Seat Belt System Chevrolet Colorado I

Restraints Control Systems 3 illustrations ~4770 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Child Seat Restraint Bracket Bolt52.5 N.m39 lb ft
Front Seat Belt Anchor Bolt52.5 N.m39 lb ft
Front Seat Belt Buckle Bolt55 N.m41 lb ft
Front Seat Belt Retractor/Pretensioner Bolt52.5 N.m39 lb ft
Front Seat Belt Shoulder Adjuster Bolt52.5 N.m39 lb ft
Front Seat Belt Upper Guide Bolt52.5 N.m39 lb ft
Front Seat Mounting Bolt52.5 N.m39 lb ft
Rear Bench Seat Mounting Nut52.5 N.m39 lb ft
Rear Center Seat Belt Bolt52.5 N.m39 lb ft
Rear Seat Belt Anchor Bolt52.5 N.m39 lb ft
Rear Seat Belt Retractor Bolt52.5 N.m39 lb ft
Rear Seat Belt Upper Guide Bolt52.5 N.m39 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Seat Belt Schematics
Scheme 1: Seat Belt Schematics

Diagnostic Starting Point - Seat Belts

Begin the system diagnosis by reviewing the Seat Belt System Description and Operation . Reviewing the Description and Operation will help identify the correct symptom diagnostic procedure when a malfunction exists. The Description and Operation will also assist in determining if the condition described by the customer is normal system operation. Refer to Symptoms - Seat Belts in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Operational and Functional Checks

IMPORTANTIf the vehicle has been in a collision, refer to Repairs and Inspections Required After a Collision for additional information.

Perform the following inspection from the driver seat

  1. Turn the ignition switch to the ON position. Verify proper operation of the seat belt reminder lamp with the belt buckled and with the belt unbuckled.
  2. Inspect the shoulder belt guide in order to ensure that the following conditions are met: The shoulder belt guide swivels freely. The seat belt webbing is seated flatly in the guide slot. The seat belt webbing does not bind.
  3. Verify that the seat belt buckle faces inboard and is accessible.
  4. Verify that the seat belt retractor units are securely attached.
  5. Verify that the seat belt anchor bolts are secure.
  6. Fully extend the seat belt webbing. Verify that the seat belt webbing does not have any twists or tears.
  7. Allow the seat belt webbing to retract. Verify that the seat belt webbing returns freely and completely back into the retractor. If the seat belt webbing will not retract, refer to «Seat Belt Does Not Retract»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system__seat-belt-does-not-retract) .
  8. Snap the seat belt latch plate into the buckle.
  9. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  10. Push the button on the buckle: Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Repeat the inspection procedure, steps 2-10, from the front passenger seat.

Test the function of the automatic locking child restraint feature, if equipped

  1. To engage the automatic locking feature, pull the belt to the fully extended position. Allow the belt to retract to the proper position for the child seat and fasten the latch plate to the buckle. As the belt retracts, a ratcheting sound should be heard.
  2. To disengage the automatic locking feature, allow the belt to retract to the fully stowed position. Before the belt is completely stowed, the cinch feature will reset, the ratcheting sound will stop and the belt will extract freely.

Perform the following steps in order to inspect the center seat belts

  1. Verify that the center seat belts are accessible.
  2. Verify that the center seat belts have no twists or tears in the webbing.
  3. Snap the center seat belt latch plate into the buckle.
  4. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  5. Push the button on the buckle: Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Repeat the inspection procedure, steps 2-10, from the rear seats.

Repeat the center seat belt inspection procedure, steps 1-5, from the rear seat.

Emergency Locking Retractors

CAUTIONPerform this test in an area clear of other vehicles or obstructions. Do not conduct this test on the open road. A large, empty parking lot is suitable. Failure to observe this precaution may result in damage to the vehicle and possible personal injury.

Scheme 2

Scheme 2
Scheme 2
  1. Fasten the seat belts, an assistant is needed when the retractor under test is not part of the driver seat belt.
  2. Accelerate the vehicle slowly to 16 km/h (10 mph) and apply the brakes firmly.
  3. Verify that the seat belt locks when braking firmly.
  4. If the belt does not lock, proceed with the following steps: Remove the seat belt retractor assembly. Tilt the seat belt retractor slowly. Ensure that the seat belt webbing can be pulled from the retractor at an inclination of 15 degrees or less and cannot be pulled from the retractor at an inclination of 60 degrees or more. If the seat belt retractor does not operate as described, replace the retractor assembly. Refer to the following procedures: «Front Seat Belt Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system) or «Front Seat Belt Replacement (Regular and Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system) «Rear Seat Belt Replacement»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system)

Symptoms - Seat Belts

IMPORTANTReview the seat belt system description and operation in order to familiarize yourself with the system and how it functions. Refer to Seat Belt System Description and Operation .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the seat belt system. Refer to «Checking Aftermarket Accessories»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__checking-aftermarket-accessories) .
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

  1. Refer to «Seat Belt Indicator Circuit Malfunction - Driver»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system) in order to diagnose the symptom.
  2. Refer to «Seat Belt Indicator Circuit Malfunction - Passenger»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system) in order to diagnose the symptom.

Seat Belt Does Not Retract

  1. Grab the seat belt webbing and slowly and firmly extract 15-25 mm (5/8-1 in) of webbing from the seat belt.
  2. Release the seat belt and allow the webbing to slowly retract back into the retractor.
  3. Check to see if the seat belt is released. If the seat belt is not released, repeat steps 1 and 2, two times more.
  4. If the retractor does not release after repeating the steps, replace with a new retractor.

Diagnostic Instructions

  1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/colorado/i-2004-2012/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-system-check-vehicle) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/colorado/i-2004-2012/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/colorado/i-2004-2012/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Circuit/System Description

The inflatable restraint sensing and diagnostic module (SDM) sends the status of the driver seat belt switch to the instrument panel cluster (IPC) via a serial data communication message. If the seat belt is unfastened, the SDM will send a message to the IPC to illuminate the fasten safety belt indicator for 72 seconds or until the seat belt is fastened.

Reference Information

Schematic Reference

Connector End View Reference

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information.

Circuit/System Testing

  1. Observe the fasten seat belt indicator located in the IPC. Turn ON the ignition and use the scan tool. Buckle the driver seat belt and monitor the Driver Side Belt Status parameter in the SIR scan tool data list in the scan tool. Verify that the Seat Belt indicator turns ON while the scan tool shows the driver seat belt is buckled. If the scan tool displays the driver seat belt is buckled and the driver seat belt indicator does not turn ON, replace the IPC.
  2. Sit in the front driver seat with the ignition ON and with a scan tool. Monitor the scan tool and while buckling and unbuckling the driver seat belt, verify the scan tool is showing the driver seat belt is buckling and unbuckling. If the scan tool indicates that the driver seat belt does perform as described, turn OFF the ignition, remove the SDM connector and the driver seat belt buckle connector. Test and repair both seat belt switch - left signal and ground circuit for an open, high resistance or replace the seat belt switch - left.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Front Seat Belt Buckle Replacement»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system)
  2. «Control Module References»(/chevrolet/colorado/i-2004-2012/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for SDM and IPC replacement, setup, and programming
  1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/colorado/i-2004-2012/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-system-check-vehicle) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/colorado/i-2004-2012/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/colorado/i-2004-2012/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The inflatable restraint sensing and diagnostic module (SDM) sends the status of the passenger seat belt switch to the Passenger Air Bag ON/OFF indicator via a serial data communication message. The instrument panel cluster (IPC) controls the passenger seat belt indicator by using the serial data communication message from the SDM. If the seat belt is unfastened, only if an occupant is seated in the front passenger seat, the SDM will send a message to the IPC to illuminate the fasten safety belt indicator for 72 seconds or until the seat belt is fastened.

Schematic Reference

Connector End View Reference

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__testing-for-intermittent-conditions-and-poor)
  4. «Wiring Repairs»(/chevrolet/colorado/i-2004-2012/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information.

Circuit/System Verification

IMPORTANTWhen removing connectors inspect for damage or corrosion. Damage or corrosion in the following requires repair or replacement of the affected component/connector. The seat belt switch - right The SDM module The seat belt switch - right wiring harness connector The SDM wiring harness connector
  1. Observe the Passenger Air Bag ON/OFF status indicator located in the instrument panel (I/P). Turn ON the ignition, both ON and OFF indicators will turn ON for 5 seconds. Verify that the Passenger Air Bag ON/OFF status indicator illuminates. If the Passenger Air Bag ON/OFF status indicator does not illuminate, refer to «Passenger Presence System Indicator Circuit Malfunction»(/chevrolet/colorado/i-2004-2012/remont/airbag/#supplemental-inflatable-restraint-system) .
  2. Sit in the front passenger seat with the ignition ON and observe the Passenger Air Bag ON/OFF indicator, which contains the passenger seat belt indicator. Monitor the passenger seat belt indicator while buckling and unbuckling the passenger seat belt. The passenger seat belt indicator should turn OFF and ON when the passenger seat belt is unbuckled and buckled. Verify that the passenger seat belt indicator turns ON and OFF. If the indicator does perform as described, turn OFF the ignition, then remove the SDM connector and the passenger seat belt buckle connector. Refer to SDM replacement in Repair Instructions for connector location. Test and repair both seat belt switch - right signal and ground circuit for an open, high resistance. If both circuits test normal then replace the seat belt switch - right.
  3. Ignition OFF, remove the IPC connector and the Passenger Air Bag ON/OFF connector. Refer to «Accessory Switch Replacement»(/chevrolet/colorado/i-2004-2012/remont/gauges-instrument-panels/#instrument-panel-system-displays-gages) . Test the Passenger Seat Belt Indicator Control circuit between the IPC and the passenger Air Bag ON/OFF connector for an open or high resistance. Verify that an open or high resistance does not exist. If any of the above conditions are found, make the appropriate repair.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Front Seat Belt Buckle Replacement»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system)
  2. «Accessory Switch Replacement»(/chevrolet/colorado/i-2004-2012/remont/gauges-instrument-panels/#instrument-panel-system-displays-gages)
  3. «Control Module References»(/chevrolet/colorado/i-2004-2012/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for SDM and BCM replacement, setup, and programming

Seat Belt Service Precautions

  1. Do not bleach or dye the seat belt webbing. Use only the following items in order to clean the seat belt webbing: A mild soap and water solution A soft brush or cloth
  2. Keep sharp edges and damaging objects away from the seat belts. Do not bend or damage any part of the seat belt buckle or latch plate. Replace any seat belts that are cut or otherwise damaged in any manner.
  3. Use only the correct seat belt anchor fasteners. Begin tightening the seat belt anchor fasteners by hand in order to ensure that the bolt is threaded straight. Tighten the correct seat belt anchor nut to the correct torque value. Refer to «Fastener Tightening Specifications»(/chevrolet/colorado/i-2004-2012/remont/restraints-control-systems/#seat-belt-system__fastener-tightening-specifications) .
  4. Some seat belts and retractors require service as a set with service replacement components only. Do not repair individual components that require service as a set.
  5. Verify that the replacement part number is correct for the vehicle at that seating position. Do not substitute a seat belt from a different seating position.
  6. Replace any seat belts that have a visible Caution label instructing replacement.
  7. Some seat belts have an Energy Management Loop. An Energy Management Loop is an overlap of the seat belt webbing that is stitched together. If any separated stitching exists, replace the seat belt.

Repairs and Inspections Required After a Collision

CAUTIONRestraint systems can be damaged in a collision. To help avoid injury and ensure that all parts in need of replacement are replaced: Replace any seat belt system that was in use during the collision serious enough to deploy any automatic restraint device such as air bags and seat belt pretensioners. This not only includes seat belt systems in use by people of adult size, but seat belt systems used to secure child restraints, infant carriers and booster seats, including LATCH system and top tether anchorages. Replace any seat belt system that has torn, worn, or damaged components. This not only includes adult seat belt systems, but built-in child restraints and LATCH system components, if any. Replace any seat belt system if you observe the words "REPLACE" or "CAUTION", or if a yellow tag is visible. Do not replace a seat belt if only the child seat caution label is visible. Replace any seat belt system if you are doubtful about its condition. This not only includes adult seat belt systems, but built-in child restraints, LATCH system components, and any restraint system used to secure infant carriers, child restraints, and booster seats. Do NOT replace single seat belt system components in vehicles that have been in a collision as described above. Always replace the entire seat belt system with the buckle, guide and retractor assembly, which includes the latch and webbing material.

After a minor collision where no automatic restraint device was deployed, seat belt system replacement may not be necessary, unless some of the parts are torn, worn, or damaged.

Scheme 3

Scheme 3: Seat Belt Latch Stop Installation
Scheme 3: Seat Belt Latch Stop Installation
CalloutComponent Name
Preliminary Procedure Locate the hole in the seat belt webbing where the original seat belt stop button was located. If the original hole in the seat belt webbing is not visible, perform the following: If either the right or left stop button is missing use the opposing seat belt as a reference. With the opposing seat belt fully stowed, measure the distance between the seat belt lower anchor and the stop button. Using the measurement obtained above, measure and mark the location of the missing stop button on the center of the seat belt webbing. Ensure the seat belt latch plate is located above the mark or original hole.
1Seat Belt Stop Button Procedure Work the male half of the stop button through the hole in the webbing or at the marked location. Align the female half of the stop button with the male half of the stop button. Snap the two halves together. Trim off any access of the male half of the stop button flush with the female half of the stop button. Tip: Ensure the male half of the stop button is facing forward in the vehicle in order to ensure the stop button will not snag customers clothing.

Seat Belt Latch Stop Installation

Removal Procedure

  1. Remove the seat from the vehicle. Refer to «Front Seat Replacement - Bucket»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Split Bench Seat Replacement»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  2. Disconnect the seat belt buckle electrical connector (1).
  3. Remove the bolt (2) securing the seat belt buckle assembly (1) to the seat adjuster.
  4. Pull the seat belt buckle assembly (1) out though the opening in the seat cushion.

Installation Procedure

  1. Install the seat belt buckle assembly (1) through the seat cushion pad.
  2. Install the seat belt buckle assembly (1) to the seat adjuster with the bolt (2). Tighten: Tighten the front seat belt buckle bolt to 55 N.m (41 lb ft).
  3. Connect the seat belt buckle electrical connector (1).
  4. Install the seat from the vehicle. Refer to «Front Seat Replacement - Bucket»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Split Bench Seat Replacement»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  1. Remove the rear inboard seat bolt from the driver seat.
  2. Remove the grommet securing the center seat belt buckle assembly (1) to the seat adjuster.
  3. Remove the center seat belt buckle assembly (1).
  1. Position the seat belt buckle assembly (1) over the rear inboard seat adjuster mounting hole.
  2. Install the front seat mounting bolt (2). Tighten: Tighten the front seat mounting bolt to 52.5 N.m (39 lb ft).
  1. Remove the rear bench seat from the vehicle. Refer to «Rear Bench Seat Replacement»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  2. Remove the grommet securing the rear seat belt buckle assembly to the seat.
  3. Remove the rear seat belt buckle assembly from the seat cushion.
  1. Install the rear bench seat in the vehicle. Refer to «Rear Bench Seat Replacement»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) . Do not install the rear bench seat mounting nut.
  2. Install the rear seat belt buckle through the seat cushion loop and position the seat belt buckle assembly over the rear bench seat mounting hole.
  3. Install the rear bench seat mounting nut. Tighten: Tighten the rear bench seat mounting nut to 52.5 N.m (39 lb ft).
  1. Remove the rear folding seat from the vehicle. Refer to «Folding Seat Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  2. Remove the rear seat belt buckle assembly (1) from the vehicle.
  1. Position the rear seat belt buckle assembly (1) in the vehicle under the inboard leg (2) of the rear folding seat.
  2. Install the rear folding seat in the vehicle. Refer to «Folding Seat Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/chevrolet/colorado/i-2004-2012/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  2. Open the front seat belt upper guide shoulder bolt trim cover.
  3. Remove the front seat belt upper guide shoulder bolt.
  4. Remove the lower center pillar trim panel. Refer to «Center Pillar Lower Trim Panel Replacement»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  5. Remove the front seat belt anchor bolt.
  6. Disconnect the electrical connector from the retractor/pretensioner.
  7. Remove the bolt that retains the seat belt retractor/pretensioner assembly to the body.
  8. Remove the front seat belt assembly from the vehicle.
  1. Position the rear seat belt retractor/pretensioner assembly to the vehicle.
  2. Install the bolt which retains the seat belt retractor/pretensioner assembly to the body. Tighten: Tighten the front seat belt retractor/pretensioner bolt to 52.5 N.m (39 lb ft).
  3. Connect the electrical connector to the retractor/pretensioner.
  4. Install the front seat belt upper guide with the bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the front seat belt upper guide bolt to 52.5 N.m (39 lb ft).
  5. Install the front seat belt upper guide shoulder bolt trim cover.
  6. Install the lower center pillar trim panel. Refer to «Center Pillar Lower Trim Panel Replacement»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  7. Install the front seat belt anchor bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the front seat belt anchor bolt to 52.5 N.m (39 lb ft).
  8. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/chevrolet/colorado/i-2004-2012/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/chevrolet/colorado/i-2004-2012/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  2. Open the front seat belt upper guide shoulder bolt trim cover (4).
  3. Remove the front seat belt upper guide shoulder bolt (5).
  4. Remove the body rear corner trim panel. Refer to «Body Side Rear Lower Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Regular Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) . On extended cab models, the front seat belt retractor/pretensioner is located in the rear door, not the rear corner of the cab.
  5. Remove the front seat belt anchor bolt (2).
  6. Disconnect the electrical connector from the retractor/pretensioner (1).
  7. Remove the bolt (3) that retains the seat belt retractor/pretensioner assembly to the body.
  8. Remove the front seat belt assembly from the vehicle.
  1. Position the rear seat belt retractor/pretensioner assembly to the vehicle.
  2. Install the bolt (3) which retains the seat belt retractor/pretensioner assembly (1) to the body. Tighten: Tighten the seat belt retractor/pretensioner bolt to 52.5 N.m (39 lb ft).
  3. Connect the electrical connector to the retractor/pretensioner.
  4. Install the front seat belt upper guide with the bolt (5). Ensure that the seat belt webbing is not twisted. Tighten: Tighten the front seat belt upper guide bolt to 52.5 N.m (39 lb ft).
  5. Install the front seat belt upper guide shoulder bolt trim cover (4).
  6. Install the body rear corner trim panel. Refer to «Body Side Rear Lower Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Regular Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  7. Install the front seat belt anchor bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the front seat belt anchor bolt to 52.5 N.m (39 lb ft).
  8. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/chevrolet/colorado/i-2004-2012/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  1. Remove the rear inboard seat bolt (1) from the passenger seat.
  2. Remove the grommet securing the center seat belt assembly (2) to the seat adjuster.
  3. Remove the center seat belt assembly.
  1. Position the center seat belt assembly (2) over the rear inboard seat adjuster mounting hole.
  2. Install the front seat mounting bolt (1). Tighten: Tighten the front seat mounting bolt to 52.5 N.m (39 lb ft).
  1. Open the rear seat belt upper guide shoulder bolt trim cover.
  2. Remove the rear seat belt upper guide shoulder bolt.
  3. Remove the body rear corner trim panel. Refer to «Body Side Rear Lower Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Regular Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  4. Remove the rear seat belt anchor bolt.
  5. Remove the bolt that retains the seat belt retractor assembly to the body.
  6. Remove the rear seat belt assembly from the vehicle.
  1. Position the rear seat belt retractor assembly to the vehicle.
  2. Install the bolt which retains the seat belt retractor assembly to the body. Tighten: Tighten the rear seat belt retractor bolt to 52.5 N.m (39 lb ft).
  3. Install the rear seat belt upper guide with the bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the rear seat belt upper guide bolt to 52.5 N.m (39 lb ft).
  4. Install the rear seat belt upper guide shoulder bolt trim cover.
  5. Install the body rear corner trim panel. Refer to «Body Side Rear Lower Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Rear Lower Trim Panel Replacement (Regular Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  6. Install the rear seat belt anchor bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the rear seat belt anchor bolt to 52.5 N.m (39 lb ft).
  1. Remove the rear seat shoulder belt guide cover.
  2. Remove the body rear trim panel. Refer to «Body Rear Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Rear Trim Panel Replacement (Regular Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Rear Trim Panel Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  3. Remove the bolt that retains the rear center seat belt assembly to the floor panel.
  4. Remove the rear center seat belt assembly from the vehicle.
  1. Position the rear center seat belt assembly on the floor panel.
  2. Install the bolt which retains the rear center seat belt assembly to the floor. Tighten: Tighten the rear center seat belt bolt to 52.5 N.m (39 lb ft).
  3. Route the rear center seat belt webbing up through the guide loop. Ensure that the seat belt webbing is not twisted.
  4. Install the body rear trim panel. Refer to «Body Rear Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Rear Trim Panel Replacement (Regular Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Rear Trim Panel Replacement (Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  5. Install the rear seat shoulder belt guide cover.
  1. Open the front seat belt upper guide shoulder bolt trim cover.
  2. Remove the front seat belt upper guide shoulder bolt.
  3. Remove the knob (2) from the front seat belt shoulder adjuster (3).
  4. Remove the upper center pillar trim panel (1). Refer to «Center Pillar Upper Trim Panel Replacement»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  5. Remove the 2 bolts securing the adjuster to the vehicle.
  6. Remove the front seat belt shoulder adjuster from the vehicle.
  1. Install the 2 bolts securing the front seat belt shoulder adjuster (3) to the vehicle. Tighten: Tighten the front seat belt shoulder adjuster bolts to 52.5 N.m (39 lb ft).
  2. Install the upper center pillar trim panel (1). Refer to «Center Pillar Upper Trim Panel Replacement»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  3. Install the knob (2) on the front seat belt shoulder adjuster (3).
  4. Install the front seat belt upper guide with the bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the front seat belt upper guide bolt to 52.5 N.m (39 lb ft).
  5. Install the front seat belt upper guide shoulder bolt trim cover.
  1. Remove the knob (2) from the front seat belt shoulder adjuster (1).
  2. Open the front seat belt upper guide shoulder bolt trim cover.
  3. Remove the front seat belt upper guide shoulder bolt.
  4. Remove the rear side access door upper trim panel (3).
  5. Remove the 2 bolts securing the adjuster to the vehicle.
  6. Remove the front seat belt shoulder adjuster from the vehicle.
  1. Install the 2 bolts securing the front seat belt shoulder adjuster (1) to the vehicle. Tighten: Tighten the front seat belt shoulder adjuster bolts to 52.5 N.m (39 lb ft).
  2. Install the rear side access door upper trim panel (3).
  3. Install the front seat belt upper guide with the bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the front seat belt upper guide bolt to 52.5 N.m (39 lb ft).
  4. Install the front seat belt upper guide shoulder bolt trim cover.
  5. Install the knob (2) on the front seat belt shoulder adjuster (1).
  1. Open the front seat belt upper guide shoulder bolt trim cover.
  2. Remove the front seat belt upper guide shoulder bolt.
  3. Remove the knob (2) from the front seat belt shoulder adjuster (1).
  4. Remove the body rear corner upper trim panel (3). Refer to «Body Side Upper Trim Panel Replacement (Regular Cab, Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Upper Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  5. Remove the 2 bolts securing the adjuster to the vehicle.
  6. Remove the front seat belt shoulder adjuster from the vehicle.
  1. Install the 2 bolts securing the front seat belt shoulder adjuster (1) to the vehicle. Tighten: Tighten the front seat belt shoulder adjuster bolts to 52.5 N.m (39 lb ft).
  2. Install the body rear corner upper trim panel (3). Refer to «Body Side Upper Trim Panel Replacement (Regular Cab, Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Upper Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  3. Install the knob (2) on the front seat belt shoulder adjuster (1).
  4. Install the front seat belt upper guide with the bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the front seat belt upper guide bolt to 52.5 N.m (39 lb ft).
  5. Install the front seat belt upper guide shoulder bolt trim cover.
  1. Open the rear seat belt upper guide shoulder bolt trim cover.
  2. Remove the rear seat belt upper guide shoulder bolt.
  3. Remove the knob from the rear seat belt shoulder adjuster (1).
  4. Remove the body rear corner upper trim panel (2). Refer to «Body Side Upper Trim Panel Replacement (Regular Cab, Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Upper Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  5. Remove the 2 bolts securing the adjuster to the vehicle.
  6. Remove the rear seat belt shoulder adjuster from the vehicle.
  1. Install the 2 bolts securing the rear seat belt shoulder adjuster (1) to the vehicle. Tighten: Tighten the rear seat belt shoulder adjuster bolts to 52.5 N.m (39 lb ft).
  2. Install the body rear corner upper trim panel (2). Refer to «Body Side Upper Trim Panel Replacement (Regular Cab, Extended Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) or «Body Side Upper Trim Panel Replacement (Crew Cab)»(/chevrolet/colorado/i-2004-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
  3. Install the knob on the rear seat belt shoulder adjuster (1).
  4. Install the rear seat belt upper guide with the bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the rear seat belt upper guide bolt to 52.5 N.m (39 lb ft).
  5. Install the rear seat belt upper guide shoulder bolt trim cover.
  1. Remove the bolt securing the child seat restraint bracket to the vehicle.
  2. Remove the child seat restraint bracket from the vehicle.
  1. Position the child seat restraint bracket by hooking the 2 tabs on the rear of the bracket into the slots in the vehicle.
  2. Install the bolt which retains the child seat restraint bracket to the vehicle. Tighten: Tighten the child seat restraint bracket bolt to 52.5 N.m (39 lb ft).

Restraint System

Seat belts are the primary means of occupant restraint.

Seat belts help to keep occupants inside the passenger compartment and to gradually reduce the impact forces.

All seat belt retractors have emergency locks. The retractors remain unlocked during normal operation and under normal driving conditions. The retractors remain unlocked during normal conditions in order to allow free movement of the upper body of each occupant.

A pendulum locks the seat belt webbing into position. The pendulum causes a locking bar to engage a cog on the spool of the retractor mechanism when the following conditions occur

  1. A rapid extraction of the seat belt webbing from the retractor
  2. An abrupt change in the vehicle speed
  3. An abrupt change in the vehicle direction
  4. Operation of the vehicle on a steep upgrade
  5. Operation of the vehicle on a steep downgrade

The seat belts, except for the driver seat belt, have an automatic locking feature, or a cinch feature. The cinch feature is recommended for securing a child seat. The cinch feature is engaged by fully extending the seat belt from the retractor. Once engaged, the seat belt can retract, but cannot be extended again until the cinch feature is cancelled. The cinch feature is cancelled when the seat belt has fully retracted.

This vehicle is also equipped with a supplemental inflatable restraint (SIR) system. Refer to SIR System Description and Operation for a description of the seat belt pretensioner system.

The front seat belt system includes the following components

  1. The driver and passenger seat belt buckles, attached to the inboard side of the seat frame
  2. The driver and passenger seat belt pretensioners
  3. The driver and passenger seat belt switch located in the seat belt buckles

There are two fasten safety belt indicators for this vehicle. The driver fasten safety belt indicator is located on the instrument panel cluster (IPC) and the passenger fasten safety belt indicator is located near the center of the instrument panel (I/P). Both indicators are controlled by the IPC at the request of the inflatable restraint sensing and diagnostic module (SDM). The driver and passenger indicators when initiated will illuminate for 20 seconds followed by 55 seconds of flashing. Audible warnings will initiate simultaneously with visual warnings and last for 8 seconds. Subsequently, similar events will occur until the seat belts are buckled or the ignition is returned to the OFF position.

The driver fasten safety belt indicator will illuminate when any of the following occur

  1. The driver seat belt is unbuckled while the ignition is ON.
  2. The driver seat belt remains unbuckled and vehicle speed is greater than 8 km/h (5 mph).
  3. Three minutes after previous seat belt status reminder event
  4. The IPC performs the displays test at the start of each ignition cycle.
IMPORTANTThe front passenger seat is equipped with a passenger presence system (PPS), which detects an occupant. If the PPS detects an empty front passenger seat, then the passenger fasten safety belt indicator will be disabled.

The passenger fasten safety belt indicator will illuminate when any of the following occur

  1. Twenty-five seconds after the ignition is ON and the front passenger seat belt remains unbuckled with passenger present
  2. The front passenger seat belt remains unbuckled with passenger present and vehicle speed is greater than 5 mph (8 km/h).
  3. Three minutes after previous seat belt status reminder event
  4. The IPC performs the displays test at the start of each ignition cycle.

Refer to Symptoms - Seat Belts in order to diagnose faults of the fasten safety belt indicators.
