Object Detection System - Park Assist System Chevrolet Equinox II

Scheme 1

Scheme 2

Scheme 3

Diagnostic Code Index

DIAGNOSTIC CODE INDEX

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

Circuit/System Description

The object sensors are 3-wire sensors that are used to determine the distance between the vehicle and an object of interest. The parking assist control module supplies 8 V to the object sensors via the 8 V reference circuit and provides ground via the low reference circuit. The parking assist control module triggers the sensors in a sequential loop. After each sensor transmits, the parking assist control module uses the sensor echo received through the signal circuit to calculate the distance and position of an object.

Conditions for Running the DTC

1. Ignition ON
2. Transmission in REVERSE

Conditions for Setting the DTC

B0958 01, B0959 01, B0960 01, or B0961 01

The parking assist control module has detected the voltage at the sensor circuit is greater than 11.5 V or the object sensor is not grounded.

B0958 06, B0959 06, B0960 06, or B0961 06

The parking assist control module has detected the voltage at the sensor circuit less than 0.5 V.

B0958 08, B0959 08, B0960 08, or B0961 08

The parking assist control module has received an invalid signal.

B0958 21, B0959 21, B0960 21, or B0961 21

The object sensor determines no change in the position of an object while the vehicle is in motion.

B0958 3A, B0959 3A, B0960 3A, or B0961 3A

The parking assist control module determines the wrong sensor type is installed.

Action Taken When the DTC Sets

1. The parking assist is disabled.
2. The driver information center displays SERVICE PARK ASSIST.

Conditions for Clearing the DTC

The condition for setting the DTC is no longer present.

Reference Information

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

1. Verify that DTC B1405 is not present. If DTC is present, refer to «DTC B1405»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) .
2. Verify that DTC B0958 01, B0959 01, B0960 01 or B0961 01 is not present. If DTC is present, check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, refer to Circuit/System Testing below.
3. Verify that DTC B0958 21, B0959 21, B0960 21 or B0961 21 is not present. If DTC is present, check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, replace the sensor.
4. Verify that DTC B0958 3A, B0959 3A, B0960 3A or B0961 3A is not present. If DTC is present, replace the appropriate sensor with a sensor of correct sensor type.
5. Ignition ON, transmission in REVERSE, verify the scan tool Parking Assist System Status parameter displays Enabled.

Circuit/System Testing

1. Doors closed, ignition OFF for 30 seconds, disconnect the harness connector at the appropriate B78 rear object sensor.
2. Test for less than 30 ohms between the low reference circuit terminal 2 and ground. If greater than the specified value, test the low reference circuit for an open/high resistance. If the circuit tests normal, replace the K41R rear parking assist control module.
3. Ignition ON, test for 6.3-10.4 V between the 8 V reference circuit terminal 1 and ground. If less than the specified range, test the 8 V reference circuit for an open/high resistance. If the circuit tests normal, replace the K41R rear parking assist control module. If greater than the specified value, test the 8 V reference circuit for a short to voltage. If circuit tests normal, replace the K41R rear parking assist control module.
4. Ignition OFF, remove the malfunctioning object sensor and swap locations with another properly functioning rear object sensor. Connect the harness connector at both sensors.
5. Ignition ON, verify the DTC is set for the new location in which the malfunctioning sensor is installed. If the DTC does not set for the new location, test the signal circuit terminal 3 at the original location where DTC set for a short to voltage, short to ground, or an open/high resistance. If the circuit tests normal, replace the K41R rear parking assist control module.
6. If the DTC sets for the new location in which the malfunctioning sensor is installed, replace the appropriate B78 rear object sensor.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Parking Assist Alarm Sensor Replacement»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system)
2. «Control Module References»(/chevrolet/equinox/ii-2009-2015/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for parking assist control module replacement, programming and setup

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The lane departure warning is enabled and disabled through a switch located in the left steering wheel controls switch. When enabled, the front view camera module will illuminate the indicator located in the switch.

Ignition ON.

The front view camera module has detected a short to battery or open/high resistance in the control circuit.

1. Lane departure warning is disabled.
2. SERVICE LANE DEPARTURE SYSTEM is displayed on the driver information center.

The condition for setting the DTC is no longer present.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON.
2. Verify that DTC B356A is not set. If the DTC is set Refer to «DTC B356A»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) . If the DTC is not set
3. All OK.

1. Ignition OFF and all vehicle systems OFF, disconnect the harness connector at the K109 Front View Camera Module and at the S70L Steering Wheel Controls Switch - Left. It may take up to 2 minutes for all vehicle systems to power down.
2. Test for infinite resistance between the S70L Steering Wheel Controls Switch - Left control circuit terminal 5 and ground. If less than infinite resistance Repair the short to ground on the circuit. If infinite resistance
3. Ignition ON.
4. Test for less than 1 V between the S70L Steering Wheel Controls Switch - Left control circuit terminal 5 and ground. If greater than 1 V Repair the short to voltage on the circuit. If less than 1 V
5. Ignition OFF.
6. Test for less than 2 ohms in the S70L Steering Wheel Controls Switch - Left control circuit terminal 5 end to end. If 2 ohms or greater Repair the open/high resistance in the circuit. If less than 2 ohms
7. Test for infinite resistance between the S70L Steering Wheel Controls Switch - Left control circuit terminal 4 and ground. If less than infinite resistance Repair the short to ground on the circuit. If infinite resistance
8. Ignition ON.
9. Test for less than 1 V between the S70L Steering Wheel Controls Switch - Left control circuit terminal 4 and ground. If greater than 1 V Repair the short to voltage on the circuit. If less than 1 V
10. Ignition OFF.
11. Test for less than 2 ohms in the S70L Steering Wheel Controls Switch - Left control circuit terminal 4 end to end. If 2 ohms or greater Repair the open/high resistance in the circuit. If less than 2 ohms
12. Replace the S70L Steering Wheel Controls Switch - Left, ignition ON.
13. Verify the DTC does not set while operating the vehicle under Conditions for Running the DTC. If the DTC sets Replace the K109 Front View Camera Module. If the DTC does not set
14. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for front view camera module replacement, programming and setup.

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The front view camera module permanently monitors the serial data bus for error messages. When a malfunction is detected by the front view camera module, the system will be disabled and an error message will be stored in the front view camera module disable history buffer which is used to store information about the front camera features that are disabled.

1. Ignition ON
2. Front view camera enabled

The front view camera module detects a malfunction.

1. The front view camera module is disabled.
2. The front view camera module disable history buffer stores information why the system was disabled.

The condition for setting the DTC is no longer present.

Diagnostic Aids

The front view camera module disable history buffers are used to store information about the front view camera module features that are disabled. The Buffers will only update if the disable condition changes.

Example: If the data received from the steering wheel angle sensor is Invalid across many ignition cycles then it will only appear in 1 history buffer and not all history buffers. If this condition is the current reason why the front view camera module is disabled then it will be set in front view camera module disable history buffer 1. If a new reason occurs, such as vehicle speed validity is invalid, then the invalid steering wheel angle sensor fault will shift into disable history buffer 2 and vehicle speed validity invalid will be in disable history buffer 1. Since there are only 4 disable history buffers, the invalid steering wheel angle sensor will age out if 4 other disable reasons occur since the last invalid steering wheel angle sensor event occurred. Front view camera module disable history buffer 1 contains the current reason that one of the front view camera module features is disabled.

The front view camera module disable history buffers can display the following values

1. Lane Departure Warning Indicator Malfunction
2. Lane Departure Warning Switch Malfunction
3. Camera Obstructed
4. Accelerator Pedal Position Out of Range
5. Driven Wheel Speed Signal Invalid
6. Non-Driven Wheel Speed Signal Invalid
7. Brake Pedal Moderate Travel Signal Invalid
8. Brake Pedal Initial Travel Position Achieved
9. Lost Communication with Steering Wheel Angle Sensor Module
10. Invalid Data Received From Steering Wheel Angle Sensor Module
11. Forward Collision Alert Switch Malfunction
12. Clutch Pedal Position (CPP) Sensor Performance
13. Clutch Pedal Position (CPP) Sensor Performance
14. Transmission Gear Engaged
15. Acceleration Sensor Longitudinal Signal
16. Invalid Data Received From Yaw Rate Sensor Module
17. Power Mode Controlled by Backup Device
18. System Power Mode
19. Overvoltage
20. Undervoltage
21. Undefined

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Verify no DTC is set. If a DTC is present, diagnose this first. Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-trouble-code-dtc-list) .
2. Verify the scan tool Vehicle Direction Camera System parameter is NORMAL. If not the specified value, refer to «Front View Camera Module Malfunction (UFL)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) , «Front View Camera Module Malfunction (UEU)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) .
3. Verify the scan tool Vehicle Direction Camera Calibration Status parameter is CALIBRATED. If not the specified value, calibrate the K109 Frontview Camera Module. Refer to «Front View Camera Module Calibration»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system__front-view-camera-module-calibration) .

Note. Perform the Circuit/System Verification before proceeding with the Circuit/System Testing.

1. Verify the scan tool Front View Camera Module Disable History displays no current malfunction. Refer to Diagnostic Aids above. If a current malfunction is displayed, diagnose the system that sets the malfunction.
2. If no malfunction is displayed in the Front View Camera Module Disable History, refer to «Front View Camera Module Malfunction (UFL)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) , «Front View Camera Module Malfunction (UEU)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) .

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for front view camera module programming and setup

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

When the ignition is turned ON, the parking assist control module receives the vehicle identification number (VIN) from the body control module. The parking assist control module will compare the VIN received to the VIN stored in memory.

Ignition voltage is between 9-16 V.

The VIN stored in the parking assist control module does not match the received VIN.

1. The parking assist is disabled.
2. The driver information center displays SERVICE PARK ASSIST.

The VIN stored in the parking assist control module matches the VIN stored in the body control module.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, program the K41 Parking Assist Control Module and verify the DTC does not reset.

1. If the DTC is reset, replace the K41 Parking Assist Control Module

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for parking assist control module replacement, setup and programming

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The parking assist indicator is located in the interior rear of the vehicle. The indicator contains three LEDs: two amber and one red. The parking assist control module controls these three LEDs as a visual indicator of how close the vehicle bumper is to an object. The parking assist control module supplies voltage to each of the LEDs and commands each LED on by supplying an individual ground.

1. Ignition ON
2. Transmission in REVERSE

B1395 02

The parking assist control module has detected a short to ground.

B1395 03

The parking assist control module detects the sensor reference voltage out of range. The reference voltage is less than 9V.

B1395 07

The parking assist control module detects the sensor reference voltage out of range. The reference voltage is greater than 13V.

1. The parking assist is disabled.
2. The driver information center displays SERVICE PARK ASSIST.

The condition for setting the DTC is no longer present.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References

Ignition ON, perform the scan tool LED Test. Each of the three LEDs should illuminate during the test cycle.

1. Ignition OFF, disconnect the harness connector at the P24 Park Assist Display.
2. Ignition ON, test for 9-13V between the B+ circuit terminal A and ground. If less than the specified range, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the K41 Parking Assist Control Module. If greater than the specified range, test the B+ circuit for a short to voltage. If the circuit tests normal, replace the K41 Parking Assist Control Module.
3. If all circuits test normal, replace the P24 Park Assist Display.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Information Center Telltale Assembly Replacement»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system)
2. «Control Module References»(/chevrolet/equinox/ii-2009-2015/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for parking assist control module replacement, setup and programming

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The object sensors are 3-wire sensors that are used to determine the distance between the vehicle and an object of interest. The parking assist control module supplies 8 V to the object sensors via the 8 V reference circuit and provides ground via the low reference circuit. The parking assist control module triggers the sensors in a sequential loop. After each sensor transmits, the parking assist control module uses the sensor echo received through the signal circuit to calculate the distance and position of an object.

1. Ignition ON
2. Transmission in REVERSE

B1405 02

The parking assist control module has detected the 8 V reference circuit is shorted to ground.

B1405 03

The parking assist control module has detected the 8 V reference circuit is less than 6.3 V.

B1405 07

The parking assist control module has detected the 8 V reference circuit is greater than 10.4 V.

1. The parking assist is disabled.
2. The driver information center displays SERVICE PARK ASSIST.

The condition for setting the DTC is no longer present.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, transmission in REVERSE, observe the scan tool Sensor Feed Voltage Output parameter. The reading should be between 6.3-10.4 V.

1. Ignition OFF, disconnect the harness connector at each of the object sensors.
2. Ignition ON, transmission in REVERSE, test for 6.3-10.4 V between the 8 V reference circuit terminal 1 at the rear object sensor harness connector and ground. If less than the specified range, test the 8 V reference circuit for a short to ground. If the circuit tests normal, replace the rear object alarm module. If greater than the specified range, test the 8 V reference circuit for a short to voltage. If the circuit tests normal, replace the rear object alarm module.
3. Install each object alarm sensor harness connector one at a time, checking DTCs after each sensor is connected. Verify DTC B1405 is not set as current. If the DTC is set, replace the object alarm sensor that was connected immediately before the DTC set.
4. If all circuits test normal, replace the rear object alarm module.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Parking Assist Alarm Sensor Replacement»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system)
2. «Control Module References»(/chevrolet/equinox/ii-2009-2015/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for rear object alarm module replacement, setup and programming

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The lane departure warning is enabled and disabled through the vehicle direction warning switch located in the left steering wheel controls switch. When enabled, the front view camera module will illuminate the indicator located in the switch.

Ignition ON

The front view camera module has detected a short to ground for more than 10 s.

1. Lane departure warning is disabled.
2. Service Front Camera is displayed on the driver information center.

The condition for setting the DTC is no longer present.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool Vehicle Direction Warning Switch Status parameter while pressing and releasing the vehicle direction warning switch. The parameter should change between ON and OFF.

1. Ignition OFF, remove the ignition key, open the driver door, disconnect the scan tool, all vehicle systems OFF, this may take up to 2 min.
2. Disconnect the harness connector at the S70L Steering Wheel Controls Switch - Left.
3. Test for less than 5 ohms between the S70L Steering Wheel Controls Switch - Left ground circuit terminal 7 and ground. If greater than the specified value, test the ground circuit for an open/high resistance.
4. Ignition ON, verify the scan tool Vehicle Direction Warning Switch Status parameter is OPEN. If not the specified value, test the signal circuit terminal 2 for a short to ground. If the circuit tests normal, replace the K109 Frontview Camera Module.
5. Install a 3 A fused jumper wire between the signal circuit terminal 2 and ground circuit terminal 7. Verify within 10 s the scan tool Vehicle Direction Warning Switch Status parameter is CLOSED. If not the specified value, test the signal circuit terminal for a short to battery or an open/high resistance. If the circuit tests normal, replace the K109 Frontview Camera Module.
6. If all circuits test normal, replace the S70L Steering Wheel Controls Switch - Left.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Cruise Control Switch Replacement (NK5)»(/chevrolet/equinox/ii-2009-2015/remont/cruise-control-systems/#cruise-control-system) , «Cruise Control Switch Replacement (NP5)»(/chevrolet/equinox/ii-2009-2015/remont/cruise-control-systems/#cruise-control-system)
2. «Control Module References»(/chevrolet/equinox/ii-2009-2015/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for front view camera replacement, programming and setup.

Symptoms - Object Detection

Note. The following steps must be completed before using the symptom tables

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Object Detection Description and Operation (UD7)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system__object-detection-description-and-operation-ud7) , «Object Detection Description and Operation (Front View Camera with UEU)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system__object-detection-description-and-operation-front) , «Object Detection Description and Operation (Front View Camera with UFL)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system__object-detection-description-and-operation-front) , «Object Detection Description and Operation (UVC)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) .

Visual/Physical Inspection

1. Inspect for aftermarket devices which may affect the operation of the system. Refer to «Checking Aftermarket Accessories»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories) .
2. Inspect the easily accessible or visible system components for obvious damage or conditions which may cause the symptom.
3. Make sure the parking assist sensors located on the vehicle front and rear bumper are clear. Remove any snow, mud or ice that is blocking the sensors.
4. Make sure the rear vision camera is clear. Remove any snow, mud or ice that is blocking the rear vision camera.
5. Make sure the front view camera is clear. Remove any dust from the lens and the windscreen that is blocking the front view camera.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

1. «Parking Assist System Malfunction»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system)
2. «Rear Vision Camera System Malfunction»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system)
3. «Front View Camera Module Malfunction (UFL)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) , «Front View Camera Module Malfunction (UEU)»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system)

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The lane departure warning system is controlled by the front view camera module mounted on the windshield. The lane departure warning is enabled and disabled through a switch located in the steering wheel. When enabled, the front view camera module will illuminate the amber indicator located in the switch.

When the system is operating and can detect the lane markings, the front view camera module will request via serial data communications that the instrument cluster illuminates the green lane departure ready-to-assist indicator. If the front view camera module detects that the vehicle unintentionally crosses a lane marking without the turn signal being used, the module will request the vehicle direction display to flash the amber lane departure warning indicator. An audible warning will also sound three times when the amber lane departure warning indicator in the vehicle direction display is flashing.

Certain factors will affect the operation of the lane departure warning system. When the system is operating properly, the green lane departure warning indicator will illuminate on the instrument cluster. This indicates that all of the required operating conditions to permit lane departure warning have been met. The green lane departure warning indicator will not appear when the system is having difficulty seeing the lines on the road or if the view of the front view camera is blocked with mud, dirt, snow, ice, or slush, if the windshield is damaged, or when weather limits visibility, such as while driving in fog, rain, or snow conditions. This is normal operation, the vehicle does not need service. Additionally, lane departure warnings may occasionally occur in a properly operating vehicle due to tar marks, shadows, cracks in the road, or other road imperfections. This is normal system operation and the vehicle does not require service. The driver information center may also display Lane Departure System Unavailable due to the temporary conditions listed above.

Additionally, the Front View Camera Disable History can give useful hints about what affected the operation of the lane departure warning system. For the Front View Camera Disable History, please refer to DTC B1011 .

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Note. Refer to Diagnostic Aids before performing Circuit/System Verification below.

1. Observe the scan tool Lane Departure Warning Switch Status parameter while pressing the lane departure warning switch. The parameter should change between OPEN and CLOSED. If the parameter does not change between the specified values, refer to Lane Departure Warning Switch Malfunction in Circuit/System Testing below.
2. Observe the switch indicator while cycling the lane departure warning switch. The indicator should turn ON and OFF when cycling between the commanded states. If the indicator does not turn ON and OFF, refer to Lane Departure Warning Switch Indicator Malfunction in Circuit/System Testing below.
3. Inspect the area of the K109 Front View Camera Module for contamination. If it needs to be cleaned, clean the windshield.

Lane Departure Warning Switch Malfunction

1. Ignition OFF, remove the ignition key, open the driver door and disconnect the scan tool, all vehicle systems OFF, this may take up to 2 min.
2. Disconnect the harness connector at the S70L Steering Wheel Controls Switch - Left.
3. Test for less than 5 ohms between the S70L Steering Wheel Controls Switch - Left ground circuit terminal 7 and ground. If greater than the specified value, test the ground circuit for an open/high resistance.
4. Ignition ON, verify the scan tool Lane Departure Warning Switch Status parameter is OPEN. If not the specified value, test the signal circuit terminal 2 for a short to ground. If the circuit tests normal, replace the K109 Front View Camera Module.
5. Install a 3 A fused jumper wire between the signal circuit terminal 2 and ground circuit terminal 7. Verify within 10 s the scan tool Lane Departure Warning Switch Status parameter is CLOSED. If not the specified value, test the signal circuit terminal for a short to battery or an open/high resistance. If the circuit tests normal, replace the K109 Front View Camera Module.
6. If all circuits test normal, replace the S70L Steering Wheel Controls Switch - Left.

Lane Departure Warning Switch Indicator Malfunction

1. Ignition OFF, remove the ignition key, open the driver door and disconnect the scan tool, all vehicle systems OFF, this may take up to 2 min.
2. Disconnect the harness connector at the S70L Steering Wheel Controls Switch - Left.
3. Test for 6.2-10.9 V DC between the S70L Steering Wheel Controls Switch - Left BCM pwm reference circuit terminal 4 and ground. If not the specified value, test the circuit for a short to ground or short to voltage.
4. Disconnect the harness connector at the K109 Front View Camera Module, reconnect the harness connector at the S70L Steering Wheel Controls Switch - Left.
5. Ignition ON, observe the lane departure warning switch indicator. The indicator should be OFF. If the indicator is always ON, test the control circuit terminal 5 for a short to ground. If the circuit tests normal, replace the S70L Steering Wheel Controls Switch - Left.
6. Ignition OFF, install a 3 A fused jumper wire between the K109 Front View Camera Module harness connector indicator control circuit terminal 4 and ground. The indicator should be ON. If the indicator is always OFF, test the control circuit terminal 4 for an open/high resistance. If the circuit tests normal, replace the S70L Steering Wheel Controls Switch - Left.
7. If all circuits test normal, replace the K109 Front View Camera Module.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Cruise Control Switch Replacement (NK5)»(/chevrolet/equinox/ii-2009-2015/remont/cruise-control-systems/#cruise-control-system) , «Cruise Control Switch Replacement (NP5)»(/chevrolet/equinox/ii-2009-2015/remont/cruise-control-systems/#cruise-control-system)
2. «Control Module References»(/chevrolet/equinox/ii-2009-2015/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for front view camera replacement, programming and setup.

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The forward collision alert system is controlled by the front view camera module mounted on the windshield. The forward collision alert system is always active and operates at speeds above 40 km/h (25 mph). When the system detects a vehicle in the path ahead, the green vehicle ahead alert indicator in the vehicle direction display is illuminated. When approaching another vehicle too rapidly, the collision alert symbol will flash in the vehicle direction display and the radio will simultaneously give an audible alert sound. The red collision alert display will stay continuously illuminated if the vehicle ahead remains much too close. These actions are requested by the front view camera module via serial data. The forward collision alert switch is part of the left steering wheel controls and is used to adjust the timing sensitivity of the front collision alert system.

Certain factors will affect the operation of the forward collision alert system. Forward collision alert does not warn the driver of any objects that are not detected as a vehicle, like e.g. pedestrians, animals, signs, guard rails, bridges, construction barrels or other stationary or slow moving objects. In some cases the camera may detect a vehicle that is not in the path ahead, or the system may occasionally provide unrealistic alerts. This could respond to a turning vehicle ahead, guard rails, traffic signs, or other stationary objects. This is normal operation, the vehicle does not need service. When the system is operating properly, the green vehicle ahead alert indicator will illuminate on the vehicle direction display when the system detects a vehicle in the path ahead. This indicates that all of the required operating conditions are met. The green vehicle ahead alert indicator will not appear when the system is having difficulty seeing other vehicles on the road or if the view of the front view camera is blocked with mud, dirt, snow, ice, or slush, if the windshield is damaged, or when weather limits visibility, such as while driving in fog, rain, or snow conditions. This is normal operation, the vehicle does not need service.

Additionally, the Front View Camera Disable History can give useful hints about what affected the operation of the lane departure warning system. For the Front View Camera Disable History please refer to DTC B1011 .

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Note. Refer to Diagnostic Aids before performing Circuit/System Verification below.

1. Observe the scan tool Forward Collision Alert Function Status parameter. The parameter should show Off, Disabled, Not Ready To Assist or Ready To Assist. If the parameter shows Malfunction, refer to Forward Collision Alert System Malfunction in Circuit/System Testing below.
2. Drive the vehicle behind another vehicle with sufficient safety distance. The green vehicle ahead alert indicator in vehicle direction display should turn ON when the vehicle on the path ahead is detected. With no vehicle driving in front of the host vehicle, increasing the safety distance or changing the driving path, the green vehicle ahead alert indicator in the instrument panel should turn OFF. If the indicator does not turn ON and OFF, refer to Forward Collision Alert System Malfunction in Circuit/System Testing below.
3. Inspect the area of the K109 Frontview Camera Module for contamination. If it needs to be cleaned, clean the windshield.

Note. You must perform the Circuit/System Verification before proceeding with Circuit/System Testing.

Forward Collision Alert System Malfunction

1. Verify no DTCs are set. If any DTCs are set, diagnose those first. Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-trouble-code-dtc-list) .
2. Ignition OFF, remove the ignition key, open the driver door and disconnect the scan tool, all vehicle systems OFF, this may take up to 2 min.
3. Disconnect the harness connector at the K109 Frontview Camera Module.
4. Connect a test lamp between the K109 Frontview Camera Module B+ circuit terminal 3 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the K109 Frontview Camera Module.
5. Test for less than 5 ohms between the ground circuit terminal 1 and ground. If greater than the specified value, test the ground circuit for an open/high resistance. If the circuit tests normal, replace the K109 Frontview Camera Module.
6. Test for infinite resistance between the forward collision alert switch signal circuit terminal 10 and ground with the forward collision alert switch not pressed. If less than infinite resistance, test the switch signal circuit for a short to ground. If the circuit tests normal, replace the S70L Steering Wheel Controls Switch - Left.
7. Test for 1.2-1.4 kohms between the forward collision alert switch signal circuit terminal 10 and ground with the forward collision alert switch pressed. If greater than the specified value, test the switch signal circuit for an open high resistance. If the circuit tests normal, replace the S70L Steering Wheel Controls Switch - Left.
8. If all circuits test normal, replace the K109 Frontview Camera Module.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Cruise Control Switch Replacement (NK5)»(/chevrolet/equinox/ii-2009-2015/remont/cruise-control-systems/#cruise-control-system) , «Cruise Control Switch Replacement (NP5)»(/chevrolet/equinox/ii-2009-2015/remont/cruise-control-systems/#cruise-control-system)
2. «Control Module References»(/chevrolet/equinox/ii-2009-2015/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for front view camera replacement, programming and setup

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The ultrasonic parking assist system is designed to identify and notify the driver of an object in the vehicle's path when reversing at speeds of less than 8 km/h (5 mph). The distance and location of the object is determined by four object sensors located in the rear bumper. The parking assist system will notify the driver using an audible signal through the radio.

When the "Park Assist Off" or "Service Park Assist" message is displayed in the DIC the disable reason is stored in the Park Assist Disable History.

The scan tool Park Assist Disable History parameters are a list of the previous reasons the parking assist system was disabled. These parameters may help in the diagnosis of an intermittent concern or a customer concern which is the result of normal system operation. The following is a brief description of potential causes which may aid in diagnosis

1. 3Disable - The parking assist system has been disabled through the audio system personalization menu.
2. Hitch/Object Attached - The parking assist control module is detecting an object that is attached to the vehicle. Common items such as a hitch receiver, trailer, object hanging out of tailgate, lowered tailgate, or a bicycle rack may cause this concern. If the customer does have a ball mount attached to the factory hitch, then refer to Owners Manual and "Vehicle Personalization" to enable "Towbar" option. Additionally, damage to the rear of the vehicle or a misaligned sensor may cause this concern. If the vehicle is damaged in a manner that causes the sensor to detect the bumper itself, the parking assist control module will interpret this as an attached object and disable the system. Carefully inspect the bumper, bumper mounting surface, and sensor retainers before continuing with normal diagnosis. After the detected cause has been addressed the vehicle must be driven at speed greater than 40 km/h (25 MPH).
3. Reverse Overspeed - The vehicle is travelling too fast in reverse at speeds of greater than 8 km/h (5 mph).
4. Inhibit - The parking assist control module has lost or received invalid GMLAN signal(s).
5. Sensor Disturbance - An outside interference is causing sensor movement. Such interference may be caused a heavy pounding, like that of a nearby jackhammer, or large changes in pressure, such as a large truck's air brakes.
6. Sensor Ring Time - If the sensor fails its own diagnostic initialization the parking assist control module will set this error. After the detected cause has been addressed the vehicle must be driven at speed greater than 40 km/h (25 mph). The following is a list of reasons this cause may have set: One or more of the sensors may be blocked by snow, mud, ice, or other debris. This might happen after going through a car wash in cold weather. Silicone insulator surrounding sensor maybe missing, cut, or twisted. Improperly installed sensor, sensor maybe be crooked due to a tight wire harness. One or more of the sensors may be scratched or the paint maybe chipped. Excessive paint thickness on a sensor may cause an excessive sensor ring time. When replacing or refinishing a sensor, do not apply an excessive amount of paint or clear coat.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Manual Transmission

1. Engine running, transmission in REVERSE.
2. Verify the scan tool Calculated Transmission Range parameter is Reverse. If parameter is not Reverse Refer to «Backup Lamps Malfunction»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) . If parameter is Reverse
3. Verify the scan tool Park Assist System Status parameter displays Enable.
4. If status is not Enable Refer to Diagnostic Aids and the scan tool Park Assist Disable History parameters to determine the cause of the inhibit. If status is Enable
5. Replace the K41 Parking Assist Control Module.

Automatic Transmission

1. Engine running, transmission in REVERSE.
2. Verify the scan tool Park Assist System Status parameter displays Enable.
3. If status is not Enable Refer to Diagnostic Aids above and the scan tool Park Assist Disable History parameters to determine the cause of the inhibit. If status is Enable
4. Replace the K41 Parking Assist Control Module.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for module replacement, programming and setup

1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/chevrolet/equinox/ii-2009-2015/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

When the transmission is placed into REVERSE, a 12 V signal is sent to the rearview camera indicating that camera operation is requested. Ignition voltage and ground are supplied to the rearview camera. The rearview camera sends video information to the radio through a video signal + and a video signal - circuit. A grounded shielding also wraps the video signal circuits to reduce electronic interference which may degrade the video signal and cause a distorted or otherwise degraded image.

A poor video image can be caused by ice, snow, and mud buildup on the lens of the rearview camera. Also, extreme lighting conditions can affect performance, such as operating in the dark or with bright sunlight shining on the camera. Extreme high or low temperatures can also affect the image quality. An open in the shield of the video signal circuit can also cause a distorted screen.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (UD7) , Object Detection Description and Operation (Front View Camera with UEU) , Object Detection Description and Operation (Front View Camera with UFL) , Object Detection Description and Operation (UVC)

Electrical Information Reference

1. «Circuit Testing»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
4. «Wiring Repairs»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Inspect the rearview camera and verify there are no debris on the lens and that the bezel or bezel seal is not damaged. If debris are found on the lens, clean the lens. If the lens, bezel, or bezel seal are damaged, replace as necessary.
2. Ignition ON, vehicle in PARK, verify the backup lamps are off. If the backup lamps are illuminated, refer to «Backup Lamps Malfunction»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
3. Transmission in REVERSE, verify the backup lamps are on. If the backup lamps are not illuminated, refer to «Backup Lamps Malfunction»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
4. Engine running, transmission in REVERSE, verify a clear rear vision image is displayed on the radio. If a clear image is not displayed, refer to Circuit/System Testing below.

Note. Circuit/System Verification must be performed before Circuit/System Testing.

1. Ignition OFF, disconnect the harness connector at the rearview camera.
2. Test for less than 5 ohms between the ground circuit terminal 5 and ground. If greater than the specified value, test the ground circuit for an open/high resistance.
3. Ignition ON, verify a test lamp illuminates between the ignition circuit terminal 6 and ground. If the test lamp does not illuminate, test the ignition circuit for a short to ground or an open/high resistance.
4. Engine running, park brake applied, transmission in REVERSE, test for greater than 11 V between the control circuit terminal 3 and ground. If less than the specified value, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the K9 Body Control Module.
5. Ignition OFF, disconnect the X4 harness connector at the A11 Radio.
6. Ignition ON, test for less than 0.3 V between the following signal circuit terminals at the rearview camera harness connector and ground: Signal (+) circuit terminal 1 Signal (-) circuit terminal 4 If greater than the specified value, test the signal circuit for a short to voltage.
7. Test for infinite resistance between the following circuit terminals at the rearview camera harness connector and ground: Signal (+) circuit terminal 1 Signal (-) circuit terminal 4 If not the specified value, test the circuit for a short to ground.
8. Test for less than 5 ohms between the signal (+) circuit terminal 1 at the rearview camera harness connector and the signal (+) circuit terminal 5 X4 at the A11 Radio harness connector. If greater than the specified value, test the signal circuit for an open/high resistance.
9. Test for less than 5 ohms between the signal (-) circuit terminal 4 at the rearview camera harness connector and the signal (-) circuit terminal 15 X4 at the A11 Radio harness connector. If greater than the specified value, test the signal circuit for an open/high resistance.
10. If all circuits test normal, replace the rearview camera.
11. Engine running, transmission in REVERSE, verify a clear rear vision image is displayed on the radio. If a clear rear vision image is not displayed, replace the A11 Radio.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rearview Camera Image Display Module Replacement»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system)
2. «Control Module References»(/chevrolet/equinox/ii-2009-2015/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for body control module or radio replacement, setup and programming

Scheme 4

Rear Object Alarm Control Module Replacement

Scheme 5

Information Center Telltale Assembly Replacement

Removal Procedure

1. Remove rear bumper fascia. Refer to «Rear Bumper Fascia Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exterior-body-panels/#bumpers-and-fascias) .
2. Disconnect electrical from the rear object sensor.
3. Lift the locking tabs on the housing and remove the rear object sensor.

Installation Procedure

1. Paint the rear object sensor. Refer to «Basecoat/Clearcoat Paint Systems»(/chevrolet/equinox/ii-2009-2015/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
2. Ensure the paint does not exceed 6 mils. Use a paint thickness gauge suitable for non-ferrous metals. Refer to «Paint Gauges»(/chevrolet/equinox/ii-2009-2015/remont/paintcoatings/#paint-and-coatings__paint-gauges) .
3. Insert the sensor into the housing.
4. Connect the electrical connector to the rear object sensor.
5. Install the rear bumper fascia. Refer to «Rear Bumper Fascia Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exterior-body-panels/#bumpers-and-fascias) .

The housings are adhesively retained to the backside of the fascia and must be removed prior to paint refinish operations every time the fascia is refinished due to paint bridging concerns. Adhesive tape cannot be removed and re-used with retention confidence. Thus the rear object sensor housing is considered a onetime use application, requiring that all 4 housings be replaced every time the fascia is refinished.

1. Remove the rear fascia. Refer to «Rear Bumper Fascia Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exterior-body-panels/#bumpers-and-fascias) .
2. Remove the rear object sensor. Refer to «Rear Parking Assist Alarm Sensor Replacement»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) .
3. Remove the sensor housing (1) from the fascia.
4. Remove all remaining adhesive.

1. Clean the sensor housing mating surface of the fascia with a lint-free rag using a naptha solvent or equivalent.
2. Mating surface must be dry before applying adhesion promoter.
3. Apply adhesion promoter 3M Products P/N 06396 or equivalent to the sensor housing mating surface (1) of the fascia.
4. Remove the protective paper backing from the sensor housing.
5. Position the sensor housing (1) to the fascia.
6. Press firmly to secure the sensor housing to the fascia.
7. Install the rear object sensor. Refer to «Rear Parking Assist Alarm Sensor Replacement»(/chevrolet/equinox/ii-2009-2015/remont/collisionavoidance/#object-detection-system-park-assist-system) .
8. Install the rear fascia. Refer to «Rear Bumper Fascia Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exterior-body-panels/#bumpers-and-fascias) .

Scheme 6

Front View Camera Replacement

Scheme 7

Rearview Camera Image Display Module Replacement

Front View Camera Module Calibration

The calibration process for the front view camera system is necessary when a front view camera module is replaced by a new one. This process shall not be required when only replacing the windshield and the front view camera module has been mounted again properly. This is a self-calibration procedure, which starts after the SPS configuration and setup is done. This process shall be completed within 3-10 min when the correct driving conditions are met.

If conditions are not met correct, the front view camera module shall continuously run the service point calibration until successfully completed. This process shall work across ignition cycles and shall not be required to be reinitialized at start up.

When this process is initiated on modules with the lane departure warning feature, the front view camera module shall command the lane departure warning system amber indicator on continuously until the alignment is completed. Once alignment is complete, the amber indicator will clear automatically.

Operate the system in the following conditions until the alignment is complete

1. Clean windshield.
2. Avoid lane change.
3. Drive during the daytime.
4. Lane departure warning system is ON.
5. Maintain vehicle speeds between 56-90 km/h (35-56 MPH).
6. Ensure the road contains visible references (well defined lane markings, curbs, guard rails, fences, buildings, etc.).

When the calibration is complete, the amber indicator will clear automatically, if well defined lane markings were seen and the vehicle speed was between 56-90 km/h (35-56 MPH). Then the system is ready to assist.

One or more of the following conditions may increase the length of time required to complete the self-calibration procedure

1. Heavy traffic
2. Maintained roads
3. Curves in roadway
4. Poor contrast lane markings
5. Botts' Dots type lane markings
6. Operating the vehicle speed is greater than 90 km/h (56 MPH)
7. Driving through snow or fog, driving at night, or driving directly into the sun

Conditions that will prevent completion of the self-calibration procedure

1. Operating the vehicle with speed less than 56 km/h (31 MPH)
2. No visible lane markings

Object Detection Description and Operation (UD7)

The ultrasonic rear parking assist system is designed to identify and notify the driver of an object in the vehicle's path when reversing at speeds of less than 8 km/h (5 MPH). The distance and location of the object is determined by 4 object sensors located in the rear bumper. The parking assist system will notify the driver using the parking assist indicators and an audible beep signal through the radio.

The rear parking assist system is made up of the following components

1. Parking assist control module
2. Rear object alarm sensors
3. Parking assist indicator

Parking Assist Control Module

The parking assist control module provides an 8 V reference and a low reference to the four rear parking assist sensors. The parking assist control module receives individual signals from each of the four sensors and determines the location and distance of an object based on these inputs. When an object is detected, the parking assist control module will illuminate the appropriate LED on the parking assist indicator and send a serial data message to the radio requesting an audible alert.

Rear Object Alarm Sensors

The rear object alarm sensors are located the in rear bumper of the vehicle. The sensors are used to determine the distance between an object and the rear bumpers. Each sensor emits an ultrasonic frequency which is reflected off object located behind the vehicle. These reflections are received by the sensors. The time difference between when the frequency was emitted and when the reflection is received, known as sensor echo time, is used to determine the distance to the object. The sensors report this information to the parking assist control module.

Parking Assist Indicator

The parking assist indicator is located in the interior rear of the vehicle and is visible through the inside rearview mirror. The indicator contains three LEDs: two amber and one red. The parking assist control module controls these three LEDs as a visual indicator of how close the vehicle bumper is to an object. The parking assist control module supplies voltage to each of the LEDs and commands each LED on by supplying an individual ground.

Rear Parking Assist Operation

When the vehicle is first placed into reverse, the rear parking assist system performs a bulb check. During the bulb check, the all three LED located in the parking assist indicator will illuminate for approximately 2 s to indicate that the system is working.

When backing up at speed of less than 8 km/h (5 MPH), the system is constantly monitoring for object of interest located behind the vehicle. The rear parking assist system can detect objects greater than 7.6 cm (3 in) wide and 25.4 cm (10 in) tall. The system cannot detect objects below the bumper, underneath the vehicle. If an object is detected, one of the following will occur

1. If the object is 1-2.5 m (3.3-8.2 ft) away from the vehicle, the amber outside indicator will illuminate and a single chime will sound when the object is first detected.
2. If the object is 0.6-1.0 m (2-3.3 ft) away from the vehicle, the amber outside and the amber middle indicators will illuminate.
3. If the object is 0.3-0.6 m (1-2 ft) away from the vehicle, the amber outside, amber middle, and red outside indicators will illuminate and the chime sounds continuously.
4. If the object is less than 0.3 m (1 ft) away from the vehicle, the amber outside, amber middle, and red outside indicators will flash and the chime sounds continuously.

If the rear parking assist system detects a malfunction, a DTC will be stored and the parking assist control module will send a serial data message to the instrument panel cluster to display the SERVICE PARK ASSIST message on the driver information center. The red LED on the parking assist indicator will be illuminated as a notification to the driver that a malfunction exists and the system is disabled.

Towbar Enabling

If the vehicle has a factory Trailer Hitch installed and the owner uses a factory ball mount package there is a personalization option available to allow the Rear Park Assist system to work with the factory Trailer Hitch.

This option can be selected using the Vehicle Personalization in the Radio and selecting Collision/Detection Systems. Press the MENU/SELECT knob when Park Assist is highlighted. Turn the knob to select Tow Bar. Press the knob to confirm and go back to the last menu.

Rear Parking Assist System Driver Information Center Messages

SERVICE PARK ASSIST

The driver information center displays SERVICE PARK ASSIST when the parking assist control module detects a malfunction in the rear parking assist system and the system is disabled. The driver information center also displays SERVICE PARK ASSIST when a loss of communication occurs with the parking assist control module.

PARK ASSIST OFF

The PARK ASSIST OFF message is displayed in the driver information center when the parking assist system is disabled due to conditions that disable or inhibit the system. The red LED in the park assist indicator will be illuminated. The parking assist control module requests the driver information center display PARK ASSIST OFF when it detects that one of the following conditions

1. The rear parking assist system is manually disabled by the vehicle operator through the audio system personalization menu.
2. An object is attached to the rear of the vehicle, such as a trailer, bicycle rack, trailer hitch receiver, or tow bar. Also, an object extending beyond a lowered tailgate will disable the system.
3. The parking assist sensors are covered by snow, mud, dirt, slush, or ice.
4. The vehicle bumper is damaged.
5. Excessive paint thickness on a replacement parking assist sensor.
6. The parking assist sensors are disrupted by vibrations, like those caused by a large nearby vehicle or from heavy equipment such as a jackhammer.

Object Detection Description and Operation (Front View Camera with UEU)

The forward collision alert system is a convenience feature of the front view camera that issues a warning to the driver when a potential collision risk exists. The front view camera is located behind the windshield, looking out at the road ahead and detecting vehicles directly ahead, within a distance of approximately 60 meters (197 ft). The forward collision alert system is always active and operates at speeds above 40 kph (25 mph). When the system detects a vehicle in the path ahead, the green vehicle ahead indicator in the vehicle direction display is illuminated. When approaching another vehicle too rapidly, the collision alert symbol will flash in the vehicle direction display. Simultaneously an audible alert sounds. Forward collision alert does not warn the driver of any objects that are not detected as a vehicle, like e.g. pedestrians, animals, signs, guard rails, bridges, construction barrels or other stationary or slow moving objects. The forward collision alert timing sensitivity to control the distance to the vehicle ahead can be set using the forward collision alert switch in the left steering wheel controls.

In some cases the camera may detect a vehicle that is not in the path ahead, or the system may occasionally provide unrealistic alerts. This could respond to a turning vehicle ahead, guard rails, traffic signs, or other stationary objects. This is normal operation, the vehicle does not need service. Forward collision alert may sometimes set unnecessary alerts to turning vehicles, vehicles in other lanes, objects that are not vehicles, or shadows. These alerts are normal operation and the vehicle does not need service.

The forward collision alert system is made up of the following components

1. Front view camera module
2. Forward collision alert switch
3. Instrument cluster/Vehicle direction display
4. Radio

Front View Camera Module

The camera detects vehicles in front of the host vehicle. The front view camera module requests the green vehicle ahead alert indicator in the vehicle direction display ON via serial data when the front view camera system has detected a vehicle in the driving path ahead. The front view camera module also communicates via serial data with the driver information center and the radio to request visual and audible alerts.

1. Lane departure warning system unavailable
2. Forward collision alert OFF
3. Service front camera

Forward Collision Alert Switch

The forward collision alert switch provides an input to the front view camera module to select the alert timing sensitivity when approaching another vehicle too rapidly. The front view camera module provides a signal voltage to the normally open switch. When the switch is pressed, the signal circuit is pulled to ground, indicating to the front view camera module that the system has been requested to change the alert timing sensitivity. The first button press shows the current alert timing setting on the driver information center. With every button press, the alert timing sensitivity is changed. The current alert timing setting will be maintained until it is changed. The preset alert timing setting is displayed in the top line of the driver information center. The position of the forward collision alert switch can vary with different vehicles. For the exact position please refer to the user's manual.

Instrument Cluster

The Vehicle direction display contains the green vehicle ahead indicator, which indicates to the driver that the Front View Camera system has detected a vehicle in the driving path ahead and is controlled via serial data. When approaching another vehicle too rapidly, the collision alert symbol will flash in the Vehicle direction display. The red Front collision alert display will stay continuously illuminated if the vehicle ahead remains much too close.

Radio

The radio controls the audible alert for the forward collision alert system. If the host vehicle is approaching another vehicle too rapidly, the radio will command an audible alert to the driver.

Forward Collision Alert System Driver Information Center Messages

The front view camera module can command the driver information center to display the various messages to alert the driver of a system concern or status information. For detailed information about the possible messages please refer to the user's manual.

Object Detection Description and Operation (Front View Camera with UFL)

The lane departure warning system is a convenience feature of the front view camera that issues a warning when the system detects that the vehicle has unintentionally crossed a lane marking. The front view camera is located behind the windshield, looking out at the road ahead and detecting any lane markings. When the vehicle unintentionally leaves a detected lane, a visual and audible alert is given to the driver.

The lane departure warning system is made up of the following components

1. Front view camera module
2. Lane departure warning switch
3. Instrument cluster/Vehicle Direction Display
4. Radio

Front View Camera Module

The camera detects visual queues such as lane markings. When it is determined that the vehicle has unintentionally moved outside of the lane, a visual and audible warning is given to the driver. The front view camera module receives an input from the lane departure warning switch and controls the lane departure warning switch indicator output. The front view camera module also communicates via serial data with the instrument cluster and radio to request visual and audible alerts.

Lane Departure Warning Switch

The lane departure warning switch provides an input to the front view camera module to turn the lane departure warning system ON and OFF. The front view camera module provides a signal voltage to the normally open momentary switch. When the switch is pressed, the signal circuit is pulled to ground, indicating to the front view camera module that the system has been requested to turn ON or OFF. The lane departure warning switch also contains the lane departure warning switch indicator, which is controlled by the front view camera module to indicate the ON and OFF status of the lane departure warning system. When the system has been enabled by the lane departure warning switch, the front view camera module applies ground to the switch indicator and illuminates the LED. The location of the lane departure warning switch can vary with different vehicles. For the exact location please refer to the user's manual.

Instrument Cluster

The vehicle direction display contains green and amber lane departure warning indicators. These indicate to the driver the current status of the lane departure warning system and are controlled via serial data by the front view camera module. When the vehicle speed is above 56 km/h (35 MPH) and the system has detected the required lane markings and is ready to assist, the green indicator will be illuminated on the vehicle direction display. If the vehicle has unintentionally left the lane, the amber indicator will flash.

Radio

The radio controls the audible alert for the lane departure warning. If the vehicle has unintentionally left the lane, the radio will command three beeps as an audible alert to the driver.

Lane Departure Warning Operation

System operation can be describe by the following modes

1. Off State: The system has been turned off by the driver, using the lane departure warning switch. The lane departure warning indicator will not be illuminated.
2. Not Ready To Assist: The system is enabled and the lane departure warning indicator is illuminated, but not ready to assist when any of the following conditions is true: Vehicle speed is less than 56 km/h (35 MPH). The system is designed to function at speeds greater than 56 km/h (35 MPH). The system cannot detect lane markings. This may be because there are no lane markings, as on a country road or that the lane markings cannot be determined due to snow, rain, or other driving conditions. The windshield area in front of the camera or the camera lens is blocked by fog, dirt, damage to the windshield or other elements that may prevent the camera from detecting lane markings.
3. Ready To Assist: The system is enabled and ready to warn of the unintentional lane crossing. The system is ready to assist when the green lane departure warning indicator is illuminated on the vehicle direction display.

Lane Crossing Alerts

1. When one of the following conditions are met, the system will not give alerts: The correct turn signal is activated. An activated turn signal is interpreted as an intentional lane crossing. The operator makes an intentional steering maneuver. The operator makes an intentional accelerating maneuver. The operator makes an intentional braking maneuver.
2. Lane crossing alert consists of the following: Three chimes are activated through the radio. The amber lane departure warning indicator will flash.

Lane Departure Warning System Driver Information Center Messages

The front view camera module can command the driver information center to display the various messages to alert the driver of a system concern or status information. For detailed information about the possible messages please refer to the user's manual.

Rear Vision Camera System Operation

The rear vision camera system consists of a video camera located at the rear of the vehicle and the radio.

When the transmission is placed into REVERSE, a 12 volt signal is sent to the rear vision camera by the body control module (BCM). This signal indicates to the camera that the vehicle is in reverse and image display is requested. The rear vision camera receives ignition voltage and a constant ground to power the camera. Video signal + and video signal - circuits carry the video image from the rear vision camera to the radio. Additionally, the video signal circuits are shielded to prevent any interference which may lead to a loss of video signal resolution and a degraded video image. The shield is provided a ground path by the rear vision camera.

The following conditions may cause a degraded rear vision camera image

1. Ice, snow, or mud has built up on the rear vision camera
2. Dark conditions
3. Extreme light conditions, such as glare from the sun or the headlights of another vehicle
4. Damage to the rear of the vehicle
5. Extreme high temperatures or extreme temperature changes

If a malfunction is detected in the system, Service Rear Vision Camera may be displayed on the navigation radio as an indicator to the customer that a problem exists that requires service.

See also:
• Diagnostic System Check - Vehicle
• Strategy Based Diagnosis
• Diagnostic Procedure Instructions
• COMPONENT CONNECTOR END VIEWS - INDEX
• Circuit Testing
• Connector Repairs
• Testing for Intermittent Conditions and Poor Connections
• Wiring Repairs
• Control Module References
• Diagnostic Repair Verification
• Diagnostic Trouble Code (DTC) List - Vehicle
• Cruise Control Switch Replacement (NK5)
• Checking Aftermarket Accessories
• Backup Lamps Malfunction
• Body Side Trim Panel Replacement - Left Side
• Fastener Caution
• Rear Bumper Fascia Replacement
• Basecoat/Clearcoat Paint Systems
• Paint Gauges
• Liftgate Applique Replacement (Terrain)
• Liftgate Applique Replacement (Equinox wo/UVC)
• DTC B0958, B0959, B0960, or B0961
• Object Detection Description and Operation (UD7)
• Object Detection Description and Operation (Front View Camera with UEU)
• Front View Camera Module Calibration
