HVAC System - Automatic: Specifications Chevrolet Cruze I facelift

Automatic HVAC System 4 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Conditioning Control Module Bolt2.5 N.m22 lb in
Air Conditioning Module Wiring Harness Bolt5 N.m44 lb in
Air Inlet Housing Bolt2.5 N.m22 lb in
Air Inlet Valve Actuator Bolt2.5 N.m22 lb in
Instrument Panel Tie Bar Bolts22 N.m16 lb ft
Instrument Panel Tie Bar Nuts9 N.m80 lb in
Mode Control Cam Actuator Screw2.5 N.m22 lb in
Mode Valve Actuator Bolt2.5 N.m22 lb in
Temperature Valve Actuator Bolt2.5 N.m22 lb in

Fastener Tightening Specifications

Scheme 45

Scheme 45: Module Power and Ground, Blower Control, and Serial Data Wiring Schematics
Scheme 45: Module Power and Ground, Blower Control, and Serial Data Wiring Schematics

Scheme 46

Scheme 46: Air Delivery and Temperature Controls
Scheme 46: Air Delivery and Temperature Controls

Scheme 47

Scheme 47: Compressor Controls Wiring Schematics
Scheme 47: Compressor Controls Wiring Schematics

Scheme 48

Scheme 48: Temperature Sensors Wiring Schematics
Scheme 48: Temperature Sensors Wiring Schematics
