Power Mirror System Chevrolet Chevy Van G2500

DESCRIPTION & OPERATION

Power mirror assemblies contain 2 motors each. One motor positions the mirror up and down, and the other positions mirror right and left. Reversing polarity of motors will move power mirrors in opposite directions. The power mirror switch is located on the left door trim panel.

TROUBLE SHOOTING

Before proceeding with specific testing, check the following for proper operation

1. Check courtesy light and CTSY (15-amp or 20-amp) fuse for proper operation.
2. Check power seat system operation. Ensure power accessory circuit breaker is okay.
3. Check and ensure grounds are clean and tight.
4. Check for broken or partially broken wire inside insulation, which could cause system malfunction, but prove good in a continuity/voltage check with system disconnected. These circuits may be intermittent or have high resistance when loaded, and if possible, should be checked by monitoring voltage drop with system operational (under load).
5. Check for proper installation of aftermarket electronic equipment.

TESTING

Note. In the following tests, use a self-powered test light unless otherwise specified.

BOTH POWER MIRRORS DO NOT OPERATE

1. Disconnect power mirror switch connector. Connect test light between power mirror switch harness connector terminal "E" (Orange wire) and ground. If test light illuminates, go to next step. If test light does not illuminate, repair open in Orange wire between power mirror switch and instrument panel fuse block.
2. Connect DVOM between power mirror switch harness connector terminal "D" (Black wire) and ground. If test light illuminates, check for poor connection at power mirror switch connector. If connection is okay, replace power mirror switch. If test light does not illuminate, repair poor connection or open in Black wire between power mirror switch and ground.

LEFT POWER MIRROR DOES NOT OPERATE

Disconnect left power mirror connector. Disconnect power mirror switch. Connect test light between left power mirror harness connector terminal "E" (Light Green wire) and power mirror switch connector terminal "H" (Light Green wire). If test light illuminates, replace power mirror switch. If test light does not illuminate, repair open in Light Green wire between power mirror switch and left power mirror.

RIGHT POWER MIRROR DOES NOT OPERATE

Disconnect right power mirror connector. Disconnect power mirror switch. Connect test light between right power mirror harness connector terminal "E" (Light Blue/White wire) and power mirror switch connector terminal "C" (Light Blue/White wire). If test light illuminates, replace power mirror switch. If test light does not illuminate, repair open in Light Blue/White wire between power mirror switch and right power mirror.

LEFT POWER MIRROR DOES NOT OPERATE IN UP/DOWN POSITIONS

1. Disconnect power mirror switch connector. Connect test light between power mirror switch terminals "E" (Orange wire) and "F" (Yellow wire). With left mirror selected, move power mirror switch to up position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
2. Connect test light between power mirror switch terminals "D" (Black wire) and "H" (Light Green wire). Move power mirror switch to up position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
3. Connect test light between power mirror switch terminals "D" (Black wire) and "F" (Yellow wire). Move power mirror switch to down position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
4. Connect test light between power mirror switch terminals "E" (Orange wire) and "H" (Light Green wire). Move power mirror switch to down position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
5. Disconnect left power mirror connector. Connect test light between power mirror switch harness connector terminal "F" (Yellow wire) and left power mirror harness connector terminal "D" (Yellow wire). If test light illuminates, go to next step. If test light does not illuminate, repair open in Yellow wire between power mirror switch and left powermirror.
6. Connect test light between power mirror switch harness connector terminal "H" (Light Green wire) and left power mirror harness connector terminal "E" (Light Green wire). If test light illuminates, replace left power mirror. If test light does not illuminate, repair open in Light Green wire between power mirror switch and left power mirror.

RIGHT POWER MIRROR DOES NOT OPERATE IN UP/DOWN POSITIONS

1. Disconnect power mirror switch connector. Connect test light between power mirror switch terminals "E" (Orange wire) and "B" (Brown/White wire). With right mirror selected, move power mirror switch to up position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
2. Connect test light between power mirror switch terminals "D" (Black wire) and "C" (Light Blue/White wire). Move power mirror switch to up position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
3. Connect test light between power mirror switch terminals "D" (Black wire) and "B" (Brown/White wire). Move power mirror switch to down position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
4. Connect test light between power mirror switch terminals "E" (Orange wire) and "C" (Light Blue/White wire). Move power mirror switch to down position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
5. Disconnect right power mirror connector. Connect test light between power mirror switch harness connector terminal "B" (Brown/White wire) and right power mirror harness connector terminal "D" (Brown/White wire). If test light illuminates, go to next step. If test light does not illuminate, repair open in Brown/White wire between power mirror switch and right power mirror.
6. Connect test light between power mirror switch harness connector terminal "C" (Light Blue/White wire) and right power mirror harness connector terminal "E" (Light Blue/White wire). If test light illuminates, replace right power mirror. If test light does not illuminate, repair open in Light Blue/White wire between power mirror switch and right power mirror.

LEFT POWER MIRROR DOES NOT OPERATE IN LEFT/RIGHT POSITIONS

1. Disconnect power mirror switch connector. Connect test light between power mirror switch terminals "E" (Orange wire) and "G" (Light Blue wire). With left mirror selected, move power mirror switch to left position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
2. Connect test light between power mirror switch terminals "D" (Black wire) and "H" (Light Green wire). Move power mirror switch to left position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
3. Connect test light between power mirror switch terminals "D" (Black wire) and "G" (Light Blue wire). Move power mirror switch to right position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
4. Connect test light between power mirror switch terminals "E" (Orange wire) and "H" (Light Green wire). Move power mirror switch to right position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
5. Disconnect left power mirror connector. Connect test light between power mirror switch harness connector terminal "G" (Light Blue wire) and left power mirror harness connector terminal "F" (Light Blue wire). If test light illuminates, go to next step. If test light does not illuminate, repair open in Light Blue wire between power mirror switch and left power mirror.
6. Connect test light between power mirror switch harness connector terminal "H" (Light Green wire) and left power mirror harness connector terminal "C" (Light Green wire). If test light illuminates, replace left power mirror. If test light does not illuminate, repair open in Light Green wire between power mirror switch and left power mirror.

RIGHT POWER MIRROR DOES NOT OPERATE IN LEFT/RIGHT POSITIONS

1. Disconnect power mirror switch connector. Connect test light between power mirror switch terminals "E" (Orange wire) and "A" (Gray wire). With right mirror selected, move power mirror switch to left position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
2. Connect test light between power mirror switch terminals "D" (Black wire) and "C" (Light Blue/White wire). Move power mirror switch to left position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
3. Connect test light between power mirror switch terminals "D" (Black wire) and "A" (Gray wire). Move power mirror switch to right position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
4. Connect test light between power mirror switch terminals "E" (Orange wire) and "C" (Light Blue/White wire). Move power mirror switch to right position. If test light illuminates, go to next step. If test light does not illuminate, replace power mirror switch.
5. Disconnect right power mirror connector. Connect test light between power mirror switch harness connector terminal "A" (Gray wire) and right power mirror harness connector terminal "F" (Gray wire). If test light illuminates, go to next step. If test light does not illuminate, repair open in Gray wire between power mirror switch and right power mirror.
6. Connect test light between power mirror switch harness connector terminal "C" (Light Blue/White wire) and right power mirror harness connector terminal "C" (Light Blue/White wire). If test light illuminates, replace right power mirror. If test light does not illuminate, repair open in Light Blue/White wire between power mirror switch and right power mirror.

REMOVAL & INSTALLATION

1. Disconnect negative battery cable. Using Door Handle Clip Remover (J-9886-01), remove window regulator handle (if equipped). Remove window regulator handle bezel (if equipped). Remove front garnish. Remove inside door handle bezel.
2. Remove screws and trim plate. Remove armrest screws. Remove trim panel. Disconnect electrical connector. Remove power mirror mounting nuts. Remove power mirror assembly from vehicle. To install, reverse removal procedure. Tighten power mirror mounting nuts to 89 INCH lbs. (10 N.m).
