed plastic trim tool in order to release the clips and remove the sill plate.

Front Side Door Sill Trim Plate Replacement

Scheme 38

Scheme 38: Rear Side Door Sill Trim Plate Replacement
Scheme 38: Rear Side Door Sill Trim Plate Replacement
CalloutComponent Name
1Rear Side Door Sill Trim Plate Assembly
2Rear Side Door Sill Trim Plate Assembly Clip (Qty: 2) Procedure Use a flat-bladed plastic trim tool in order to release the clips and remove the sill plate.

Rear Side Door Sill Trim Plate Replacement

Scheme 39

Scheme 39: Roof Rail Front Assist Handle Replacement
Scheme 39: Roof Rail Front Assist Handle Replacement
CalloutComponent Name
1Roof Rail Front Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to open the assist handle covers to access the screws. Tighten 6 N.m (53 lb in)
2Roof Rail Front Assist Handle
CAUTION
Refer to Fastener Caution .

Roof Rail Front Assist Handle Replacement

Scheme 40

Scheme 40: Roof Rail Rear Assist Handle Replacement
Scheme 40: Roof Rail Rear Assist Handle Replacement
CalloutComponent Name
1Roof Rail Rear Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to open the assist handle covers to access the screws. Tighten 6 N.m (53 lb in)
2Roof Rail Rear Assist Handle
CAUTION
Refer to Fastener Caution .

Roof Rail Rear Assist Handle Replacement

Scheme 41

Scheme 41: Coat Hook Replacement
Scheme 41: Coat Hook Replacement
CalloutComponent Name
1Coat Hook Fastener CAUTION: Refer to Fastener Caution . Tighten 3.3 N.m (29 lb in)
2Coat Hook Assembly
CAUTION
Refer to Fastener Caution .

Coat Hook Replacement

Scheme 42

Scheme 42: Inside Rearview Mirror Mount Plate Cover Replacement
Scheme 42: Inside Rearview Mirror Mount Plate Cover Replacement
CalloutComponent Name
1Inside Rearview Mirror Mount Plate Insert Procedure Adjust the mirror to the full downward position. Using a suitable plastic tool, insert the tool between the edge of the insert and the headliner, turn the tool until the insert releases.
2Inside Rearview Mirror Mount Plate Cover Procedure Grasp both sides of the inside rearview mirror mount plate cover. Pull cover downward, releasing the cover tabs from the windshield retainer.

Inside Rearview Mirror Mount Plate Cover Replacement

Scheme 43

Scheme 43: Sunshade Replacement
Scheme 43: Sunshade Replacement
CalloutComponent Name
Preliminary Procedure Lower the front of the headliner to access the sunshade electrical connector, if necessary. Refer to Headlining Trim Panel Replacement .
1Sunshade Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . TIP: The closeout snaps into place. Tighten 3 N.m (27 lb in)
2Sunshade Assembly Procedure Squeeze the tabs at the base of the sunshade assembly to remove from the headliner. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Sunshade Replacement

Scheme 44

Scheme 44: Sunshade Support Replacement
Scheme 44: Sunshade Support Replacement
CalloutComponent Name
1Sunshade Support Fastener CAUTION: Refer to Fastener Caution . TIP: Pull the cover downward to access the fastener. Tighten 3 N.m (27 lb in)
2Sunshade Support Disengage the sunshade from the support. Unclip the sunshade from the support and reposition.
CAUTION
Refer to Fastener Caution .

Sunshade Support Replacement

Scheme 45

Scheme 45: Windshield Side Garnish Molding Replacement
Scheme 45: Windshield Side Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedure Disable the SIR system. Refer to SIR Disabling and Enabling .
1Windshield Side Garnish Molding Assembly Procedure Tether clip at upper portion of garnish molding MUST be replaced every time windshield pillar molding is removed. Starting at the top, gently pull on the garnish molding to disengage the clips. Tabs must be installed prior to retainer clips. Tabs to be fully seated in instrument panel trim panel retainer and valance panel. Disconnect the electrical connector. When replacing the windshield side garnish molding, transfer all necessary components.

Windshield Side Garnish Molding Replacement

Scheme 46

Scheme 46: Center Pillar Upper Trim Panel Replacement
Scheme 46: Center Pillar Upper Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the seat belt from the seat anchor. Refer to Driver or Passenger Seat Retractor Side Belt Replacement . Remove the center pillar lower trim panel. Refer to Center Pillar Lower Trim Panel Replacement .
1Center Pillar Upper Trim Panel Bolt Cap
2Center Pillar Upper Trim Panel Fastener CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
3Center Pillar Upper Trim Panel Assembly Procedure Pull the trim panel toward the inside of the vehicle to disengage the retainers.
4Center Pillar Upper Trim Clip (Qty: 2)
CAUTION
Refer to Fastener Caution .

Center Pillar Upper Trim Panel Replacement

Scheme 47

Scheme 47: Center Pillar Lower Trim Panel Replacement
Scheme 47: Center Pillar Lower Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Disable the SIR. Refer to SIR Disabling and Enabling . Remove the rear side door opening floor carpet retainer. Refer to Rear Side Door Opening Floor Carpet Retainer Replacement . Remove the body hinge pillar trim panel. Refer to Body Hinge Pillar Trim Panel Replacement .
1Center Pillar Lower Trim Panel TIP: Start at the top of the lower garnish molding, pull at the clip locations to disengage the clips.
2Center Pillar Lower Trim Panel Retainer Clip (Qty: 6)

Center Pillar Lower Trim Panel Replacement

Scheme 48

Scheme 48: Quarter Window Trim Finish Panel Replacement
Scheme 48: Quarter Window Trim Finish Panel Replacement
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the body side trim panel. Refer to Body Side Trim Panel Replacement - Left Side , or Body Side Trim Panel Replacement - Right Side . Remove the rear seat lower anchor plate bolt on the side of the trim panel being replaced. Refer to Rear Seat Retractor Side Belt Replacement .
1Quarter Window Trim Finish Panel Bolt Cap (Qty: 2)
2Quarter Window Trim Finish Panel Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
3Quarter Window Trim Finish Panel Assembly Procedure Remove fasteners from body side trim panel. Refer to Body Side Trim Panel Replacement - Left Side , or Body Side Trim Panel Replacement - Right Side . Remove upper and lower together. Separate after removal, if necessary. Loosen the rear compartment opening weatherstrip. Route the seat belt through trim panel. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Quarter Window Trim Finish Panel Replacement

Scheme 49

Scheme 49: Body Side Trim Panel Replacement - Left Side
Scheme 49: Body Side Trim Panel Replacement - Left Side
CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear compartment front carpet opening cover by pulling upward to disengage the integral hook and loop fasteners. Remove the rear end trim finish panel. Refer to Rear End Trim Finish Panel Replacement . Remove the rear side door opening floor carpet retainer. Refer to Rear Side Door Opening Floor Carpet Retainer Replacement .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 13 N.m (9 lb ft)
3Cargo Tie Down Loop
4Bodyside Trim Panel Assembly Procedure Remove fasteners from quarter window trim finish panel. Refer to Quarter Window Trim Finish Panel Replacement . Remove upper and lower together. Separate after removal, if necessary. Pull outward to disengage the trim panel retainers. Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Body Side Trim Panel Replacement - Left Side

Scheme 50

Scheme 50: Body Side Trim Panel Replacement - Right Side
Scheme 50: Body Side Trim Panel Replacement - Right Side
CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear compartment front carpet opening cover by pulling upward to disengage the integral hook and loop fasteners. Remove the rear end trim finish panel. Refer to Rear End Trim Finish Panel Replacement . Remove the rear side door opening floor carpet retainer. Refer to Rear Side Door Opening Floor Carpet Retainer Replacement .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 13 N.m (9 lb ft)
3Cargo Tie Down Loop
4Bodyside Trim Panel Assembly Procedure Remove fasteners from quarter window trim finish panel. Refer to Quarter Window Trim Finish Panel Replacement . Remove upper and lower together. Separate after removal, if necessary. Pull outward to disengage the trim panel retainers. Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Body Side Trim Panel Replacement - Right Side

Scheme 51

Scheme 51: Rear End Trim Finish Panel Replacement
Scheme 51: Rear End Trim Finish Panel Replacement
CalloutComponent Name
1Rear End Trim Finish Panel Assembly Procedure Grasp and gently pull up on the rear end trim finish panel in order to release the integral retaining clips.

Rear End Trim Finish Panel Replacement

Scheme 52

Scheme 52: Liftgate Upper Trim Finish Panel Replacement
Scheme 52: Liftgate Upper Trim Finish Panel Replacement
CalloutComponent Name
1Liftgate Upper Trim Finish Panel Assembly TIP: The left and right outboard lower ends of the trim finish panel snap into the liftgate lower trim finish panel.

Liftgate Upper Trim Finish Panel Replacement

Scheme 53

Scheme 53: Liftgate Lower Trim Finish Panel Replacement
Scheme 53: Liftgate Lower Trim Finish Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the liftgate upper trim finish panel. Refer to Liftgate Upper Trim Finish Panel Replacement .
1Liftgate Trim Finish Panel Bolt Cap
2Liftgate Lower Trim Finish Panel Fastener CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
3Liftgate Lower Trim Finish Panel Assembly Procedure Use a trim panel removal tool to aid in the removal of the trim panel from the liftgate assembly. Start at the top clip on the right-hand side of liftgate lower trim finish panel. Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Liftgate Lower Trim Finish Panel Replacement

Scheme 54

Scheme 54: Quarter Outer Panel Pressure Relief Valve Replacement
Scheme 54: Quarter Outer Panel Pressure Relief Valve Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear bumper fascia. Refer to Rear Bumper Fascia Replacement . Reposition any wiring to gain access to pressure relief valve.
1Pressure Relief Valve

Quarter Outer Panel Pressure Relief Valve Replacement
