Drive Belt Routing Chevrolet Corvette C4

Accessory Drive Belts 3 illustrations

BELT ADJUSTMENT SPECIFICATIONS

For information on serpentine belt alignment and belt tensioner indicator marks (Scheme 1)and (Scheme 2). For serpentine belt routing (Scheme 3)

ApplicationTension Lbs. (kg) (1)
Serpentine Belt (2)
5.7L (VIN 7)99-121 (45-55)
5.7L (VIN 8)60-90 (27-41)
(1) Specifications are for new belts only. Measure tension with belt tension gauge. (2) Engines with serpentine belts have automatic tensioner. If tension reading is not as specified, check belt's operating length or tensioner's operating range. Replace belt as necessary.
(1)Specifications are for new belts only. Measure tension with belt tension gauge.
(2)Engines with serpentine belts have automatic tensioner. If tension reading is not as specified, check belt's operating length or tensioner's operating range. Replace belt as necessary.

BELT ADJUSTMENT

Scheme 1

Scheme 1: Aligning Serpentine Belt
Scheme 1: Aligning Serpentine Belt

Scheme 2

Scheme 2: Identifying Serpentine Belt Tensioner Marks (Typical)
Scheme 2: Identifying Serpentine Belt Tensioner Marks (Typical)

Scheme 3

Scheme 3: Serpentine Belt Routing (5.7L Corvette)
Scheme 3: Serpentine Belt Routing (5.7L Corvette)
