Seat Belt System Chevrolet Equinox I

Fastener Tightening Specifications

Fastener Tightening Specifications

Seat Belt Schematic Icons

Seat Belt Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 2

Seat Belt Connector End Views

Seat Belt Switch - Left Connector Part Information OEM: 12052832 Service: 12101825 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A TN/WH 5016 Left Seat Belt Switch Signal B D-BU 650 Ground

Diagnostic Starting Point - Seat Belts

Begin the system diagnosis by reviewing the Seat Belt System Description and Operation . Reviewing the description and operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the description and operation information will also help you determine if the condition described by the customer is normal operation.

Refer to Symptoms - Seat Belts in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Front and Rear Seat Belt Retractors

Front and rear seat belt retractors will lock under the following conditions

1. The vehicle exceeds a 15-degree angle
2. The vehicle exceeds 0.60 g of deceleration force
3. The webbing is pulled out of the retractor rapidly
4. During hard cornering or while descending a winding downhill grade
5. While braking to stop at a downhill intersection

All retractors will unlock when 25.4 mm (1 in) of the belt is fed back into the retractor.

Static Test

1. Remove the retractor assembly.
2. Tilt the retractor slowly.
3. Verify that the belt can be pulled out of the retractor at an inclination of 15 degrees or less, but not at an inclination of 45 degrees or more.

Static Test Seat Belts with Child Hold-Out Mechanism (CHOM) Feature

Front Passenger Seat, Rear Outboard Seats

1. Pull the seat belts all the way out of the retractor.
2. Feed a few inches of belt back into the retractor and listen for the audible clicking of the child hold-out mechanism (CHOM) system.
3. Verify that the belt cannot be pulled out of the retractor.
4. Feed the seat belt all of the way into the retractor and verify that the belt returns to normal operating conditions.

Front and Rear Restraints

The front seats and rear seats have a three-point seat belt system with a seat belt retractor. The rear seat latch plate should move up and down easily on the belt. An audible click should be heard when the front or rear latch plate is inserted into the buckle. Inspect the attachment of the latch plate to the buckle by grasping the belt and pulling firmly. The belt should disconnect easily when the button on the buckle is pushed in.

Symptoms - Seat Belts

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the seat belt system. Refer to «Checking Aftermarket Accessories»(/chevrolet/equinox/i-2004-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) in Wiring Systems.
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to the following symptom diagnostic procedure in order to diagnose the symptom

Seat Belt Indicator Circuit Malfunction

Seat Belt Indicator Circuit Malfunction

Seat Belt Indicator Circuit Malfunction

Seat Belt Service Precautions

1. Do not bleach or dye the seat belt webbing. Use only the following items in order to clean the seat belt webbing: A mild soap and water solution A soft brush or cloth
2. Keep sharp edges and damaging objects away from the seat belts. Do not bend or damage any part of the seat belt buckle or latch plate. Replace any seat belts that are cut or otherwise damaged in any manner.
3. Use only the correct seat belt anchor fasteners. Begin tightening the seat belt anchor fasteners by hand in order to ensure that the bolt is threaded straight. Tighten the correct seat belt anchor nut to the correct torque value. Refer to «Fastener Tightening Specifications»(/chevrolet/equinox/i-2004-2009/remont/restraints-control-systems/#seat-belt-system__fastener-tightening-specifications) .
4. Verify that the replacement part number is correct for the vehicle at that seating position. Do not substitute a seat belt from a different seating position.
5. Replace any seat belts that have a visible Caution label instructing replacement.

Repairs and Inspections Required After a Collision

After a minor collision where no automatic restraint device was deployed, seat belt system replacement may not be necessary unless some of the parts are torn, worn, or damaged.

After any collision, verify that the pretentioners on the front seat belt retractor have not deployed.

1. Pull the seat belt webbing.
2. If you hear a grinding or a rattling, replace the retractor.

Removal Procedure

1. Using a small flat-bladed tool, depress the button on the seat buckle quick disconnect while pulling up on the shoulder belt to disengage the shoulder belt from the front seat.
2. Remove the front seat from the vehicle. Refer to «Seat Replacement - Front Bucket»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.
3. On the driver side, using a 90-degree pair of pliers, pull firmly on the recliner and riser handle cover to remove the handle cover.
4. On the passenger side, remove the recliner side cover fastener and remove the cover.
5. Remove the side trim fasteners and remove the side trim.
6. Remove the fastener and remove the shoulder belt quick disconnect.

Installation Procedure

1. Install the shoulder belt quick disconnect. Tighten: Tighten the fasteners to 50 N.m (37 lb ft).
2. Install the side trim with the fasteners. Tighten: Tighten the fasteners to 2.5 N.m (22 lb in).
3. On the passenger side, install the recliner side cover with the fasteners. Tighten: Tighten the fasteners to 2.5 N.m (22 lb in).
4. On the driver side, install the recliner and seat riser covers by firmly pushing on the handle cover.
5. Install the front seat to the vehicle. Refer to «Seat Replacement - Front Bucket»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.
6. Install the shoulder belt into the shoulder belt quick disconnect.

1. Using a small flat-bladed tool, depress the button on the seat buckle quick disconnect while pulling up on the shoulder belt to disengage the shoulder belt from the front seat.
2. Remove the front seat from the vehicle. Refer to «Seat Replacement - Front Bucket»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.
3. Remove the seat belt buckle fastener and remove the seat belt buckle.
4. On the driver side, remove the belt buckle wiring clip from the seat adjuster. Remove the seat belt buckle.

1. Install the seat belt buckle and the fastener to the seat adjuster. Tighten: Tighten the fasteners to 45 N.m (33 lb ft).
2. On the driver side, attach the seat belt wiring clip to the seat adjuster.
3. Install the front seat in the vehicle. Refer to «Seat Replacement - Front Bucket»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.
4. Snap the shoulder belt assembly into the front seat mini-belt buckle.
5. Operate the front seat shoulder belt.

1. Remove the rear seat assembly. Refer to «Seat Replacement - Rear»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.
2. Remove the fastener from the seat belt center buckle.
3. Pull the buckle through the opening gin the seat cushion and remove the buckle.

1. Route the buckle through the openings in the seat cushion.
2. Install the seat belt buckle with the fastener. Tighten: Tighten the fasteners to 50 N.m (37 lb ft).
3. Install the rear seat assembly. Refer to «Seat Replacement - Rear»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.

1. Using a small flat-bladed tool, depress the button on the seat buckle quick disconnect feature while pulling up on the shoulder belt to disengage the shoulder belt from the front seat assembly.
2. Remove the lower garnish molding from the center pillar. Refer to «Garnish Molding Replacement - Center Pillar Lower»(/chevrolet/equinox/i-2004-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
3. Remove the retractor fastener and remove the retractor.
4. Remove the shoulder belt webbing retainer by pulling on the retainer while using a flat-bladed tool to disengage the attaching clips.
5. Remove the shoulder belt from the vehicle.

1. Position the shoulder belt retractor into the center pillar positioning unit with the locking tab in the body structure notch.
2. Install the retractor fastener. Tighten: Tighten the fastener to 45 N.m (33 lb ft).
3. Snap the shoulder belt webbing retainer into the center pillar.
4. Install the lower garnish molding into the center pillar. Refer to «Garnish Molding Replacement - Center Pillar Lower»(/chevrolet/equinox/i-2004-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
5. Install the seat belt to the seat assembly.

1. Remove the rear lower quarter trim. Refer to «Trim Panel Replacement - Rear Quarter Lower»(/chevrolet/equinox/i-2004-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Remove the rear wheel quarter trim panel by pulling at the attaching clip locations.
3. On the driver side, disconnect the auxiliary plug wire harness connection.
4. Remove the shoulder belt fastener at the floor.
5. Remove the retractor fastener and remove the retractor.
6. Unsnap the upper fastener cover and remove the shoulder belt upper fastener. Remove the shoulder belt assembly.

1. Position the retractor into the structure. Verify that the locking tabs are in place. Install the fastener. Tighten: Tighten the fastener to 45 N.m (33 lb ft).
2. Install the shoulder belt upper fastener. Tighten: Tighten the fastener to 45 N.m (33 lb ft).
3. Snap the fastener cover closed.
4. Install the shoulder belt to the floor with the fastener. Tighten: Tighten the fastener to 45 N.m (33 lb ft).
5. On the driver side, connect the auxiliary plug connection.
6. Install the lower quarter trim. Refer to «Trim Panel Replacement - Rear Quarter Lower»(/chevrolet/equinox/i-2004-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
7. Operate the shoulder belt to ensure proper installation.

1. Remove the rear seat assembly. Refer to «Seat Replacement - Rear»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.
2. Remove the seat back cover. Refer to «Seat Back Cover and Pad Replacement - Rear (Passenger Side, 40 Percent)»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) or «Seat Back Cover and Pad Replacement - Rear (Driver Side, 60 Percent)»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.
3. Remove the comfort guide, if equipped.
4. Remove the seat back cover.
5. Feed the seat belt webbing, the bezel, and the anchor plate through the cover.
6. Remove the retractor cover fasteners.
7. Remove the rear shoulder belt fasteners.
8. Pull upward on the retractor unit cover and remove the retractor from the rear seat back frame.

1. Position the retractor into the rear seat back frame and install the fasteners. Tighten: Tighten the fasteners to 45 N.m (33 lb ft).
2. Position the retractor cover over the shoulder belt retractor and install the TORX® fasteners. Tighten: Tighten the fasteners to 20 N.m (15 lb ft).
3. Route the webbing and the escutcheon through the seat back trim cover.
4. Continue to install the seat back trim cover by pressing over the hook and loop locations to ensure proper engagement.
5. Install the seat belt webbing bezel. Tighten: Tighten the rear seat belt center bezel screws to 2.5 N.m (22 lb in).
6. Install the seat back cover. Refer to «Seat Back Cover and Pad Replacement - Rear (Passenger Side, 40 Percent)»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) or «Seat Back Cover and Pad Replacement - Rear (Driver Side, 60 Percent)»(/chevrolet/equinox/i-2004-2009/remont/seats/#seat-system) in Seats.

1. Remove the center pillar upper garnish molding. Refer to «Garnish Molding Replacement - Center Pillar Lower»(/chevrolet/equinox/i-2004-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Remove the fasteners from the shoulder belt height adjuster. Remove the height adjuster.

1. Install the shoulder belt height adjuster with the fasteners. Tighten: Tighten the fasteners to 40 N.m (30 lb ft).
2. Install the center pillar upper garnish molding. Refer to «Garnish Molding Replacement - Center Pillar Lower»(/chevrolet/equinox/i-2004-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim
3. Operate the shoulder belt to ensure proper installation.

1. Fold down the rear seat back.
2. Remove the tether anchor bezel by pulling up at the sides.

1. Install the tether anchor bezel by pushing down on the sides.
2. Move the rear seat back to the upright position.

1. Fold down the rear seat back.
2. Remove the tether anchor escutcheon by pulling up at the sides.
3. Remove the tether anchor fastener and remove the tether anchor.

1. Position the tether anchor onto the rear seat structure.
2. Install the tether anchor fastener. Tighten: Tighten the fastener to 25 N.m (18 lb ft).
3. Install the tether anchor escutcheon.

1. Lower the rear seat assembly.
2. Remove the shoulder belt from the comfort guide.
3. Remove the comfort guide retainer and remove the comfort guide.

1. Install the comfort guide to the rear seat back with the retainer.
2. Install the comfort guide to the shoulder belt assembly.
3. Operate the rear seat shoulder belt assembly to verify proper installation.

Restraint System

Seat belts are the primary means of occupant restraint. Seat belts help to keep the occupants inside the passenger compartment and to gradually reduce the impact forces during the following events

1. Frontal impact type crashes
2. Rear impact type crashes
3. Side impact type crashes
4. Roll-over type crashes

All seat belt retractors have emergency locks. The retractors remain unlocked during normal operation and under normal driving conditions. The retractors remain unlocked during normal conditions in order to allow free movement of the upper body of each occupant. A pendulum locks the seat belt webbing into position. The pendulum causes a locking bar to engage a cog on the spool of the retractor mechanism when the following conditions occur

1. A rapid extraction of the seat belt webbing from the retractor
2. An abrupt change in vehicle speed
3. An abrupt change in vehicle direction
4. Operation of the vehicle on a steep upgrade
5. Operation of the vehicle on a steep downgrade

This vehicle is also equipped with a supplemental inflatable restraint (SIR) system. Refer to SIR System Description and Operation in SIR.

The front seat belt system includes a driver and a passenger inflatable restraint seat belt retractor and buckle. For additional information on seat belt pretensioners, refer to SIR System Description and Operation in SIR.

The driver seat belt system includes a seat belt switch in the driver seat buckle which controls a reminder lamp and a tone alarm.

1. When the driver seat belt is buckled, the driver door is closed, and the ignition switch is turned ON, the following events will occur: The tone alarm will not operate. The reminder lamp will not operate.
2. When the driver seat belt is not buckled, the driver door is closed, and the ignition switch is in ON position, the following events will occur: The tone alarm will operate for 4 to 8 seconds and then go OFF. The fasten safety belt indicator will turn ON for 20 seconds, until the driver seat belt is buckled.

The rear seat belt system includes the following components

1. The rear seat belt retractor is located under the rear shelf trim panel and is attached to the rear shelf body panel.
2. The center rear seat belt buckle and the outer seat belt buckle are located in the center of the seat cushion. The seat belt buckles are attached to the rear floor pan.

Child Seat Restraint System

The child seat may only be used in a forward facing seating location. The child seat should be installed and secured according to the manufacturer's directions. If the child seat has a top strap, the seat will need to be anchored. Passengers should not be allowed to sit at locations where the seat belts are being used to secure the child seat.

This seat belt system has an automatic locking (cinch) feature. Use of the cinch feature is recommended for securing a child seat. The cinch feature is activated when the seat belt webbing is completely extended from the retractor. The cinch feature prevents the webbing from extending beyond the position from which it is allowed to retract. The cinch feature may be cancelled by allowing the webbing to wind back completely into the retractor. After the cinch feature is cancelled, the webbing will extend from the retractor.

If a child seat is to be used in the second seat position, a special dealer-installed anchor must be used in order to anchor the child seat top strap. (This only applies to the seats designed with the top strap provision and for the vehicles sold in Canada). In order to ensure the correct top strap angle, the child seat is only to be used at the seating position for which the top strap anchor is installed.

Fasten Safety Belt Indicator (Red)

The fasten safety belt indicator may only be ON during RUN. The instrument panel cluster (IPC) illuminates the fasten safety belt indicator under the following conditions

1. The inflatable restraint sensing and diagnostic module (SDM) detects that the driver seat belt is unbuckled. The IPC receives a Class 2 message from the SDM requesting illumination. The IPC illuminates the indicator for 20 seconds and then flashes the indicator for 55 seconds. If the driver seat belt is buckled anytime during this function, a Class 2 message shall be sent to the IPC to command the telltale OFF. The SDM also sends a Class 2 message to the IPC in order to activate an audible warning.
2. The IPC performs the displays test at the start of each ignition cycle. The indicator illuminates for approximately 3 seconds.
