Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Drivetrain and Front Suspension Frame Bolt Front | 160 | 118 lb ft |
| Drivetrain and Front Suspension Frame Bolt Rear | 160 | 118 lb ft |
| Front Compartment Insulator Bolt | 3 | 27 lb in |
| Front Compartment Splash Shield Bolt | 3 | 27 lb in |
| Front Wheelhouse Liner Bolt | 2.5 | 22 lb in |
| Intermediate Steering Shaft Lower Bolt | 34 | 25 lb ft |
| Power Steering Fluid Cooling Pipe Bolt | 9 | 80 lb in |
| Power Steering Inlet and Outlet Hose Bolt | 11 | 97 lb in |
| Rear Wheelhouse Liner Bolt | 2.5 | 22 lb in |
| Stabilizer Shaft Link Nut (1) | 65 | 48 lb ft |
| Steering Linkage Tie Rod Nut | 65 | 48 lb ft |
| Transmission Front Mount Bolt | 100 | 74 lb ft |
| Transmission Rear Mount Bracket Bolt | 100 | 74 lb ft |
| (1) = Use new fastener |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Engine Shield Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . |
| 1 | Engine Shield Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 40 N.m (30 lb ft) |
| 2 | Engine Shield |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Engine Shield Replacement
Scheme 2
Scheme 2: Front Compartment Insulator Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . |
| 1 | Front Compartment Insulator Screw (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in) |
| 2 | Front Compartment Insulator Plastic Retainer (Qty: 5) |
| 3 | Front Compartment Insulator |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Front Compartment Insulator Replacement
