Accessory Power Socket Chevrolet Equinox I

Body Electrical 2 illustrations ~327 words

Scheme 101

Scheme 101: Cigar Lighter/Auxiliary Outlets Schematics
Scheme 101: Cigar Lighter/Auxiliary Outlets Schematics

Scheme 102

Scheme 102: Power Outlet Component Views
Scheme 102: Power Outlet Component Views
CalloutComponent Name
1Auxiliary Power Outlet - Rear
2Auxiliary Power Outlet - Front
3Cigar Lighter

Power Outlet Connector End Views

Auxiliary Power Outlet - Front Connector Part Information OEM: 12176836 Service: 15305923 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 340 Battery Positive Voltage B - - Not Used C BK 650 Ground

Auxiliary Power Outlet - Rear Connector Part Information OEM: 12176836 Service: 15305923 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 1840 Battery Positive Voltage B - - Not Used C BK 850 Ground

Cigar Lighter Connector Part Information OEM: 12176836 Service: 15305923 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 840 Battery Positive Voltage B - - Not Used C BK 650 Ground

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools .

Removal Procedure

  1. Remove the fuse located in the instrument panel (I/P) fuse block.
  2. Lift the tether cap and locate 2 square holes in the receptacle.
  3. Hold J 42059 at a 30 degree angle as you insert the tool into the receptacle. See «Special Tools»(/chevrolet/equinox/i-2004-2009/remont/body-electrical/#accessory-power-socket__special-tools) .
  4. Position one side of the tool in each hole.
  5. Pull the receptacle straight out.
  6. Disconnect the connector and remove the receptacle.

Installation Procedure

  1. Connect the receptacle connector.
  2. Push the receptacle into the side trim.
  3. Install the fuse.

J 42059 Cigar Lighter Socket Remover. See Special Tools .

  1. Remove the fuse located in the instrument panel (I/P) fuse block.
  2. Lift the tether cap and locate 2 square holes in the receptacle.
  3. Hold J 42059 at a 30 degree angle as you insert the tool into the receptacle. See «Special Tools»(/chevrolet/equinox/i-2004-2009/remont/body-electrical/#accessory-power-socket__special-tools) .
  4. Position one side of the tool in each hole.
  5. Pull the receptacle straight out.
  6. Disconnect the connector and remove the receptacle.
  1. Connect the receptacle connector.
  2. Push the receptacle into the side trim.
  3. Install the fuse.

Special Tools

Special Tools Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
