Fastener Tightening Specifications

ApplicationSpecifications
MetricEnglish
Air Inlet Assembly Screws1.5 N.m13 lb in
Air Outlet Duct Screws1.5 N.m13 lb in
Battery Box to Body Bolts15 N.m11 lb ft
Blower Case Assembly Screws1.5 N.m13 lb in
Blower Motor Control Module Screws1.5 N.m13 lb in
Blower Motor Screws1.5 N.m13 lb in
Center Air Outlet Duct Fastener1.5 N.m13 lb in
Compressor Clutch Bolt12 N.m106 lb in
Compressor Clutch Coil Connector Bracket Screw4.3 N.m38 lb in
Compressor Clutch Coil Screws4.9 N.m43 lb in
Compressor Hose Assembly to Battery Box Nut9 N.m80 lb in
Compressor Hose Assembly to Compressor Nut22 N.m16 lb ft
Compressor Hose Assembly to Condenser Nut22 N.m16 lb ft
Compressor Pressure Relief Valve8 N.m70 lb in
Compressor Mounting Bolts LAF22 N.m16 lb ft
Compressor Mounting Bolt LF158 N.m43 lb ft
Condenser to Radiator Bolts9 N.m80 lb in
CRFM Bracket Bolts20 N.m15 lb ft
Evaporator Case Assembly Screws1.5 N.m13 lb in
Evaporator Outlet Hose and Liquid Line Clamp Bracket Nut to TXV22 N.m16 lb ft
Evaporator Outlet Hose to Compressor Hose Nut22 N.m16 lb ft
Front of Dash to HVAC Module Seal Nuts9 N.m80 lb in
Heater and Air Conditioning Evaporator and Blower Module Fastener9 N.m80 lb in
Heater Core Cover Screws1.5 N.m13 lb in
HVAC Module to Cross Car Beam Nuts and Bolts8 N.m71 lb in
Instrument Panel Air Outlet Fasteneer2.5 N.m22 lb in
Intermediate Duct Fasteners2.5 N.m22 lb in
Liquid Line to Condenser Nut22 N.m16 lb ft
Liquid Line to Strut Tower Nut9 N.m80 lb in
Mode Actuator to Evaporator Case Screws1.5 N.m13 lb in
Mode Cam Bracket to Evaporator Case Screws1.5 N.m13 lb in
Receiver Dehydrator to Condenser Bolt4.2 N.m37 lb in
Receiver Dehydrator Upper Clamp Bolt to Condenser6.5 N.m58 lb in
Refrigerant Pressure Sensor to Compressor Hose Assembly4 N.m35 lb in
Surge Tank to Body Bolts9 N.m80 lb in
TXV Backing Plate Bolts4.7 N.m41 lb in

Fastener Tightening Specifications

Refrigerant System Specifications

ApplicationSpecification
MetricEnglish
PAG Oil GM P/N 12378526 for United States PAG Oil GM P/N 88900060 for Canada
Abrupt Refrigerant Loss65 ml2.20 oz
Compressor Replacement
The service compressor is precharged with the specified amount of PAG oil.74 ml2.50 oz
Condenser Replacement with the Receiver Dehydrator60 ml2 oz
Condenser Replacement without the Receiver Dehydrator30 ml1 oz
Evaporator Replacement30 ml1 oz
Receiver Dehydrator Replacement30 ml1 oz
Thermal Expansion Valve Replacement20 ml0.75 oz
Total System PAG Oil Capacity150 ml5 oz
R-134a
Refrigerant Charge0.65 kg1.43 lb
Abrupt refrigerant loss due to a large leak, hose rupture, collision, or pressure relief valve opening. Conditions that allow the refrigerant to seep or bleed off over time do not cause this oil loss. Upon replacement of a component that caused a large refrigerant loss, also add the required amount of oil for the particular component. If more than the specified amount of PAG oil was drained from a component, add the equal amount of oil drained.

Refrigerant System Specifications

Handling of Refrigerant Lines and Fittings

CAUTIONTo avoid system damage use only R-134a dedicated tools when servicing the A/C system.
  1. Keep all metal tubing lines free of dents or kinks. Any line restrictions will cause the loss of system capacity.
  2. Never bend a flexible hose line to a radius of less than four times the diameter of the hose.
  3. Never allow a flexible hose line to come within 65 mm (2-1/2 in) of the exhaust manifold.
  4. Inspect flexible hose lines regularly for leaks or brittleness.
  5. Replace flexible hose lines with new lines if you find signs of deterioration or leaking.
  6. Discharge the refrigeration system of all refrigerant before disconnecting any fitting in the refrigeration system.
  7. Proceed very cautiously regardless of the gauge readings.
  8. Open the fittings very slowly.
  9. If you notice pressure when you loosen a fitting, allow the pressure to bleed off as described Discharging, Adding Oil, Evacuating, and Charging Procedures for A/C System.
  10. Cap or tape any refrigerant line immediately after it is opened. This will prevent the entrance of moisture and dirt, which can cause internal compressor wear or plugged lines in the condenser, the evaporator core, the expansion valve, or the compressor inlet screens.
  11. Keep the sealing surfaces in perfect condition. A burr or a piece of dirt may cause a refrigerant leak.
  12. When seal washers are used, always install the seal washer without lubrication.
  13. When O-rings are used, always lightly coat the new O-ring seal with mineral base 525 viscosity refrigerant oil prior to installation.

Special Tools

  1. J 39400-A Halogen Leak Detector
  2. J 41447 R-134A A/C Tracer Dye-Box of 24
  3. J 42220 Universal 12V Leak Detection Lamp
  4. J 43872 Fluorescent Dye Cleaner
  5. J 46297 A/C Dye Injector Kit
  6. J 46297-12 Replacement Dye Cartridges

Refrigerant Leak Testing

Note. General Motors vehicles are now manufactured with fluorescent dye installed directly into the air conditioning (A/C) system.

The fluorescent dye mixes and flows with the polyalkylene glycol (PAG) oil throughout the refrigerant system.

Verifying some passive leaks may require using the J 39400-A halogen leak detector, even though the A/C system contains fluorescent dye.

The only time that adding additional fluorescent dye is required is after flushing the A/C system.

Fluorescent Leak Detector

Fluorescent dye will assist in locating any leaks in the A/C system.

  1. Condensation on the evaporator core or the refrigerant lines may wash the PAG oil and fluorescent dye away from the actual leak. Condensation may also carry dye through the HVAC module drain.
  2. Leaks in the A/C system will be indicated in a light green or yellow color when using the leak detection lamp. Use the leak detection lamp in the following areas: All fittings or connections that use seal washers or O-rings All of the A/C components The A/C compressor shaft seal The A/C hoses and pressure switches The HVAC module drain tube, if the evaporator core is suspected of leaking The service port sealing caps The sealing cap is the primary seal for the service ports.
  3. Follow the instructions supplied with the J 42220 Universal 12V leak detection lamp.
  4. To prevent false diagnosis in the future, thoroughly clean the residual dye from any area where leaks were found. Use a rag and the approved J 43872 fluorescent dye cleaner.

Fluorescent Dye Injection

  1. Not all of the fluorescent dyes are compatible with PAG oil. Some types of dye decrease the oil viscosity or may chemically react with the oil.
  2. R-134A leak detection dye requires time to work. Depending upon the leak rate, a leak may not become visible for between 15 minutes and 7 days.
  3. To prevent false diagnosis, thoroughly clean any residual dye from the service port with a rag and the approved fluorescent dye cleaner J 43872 fluorescent dye cleaner.

Halogen Leak Detector

WARNINGDo not operate the detector in a combustible atmosphere since its sensor operates at high temperatures or personal injury and/or damage to the equipment may result.

Ensure that the vehicle has at least 0.45 kg (1 lb) of refrigerant in the A/C refrigeration system in order to perform a leak test. Refer to Refrigerant Recovery and Recharging for recharging the A/C system.

Note. Halogen leak detectors are sensitive to the following items: Windshield washing solutions Many solvents and cleaners Some adhesives used in the vehicle

Clean and dry all surfaces in order to prevent a false warning. Liquids will damage the detector.

Note. Follow a continuous path in order to ensure that you will not miss any possible leaks. Test all areas of the system for leaks.

Follow the instructions supplied with the J 39400-A halogen leak detector.

Air Conditioning (A/C) System Performance Test (LF1 or LFW)

This test measures the operating efficiency of the A/C system under the following conditions

  1. The current ambient air temperature
  2. The current relative humidity
  3. The high side pressure of the A/C system
  4. The low side pressure of the A/C system
  5. The temperature of the air being discharged into the passenger compartment

Test Description

The numbers below refer to the step numbers on the diagnostic table.

  1. 1 This step determines if the A/C system has at least the minimum refrigerant charge required to operate the system without damage.
  2. 2 This step measures the performance of the A/C system.
  3. 3 This step is to allow for vehicle variations as well as high ambient temperatures.
StepActionValuesYesNo
NOTE: The ambient air temperature must be at least 16°C (60°F). Do not induce additional air flow across the front of the vehicle during the test. If you were sent here from a DTC diagnostic table, clear the DTC upon completion of this test.
1Park the vehicle inside or in the shade. Update the ambient air temperature display. Refer to Ambient Air Temperature Display Updating . Open the windows in order to ventilate the interior of the vehicle. If the A/C system was operating, allow the A/C system to equalize for about 2 minutes. Turn OFF the ignition. Install the J 43600 ACR 2000 Air Conditioning Service Center. Record the ambient air temperature displayed on the J 43600 ACR 2000 Air Conditioning Service Center. Record the low and high side STATIC pressure readings. Are both the low side and high side pressures within the specified value?More than 16°C (60°F) - 345 kPa (50 psi) More than 24°C (75°F) - 483 kPa (70 psi) More than 33°C (90°F) - 690 kPa (100 psi)Go to Step 2Go to Leak Testing
2NOTE: Record the relative humidity and the ambient air temperature at the time of the test. Close the vehicle doors and windows. Open the drivers door window 12.7-15.2 cm (5-6 in). Select the following HVAC control settings: The A/C is ON The coldest temperature setting The maximum blower speed Recirculation mode The panel outlet mode All panel outlets are OPEN Install the temperature probes of the J 43600 ACR 2000 Air Conditioning Service Center in the left and right center panel air outlets. Apply the parking brake. Place the transaxle/transmission in PARK. Start the engine. Operate the A/C system for 5 minutes. Inspect A/C components for the following conditions: Abnormal frost areas Unusual noises Print the following information: The panel outlet air temperatures The low-side pressure The high-side pressure Compare the low and high side pressures and the panel output temperatures to the A/C performance table below. Does all the data recorded fall within the specified ranges of the A/C performance table?Go to Step 5Go to Step 3
3If the pressures and temperatures recorded do not fall within the specified ranges: Continue to operate the A/C system for an additional 5 minutes. RESET the J 43600 ACR 2000 Air Conditioning Service Center and record the pressures and temperatures again. Compare the low and high side pressures and the panel output temperature to the A/C performance table. Does all the data recorded fall within the specified ranges of the A/C performance table?Go to Step 5Go to Step 4
4Perform the necessary repairs. Refer to A/C Diagnostics Chart . Is the action complete?Go to Step 5
5Operate the system in order to verify the test results. Did you find the same results?System OKGo to Symptoms - HVAC Systems - Manual
NOTE
The ambient air temperature must be at least 16°C (60°F). Do not induce additional air flow across the front of the vehicle during the test. If you were sent here from a DTC diagnostic table, clear the DTC upon completion of this test.
NOTE
Record the relative humidity and the ambient air temperature at the time of the test.

Air Conditioning (A/C) System Performance Test (LF1 or LFW)

Ambient TemperatureRelative HumidityLow Side Service Port PressureHigh Side Service Port PressureMaximum Left Center Discharge Air Temperature
13-18°C (55-65°F)0-100%151-199 kPa (22-29 psi)799-1129 kPa (116-164 psi)12°C (52°F)
19-24°C (66-75°FBelow 40%151-220 kPa (22-32 psi)950-1309 kPa (138-190 psi)12°C (52°F)
Above 40%151-248 kPa (22-36 psi)999-1391 kPa (145-202 psi)13°C (55°F)
25-29°C (76-85°F)Below 35%165-241 kpa (24-35 psi)1178-1502 kPa (171-218 psi)13°C (54°F)
35-50%179-254 kPa (26-37 psi)1219-1543 kPa (177-224 psi)13°C (55°F)
Above 50%213-303 kPa (31-44 psi)1460-1880 kPa (212-273 psi)15°C (59°F)
30-35°C (86-95°F)Below 30%186-268 kPa (27-39 psi)1357-1708 kPa (203-258 psi)14°C (57°F)
30-50%199-282 kPa (29-41 psi)1398-1777 kPa (218-263 psi)14°C (57°F)
Above 50%227-303 kPa (33-44 psi)1515-1839 kPa (220-267 psi)15°C (59°F)
36-41°C (96-105°F)Below 20%213-296 kPa (31-43 psi)1570-1901 kPa (228-276 psi)15°C (59°F)
20-40%220-310 kPa (32-45 psi)1598-1977 kPa (232-287 psi)15°C (59°F)
Above 40%234-323 kPa (34-47 psi)1667-2060 kPa (242-299 psi)17°C (61°F)
42-46°C (106-115°F)Below 20%248-316 kPa (36-46 psi)1777-2087 kPa (258-303 psi)17°C (61°F)
Above 20%254-330 kPa (37-48 psi)1818-2177 kPa (264-316 psi)18°C (63°F)
47-49°C (116-120°F)Below 30%275-351 kPa (40-51 psi)2011-2328 kPa (292-338 psi)18°C (64°F)

A/C Performance Table

A/C Diagnostics Chart

Low Side Gauge ReadingHigh Side Gauge ReadingPotential Causes
LowLowLow Refrigerant Charge
Restriction between Compressor and High Side port
Low/NormalEvaporator Freezing
HighRestriction between the Low Side and High Side ports or Restricted TXV/Orifice Tube
Compressor Stuck at Maximum Displacement
HighLowCompressor has Low Displacement or Internal Malfunction
HighMalfunctioning Cooling Fans
Refrigerant Overcharge
Restriction between the Low Side Port and Compressor Inlet
Restricted Condenser Air Flow
Expansion Device Stuck Open
Air in A/C System
Normal/HighNormal/HighRefrigerant Contamination
PAG or POE Oil Overcharge

A/C Diagnostics Chart

Defrosting Insufficient

StepActionYesNo
DEFINITION: Time required to defrost the windshield is longer than usual.
1Were you sent here from Symptoms or another diagnostic table?Go to Step 2Go to Symptoms - HVAC Systems - Automatic
2Start the engine. Select the DEFROST mode. Select the maximum blower speed. Does sufficient air flow from the defroster outlets?Go to Step 3Go to Step 11
3Measure the engine operating temperature. Does engine reach normal operating temperature?Go to Step 4Go to Step 9
4Select the minimum blower speed. Select the warmest temperature setting. WARNING: Refer to Moving Parts and Hot Surfaces Warning . Feel the temperature of the inlet and outlet hoses at the heater core. Does the inlet heater hose feel warmer than the outlet heater hose?Go to Step 12Go to Step 5
5Is the vehicle equipped with A/C?Go to Step 6Go to Step 14
6Test the operation of the A/C compressor clutch. Does the A/C compressor clutch engage?Go to Step 8Go to Step 7
7Repair the A/C compressor clutch. Refer to Air Conditioning Compressor Malfunction . Is the repair complete?Go to Step 15
8Perform the A/C system performance test. Refer to Air Conditioning (A/C) System Performance Test (LF1 or LFW) . Is the A/C system operating within the specifications?Go to Step 10Go to Step 13
9Repair the low engine temperature concern. Refer to Engine Fails To Reach Normal Operating Temperature . Is the repair complete?Go to Step 15
10Inspect for correct operation of the recirculation door. Is the recirculation door operating correctly?Go to Step 15Go to Step 14
11Repair the air delivery concern. Refer to Vent Valve Replacement . Is the repair complete?Go to Step 15
12Repair the heating concern. Refer to Symptoms - HVAC Systems - Automatic Is the repair complete?Go to Step 15
13Repair the A/C performance concern. Refer to Air Conditioning (A/C) System Performance Test (LF1 or LFW) . Is the repair complete?Go to Step 15
14Repair the recirculation door concern. Refer to Vent Valve Replacement . Is the repair complete?Go to Step 15
15Operate the system in order to verify the repair. Did you find and correct the condition?System OKGo to Step 2

Defrosting Insufficient

Noise Diagnosis - Blower Motor

StepActionYesNo
DEFINITION: Noise originating from the blower motor.
1Were you sent here from Symptoms or another diagnostic table?Go to Step 2Go to Symptoms - HVAC Systems - Manual or Go to Symptoms - HVAC Systems - Automatic
2Inspect the air inlet grille for debris. Is debris present?Go to Step 8Go to Step 3
3Sit inside the vehicle. Close the vehicle doors and windows. Turn ON the ignition, with the engine OFF. Cycle the blower motor through all of the speeds in order to determine where and when the noise occurs. Did you hear a noise during the blower operation?Go to Step 4Go to Step 11
4Inspect for excessive vibration at each blower motor speed by feeling the blower case. Is excess vibration present?Go to Step 6Go to Step 5
5Listen to the blower motor at each blower speed. Is the blower motor making a squeaking or chirping noise?Go to Step 9Go to Step 11
6Remove the blower motor. Refer to Blower Motor Replacement . Inspect the blower motor impeller for deposits of foreign material. Inspect the blower motor for deposits of foreign material. Did you find any foreign material on the blower motor or blower motor impeller?Go to Step 8Go to Step 7
7Inspect the blower motor for the following conditions: Cracked blades A loose impeller retainer Improper impeller alignment Did you find any of these conditions?Go to Step 9Go to Step 10
8Remove the foreign material. Is the action complete?Go to Step 10
9Replace the blower motor. Refer to Blower Motor Replacement . Is the repair complete?Go to Step 11
10Install the blower motor. Refer to Blower Motor Replacement . Is the action complete?Go to Step 11
11Operate the system in order to verify the repair. Did you find and correct the condition?System OKGo to Step 2

Noise Diagnosis - Blower Motor

Air Conditioning Compressor Oil Diagnosis

ConditionCorrective Action
NOTE: To avoid repeat compressor failure, always inspect the condition of the refrigerant oil and take the appropriate corrective action before installing the replacement compressor.
Clean Oil no debris presentNo corrective action necessary.
Clean Oil with debris presentInspect the suction port of the replacement compressor for presence of a suction screen. If the replacement compressor does NOT contain a suction screen, install suction screen in the line. Replace desiccant or component containing the desiccant. Replace desiccant filter if applicable. Remove and inspect high pressure side filter (if applicable). Remove, inspect, clean, or replace orifice tube. If the system has a front orifice tube and is equipped with a filter in the rear auxiliary line, remove, inspect, clean, or replace the filter.
Dark brown/black and/or pungent/unusual odor with no debris presentReplace desiccant or component containing the desiccant. Replace desiccant filter if applicable. Flush refrigerant system.
Dark brown/black and/or pungent/unusual odor with debris presentReplace desiccant or component containing the desiccant. Replace desiccant filter if applicable. Flush refrigerant system. Inspect the suction port of the replacement compressor for presence of a suction screen. If the replacement compressor does NOT contain a suction screen, install suction screen. Remove and inspect high pressure side filter (if applicable). Remove, inspect, clean, or replace orifice tube. If the system has a front orifice tube and is equipped with a filter in the rear auxiliary line, remove, inspect, clean, or replace the filter.
Oil OverchargeFlush refrigerant system.
Refrigerant ContaminationFlush refrigerant system.
Hybrid Polyolester Refrigerant Oil (POE) ContaminationFlush refrigerant system. Replace desiccant or component containing the desiccant. Replace desiccant filter if applicable.
NOTE
To avoid repeat compressor failure, always inspect the condition of the refrigerant oil and take the appropriate corrective action before installing the replacement compressor.

Air Conditioning Compressor Oil Diagnosis

Odor Diagnosis

StepActionYesNo
DEFINITION: Odor originating or noticed through the HVAC system.
1Were you sent here from Symptoms or another diagnostic table?Go to Step 2Go to Symptoms - HVAC Systems - Automatic
2Sit inside the vehicle. Close all of the doors and windows. Start the engine. Allow the engine idle at normal operating temperature. Select the maximum blower speed. Select the PANEL air outlet mode. Select the coldest temperature setting. Cycle through all of the blower speeds, modes and temperatures to define what type of odor is present. Musty smell Coolant smell Oil smell Does the odor have a musty smell?Go to Step 3Go to Step 8
3Inspect the HVAC filter and the air inlet grille for debris. Is debris present?Go to Step 4Go to Step 5
4Remove any debris. Is the action complete?Go to Step 15
5Inspect for wet carpeting. Is the carpet wet?Go to Step 6Go to Step 14
6Inspect for the following conditions: Water leaks around the windshield Blockage of the HVAC module drain Leaks around the door seals Is a leak present?Go to Step 7Go to Step 14
7Repair the leak as necessary. Is the repair complete?Go to Step 15
8Does the odor have a coolant smell?Go to Step 9Go to Step 12
9Inspect the cooling system for leaks. Refer to Loss of Coolant . Is a leak present?Go to Step 10Go to Step 12
10Inspect for coolant leaking inside the vehicle or for a film build-up on the windshield. Is the condition present?Go to Step 11Go to Step 15
11Replace the heater core. Refer to Heater Core Replacement . Is the repair complete?Go to Step 15
12Does the odor have an oily smell?Go to Step 13Go to Step 15
13Inspect the engine compartment for any leaks. Refer to the following procedures: Cooling System Leak Testing Oil Leak Diagnosis Repair any oil leaks. Is the repair complete?Go to Step 15
14A musty odor can be caused by mold or mildew build-up on the evaporator or the heater core or inside of the HVAC module. Refer to Heater and Air Conditioning Evaporator and Blower Module Replacement . Is the action complete?Go to Step 15
15Operate the system in order to verify the repair. Did you find and correct the condition?System OKGo to Step 2

Odor Diagnosis

Refrigerant Recovery and Recharging

Special Tools

J 34100 Smart Cart

WARNINGTo prevent personal injury, avoid breathing A/C Refrigerant and lubricant vapor or mist. Work in a well ventilated area. To remove refrigerant from the A/C System, use service equipment designed for recovery that is certified to meet the requirements of the appropriate SAE Standards. If an accidental system discharge occurs, ventilate the work area before continuing service. Additional health and safety information may be obtained from the refrigerant, refrigerant recovery, and lubricant manufacturers.
WARNINGFor personal protection, goggles and lint-free gloves should be worn and a clean cloth wrapped around fittings, valves, and connections when doing work that includes opening the refrigerant system. If refrigerant comes in contact with any part of the body severe frostbite and personal injury can result. The exposed area should be flushed immediately with cold water and prompt medical help should be obtained.
CAUTIONYou must replace the desiccant if the A/C refrigerant system has been open to atmosphere for more than four hours, or if the A/C refrigerant oil has been contaminated. Failure to replace the desiccant will result in damage to the A/C refrigerant system.
CAUTIONR-134a is the only approved refrigerant for use in this vehicle. The use of any other refrigerant may result in poor system performance or component failure.
CAUTIONTo avoid system damage use only R-134a dedicated tools when servicing the A/C system.
CAUTIONUse only Polyalkylene Glycol Synthetic Refrigerant Oil (PAG) for internal circulation through the R-134a A/C system and only 525 viscosity mineral oil on fitting threads and O-rings. If lubricants other than those specified are used, compressor failure and/or fitting seizure may result.

The J 34100 Smart Cart is a complete air conditioning service center for R-134a. The Smart Cart recovers, recycles, evacuates and recharges A/C refrigerant quickly, accurately and automatically. The unit has a display screen that contains the function controls and displays prompts that will lead the technician through the recover, recycle, evacuate and recharge operations. R-134a is recovered into and charged out of an internal storage vessel. The ACR 2000 automatically replenishes this vessel from an external source tank in order to maintain a constant 5.45-6.82 kg (12-15 lbs) of A/C refrigerant.

The Smart Cart has a built in A/C refrigerant identifier that will test for contamination, prior to recovery and will notify the technician if there are foreign gases present in the A/C system. If foreign gases are present, the Smart Cart will not recover the refrigerant from the A/C system.

The Smart Cart also features automatic air purge, single pass recycling and an automatic oil drain.

Refer to the J 34100 Smart Cart Smart Cart manual for operation and setup instruction. Always recharge the A/C System with the proper amount of R-134a. Refer to Refrigerant System Specifications for the correct amount.

A/C Refrigerant System Oil Charge Replenishing

If oil was removed from the A/C system during the recovery process or due to component replacement, the oil must be replenished.

  1. J 41447 R-134A A/C Tracer Dye - Box of 24
  2. J 42220 Universal 12V Leak Detection Lamp
  3. J 43600 ACR 2000 Air Conditioning Service Center
  4. J 45268 A/C Flushing Adapter Kit

Note. Flushing with the J 43600 ACR 2000 Air Conditioning Service Center is not intended to remove metal from the A/C system.

Flushing is intended to remove the following

  1. Contaminated PAG oil
  2. Desiccant, following a desiccant bag failure
  3. Overcharge of PAG oil
  4. Refrigerant contamination

Forward Flushing Setup

  1. Install both J 45268-9 (2) onto the J 45268-10 (3).
  2. Install the J 45268-7 (4) onto the suction side of the J 45268-10 (3).
  3. Install the J 45268-8 (1) onto the discharge side of the J 45268-10 (3).

Reverse Flushing Setup

  1. Install both J 45268-9 (2) onto the J 45268-10 (3).
  2. Install the J 45268-8 (1) onto the suction side of the J 45268-10 (3).
  3. Install the J 45268-7 (4) onto the discharge side of the J 45268-10 (3).

Flush Procedure

  1. Recover the refrigerant. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  2. Remove the TXV. Refer to «Air Conditioning Evaporator Thermal Expansion Valve Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  3. Install the stud onto the J 45268-115.
  4. Install new sealing washers onto the evaporator core. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  5. Install J 45268-115 in place of the TXV.
  6. Install TXV mounting bolts and tighten to 7 N.m (62 lb in).
  7. Install new washers onto the rear evaporator line assembly. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  8. Connect the rear evaporator line assembly to the J 45268-115.
  9. Install the TXV block fitting nut and tighten to 20 N.m (15 lb ft).
  10. Remove the A/C compressor. Refer to «Air Conditioning Compressor Replacement (LEA)»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , «Air Conditioning Compressor Replacement (LFW)»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Service the filter with ACDelco P/N GF 470, before each flush.
  12. Install the J 45268-10 to the compressor hose assembly.
  13. Connect the J 45268-1 flush filter to the J 45268-7 flush adapter.
  14. Connect the blue hose from the J 43600 ACR 2000 Air Conditioning Service Center to J 45268-1 flush filter adapter.
  15. Connect the red hose from the J 43600 ACR 2000 Air Conditioning Service Center to J 45268-8 flush adapter.
  16. Flush the A/C system. Follow the instructions supplied with the J 43600 ACR 2000 Air Conditioning Service Center.
  17. Disconnect the red hose from the J 43600 ACR 2000 Air Conditioning Service Center to J 45268-8 flush adapter.
  18. Disconnect the blue hose from the J 43600 ACR 2000 Air Conditioning Service Center to J 45268-1 flush filter adapter.
  19. Disconnect the J 45268-1 flush filter from the J 45268-10 flush adapter.
  20. Remove the J 45268-10 from the compressor hose assembly.
  21. If you will reinstall the removed A/C compressor, perform the following procedure: Drain the PAG oil from the A/C compressor. Rotate the compressor input shaft to assist in draining the PAG oil from the compressor. Add the total system capacity of PAG oil to the crankcase of the A/C compressor. Refer to «Refrigerant System Specifications»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-system-specifications) . NOTE: Flushing will remove the fluorescent leak detection dye from the A/C system. Add one bottle of J 41447 R-134A A/C Tracer Dye - Box of 24 directly to the A/C compressor.
  22. Install the A/C compressor. Refer to «Air Conditioning Compressor Replacement (LEA)»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , «Air Conditioning Compressor Replacement (LFW)»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  23. Remove the TXV block fitting nut.
  24. Disconnect the rear evaporator line assembly from the J 45268-115.
  25. Remove the TXV bolts retaining the J 45268-115.
  26. Remove the J 45268-115.
  27. Inspect the TXV for debris. Clean or replace as needed.
  28. Install the TXV. Refer to «Air Conditioning Evaporator Thermal Expansion Valve Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  29. Evacuate and recharge the A/C system. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  30. Leak test the fittings using J 42220 Universal 12V Leak Detection Lamp.

Draining Procedure

  1. Remove the compressor crankcase oil drain plug and drain the crankcase into a clean, graduated container.
  2. Drain the oil from both the suction and discharge ports of the removed compressor (1) into the same container. Rotate the compressor shaft to assist in draining the compressor (1).
  3. Measure and record the amount of oil drained from the removed compressor (1). This measurement will be used during installation of the replacement compressor (1).
  4. Inspect oil drained from removed compressor (1). Refer to «Air Conditioning Compressor Oil Diagnosis»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__air-conditioning-compressor-oil-diagnosis) .
  5. Properly discard the used refrigerant oil.

Balancing Procedure

  1. The replacement compressor is shipped partially filled with refrigerant oil. The amount of oil has to be balanced according to below.
  2. Before installing the compressor (1) the refrigerant oil will have to be partially drained: Refer to the amount of refrigerant oil recorded during the compressor removal. Subtract the amount recorded from the total system capacity. Refer to «Refrigerant System Specifications»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-system-specifications) . The difference between the total system capacity and the recorded amount is the calculated amount to be drained from the replacement compressor (1).
  3. Drain the calculated amount of refrigerant oil from the replacement compressor.

Scheme 1

Scheme 1: Air Conditioning Compressor Replacement (LEA)
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle Remove engine splash shield right side. Refer to Engine Splash Shield Replacement - Right Side . Remove the drive belt. Refer to Drive Belt Replacement . Disconnect the A/C compressor electrical connector. Remove the air conditioning compressor hose. Refer to Air Conditioning Compressor Hose Replacement (LF1 or LFW) , Air Conditioning Compressor Hose Replacement (LEA)
1A/C Compressor Bolt (Qty 3) CAUTION: Refer to Fastener Caution . Tighten 22 N.m (16 lb ft)
2A/C Compressor
CAUTION
Refer to Fastener Caution .

Air Conditioning Compressor Replacement (LEA)

Scheme 2

Scheme 2: Air Conditioning Compressor Replacement (LFW)
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle Remove engine splash shield right side. Refer to Engine Splash Shield Replacement - Right Side . Remove the drive belt. Refer to Drive Belt Replacement . Disconnect the A/C compressor electrical connector. Remove the air conditioning compressor hose. Refer to Air Conditioning Compressor Hose Replacement (LF1 or LFW) , Air Conditioning Compressor Hose Replacement (LEA)
1A/C Compressor Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . NOTE: Tighten the A/C compressor mounting bolts in sequence. Tighten 58 N.m (43 lb ft)
2A/C Compressor Bolt NOTE: Tighten the A/C compressor mounting bolts in sequence. Tighten 22 N.m (16 lb ft)
3A/C Compressor Procedure When replacing the A/C compressor, balance the compressor. Refer to Air Conditioning Compressor Oil Balancing . Replacement of the receiver and dehydrator is required upon new compressor replacement. Refer to Receiver and Dehydrator Replacement Using J 39400-A leak detector, leak test A/C compressor fittings. NOTE: Use a low viscosity, poly-alkylene glycol (PAG) oil. Use of the incorrect oil can result in compressor failure. Special Tools J 39400-A Halogen Leak Detector For equivalent region tools, refer to Special Tools .
CAUTION
Refer to Fastener Caution .
NOTE
Tighten the A/C compressor mounting bolts in sequence.
NOTE
Tighten the A/C compressor mounting bolts in sequence.
NOTE
Use a low viscosity, poly-alkylene glycol (PAG) oil. Use of the incorrect oil can result in compressor failure.

Air Conditioning Compressor Replacement (LFW)

Scheme 3

Scheme 3: Compressor Clutch Plate and Hub Assembly Removal
CalloutComponent Name
Preliminary Procedures Remove the drive belt. Refer to Drive Belt Replacement . Remove the air conditioning compressor if necessary. Refer to Air Conditioning Compressor Replacement (LEA) , Air Conditioning Compressor Replacement (LFW) . Disconnect the electrical connector from the air conditioning compressor.
1Air Conditioning Compressor Pulley Bolt CAUTION: Refer to Fastener Caution . Tighten 12 N.m (106 lb in)
2Air Conditioning Clutch Drive Plate Procedure Measure and adjust the air conditioning compressor clutch drive plate per specification. Refer to Air Conditioning Clutch Drive Plate Adjustment .
3Air Conditioning Compressor Clutch Drive Plate Adjustment Shim
4Air Conditioning Compressor Clutch Pulley Snap Ring Procedure Ensure the clutch pulley snap ring is installed with the flat side toward the air compressor.
5Air Conditioning Compressor Clutch Pulley
6Air Conditioning Compressor Clutch Coil Snap Ring Procedure Ensure the clutch coil snap ring is installed with the flat side toward the air compressor.
7Air Conditioning Compressor Clutch Coil
CAUTION
Refer to Fastener Caution .

Compressor Clutch Plate and Hub Assembly Removal

Air Conditioning Clutch Drive Plate Adjustment

  1. Install the clutch plate assembly.
  2. Measure the air gap between the pulley and the drive plate. Adjust the shims to achieve a 0.30-0.60 mm (0.011-0.023 in) air gap.
  3. Install the clutch plate retaining bolt and tighten to 12 N.m (106 lb in).

Removal Procedure

  1. Remove the seal washer from the A/C refrigerant component.
  2. Inspect the seal washer for any signs of damage.
  3. Inspect the A/C refrigerant components for damage or burrs. Repair or replace as necessary.
  4. Discard the sealing washer.

Installation Procedure

  1. Inspect the new seal washer for any signs of cracks, cuts, or damage. Do not use a damaged seal washer.
  2. Using a lint-free clean, dry cloth, clean the sealing surfaces of the A/C refrigerant components.
  3. Carefully install the new seal washer onto the A/C refrigerant component.
  4. The washer must completely bottom against the surface of the fitting.
  5. Assemble the remaining A/C refrigerant components. Refer to the appropriate repair procedure.
  1. Disassemble the A/C refrigerant components. Refer to the appropriate repair procedure For compression style fittings use a back up wrench on the fitting (2) and loosen the fitting nut (1). For banjo style fittings remove the bolt retaining the banjo type fitting.
  2. Remove the O-ring seal from the A/C refrigerant component.
  3. Inspect the O-ring seal for signs of damage to help determine the root cause of the failure.
  4. Inspect the A/C refrigerant components for damage or burrs. Repair if necessary.
  5. Cap or tape the A/C refrigerant components.
  6. Discard the O-ring seal.
  1. Inspect the new O-ring seal for any sign or cracks, cuts, or damage. Replace if necessary.
  2. Remove the cap or tape from the A/C refrigerant components.
  3. Using a lint-free clean, dry cloth, carefully clean the sealing surfaces of the A/C refrigerant components.
  4. Lightly coat the new O-ring seal with mineral base 525 viscosity refrigerant oil.
  5. Carefully slide the new O-ring seal onto the A/C refrigerant component.
  6. The O-ring seal must be fully seated.
  7. Assemble the A/C components. Refer to the appropriate repair procedure. For compression style fittings use a back up wrench on the fitting (2) and tighten the fitting nut (1) to specification. For banjo style fittings install the bolt retaining the banjo type fitting and tighten to specification.

Air Conditioning Compressor Hose Replacement (LF1 or LFW)

Special Tools

J 39400-A Halogen Leak Detector

Removal Procedures

  1. Recover the refrigerant. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  2. Remove the left headlamp. Refer to «Headlamp Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) , «Headlamp Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
  3. Remove the air conditioning compressor hose nut (2) from the air conditioning evaporator thermal expansion valve tube hose.
  4. Remove the air conditioning compressor hose from the air conditioning evaporator thermal expansion valve tube hose.
  5. Remove the compressor hose nut (2) from the condenser.
  6. Remove the compressor hose (1) from the condenser.
  7. Unclip hose from fan shroud.
  8. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#general-information) .
  9. Disconnect the electrical connector from the air conditioning refrigerant pressure sensor valve.
  10. Remove the compressor hose nut (1) at the compressor.
  11. Remove the compressor hose (2) from the compressor.
  12. Remove the compressor hose from the vehicle.
  13. Remove and discard the sealing washers from the compressor hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  1. Install new seal washers to the compressor hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  2. Install the compressor hose (2) to the compressor.
  3. Install the compressor hose nut (1) to the compressor and tighten the nut to 22 N.m (16 lb ft).
  4. Connect the electrical connector to the air conditioning refrigerant pressure sensor valve.
  5. Lower the vehicle.
  6. Position the compressor hose in the vehicle.
  7. Install a new sealing washer to the air conditioning evaporator thermal expansion valve tube hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  8. Install the air conditioning evaporator thermal expansion valve tube hose to the compressor hose.
  9. Install the compressor hose nut (2) to the air conditioning evaporator thermal expansion valve tube hose and tighten the nut to 22 N.m (16 lb ft).
  10. Install a new sealing washer to the compressor hose at the condenser. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Install the compressor hose (1) to the condenser.
  12. Install the compressor hose nut (2) to the condenser and tighten to 20 N.m (15 lb ft).
  13. Install the left headlamp. Refer to «Headlamp Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) , «Headlamp Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
  14. Recharge the A/C system. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  15. Test the affected A/C joints for leaks using J 39400-A halogen leak detector.

Air Conditioning Compressor Hose Replacement (LEA)

Special Tools

J 39400-A Halogen Leak Detector

  1. Recover the refrigerant. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  2. Remove the left headlamp. Refer to «Headlamp Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) , «Headlamp Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
  3. Remove the air conditioning compressor hose nut (1) from the air conditioning evaporator thermal expansion valve tube hose.
  4. Remove the air conditioning compressor hose from the air conditioning evaporator thermal expansion valve tube hose.
  5. Remove the compressor hose nut (1) from the condenser.
  6. Remove the compressor hose (2) from the condenser.
  7. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/equinox/ii-2009-2015/remont/ignition-switchsteering-lock/#general-information) .
  8. Disconnect the electrical connector from the air conditioning refrigerant pressure sensor valve.
  9. Remove the compressor hose nut (1) at the compressor.
  10. Remove the compressor hose (2) from the compressor.
  11. Remove the compressor hose from the vehicle.
  12. Remove and discard the sealing washers from the compressor hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  1. Install new seal washers to the compressor hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  2. Install the compressor hose (2) to the compressor.
  3. Install the compressor hose nut (1) to the compressor and tighten the nut to 22 N.m (16 lb ft).
  4. Connect the electrical connector to the air conditioning refrigerant pressure sensor valve.
  5. Lower the vehicle.
  6. Position the compressor hose in the vehicle.
  7. Install a new sealing washer to the air conditioning evaporator thermal expansion valve tube hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  8. Install the air conditioning evaporator thermal expansion valve tube hose to the compressor hose.
  9. Install the compressor hose nut (1) to the air conditioning evaporator thermal expansion valve tube hose and tighten the nut to 22 N.m (16 lb ft).
  10. Install a new sealing washer to the compressor hose at the condenser. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Install the compressor hose (2) to the condenser.
  12. Install the compressor hose nut (1) to the condenser and tighten to 22 N.m (16 lb ft).
  13. Install the left headlamp. Refer to «Headlamp Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) , «Headlamp Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
  14. Recharge the A/C system. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  15. Test the affected A/C joints for leaks using J 39400-A halogen leak detector.

Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement

Special Tools

J 39400-A Halogen Leak Detector

  1. Recover the refrigerant. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  2. Remove the left headlamp. Refer to «Headlamp Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) , «Headlamp Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
  3. Remove the surge tank. Refer to «Radiator Surge Tank Replacement»(/chevrolet/equinox/ii-2009-2015/remont/cooling-system-mechanical/#engine-cooling-system) .
  4. Remove the washer bottle. Refer to «Windshield Washer Solvent Container Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/wiperwasher-systems/#wiper-system-and-washer-system) , «Windshield Washer Solvent Container Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
  5. Remove the battery. Refer to «Battery Replacement»(/chevrolet/equinox/ii-2009-2015/remont/charging-system/#battery-charging-system-and-starting-system) .
  6. Remove the battery box bolts from the battery box.
  7. Disconnect the negative battery cable nut from the wheelhouse.
  8. Remove the nut retaining the liquid line to the strut tower.
  9. Disconnect the harness and vent hose retainers from the liquid line.
  10. Remove the evaporator outlet hose and liquid line retainer plate nut from the thermal expansion valve (TXV).
  11. Remove the evaporator outlet hose and liquid line from the TXV.
  12. Remove the liquid line nut from the condenser.
  13. Remove the liquid line from the condenser.
  14. Remove the bolt retaining the liquid line to the body.
  15. Position the battery box inboard to allow for routing of the liquid line.
  16. Route the liquid line above the battery box and the ground lug.
  17. Lift the rear portion of the liquid line upward and remove the liquid line from the vehicle.
  18. Remove and discard the sealing washer from the liquid line. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  19. Install protective caps to the condenser, the evaporator outlet hose, and the TXV to prevent contamination and desiccant saturation.
  1. Route the liquid line below the battery box and the ground lug.
  2. Connect the negative battery cable nut to the wheelhouse and tighten to 12 N.m (106 lb in).
  3. Remove the protective caps from the condenser, the evaporator outlet hose, and the TXV.
  4. Install the new sealing washer to the liquid line. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  5. Route the condenser end of the liquid line into position.
  6. Install the liquid line to the condenser.
  7. Install the liquid line nut to the condenser and tighten to 22 N.m (16 lb ft).
  8. Install the bolt to retain the liquid line to the body and tighten to 9 N.m (80 lb in).
  9. Remove the protective cap from the TXV, the liquid line, and the evaporator outlet hose.
  10. Install new seal washers to the liquid line and the evaporator outlet hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Install the liquid line and the evaporator outlet hose to the TXV.
  12. Install the liquid line and evaporator outlet hose retainer plate nut to the TXV and tighten to 22 N.m (16 lb ft).
  13. Install the four battery box bolts to the inside of the battery box and tighten to 15 N.m (11 lb ft).
  14. Install the battery box bolt to the outside of the battery box and tighten to 10 N.m (86 lb in).
  15. Install the battery. Refer to «Battery Replacement»(/chevrolet/equinox/ii-2009-2015/remont/charging-system/#battery-charging-system-and-starting-system) .
  16. Install the liquid line to the strut tower.
  17. Install the liquid line nut to the strut tower and tighten to 9 N.m (80 lb in).
  18. Connect the harness and vent hose retainers to the liquid line.
  19. Install the surge tank. Refer to «Radiator Surge Tank Replacement»(/chevrolet/equinox/ii-2009-2015/remont/cooling-system-mechanical/#engine-cooling-system) .
  20. Install the washer bottle. Refer to «Windshield Washer Solvent Container Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/wiperwasher-systems/#wiper-system-and-washer-system) , «Windshield Washer Solvent Container Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
  21. Install the left headlamp. Refer to «Headlamp Replacement (Equinox)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) , «Headlamp Replacement (Terrain)»(/chevrolet/equinox/ii-2009-2015/remont/exterior-lights/#lighting-system) .
  22. Recharge the A/C system. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  23. Test the affected A/C joints for leaks using J 39400-A Halogen Leak Detector.

Air Conditioning Evaporator Thermal Expansion Valve Hose Replacement

Special Tools

J 39400-A Halogen Leak Detector

  1. Recover the refrigerant. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  2. Remove the air conditioning compressor hose nut (1) from the air conditioning evaporator thermal expansion valve tube hose.
  3. Remove the air conditioning compressor hose from the air conditioning evaporator thermal expansion valve tube hose.
  4. Remove the compressor hose retainer nut (2) from the battery box.
  5. Remove the air conditioning evaporator thermal expansion valve tube hose nut (1) from the thermal expansion valve.
  6. Remove the air conditioning evaporator thermal expansion valve tube hose (2) from the vehicle.
  7. Remove and discard the sealing washers from the air conditioning evaporator thermal expansion valve tube hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  1. Install new seal washers to the air conditioning evaporator thermal expansion valve tube hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  2. Position the air conditioning evaporator thermal expansion valve tube hose in the vehicle.
  3. Install the air conditioning evaporator thermal expansion valve tube hose (2) to the thermal expansion valve.
  4. Install the air conditioning evaporator thermal expansion valve tube hose nut (1) to the thermal expansion valve and tighten the nut to 22 N.m (16 lb ft).
  5. Install a new sealing washer to the air conditioning evaporator thermal expansion valve tube hose at the compressor hose. Refer to «Air Conditioning System Seal Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  6. Install the air conditioning evaporator thermal expansion valve tube hose (2) to the compressor hose.
  7. Install the air conditioning evaporator thermal expansion valve tube hose nut (1) to the compressor hose and tighten to 22 N.m (16 lb ft).
  8. install the compressor hose retainer nut (2) to the battery box and tighten to 22 N.m (16 lb ft).
  9. Recharge the A/C system. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  10. Test the affected A/C joints for leaks using J 39400-A halogen leak detector.
  1. J 39400-A Halogen Leak Detector
  2. J 46246 Valve Core Removal Tool
  1. Recover the refrigerant. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  2. Use J 46246 Valve Core Removal Tool or equivalent to remove the valve core.
  1. Use J 46246 Valve Core Removal Tool or equivalent to install and tighten the valve core.
  2. Evacuate and charge the A/C system. Refer to «Refrigerant Recovery and Recharging»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
  3. Test the affected A/C fittings for leaks using J 39400-A Halogen Leak Detector.

Scheme 4

Scheme 4: Receiver and Dehydrator Replacement
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Remove the radiator air lower baffle and deflector. Refer to Radiator Air Lower Baffle and Deflector Replacement . Remove the radiator air upper baffle and deflector. Refer to Radiator Air Upper Baffle and Deflector Replacement .
1Receiver and Dehydrator Bracket Bolt CAUTION: Refer to Fastener Caution . Tighten 4.2 N.m (37 lb in)
2Receiver and Dehydrator Bracket
3Receiver and Dehydrator Bolt Tighten 6.5 N.m (58 lb in)
4Receiver and Dehydrator Procedure Add the specified amount of polyalkylene glycol (PAG) oil to the receiver dehydrator. Refer to Refrigerant System Specifications Install new O-rings to the receiver dehydrator. Refer to Air Conditioning O-Ring Seal Replacement
CAUTION
Refer to Fastener Caution .

Receiver and Dehydrator Replacement

Scheme 5

Scheme 5: Air Conditioning Evaporator Thermal Expansion Valve Replacement
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Remove the air conditioning condenser and air conditioning evaporator tube from the expansion valve. Refer to Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement .
1Thermal Expansion Valve Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 4.7 N.m (41 lb in)
2Thermal Expansion Valve TIP: Remove and discard the sealing washers. Refer to Air Conditioning System Seal Replacement .
CAUTION
Refer to Fastener Caution .

Air Conditioning Evaporator Thermal Expansion Valve Replacement

Scheme 6

Scheme 6: Air Conditioning Refrigerant Pressure Sensor Valve Replacement (LF1 or LFW)
CalloutComponent Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Disconnect the electrical connector from the refrigerant pressure sensor.
1A/C Refrigerant Pressure Sensor CAUTION: Refer to Fastener Caution . Procedure Remove the refrigerant pressure sensor from the compressor hose. Hand start the refrigerant pressure sensor to the compressor hose, taking care not to pinch the O-ring and tighten. TIP: Lubricate the refrigerant pressure sensor O-ring with mineral oil. Refer to Air Conditioning O-Ring Seal Replacement . Tighten 4 N.m (35 lb in)
CAUTION
Refer to Fastener Caution .

Air Conditioning Refrigerant Pressure Sensor Valve Replacement (LF1 or LFW)

Scheme 7

Scheme 7: Air Conditioning Refrigerant Pressure Sensor Valve Replacement (LEA)
CalloutComponent Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Disconnect the electrical connector from the refrigerant pressure sensor.
1A/C Refrigerant Pressure Sensor CAUTION: Refer to Fastener Caution . Procedure Remove the refrigerant pressure sensor from the compressor hose. Hand start the refrigerant pressure sensor to the compressor hose, taking care not to pinch the O-ring and tighten. NOTE: Lubricate the refrigerant pressure sensor O-ring with mineral oil. Refer to Air Conditioning O-Ring Seal Replacement . Tighten 4 N.m (35 lb in)
CAUTION
Refer to Fastener Caution .
NOTE
Lubricate the refrigerant pressure sensor O-ring with mineral oil. Refer to Air Conditioning O-Ring Seal Replacement .

Air Conditioning Refrigerant Pressure Sensor Valve Replacement (LEA)

Scheme 8

Scheme 8: Evaporator Air Temperature Sensor Replacement
CalloutComponent Name
Preliminary Procedures Remove the Instrument panel insulator panel. Refer to Instrument Panel Insulator Panel Replacement - Right Side (Terrain) , Instrument Panel Insulator Panel Replacement - Right Side (Equinox) . Reposition any wiring or hoses to gain access to evaporator temperature sensor.
1Evaporator Temperature Sensor Procedure Disconnect the wiring connector Rotate sensor 1/4 turn counter clock wise to remove

Evaporator Air Temperature Sensor Replacement

Scheme 9

Scheme 9: Air Conditioning Condenser Replacement
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Remove the radiator air lower baffle and deflector. Refer to Radiator Air Lower Baffle and Deflector Replacement . Remove the radiator air upper baffle and deflector. Refer to Radiator Air Upper Baffle and Deflector Replacement . Remove the air conditioning compressor hose. Refer to Air Conditioning Compressor Hose Replacement (LF1 or LFW) , Air Conditioning Compressor Hose Replacement (LEA) Remove the air conditioning condenser and air conditioning evaporator tube. Refer to Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement
1Air Conditioning Condenser Bolt CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2Air Conditioning Condenser Procedure Add the specified amount of polyalkylene glycol (PAG) oil to the condenser. Refer to Refrigerant System Specifications
CAUTION
Refer to Fastener Caution .

Air Conditioning Condenser Replacement

Scheme 10

Scheme 10: Heater and Air Conditioning Evaporator and Blower Module Replacement
CalloutComponent Name
Preliminary Procedures Remove the intake manifold sight shield. Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Remove the heater inlet hose from the heater core tube. Refer to Heater Inlet Hose Replacement (LEA) , Heater Inlet Hose Replacement (LF1 or LFW) . Remove the heater outlet hose from the heater core tube. Refer to Heater Outlet Hose Replacement (LF1 or LFW) , Heater Outlet Hose Replacement (LEA) . Remove the evaporator hose assembly from the thermal expansion valve. Refer to Air Conditioning Evaporator Thermal Expansion Valve Replacement . Remove the instrument panel carrier. Refer to Instrument Carrier Replacement (Equinox) , Instrument Carrier Replacement (Terrain) .
1Heater and Air Conditioning Evaporator and Blower Module Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2Heater and Air Conditioning Evaporator and Blower Module Procedure With the aid of an assistant, remove the heater and air conditioning evaporator and blower module from the vehicle.
CAUTION
Refer to Fastener Caution .

Heater and Air Conditioning Evaporator and Blower Module Replacement

  1. Remove the HVAC module. Refer to «Heater and Air Conditioning Evaporator and Blower Module Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  2. Remove the heater core cover screws from the evaporator case assembly.
  3. Remove the heater core cover from the evaporator case assembly.
  4. Remove the heater core from the HVAC module.
  5. Remove the evaporator case assembly screws from the blower case assembly.
  6. Remove the evaporator case assembly from the blower case assembly.
  1. Install evaporator case assembly to the blower case assembly.
  2. Install evaporator case assembly screws to the blower case assembly. Tighten Tighten the screws to 1.5 N.m (13 lb in).
  3. Install heater core to the HVAC module.
  4. Install heater core cover.
  5. Install heater core cover screws. Tighten Tighten the screws to 1.5 N.m (13 lb in).
  6. Install the HVAC module. Refer to «Heater and Air Conditioning Evaporator and Blower Module Replacement»(/chevrolet/equinox/ii-2009-2015/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .

Scheme 11

Scheme 11: Air Conditioning Evaporator Core Replacement
CalloutComponent Name
Preliminary Procedures Remove the thermal expansion valve. Refer to Air Conditioning Evaporator Thermal Expansion Valve Hose Replacement Remove the heater and air conditioning evaporator and blower module. Refer to Heater and Air Conditioning Evaporator and Blower Module Replacement . Remove the heater core. Refer to Heater Core Replacement Disconnect the Heater and air conditioning evaporator and Blower module assembly electrical connectors.
1Heater and Air Conditioning Evaporator and Blower Module Case Screw (Qty: 6) CAUTION: Refer to Fastener Caution . Tighten 1.5Y (13 lb in)
2Upper Heater Case.
3Air Conditioning Evaporator Core
CAUTION
Refer to Fastener Caution .

Air Conditioning Evaporator Core Replacement

Scheme 12

Scheme 12: Heater Inlet Hose Replacement (LF1 or LFW)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (GE 47716) , Cooling System Draining and Filling (Static LF1 or LFW) , Cooling System Draining and Filling (Static LAF or LEA) Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement
1Heater Inlet Hose Clamps (Qty 2) Procedure Using J 38185 Hose Clamp Pliers reposition the heater inlet hose. Special Tools J 38185 Hose Clamp Pliers
2Heater Inlet Hose

Heater Inlet Hose Replacement (LF1 or LFW)

Scheme 13

Scheme 13: Heater Inlet Hose Replacement (LEA)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (GE 47716) , Cooling System Draining and Filling (Static LF1 or LFW) , Cooling System Draining and Filling (Static LAF or LEA) Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement
1Heater Inlet Hose Clamps (Qty 2) Procedure Using J 38185 Hose Clamp Pliers reposition the heater inlet hose clamps. Special Tools J 38185 Hose Clamp Pliers
2Heater Inlet Hose

Heater Inlet Hose Replacement (LEA)

Scheme 14

Scheme 14: Heater Outlet Hose Replacement (LF1 or LFW)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (GE 47716) , Cooling System Draining and Filling (Static LF1 or LFW) , Cooling System Draining and Filling (Static LAF or LEA) Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement
1Heater Outlet Hose Clamps (Qty 2) Procedure Using J 38185 Hose Clamp Pliers reposition the heater outlet hose. Special Tools J 38185 Hose Clamp Pliers
2Heater Outlet Hose

Heater Outlet Hose Replacement (LF1 or LFW)

Scheme 15

Scheme 15: Heater Outlet Hose Replacement (LEA)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (GE 47716) , Cooling System Draining and Filling (Static LF1 or LFW) , Cooling System Draining and Filling (Static LAF or LEA) Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement
1Heater Outlet Hose Clamps (Qty 2) Procedure Using J 38185 Hose Clamp Pliers reposition the heater outlet hose clamps. Special Tools J 38185 Hose Clamp Pliers
2Heater Outlet Hose

Heater Outlet Hose Replacement (LEA)

Scheme 16

Scheme 16: Passenger Compartment Air Filter Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to Instrument Panel Compartment Door Replacement (Terrain) , Instrument Panel Compartment Door Replacement (Equinox) .
1Passenger Compartment Air Filter Procedure Release the retainer and open the service lid.

Passenger Compartment Air Filter Replacement

Scheme 17

Scheme 17: Air Inlet Housing Replacement
CalloutComponent Name
Preliminary Procedures Remove the Heater and Air Conditioning Evaporator and Blower Module. Refer to Heater and Air Conditioning Evaporator and Blower Module Replacement . Disconnect the electrical connectors as necessary.
1Air Inlet Housing Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Air Inlet Housing
CAUTION
Refer to Fastener Caution .

Air Inlet Housing Replacement

Scheme 18

Scheme 18: Blower Motor Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel (I/P) insulator panel - right side. Refer to Instrument Panel Insulator Panel Replacement - Right Side (Terrain) , Instrument Panel Insulator Panel Replacement - Right Side (Equinox) . Disconnect the blower motor electrical connector.
1Blower Motor Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Blower Motor
CAUTION
Refer to Fastener Caution .

Blower Motor Replacement

Scheme 19

Scheme 19: Side Window Defogger Outlet Grille Replacement (Equinox)
CalloutComponent Name
1Side Window Defroster Outlet Grilles (Left) Procedure Use a flat bladed plastic trim tool in order to release the side window defroster outlet grille from the instrument panel assembly.
2Side Window Defroster Outlet Grilles (Right) Procedure Use a flat bladed plastic trim tool in order to release the side window defroster outlet grille from the instrument panel assembly.

Side Window Defogger Outlet Grille Replacement (Equinox)

Scheme 20

Scheme 20: Side Window Defogger Outlet Grille Replacement (Terrain)
CalloutComponent Name
1Side Window Defroster Outlet Grilles (Left) Procedure Use a flat bladed plastic trim tool in order to release the side window defroster outlet grille from the instrument panel assembly.
2Side Window Defroster Outlet Grilles (Right) Procedure Use a flat bladed plastic trim tool in order to release the side window defroster outlet grille from the instrument panel assembly.

Side Window Defogger Outlet Grille Replacement (Terrain)

Scheme 21

Scheme 21: Instrument Panel Outer Air Outlet Replacement (Equinox)
CalloutComponent Name
1Instrument Panel Outer Air Outlet (Left) Procedure Use a flat bladed plastic trim tool in order to release the instrument panel outer air outlet from the instrument panel assembly.
2Instrument Panel Outer Air Outlet (Right) Procedure Use a flat bladed plastic trim tool in order to release the instrument panel outer air outlet from the instrument panel assembly.

Instrument Panel Outer Air Outlet Replacement (Equinox)

Scheme 22

Scheme 22: Instrument Panel Outer Air Outlet Replacement (Terrain)
CalloutComponent Name
1Instrument Panel Outer Air Outlet (Left) Procedure Use a flat bladed plastic trim tool in order to release the instrument panel outer air outlet from the instrument panel assembly.
2Instrument Panel Outer Air Outlet (Right) Procedure Use a flat bladed plastic trim tool in order to release the instrument panel outer air outlet from the instrument panel assembly.

Instrument Panel Outer Air Outlet Replacement (Terrain)

Scheme 23

Scheme 23: Instrument Panel Center Air Outlet Replacement (Equinox)
CalloutComponent Name
Preliminary Procedure Remove the Radio Control Assembly. Refer to Radio Control Assembly Replacement .
1Left Instrument Panel Center Air Outlet Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2Left Instrument Panel Center Air Outlet Procedure Slide a flat bladed plastic trim tool along the outward edge of the outlet assembly releasing the retainer tabs securing the outlet to the instrument panel assembly.
3Right Instrument Panel Center Air Outlet Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
4Right Instrument Panel Center Air Outlet Procedure Slide a flat bladed plastic trim tool along the outward edge of the outlet assembly releasing the retainer tabs securing the outlet to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .
CAUTION
Refer to Fastener Caution .

Instrument Panel Center Air Outlet Replacement (Equinox)

Scheme 24

Scheme 24: Instrument Panel Center Air Outlet Replacement (Terrain)
CalloutComponent Name
Preliminary Procedure Remove the Radio Control Assembly. Refer to Radio Control Assembly Replacement .
1Left Instrument Panel Center Air Outlet Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2Left Instrument Panel Center Air Outlet Procedure Slide a flat bladed plastic trim tool along the outward edge of the outlet assembly releasing the retainer tabs securing the outlet to the instrument panel assembly.
3Right Instrument Panel Center Air Outlet Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
4Right Instrument Panel Center Air Outlet Procedure Slide a flat bladed plastic trim tool along the outward edge of the outlet assembly releasing the retainer tabs securing the outlet to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .
CAUTION
Refer to Fastener Caution .

Instrument Panel Center Air Outlet Replacement (Terrain)

  1. Remove the front floor console. Refer to «Front Floor Console Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Slide the center floor air outlet duct forward enough to clear the rear floor air outlet duct, and then up, and rearward to remove.
  1. Slide the center floor air outlet duct forward enough to clear rear floor air duct, and then down, and rearward to install.
  2. Install the front floor console. Refer to «Front Floor Console Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  1. Remove the front seats. Refer to «Driver or Passenger Seat Replacement»(/chevrolet/equinox/ii-2009-2015/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  2. Remove the floor console. Refer to «Front Floor Console Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  3. Partially remove the floor carpet from the front footwells to the B-pillars. Refer to «Front Floor Panel Carpet Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exteriorinterior-trim/#floor-coverings-and-headlinings) .
  4. Remove the rear floor air outlet push pins from the floor pan.
  5. Remove the rear floor air outlet from the floor pan.
  1. Install the rear floor air outlet to the floor pan.
  2. Install the rear floor air outlet push pins to the floor pan.
  3. Install the floor carpet to the B-pillars and the front footwells. Refer to «Front Floor Panel Carpet Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exteriorinterior-trim/#floor-coverings-and-headlinings)
  4. Install the floor console. Refer to «Front Floor Console Replacement»(/chevrolet/equinox/ii-2009-2015/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Install the front seats. Refer to «Driver or Passenger Seat Replacement»(/chevrolet/equinox/ii-2009-2015/remont/seats/#seat-hardware-seat-trim-and-upholstery) .

Scheme 25

Scheme 25: Defroster Valve Replacement
CalloutComponent Name
Preliminary Procedures Remove the HVAC module. Refer to Heater and Air Conditioning Evaporator and Blower Module Replacement . Disconnect all the electrical connectors from components associated with the HVAC module. Remove any components associated with splitting the air distribution case.
1Distribution case fastener (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Split Distribution case
3Defroster Valve
CAUTION
Refer to Fastener Caution .

Defroster Valve Replacement

Scheme 26

Scheme 26: Instrument Panel Center Air Outlet Duct Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim pad retainer. Refer to Lower Trim Pad Retainer Replacement (Equinox) , Lower Trim Pad Retainer Replacement (Terrain) .
1Center Air Outlet Duct Fastener (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Center Air Outlet Duct
CAUTION
Refer to Fastener Caution .

Instrument Panel Center Air Outlet Duct Replacement

Scheme 27

Scheme 27: Air Distributor Outer Duct Replacement - Left Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel retainer. Refer to Lower Trim Pad Retainer Replacement (Equinox) , Lower Trim Pad Retainer Replacement (Terrain) .
1Air Distributor Outlet Duct - Left Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Air Distributor Outlet Duct - Left
CAUTION
Refer to Fastener Caution .

Air Distributor Outer Duct Replacement - Left Side

Scheme 28

Scheme 28: Air Distributor Outer Duct Replacement - Right Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel retainer. Refer to Lower Trim Pad Retainer Replacement (Equinox) , Lower Trim Pad Retainer Replacement (Terrain) .
1Air Distributor Outlet Duct - Right Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Air Distributor Outlet Duct - Right
CAUTION
Refer to Fastener Caution .

Air Distributor Outer Duct Replacement - Right Side

Scheme 29

Scheme 29: Windshield Defroster Duct Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel retainer. Refer to Lower Trim Pad Retainer Replacement (Equinox) , Lower Trim Pad Retainer Replacement (Terrain) .
1Remove Windshield Defroster Duct

Windshield Defroster Duct Replacement

Scheme 30

Scheme 30: Side Window Defogger Outlet Duct Replacement - Left Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel retainer. Refer to Lower Trim Pad Retainer Replacement (Equinox) , Lower Trim Pad Retainer Replacement (Terrain) .
1Side Window Defogger Duct Left Side

Side Window Defogger Outlet Duct Replacement - Left Side

Scheme 31

Scheme 31: Side Window Defogger Outlet Duct Replacement - Right Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower trim panel retainer. Refer to Lower Trim Pad Retainer Replacement (Equinox) , Lower Trim Pad Retainer Replacement (Terrain) .
1Side Window Defogger Duct Right Side

Side Window Defogger Outlet Duct Replacement - Right Side

Scheme 32

Scheme 32: Heater and Air Conditioning Remote Control Replacement (Equinox)
CalloutComponent Name
Preliminary Procedures Remove instrument panel upper trim. Refer to Instrument Panel Assembly Replacement. Instrument Panel Upper Trim Panel Replacement (Terrain) , Instrument Panel Upper Trim Panel Replacement (Equinox)
1Heater and Air Condition Remote Control. Procedure Disconnect the heater and air conditioning control harness connector. Program the heater and air conditioning remote control. Refer to Control Module References .

Heater and Air Conditioning Remote Control Replacement (Equinox)

Scheme 33

Scheme 33: Heater and Air Conditioning Remote Control Replacement (Terrain)
CalloutComponent Name
Preliminary Procedures Remove instrument panel upper trim. Refer to Instrument Panel Assembly Replacement. Instrument Panel Upper Trim Panel Replacement (Terrain) , Instrument Panel Upper Trim Panel Replacement (Equinox)
1Heater and Air Condition Remote Control. Procedure Disconnect the heater and air conditioning control harness connector. Program the heater and air conditioning remote control. Refer to Control Module References .

Heater and Air Conditioning Remote Control Replacement (Terrain)

Scheme 34

Scheme 34: Vent Valve Replacement
CalloutComponent Name
Preliminary Procedures Remove the HVAC module. Refer to Heater and Air Conditioning Evaporator and Blower Module Replacement . Disconnect all the electrical connectors from components associated with the HVAC module. Remove any components associated with splitting the air distribution case.
1Distribution Case Fastener (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Distribution Case
3Vent Valve
CAUTION
Refer to Fastener Caution .

Vent Valve Replacement

Scheme 35

Scheme 35: Heater Core Replacement
CalloutComponent Name
Preliminary Procedure Remove the heater and airconditioning evaporator and blower module. Refer to Heater and Air Conditioning Evaporator and Blower Module Replacement .
1Heater Core Cap Fasteners (Qty: 2)
2Heater Core Cap
3Heater Core Procedure Pull out the heater core.

Heater Core Replacement

Illustration Tool Number / Description J 38185 Hose Clamp Pliers J 41447 R-134a A/C Tracer Dye - Box of 24 J 41459 A/C Oil Injector J 42220 Universal 12V Leak Detection Lamp J 43600 ACR 2000 Air Conditioning Service Center J 43872 Fluorescent Dye Cleaner J 43872 Soapy Water Solution J 45037 A/C Oil Injector J 45268 A/C Flushing Adapter Kit J 46053 Electronic Leak Detector J 46246 Charge Port Valve Core Remover/Installer J 46297 A/C Dye Injector Kit J 46297-12 Replacement Dye Cartridges 7000086I Scan Tool Used for diagnosis of vehicle electrical system

Scheme 36

Scheme 36: Special Tools

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 44

Scheme 44

Scheme 45

Scheme 45

Scheme 46

Scheme 46

See also:
Ambient Air Temperature Display Updating
Symptoms - HVAC Systems - Manual
Symptoms - HVAC Systems - Automatic
Moving Parts and Hot Surfaces Warning
Air Conditioning Compressor Malfunction
Engine Fails To Reach Normal Operating Temperature
Loss of Coolant
Cooling System Leak Testing
Oil Leak Diagnosis
Fastener Caution
Lifting and Jacking the Vehicle
Engine Splash Shield Replacement - Right Side
Drive Belt Replacement
Drive Belt Replacement
Headlamp Replacement (Equinox)
Radiator Surge Tank Replacement
Windshield Washer Solvent Container Replacement (Terrain)
Battery Replacement
Instrument Panel Insulator Panel Replacement - Right Side (Terrain)
Cooling System Draining and Filling (GE 47716)
Cooling System Draining and Filling (Static LF1 or LFW)
Radio Control Assembly Replacement
Driver or Passenger Seat Replacement
Front Floor Panel Carpet Replacement
Control Module References
Refrigerant Recovery and Recharging
Leak Testing
A/C Diagnostics Chart
Air Conditioning (A/C) System Performance Test (LF1 or LFW)
Refrigerant System Specifications
Air Conditioning Compressor Oil Diagnosis
Air Conditioning Compressor Hose Replacement (LF1 or LFW)
Air Conditioning Compressor Hose Replacement (LEA)
Air Conditioning Clutch Drive Plate Adjustment
Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement
Air Conditioning Evaporator Thermal Expansion Valve Hose Replacement
