Fastener Tightening Specifications

Fastener Tightening Specifications

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to SYMPTOMS - POWER STEERING SYSTEM in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Important: The following steps must be completed before using the symptom tables.

Review the system description and operation in order to familiarize yourself with the system functions. Refer to Power Steering System Description and Operation .

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the power steering system.
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
3. Inspect the power steering reservoir for the proper power steering fluid level and condition. Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom
4. «Power Steering Fluid Leaks»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system)
5. «Rattle, Clunk, or Shudder Noise from the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system)
6. «Whine or Growl Noise from the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system)
7. «Steering Effort Hard in One or Both Directions»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system)
8. «Steering Effort Too Easy in One or Both Directions»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system)

Scheme 5

Legend

1. (1) Power Steering Return Hose
2. (2) Power Steering Pressure Hose

Test Description

The numbers below refer to the step numbers on the diagnostic table.

3. This step tests the system for restrictions.

5. This step tests the following components for the following conditions

1. The pump for internal leaks
2. The power steering pipes for kinks

6. This step tests the ability of the pump to regulate flow at maximum pressure.

8. This step tests the ability of the pump to regulate flow under normal operating conditions.

10. This step tests the internal components of the pump and the gear.

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Tools Required

1. J-35555 Metal Mityvac
2. J-43485 Power Steering Bleeder Adapter

Important: Hoses touching the frame, body, or engine may cause system noise.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Verify that the hoses do not touch any other part of the vehicle. Important: Loose connections may not leak, but could allow air into the steering system.
2. Verify that all hose connections are tight. CAUTION: If the power steering system has been serviced, an accurate fluid level reading cannot be obtained unless air is bled from the steering system. The air in the fluid may cause pump damage over a period of time. Important: Maintain the fluid level throughout the bleed procedure.
3. Remove the pump reservoir cap. Important: Use clean, new power steering fluid only.
4. Fill the pump reservoir with fluid to the FULL COLD level.
5. Attach the J-43485 to the J-35555 or equivalent.
6. Place the J-43485 on or in the pump reservoir filler neck.
7. Apply a vacuum of 68 kPa (20 in Hg) maximum.
8. Wait 5 minutes. Typical vacuum drop is 7-10 kPa (2-3 in Hg). If the vacuum does not remain steady, refer to «Excessive Vacuum Drop Diagnosis»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) at the end of this procedure.
9. Remove the J-43485 and the J-35555 .
10. Reinstall the pump reservoir cap.
11. Start the engine. Allow the engine to idle.
12. Turn off the engine.
13. Verify the fluid level. Repeat steps 11-13 until the fluid stabilizes. Important: Do not turn steering wheel to lock.
14. Start the engine. Allow the engine to idle.
15. Turn the steering wheel 180-360 degrees in both directions 5 times.
16. Switch the ignition off. CAUTION: When adding fluid or making a complete fluid change, always use the proper power steering fluid. Failure to use the proper power steering fluid. Failure to use the proper fluid will cause hose and seal damage and fluid leaks.
17. Verify the fluid level.
18. Remove the pump reservoir cap.
19. Attach the J-43485 to the J-35555 or equivalent.
20. Place the J-43485 on or in the pump reservoir filler neck.
21. Apply a vacuum of 68 kPa (20 in Hg) maximum.
22. Wait 5 minutes.
23. Remove the J-43485 and the J-35555 .
24. Verify the fluid level.
25. Reinstall the pump reservoir cap.

Scheme 21

Scheme 22

1. If the vacuum continues to drop, remove the pressure and return hose from the pump.
2. Install the plugs (1,2) supplied with the J-43485 into the pressure and return port.
3. Attach the J-43485 to the J-35555 or equivalent.
4. Place the J-43485 on or in the pump reservoir filler neck.
5. Apply a vacuum of 68 kPa (20 in Hg) maximum.
6. If the vacuum drops again, repair or replace the pump. If the vacuum holds steady, continue to check the other parts of the steering system. Important: Fluid must be free from bubbles and foam. Be aware of periodic bubbles that indicate a loose connection or leaking O-ring seal in the return hose or the pressure hose. Fluid must be free from discoloration.
7. Observe the fluid.
8. If connection persists, replace the following parts: The return hose clamps The return hose O-rings The pressure hose O-rings The gear cylinder line O-rings The reservoir to pump O-ring
9. Repeat the bleed procedure from the beginning.
10. Drive the vehicle approximately 16 km (10 ml) in order to warm the system to operating temperature. Evaluate vehicle on a smooth flat surface.
11. Verify the following conditions: There is smooth power assist. The vehicle operates quietly. The pump maintains the proper fluid level. There is not any leaking in the steering system. The fluid is free of foam or discoloration.

Checking and Adding Power Steering Fluid

1. If the power steering system has been serviced, bleed the power steering system to remove any trapped air from the system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) . Important: The oil level will appear falsely high if the hydro-boost accumulator is not fully charged. Do not apply the brake pedal with the engine off, this will discharge the hydro-boost accumulator.
2. Fully charge the hydro-boost accumulator using the following procedure: Start the engine. Firmly apply the brake pedal 2 to 3 times. Turn the engine Off. Important: The Add and Cold Full marks on the capstick are calculated for oil at ambient temperature. If the oil is hot, the oil level may appear slightly high.
3. Clean the area surrounding the reservoir cap.
4. Remove the reservoir cap. Important: The ideal oil level is between the Add and the Full Cold marks. Since overfilling is just as undesirable as underfilling, there is no reason to fill all they way up to the Full Cold mark.
5. Inspect the power steering pump fluid level at regular intervals. Add fluid when required.
6. If the fluid level is low, add power steering fluid to the proper level.
7. Install the reservoir cap.
8. When checking the fluid level after servicing the steering system, bleed the air from the system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .

Important: Do not reuse any drained power steering fluid regardless of appearance or condition.

1. Turn off the engine.
2. Raise the front end of the vehicle off the ground until the tires and wheels turn freely.
3. Place a large container under the fluid return hose in order to collect the draining fluid.
4. Remove the fluid return hose at the power steering pump reservoir inlet connection.
5. Plug the reservoir return hose inlet connection on the power steering pump. Important: This step may require 4 L (4 qt) of power steering fluid until the draining fluid appears clear. Do not run the engine without the power steering fluid level at FULL COLD.
6. Run the engine at idle while an assistant maintains the fluid level at FULL COLD in the reservoir using new approved power steering fluid.
7. Turn off the engine.
8. Turn the steering wheel fully to the left and to the right.
9. Remove the plug from the pump reservoir inlet connection.
10. Install the fluid return hose to the pump reservoir.
11. Maintain the fluid level at FULL COLD.
12. Operate the engine at idle for approximately 15 minutes.
13. Repeat steps 3 - 5 .
14. Inspect the power steering fluid for the following indications of contamination: Milky fluid - water Brown fluid - burnt Plastic debris or dirt chunks
15. If the fluid is contaminated, repeat steps 6 - 12 in order to complete a third flush.
16. Remove the plug from the pump reservoir inlet connection.
17. Install the fluid return hose to the pump reservoir.
18. Clean any spilled fluid.
19. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .

Scheme 23

Scheme 24

Scheme 25

1. Siphon the power steering fluid from the reservoir.
2. Disconnect the reservoir outlet hose from the reservoir.
3. Remove the reservoir inlet hose (3) from the reservoir.
4. Remove the power steering pump remote reservoir mounting nuts (4).
5. Remove the power steering pump remote reservoir (3).

Scheme 26

Scheme 27

Scheme 28

1. Install the power steering pump remote reservoir (3) to the vehicle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power steering pump remote reservoir (4) mounting nuts. Tighten Tighten the nuts to 6.5 N.m (58 lb in).
3. Install the reservoir inlet hose (3) to the reservoir.
4. Connect the reservoir outlet hose to the reservoir.
5. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .

Power Steering Pulley Replacement

Tools Required

1. J-25033-C Power Steering Pump Pulley Installer
2. J-25034-C Power Steering Pump Pulley Remover

Scheme 29

1. Remove the upper fan shroud. Refer to Fan Shroud Replacement in Engine Cooling .
2. Remove the drive belt. Refer to Drive Belt Replacement in «ENGINE MECHANICAL - 4.3L»(/chevrolet/chevy-express-h2500/2003-2003/remont/mechanical/#engine-mechanical-43l) or Drive Belt Replacement - Accessory or Drive Belt Replacement - Air Conditioning in «ENGINE MECHANICAL - 4.8L, 5.3L & 6.0L»(/chevrolet/chevy-express-h2500/2003-2003/remont/mechanical/#engine-mechanical-48l-53l-60l) .
3. Remove the power steering pump pulley using the J-25034-C .

Scheme 30

Scheme 31

1. Place the power steering pump pulley on the end of the power steering pump shaft.
2. Install the power steering pump pulley using J-25033-C .
3. Ensure that the power steering pump pulley is flush against the power steering pump shaft (2), with an allowable variance of 0.25 mm (0.010 in).
4. Install the drive belt. Refer to Drive Belt Replacement in «ENGINE MECHANICAL - 4.3L»(/chevrolet/chevy-express-h2500/2003-2003/remont/mechanical/#engine-mechanical-43l) or Drive Belt Replacement - Accessory or Drive Belt Replacement - Air Conditioning in «ENGINE MECHANICAL - 4.8L, 5.3L & 6.0L»(/chevrolet/chevy-express-h2500/2003-2003/remont/mechanical/#engine-mechanical-48l-53l-60l) .
5. Install the upper fan shroud. Refer to Fan Shroud Replacement in Engine Cooling .

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Place a drain pan below under the vehicle.
2. Remove the power steering pump pulley. Refer to «Power Steering Pulley Replacement»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-pulley-replacement) .
3. Raise and support the vehicle.
4. Remove the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
5. Disconnect the reservoir outlet hose from the power steering pump through the wheel well.
6. Disconnect the power steering gear outlet hose from the power steering pump through the wheel well.
7. Disconnect the power brake booster inlet hose (2) from the power steering pump (1) through the wheel well.
8. Cap the ends of the hose and the power steering pump in order to prevent the entrance of dirt.
9. Lower the vehicle.
10. Remove the power steering pump mounting bolts and the nuts.
11. Remove the accessory mounting bracket mounting bolts and nut.
12. Pull the accessory bracket forward.
13. Remove the power steering pump from the vehicle.
14. Remove the power steering pump rear bracket mounting nuts.
15. Remove the power steering pump rear bracket.

Installation Procedure

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Install the rear bracket to the power steering pump.
2. Install the power steering pump rear bracket mounting nuts. Tighten Tighten the nuts to 50 N.m (37 lb ft).
3. Install the power steering pump to the vehicle.
4. Install the power steering pump front mounting bolts. Tighten Tighten the bolts to 50 N.m (37 lb ft).
5. Reposition the accessory mounting bracket and install the mounting bolts and nut. Tighten Tighten the bolts and nut to 50 N.m (37 lb ft).
6. Install the power steering pump lower and rear mounting nuts. Tighten Tighten the nuts to 41 N.m (30 lb ft).
7. Uncap the power steering hoses.
8. Raise the vehicle. Important: Route the power steering hoses in the same location in which they were removed.
9. Install the power brake booster inlet hose (2) to the power steering pump through the wheel well. Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
10. Install the power steering gear outlet hose through the wheel well.
11. Install the reservoir outlet hose to the power steering pump through the wheel well.
12. Lower the vehicle.
13. Install the power steering pump pulley. Refer to «Power Steering Pulley Replacement»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-pulley-replacement) .
14. Bleed the system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
15. Remove the drain pan from under the vehicle.

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. Place a drain pan below under the vehicle.
2. Remove the power steering pump pulley. Refer to «Power Steering Pulley Replacement»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-pulley-replacement) .
3. Remove the lower intermediate shaft bolt to the power steering gear retaining bolt.
4. Disconnect the lower intermediate shaft from the power steering gear.
5. Raise and support the vehicle.
6. Remove the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
7. Disconnect the reservoir outlet hose from the power steering pump through the wheel well.
8. Disconnect the power steering gear outlet hose from the power steering pump through the wheel well.
9. Disconnect the power brake booster inlet hose (2) from the power steering pump through the wheel well.
10. Cap the ends of the hose and the pump in order to prevent the entrance of dirt.
11. Lower the vehicle.
12. Remove the rear power steering pump mounting bolt.
13. Remove the front power steering pump mounting bolts.
14. Remove the power steering pump from the vehicle.
15. Remove the power steering pump rear bracket mounting nuts.
16. Remove the power steering pump rear bracket from the power steering pump.

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. Install the power steering pump rear bracket to the power steering pump. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power steering pump rear bracket mounting nuts. Tighten Tighten the nuts to 50 N.m (37 lb ft).
3. Install the power steering pump to the vehicle.
4. Install the front power steering pump mounting bolts. Tighten Tighten the bolts to 50 N.m (37 lb ft).
5. Install the rear power steering pump mounting bolt. Tighten Tighten the bolt to 41 N.m (30 lb ft).
6. Uncap the power steering hoses.
7. Raise the vehicle. Important: Route the power steering hoses in the same location in which they were removed.
8. Install the power brake booster inlet hose (2) to the power steering pump through the wheel well. Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
9. Install the power steering gear outlet hose to the power steering pump through the wheel well.
10. Install the reservoir outlet hose to the power steering pump through the wheel well.
11. Remove the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
12. Lower the vehicle.
13. Connect the lower intermediate shaft to the power steering gear.
14. Install the lower intermediate shaft to the power steering gear retaining bolt. Tighten Tighten the bolt to 61 N.m (45 lb ft).
15. Install the power steering pump pulley. Refer to «Power Steering Pulley Replacement»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-pulley-replacement) .
16. Bleed the system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
17. Remove the drain pan from under the vehicle.

Scheme 56

Scheme 57

Scheme 58

1. Drain the power steering fluid from the power steering pump.
2. Remove the pump mounting studs (2).
3. Remove the connector and fitting assembly (4).
4. Remove the O-ring seal (3) from the connector and fitting assembly (4).
5. If replacement is required, remove the control valve assembly and the flow control spring from the pump housing assembly. Refer to «Power Steering Pump Flow Control Valve Replacement - Off Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
6. Remove the reservoir assembly (1) from the pump housing assembly (2).
7. Remove the O-ring seals (1), (4) and (5).
8. Remove the magnet (3).
9. Clean the magnet (3).
10. Inspect the welch plug in the power steering pump housing (2). Do not remove. If the welch plug is deformed or dislodged, replace the power steering pump.

Assembly Procedure

Important: Use new O-ring seals when assembling the power steering pump assembly.

Scheme 59

Scheme 60

Scheme 61

1. Lubricate the O-ring seals (1), (4) and (5) with power steering fluid.
2. To install the control valve assembly and flow control spring to the pump housing assembly (2). Refer to «Power Steering Pump Flow Control Valve Replacement - Off Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
3. Install the O-ring seals (1), (4) and (5) to the pump housing assembly (2).
4. Install the magnet (3) to the pump housing assembly (2).
5. Connect the reservoir assembly (1) to the pump housing assembly (2).
6. Install the O-ring seal.
7. Install the connector and fitting assembly (4) to the pump housing (1). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
8. Install the pump mounting studs (2) to the pump housing (1). Tighten Tighten the pump mounting studs (2) to 58 N.m (43 lb ft). Tighten the connector and fitting assembly (4) to 75 N.m (55 lb ft).

Scheme 62

1. Drain the oil from the reservoir (1).
2. Remove the connector and fitting assembly (2).
3. Remove the control valve assembly (4) from the pump housing (1). Make sure the flow control spring (5) does not fall out of the pump housing (1).
4. Remove and discard the O-ring seal (3) from the connector and fitting assembly (2).

Scheme 63

1. Install the flow control spring (5), if removed from the pump housing (1).
2. Lubricate the new O-ring seal (3) with power steering fluid.
3. Install the O-ring seal (3) onto the connector and fitting assembly (2).
4. Install the control valve assembly (4). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
5. Install the connector and fitting assembly (2). Tighten Tighten the connector and fitting assembly to 75 N.m (55 lb ft).

Pitman Shaft Seal Replacement - On Vehicle (Non Rack and Pinion)

Tools Required

1. J-4245 Internal Snap Ring Pliers
2. J-6278 Pitman Shaft Bearing Remover and Installer

Scheme 64

Scheme 65

Scheme 66

1. Raise and support the vehicle.
2. Mark the position of the pitman arm to the pitman shaft.
3. Remove the Pitman Arm. Refer to «PITMAN ARM REPLACEMENT»(/chevrolet/chevy-express-h2500/2003-2003/remont/steering-linkage/#steering-linkage-non-rack-pinion__pitman-arm-replacement) .
4. Drain the power steering fluid from the system.
5. Remove the pitman shaft and side cover. Refer to «Steering Gear Pitman Shaft and Housing Cover Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
6. Clean the exposed end of the pitman shaft.
7. Clean the steering gear housing.
8. Use a wire brush to clean the pitman shaft splines.
9. Remove the dust seal (1).
10. Remove the retaining ring using J-4245 . Important : Use care not to score the power steering gear housing bore when prying out the seals and the washers.
11. Use a screwdriver to pry the backup washer (3) and the double lip seal (2) from the power steering gear housing (1).
12. Inspect the power steering gear housing (1) for burrs.
13. Remove the power steering gear housing (1) If necessary.
14. Insert the J-6278 through the hole in the top of the power steering gear housing (1).
15. Drive out the needle bearing (2).

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. Coat the double lip seal (2) and the washer (3) with grease.
2. Install the needle bearing (2) to the power steering gear housing (1) using J-6278 .
3. Install the double lip seal (2).
4. Install the backup washer (3).
5. Install the retaining ring using the J-4245 .
6. Install the pitman shaft and the side cover. Refer to «Steering Gear Pitman Shaft and Housing Cover Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
7. Instal the dust seal (1).
8. Install the Pitman Arm. Refer to «PITMAN ARM REPLACEMENT»(/chevrolet/chevy-express-h2500/2003-2003/remont/steering-linkage/#steering-linkage-non-rack-pinion__pitman-arm-replacement) .
9. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
10. Lower the vehicle.

Tie Rod Replacement - Inner - On Vehicle

Tools Required

J-34028 Inner Tie Rod Wrench

Scheme 71

Scheme 72

Scheme 73

1. Raise and support the vehicle.
2. Remove the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation)
3. Remove the rack and pinion boot. Refer to «Rack and Pinion Boot Replacement - On Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__rack-and-pinion-boot-replacement) . CAUTION: Do not change the rack bearing preload adjustment before removing the inner tie rod from the steering rack. This could cause damage to the pinion of the steering rack or both.
4. Remove the shock dampener (2) from the inner tie rod (5).
5. Slide the shock dampener (2) back onto the power steering gear (1). Important: Do not hold the power steering gear while removing the inner tie rod if the preload adjustment has not been changed.
6. Remove the inner tie rod (2) from the power steering gear (4) as follows: Place J-34028 on the flats of the inner tie rod housing (3) Rotate the inner tie rod housing (3) counterclockwise until the inner tie rod (2) separates from the power steering gear.
7. Remove the old Loctite® from the threads of the power steering gear (1).

Important: Make sure the shock dampener is on the rack before installing the inner tie rod.

The threads must be clean prior to the Loctite® application. Check the Loctite®, or equivalent, container for expiration date. Use only enough Loctite® to evenly coat the threads.

Scheme 74

Scheme 75

Scheme 76

1. Apply Loctite® 262 or equivalent to the inner tie rod threads (2).
2. Install the inner tie rod (3) to the power steering gear (1). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install a torque wrench (1) to the J-34028 to tighten the inner tie rod (2). Tighten Tighten the inner tie rod to 100 N.m (74 lb ft).
4. Slide the shock dampener (2) over the inner tie rod housing (3) until the front lip of the shock dampener bottoms out against the inner tie rod housing.
5. Install the rack and pinion boot. Refer to «Rack and Pinion Boot Replacement - On Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__rack-and-pinion-boot-replacement) .
6. Install the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
7. Lower the vehicle.
8. Check the wheel alignment. Refer to Measuring Wheel Alignment in «SPECIFICATIONS»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) .

Tie Rod End Replacement - Outer

Tools Required

J-24319-B Universal Steering Linkage Puller.

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. Raise and support the vehicle.
2. Remove the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
3. Remove the outer tie rod stud retaining nut.
4. Loosen the jam nut (2) on the inner tie rod (1).
5. Disconnect the outer tie rod from the steering knuckle using J-24319-B .
6. Remove the outer tie rod (3) from the inner tie rod (1).

Scheme 81

Scheme 82

1. Connect the outer tie rod (3) to the inner tie rod (1). Do not tighten the jam nut (2).
2. Connect the outer tie rod to the steering knuckle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the outer tie rod retaining nut. Tighten Tighten the nut to 63 N.m (47 lb ft). Important: Be sure the power steering gear boot is not twisted after the toe adjustment.
4. Check the wheel alignment. Refer to Measuring Wheel Alignment in «SPECIFICATIONS»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) .

Rack and Pinion Boot Replacement - On Vehicle

Tools Required

J-22610 Keystone Clamp Pliers

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. Raise and support the vehicle.
2. Remove the outer tie rod. Refer to «Tie Rod End Replacement - Outer»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__tie-rod-end-replacement-outer) .
3. Remove the hexagon jam nut (2) from the inner tie rod (1).
4. Remove the tie rod end clamp (2) from the rack and pinion boot (1).
5. Remove the boot clamp (1) from the rack and pinion boot with side cutters.
6. Discard the boot clamp (1). Important: Prior to removing the breather tube or the rack and pinion boot, mark the location of the breather tube on the power steering gear.
7. Disconnect the breather tube from the rack and pinion boot (1). Remove the rack and pinion boot (1) from the power steering gear.

Scheme 87

Scheme 88

Scheme 89

Scheme 90

1. Prior to the rack and pinion boot installation, apply grease to the inner tie rod (2) and the power steering gear (1).
2. Install the rack and pinion boot (3) onto the inner tie rod (2).
3. Install the breather tube while aligning the breather tube with the mark made during removal and the molded nipple of the rack and pinion boot. Important: The rack and pinion boot (3) must not be twisted, puckered or out of shape in any way. If the rack and pinion boot (3) is not shaped properly, adjust the rack and pinion boot (3) by hand before installing the boot clamp.
4. Install the rack and pinion boot onto the power steering gear (1) until the rack and pinion boot (3) is seated in the power steering gear groove.
5. Install the boot clamp (1) on the rack and pinion boot (2).
6. Crimp the boot clamp (1) using the J-22610 .
7. Install the new boot clamp (2) onto the rack and pinion boot (1).
8. Install the hexagon jam nut (2) to the inner tie rod (1).
9. Install the outer tie rod. Refer to «Tie Rod End Replacement - Outer»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__tie-rod-end-replacement-outer) .
10. Check the wheel alignment. Refer to Measuring Wheel Alignment in «SPECIFICATIONS»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) .

Removal Procedure

Scheme 91

Scheme 92

Scheme 93

1. Install drain pan under vehicle.
2. Disconnect the power steering cooler hose from the power steering pump.
3. Disconnect the power steering cooler hose from the power steering gear.
4. Cap the power steering cooler ends in order to prevent the entry of dirt.
5. Remove the power steering cooler mounting bolts.
6. Remove the power steering cooler from the vehicle.

Scheme 94

Scheme 95

Scheme 96

1. Install the power steering cooler to the vehicle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power steering cooler mounting bolts. Tighten Tighten the bolts to 5 N.m (44 lb in).
3. Connect the power steering cooler hose to the power steering gear. Tighten Tighten the hose fitting to 33 N.m (24 lb in).
4. Connect the power steering cooler hose to the power steering pump.
5. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
6. Remove the drain pan from under the vehicle.

Power Steering Cooler Pipe/Hose Replacement (GT5)

Scheme 97

1. Install drain pan under the vehicle.
2. Raise and support the vehicle.
3. Disconnect the power steering cooler hose from the power steering pump.
4. Disconnect the power steering cooler hose from the power steering gear.
5. Cap the power steering pipes and cooler ends in order to prevent the entry of dirt.
6. Remove the power steering cooler mounting nuts.
7. Remove the power steering cooler from the vehicle.

Scheme 98

1. Install the power steering cooler to the vehicle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power steering cooler mounting nuts. Tighten Tighten the nuts to 28 N.m (21 lb ft).
3. Connect the power steering cooler hose to the power steering gear. Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
4. Connect the power steering cooler hose to the power steering pump.
5. Lower the vehicle.
6. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
7. Remove the drain pan from under the vehicle.

Power Steering Reservoir Inlet Pipe/Hose Replacement

Scheme 99

1. Install a drain pan under the vehicle.
2. Siphon the fluid from the reservoir to prevent excessive spillage.
3. Remove the reservoir inlet hose (3) from the power brake booster (2).
4. Remove the reservoir inlet hose (3) from the reservoir.
5. Remove the reservoir inlet hose from the vehicle.

Scheme 100

1. Route the hose in the same position the hose occupied prior to removal.
2. Install the reservoir inlet hose (3) to the power brake booster (2).
3. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
4. Remove the drain pan from under the vehicle.

Power Steering Reservoir Outlet Pipe/Hose Replacement

Scheme 101

1. Siphon the power steering fluid from the reservoir.
2. Disconnect the power steering reservoir outlet hose from the power steering pump.
3. Disconnect the power steering reservoir outlet hose from the power steering gear remote reservoir.
4. Remove the power steering reservoir outlet hose from the vehicle.

Scheme 102

1. Install the power steering reservoir outlet hose to the vehicle.
2. Install the power steering reservoir outlet hose to the power steering pump.
3. Install the power steering reservoir outlet hose to the power steering gear remote reservoir.
4. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .

Power Steering Gear Outlet Hose Replacement

Scheme 103

1. Install a drain pen under the vehicle.
2. Siphon the power steering fluid from the reservoir to prevent excessive spillage.
3. Remove the power steering outlet hose from the power steering pump.
4. Remove the power steering gear outlet hose from the power steering gear.
5. Remove the power steering gear outlet hose from the vehicle.

Scheme 104

1. Route the hose in the same position the hose occupied prior to removal. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the steering gear outlet hose to the power steering gear. Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
3. Install the power steering outlet hose to the power steering pump.
4. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
5. Remove the drain pan from under the vehicle.

Power Brake Booster Inlet Hose Replacement

Scheme 105

Scheme 106

1. Install a drain pan under the vehicle.
2. Siphon the power steering fluid from the reservoir to prevent excessive spillage.
3. Raise and support the vehicle.
4. Remove the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
5. Remove the power brake booster inlet hose (2) from the power steering pump (1) through the wheelwell.
6. Lower the vehicle.
7. Remove the power brake booster inlet hose (1) from the power brake booster (2).
8. Remove the power brake booster inlet hose from the vehicle.

Scheme 107

Scheme 108

1. Route the hose in the same position the hose occupied prior to removal. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power brake booster inlet hose (1) to the power brake booster (2). Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
3. Raise the vehicle.
4. Install the power brake booster inlet hose (2) to the power steering pump (1) through the wheelwell. Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
5. Install the tire and wheel. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
6. Lower the vehicle.
7. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
8. Remove the drain pan from under the vehicle.

Power Brake Booster Outlet Hose Replacement

Scheme 109

Scheme 110

1. Install a drain pan under the vehicle.
2. Siphon the power steering fluid from the reservoir to prevent excessive spillage.
3. Remove the power brake booster outlet hose (1) from the power brake booster (2).
4. Remove the power brake booster outlet hose from the power steering gear (2).
5. Remove the power brake booster outlet hose from the vehicle.

Scheme 111

Scheme 112

1. Route the hose in the same position the hose occupied prior to removal. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power brake booster outlet hose (1) to the power brake booster (2). Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
3. Install the power brake booster outlet hose to the power steering gear (2). Tighten Tighten the hose fitting to 33 N.m (24 lb ft).
4. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
5. Remove the drain pan from under the vehicle.

Power Steering Gear Replacement (Non-Rack and Pinion)

Tools Required

1. J-6632-01 Pitman Arm Puller
2. J-24319-B Steering Linkage and Tie Rod Puller
3. J-29107-A Pitman Arm Puller

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

1. Raise and support the vehicle.
2. Place a drain pan under the vehicle.
3. Mark the lower intermediate shaft to power steering gear alignment before removal.
4. Remove the lower intermediate shaft to power steering gear retaining bolt.
5. Disconnect the lower intermediate shaft from the power steering gear.
6. Disconnect the power brake booster outlet hose (4) and power steering gear outlet hose or the power steering cooler hose (1) from the power steering gear (2).
7. Cap the ends of the hoses and the power steering gear fittings in order to prevent the entrance of dirt.
8. Remove the pitman arm to relay rod retaining nut.
9. Disconnect the pitman arm from the relay rod using J-24319-B .
10. Remove the power steering gear mounting bolts.
11. Remove the power steering gear from the vehicle.
12. Remove the pitman arm to power steering gear retaining nut and washer.
13. Remove the pitman arm from the power steering gear using J-6632-01 or J-29107-A .

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

1. Install the pitman arm to the power steering gear. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the pitman arm to power steering gear retaining nut and washer. Tighten Tighten the nut to 250 N.m (184 lb ft).
3. Install the power steering gear to the vehicle.
4. Install the power steering gear to the frame mounting bolts. Tighten Tighten the bolts to 150 N.m (111 lb ft).
5. Install the pitman arm to relay rod.
6. Install the pitman arm to relay rod retaining nut. Tighten Tighten the nut to 63 N.m (47 lb ft).
7. Remove the caps from the steering gear and hoses.
8. Connect the power brake booster outlet hose (4) and power steering gear outlet hose or the power steering cooler hose (1) to the power steering gear (2). Tighten Tighten the hose fittings to 33 N.m (24 lb ft).
9. Align marks on lower intermediate shaft and power steering gear.
10. Connect the lower intermediate shaft to the power steering gear.
11. Install the lower intermediate shaft to power steering gear retaining bolt. Tighten Tighten the bolt to 61 N.m (45 lb ft).
12. Lower the vehicle.
13. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
14. Remove the drain pan from under the vehicle.

Power Steering Gear Replacement (Rack and Pinion)

Tools Required

J-24319-B Steering Linkage and Tie Rod Puller

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. Raise and support the vehicle.
2. Place a drain pan under the vehicle.
3. Remove the front tires and wheels. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
4. Remove the outer tie rods retaining nuts.
5. Disconnect the outer tie rods from the steering knuckles using J-24319-B .
6. Mark the lower intermediate shaft to power steering gear alignment before removal.
7. Remove the lower intermediate shaft to power steering gear retaining bolt.
8. Disconnect the lower intermediate shaft from the power steering gear.
9. Disconnect the power brake booster outlet hose (2) and power steering gear outlet hose (1) from the power steering gear (3).
10. Cap the ends of the hoses and the power steering gear fittings in order to prevent the entrance of dirt.
11. Remove the power steering gear mounting bolts.
12. Remove the power steering gear from the vehicle.

Scheme 130

Scheme 131

Scheme 132

Scheme 133

1. Install the power steering gear to the vehicle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power steering gear to the frame mounting bolts. Tighten Tighten the bolts to 150 N.m (111 lb ft).
3. Remove the caps from the steering gear and hoses.
4. Connect the power brake booster outlet hose (2) and power steering gear outlet hose (1) to the power steering gear (3). Tighten Tighten the hose fittings to 33 N.m (24 lb ft).
5. Align marks on lower intermediate shaft and power steering gear.
6. Connect the lower intermediate shaft to the power steering gear.
7. Install the lower intermediate shaft to power steering gear retaining bolt. Tighten Tighten the bolt to 61 N.m (45 lb ft).
8. Install the outer tie rods retaining nuts. Tighten Tighten the nuts to 63 N.m (47 lb ft).
9. Install the front tires and wheels. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-tire-system/#tires-wheels__tire-and-wheel-removal-and-installation) .
10. Lower the vehicle.
11. Bleed the power steering system. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
12. Remove the drain pan from under the vehicle.
13. Check the wheel alignment. Refer to Measuring Wheel Alignment in «SPECIFICATIONS»(/chevrolet/chevy-express-h2500/2003-2003/remont/wheel-alignment/#wheel-alignment-specifications-adjustment-procedures) .

Scheme 134

1. Loosen the adjuster plug lock nut (1).
2. Turn the adjuster plug clockwise until the adjuster plug bottoms in the gear assembly.
3. Turn the adjuster plug back 50 degrees to 70 degrees (approximately one flat). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Install the adjuster plug lock nut (1) to the adjuster plug. Tighten Hold the adjuster plug stationary while tightening the adjuster plug lock nut (1) to 68 N.m (50 lb ft).

Rack and Pinion Boot and Breather Tube Replacement - Off Vehicle

Tools Required

J-22610 Service Boot Clamp Installer

Scheme 135

Scheme 136

Scheme 137

Scheme 138

1. To remove the outer tie rod. Refer to «Tie Rod End Replacement - Outer»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__tie-rod-end-replacement-outer) .
2. Remove the hexagon jam nut (2) from the inner tie rod assembly (1).
3. Remove the tie rod end clamp (2) from the rack and pinion boot (1).
4. Remove the boot clamp (1) from the rack and pinion boot with side cutters.
5. Discard the boot clamp (1). Important: If a breather tube is present, mark the location of the breather tube on the gear assembly before removal of the rack and pinion boot.
6. Remove the rack and pinion boot (1) and the breather tube, if present, from the rack and pinion gear assembly.

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

1. Install the new boot clamp (1) onto the rack and pinion boot (3).
2. Prior to rack and pinion boot installation, apply grease to the inner tie rod assembly (2) and the rack and pinion gear assembly (1).
3. Install the rack and pinion boot (3) onto the inner tie rod assembly (2).
4. If present, install the breather tube while aligning the breather tube with the mark made during removal and the molded nipple of the rack and pinion boot. Important: The rack and pinion boot (3) must not be twisted, puckered or out of shape in any way. If the rack and pinion boot (3) is not shaped properly, adjust the rack and pinion boot (3) by hand before installing the boot clamp.
5. Install the rack and pinion boot onto the gear assembly (1) until the rack and pinion boot (3) is seated in the gear assembly groove.
6. Install the boot clamp (1) on the rack and pinion boot (2) with J-22610.
7. Crimp the boot clamp (1).
8. Pinch the pliers together on the rack and pinion boot (2) in order to install the tie rod end clamp.
9. Install the tie rod end clamp (2) onto the rack and pinion boot (1).
10. Install the hexagon jam nut (2) to the inner tie rod assembly (1).
11. To assemble the outer tie rod assembly. Refer to «Tie Rod End Replacement - Outer»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__tie-rod-end-replacement-outer) .

Tie Rod Replacement - Inner (Quiet Valve)

Tools Required

J-34028 Inner Tie Rod Wrench

Scheme 144

Scheme 145

Scheme 146

1. To remove the rack and pinion boot and the breather tube. Refer to «Rack and Pinion Boot and Breather Tube Replacement - Off Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__rack-and-pinion-boot-and-breather) .
2. Place the gear in a vise. CAUTION: Do not change the steering gear preload adjustment before moving the inner tie rod from the steering gear. Changing the steering gear preload adjustment before moving the inner tie rod could result in damage to the pinion and the steering gear.
3. Remove the shock dampener (4) from the inner tie rod housing (6).
4. Slide the shock dampener (4) back on the rack (5).
5. Place a pipe wrench on the rack (5) next to the inner tie rod housing (6).
6. Place a wrench on the flats of the inner tie rod housing (6).
7. Rotate the inner tie rod housing (6) counterclockwise, while holding the rack stationary, until the inner tie rod separates from the rack (5). CAUTION: Do not change the steering gear preload adjustment before moving the inner tie rod from the steering gear. Changing the steering gear preload adjustment before moving the inner tie rod could result in damage to the pinion and the steering gear.
8. Remove the shock dampener (3) from the inner tie rod housing (2).
9. Slide the shock dampener (3) back on the rack (5). CAUTION: The pipe wrench must be placed at the valve end of the steering gear and positioned up against the inner tie rod housing. Placing the pipe wrench in any other location will cause damage to the steering gear.
10. Place a pipe wrench on the rack.
11. Place a wrench on the flats of the inner tie rod housing (2).
12. Rotate the inner tie rod housing (2) counterclockwise, while holding the rack stationary, until the inner tie rod (1) separates from the rack (5).
13. If female rack (1) and male inner tie rod (3), remove the old LOCTITE® from the threads (2) of the inner tie rod and the rack. If male rack (5) and female inner tie rod (4) LOCTITE® will not be present.

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

1. Slide the shock dampener (4) forward onto the rack (3). Important: Threads must be clean prior to LOCTITE® application. Check LOCTITE®, or equivalent, container for expiration date. Use only enough LOCTITE® to evenly coat threads. If male rack (3) and female inner tie rod (2) do not apply LOCTITE®.
2. If female rack (30) and male inner tie rod (2), apply LOCTITE® 262, or equivalent, to the inner tie rod threads.
3. Attach the inner tie rod onto the rack (3). CAUTION: The pipe wrench must be placed at the valve end of the steering gear and positioned up against the inner tie rod housing. Placing the pipe wrench in any other location will cause damage to the steering gear.
4. Place a pipe wrench on the rack (3) next to the inner tie rod housing (2). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
5. Place a torque wrench and J-34028 on the flats of the inner tie rod housing (2). Tighten Tighten the inner tie rod to 100 N.m (74 lb ft).
6. Slide the shock dampener (2) forward onto the rack. Important: Threads must be clean prior to LOCTITE® application. Check LOCTITE®, or equivalent, container for expiration date. Use only enough LOCTITE® to evenly coat threads. If male rack and female inner tie rod (1) do not apply LOCTITE®.
7. If female rack and male inner tie rod (1), apply LOCTITE® 262, or equivalent, to the inner tie rod threads.
8. Attach the inner tie rod (1) onto the rack. CAUTION: The pipe wrench must be placed at the valve end of the steering gear and positioned up against the inner tie rod housing. Placing the pipe wrench in any other location will cause damage to the steering gear.
9. Place a pipe wrench on the rack next to the inner tie rod housing (4).
10. Place a torque wrench and J-34028 on the flats of the inner tie rod housing (7). Tighten Tighten the inner tie rod to 100 N.m (74 lb ft).
11. Place the inner tie rod assembly (2) in a vise. Important: If female rack (1) and male inner tie rod (2) do not stake. If male rack (1) and female inner tie rod (2) you must stake.
12. Stake both sides of the female inner tie rod assembly housing to the male rack.
13. Insert a 0.010 inch gage (1) between the rack (2) and the inner tie rod housing in order to check both stakes. The feeler (1) must not pass between the rack and the housing stake.
14. Slide the shock dampener (2) over the inner tie rod housing (3) until the front lip of the shock dampener (2) bottoms against the inner tie rod housing (3).
15. To assemble the rack and pinion boot and the breather tube. Refer to «Rack and Pinion Boot and Breather Tube Replacement - Off Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__rack-and-pinion-boot-and-breather) .

Scheme 152

Scheme 153

1. Loosen both cylinder line fittings on the cylinder line fittings on the cylinder end of the gear assembly.
2. Loosen both fittings on the cylinder line assemblies (1) at the valve end of the gear assembly.
3. Remove both cylinder line assemblies (1) from the rack and pinion gear assembly (2).
4. Remove the O-ring seals (1) from the valve end of line.
5. Discard the O-ring seals (1).

Scheme 154

Scheme 155

Scheme 156

1. Inspect the cylinder lines (1) for the following items: Cracks Dents Damage to the threads
2. Replace the parts as needed.
3. Install the new O-ring seals (1) to the valve end of the cylinder lines. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Install the cylinder line assemblies (1) to the gear assembly (2). Tighten Tighten the valve end fittings to 17 N.m (13 lb ft) Tighten the cylinder end fittings to 27 N.m (20 lb ft)

Steering Gear Stub Shaft Seals and Bearing Replacement - Off Vehicle

Tools Required

J-29810 Stub Shaft Seal Protector

Scheme 157

Scheme 158

Scheme 159

1. Remove the steering gear from the vehicle, refer to «Power Steering Gear Replacement (Non-Rack and Pinion)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-gear-replacement-non-rack-and) or «Power Steering Gear Replacement (Rack and Pinion)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-gear-replacement-rack-and) .
2. Remove the adjuster plug lock nut (5) from the adjuster plug (4).
3. Remove the adjuster plug (4) from the gear assembly (1).
4. Remove the adjuster spring (3) and the rack bearing (2).
5. Remove the spool shaft boot (1) from the rack and pinion gear assembly.
6. Remove the retaining ring (2) from the valve bore of the rack and pinion gear assembly.
7. Remove the dust cover (4) from the bottom of the rack and pinion gear assembly.
8. Remove the hex lock nut (3) from the lower end of the pinion and valve assembly while holding the stub shaft with a 14 mm crowfoot wrench. Important: When performing the following procedure, do not remove pinion and valve assembly from the rack and pinion gear assembly (5). Press the pinion and valve assembly only far enough to allow removal of the stub shaft bearing annulus (3) and the stub shaft seal (2).
9. Using an arbor press (1), press on the threaded end of the pinion until removal of the following items is possible: The stub shaft (4) The stub shaft seal (2) The stub shaft bearing annulus assembly (3)

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

1. Install the hex lock nut (1) onto the pinion while holding the valve stub shaft. Tighten Tighten the nut to 30 N.m (22 lb ft).
2. Install the dust cover (2) to the rack and pinion gear assembly.
3. Install the stub shaft bearing annulus assembly (1) onto the valve stub shaft (2).
4. Install J-29810 onto the valve stub shaft.
5. Lubricate the stub shaft seal (3) with grease.
6. Install the stub shaft seal (3) into the rack and pinion gear assembly.
7. Install the retaining ring (2) into the groove in the rack and pinion gear assembly.
8. Install the spool shaft boot (1) onto the rack and pinion gear assembly.
9. Lubricate the following items with lithium base grease: The rack bearing (2) The adjuster spring (3) The adjuster plug (4)
10. Install the following items into the gear assembly: The rack bearing (2) The adjuster spring (3) The adjuster plug (4)
11. Turn the adjuster plug (1) clockwise onto the rack and pinion gear assembly until the adjuster plug (1) bottoms in the rack and pinion gear assembly, then turn the adjuster plug (1) back 50 degrees to 70 degrees.
12. Check the rotational torque on the pinion. The maximum pinion preload torque is 1.8 N.m (16 lb in).
13. Install the adjuster plug lock nut (5) to the adjuster plug (4). Finger tighten the adjuster plug lock nut (5) while holding the adjuster plug (4) stationary. Tighten Tighten the nut to 68 N.m (50 lb ft).
14. Install the steering gear into the vehicle, refer to «Power Steering Gear Replacement (Non-Rack and Pinion)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-gear-replacement-non-rack-and) or «Power Steering Gear Replacement (Rack and Pinion)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__power-steering-gear-replacement-rack-and) . Important: Flush and bleed power the steering system (hoses, reservoir and cooler lines) with power steering fluid GM P/N 1050017 (Canadian P/N 992646) (or equivalent meeting GM Specification number 9985010).
15. Refer to «Bleeding the Power Steering System»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .

Worm Thrust Bearing Preload Adjustment - Off Vehicle (700 Gear)

Tools Required

1. J-42882 Adjuster Nut Socket
2. J-43435 Adjuster Lock Nut Wrench

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

1. Rotate the stub shaft back and forth in order to drain the power steering fluid.
2. Remove the coupling shield retainer and the lock nut from the steering gear housing using J-43435 and a torque wrench. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Turn the adjuster nut assembly (1) clockwise using J-42882 until the adjuster nut assembly (1) and the thrust support assembly (2) are firmly bottomed in the steering gear housing (3). Tighten Tighten the adjuster nut assembly (1) to 29.5 N.m (21.5 lb ft).
4. Place an index mark (1) on the steering gear housing (4) parallel with one of the holes (3) in the adjuster nut assembly (2).
5. Measure back counterclockwise 13 mm (1/2 in).
6. Place a second mark (2) on the steering gear housing (1).
7. Using J-42882 and a torque wrench, turn the adjuster nut assembly (1) counterclockwise 15-25 degrees to align the hole (2) in the adjuster nut assembly (1) with the second mark (4) on the steering gear housing (3).
8. Install the coupling shield retainer and the lock nut.
9. Hold the adjuster nut assembly in position to maintain alignment of the marks.
10. Tighten the coupling shield retainer and the lock nut using J-43435 and a torque wrench. Tighten Tighten the coupling shield retainer and the lock nut to 109 N.m (80 lb ft).
11. To adjust the pitman shaft, refer to «Pitman Shaft Over-Center Preload Adjustment - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .

Scheme 172

Scheme 173

Scheme 174

1. Adjust the worm shaft and valve, refer to «Worm Thrust Bearing Preload Adjustment - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__worm-thrust-bearing-preload-adjustment) .
2. Rotate the stub shaft (3) back and forth to drain the power steering fluid.
3. Loosen the adjuster lock nut (4).
4. Turn the pitman shaft adjuster screw (1) counterclockwise until the screw is fully extended.
5. Turn the pitman shaft adjuster screw (1) clockwise 1 full turn.
6. Rotate the stub shaft (3) from stop to stop using a 12-point socket while counting the number of turns.
7. Starting at either stop, turn the stub shaft (3) back half of the total number of turns. This is the center of the gear.
8. Make sure that the gear is centered by checking the following items: The flat on the stub shaft (3) faces upward. The flat on the stub shaft (3) is parallel with the side cover (2).
9. Align the master spline (5) on the pitman shaft (4) with the adjuster screw (1).
10. Place a torque wrench on the stub shaft (2) with the handle in the vertical position.
11. Rotate the stub shaft (2) 45 degrees from each side of the center of the stub shaft. The stub shaft (2) must rotate smoothly.
12. Record the worm bearing preload measured on or near the center (1). The recorded bearing preload must be 1.2 N.m (10.5 lb in) with the worm and the ball nut installed. If the torque is outside of this range, readjust or repair the steering gear assembly as required.
13. To obtain the correct preload torque, adjust the over-center torque by turning the pitman shaft adjuster screw clockwise. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
14. Add 0.9 N.m (8 lb in) torque to the previously measured worm bearing preload torque. Tighten Tighten the adjuster lock nut to 44 N.m (32 lb ft). Prevent the adjuster screw from turning while tightening the adjuster lock nut.

Scheme 175

Scheme 176

1. Remove the nut (3).
2. Remove the lock washer (2).
3. Clean the exposed end of the pitman shaft.
4. Clean the steering gear housing (1).
5. Use a wire brush to clean the pitman shaft splines.
6. Loosen the adjuster lock nut (1).
7. Remove the bolts (2).
8. Remove the nut.
9. Rotate the stub shaft (6) using a 12-point socket to center the steering gear (7). Important: When removing the pitman shaft assembly, the pitman arm and its components may fall from the steering gear housing. Support the pitman arm and its components while removing the pitman shaft assembly.
10. Remove the following items as an assembly: The side cover (8) The gasket (3) The pitman shaft (4)
11. Remove the pitman shaft (4) from the side cover (8).

Scheme 177

Scheme 178

1. Screw the pitman shaft (4) to the side cover (8) until it fully seats to the side cover (8).
2. Install the adjuster lock nut (10). Do not tighten the adjuster lock nut (1) until the pitman shaft adjustment is completed.
3. Install the pitman shaft assembly (4) and the side cover (8) to the steering gear housing (7). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Install the bolts (2). Tighten Tighten the bolts (2) to 60 N.m (45 lb ft).
5. Install the lock washer (2).
6. Install the nut (3).
7. If necessary, adjust the pitman shaft. Refer to «Pitman Shaft Over-Center Preload Adjustment - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) to adjust the pitman shaft.

Scheme 179

1. Rotate the stub back and forth to drain the fluid.
2. Insert a punch into the housing access hole to unseat the retaining ring (1).
3. Remove the plug (2).
4. Remove the O-ring seal (3).

Scheme 180

1. Lubricate the O-ring seal (3) with power steering fluid.
2. Install the O-ring seal (3) into the steering gear housing (5).
3. Install the plug (2).
4. Install the retaining ring (1). Ensure that the retaining ring open end is approximately 25 mm (1 in) from the access hole in the steering gear housing (5).

Scheme 181

Scheme 182

1. Remove the thrust support assembly. Refer to «Steering Gear Thrust Support Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__steering-gear-thrust-support-replacement) .
2. Remove the stub shaft (1) and the valve assembly (2) from the steering gear housing.
3. If necessary, remove the stub shaft (1) from the valve assembly (2) in the following manner: Tap the stub shaft (1) lightly on a wood block in order to loosen the cap. Pull the cap and the valve spool out from valve body (2) 6 mm (1/4 in). Disengage the stub shaft pin (3) from the hole in the valve spool (4).
4. If the valve assembly needs repair, disassemble the valve in the following manner: Simultaneously pull and rotate the valve spool (1) from the valve body (3). Remove the valve spool O-ring seal (2). Alternatively remove the valve body teflon rings (5) and the O-ring seals (4).

Scheme 183

Scheme 184

Scheme 185

Scheme 186

1. If disassembled, reassemble the valve assembly in the following manner: Alternatively install the valve body teflon rings (5) and the O-ring seals (4). Install the valve spool O-ring seal (2) to the valve spool (1). Lubricate the valve spool (1) and O-ring seal (2) with power steering fluid.
2. Simultaneously push and rotate the valve spool (2) into the valve body (1) until the hole (3) in the valve spool (2) for the stub shaft pin is accessible from the opposite end of the valve body (1).
3. If necessary, install the stub shaft to the valve spool in the following manner: Insert the stub shaft (3) into the valve spool. Insert the pin. Important: Make sure that the shaft cap notch (1) is mated with the valve body pin before installing the valve body into the steering gear assembly. The notch in the cap (1) must fully engage the valve body pin (2). Seat the cap against the valve body shoulder.
4. Install the stub shaft (7) and valve assembly (6) to the worm shaft (5). Ensure the pin fits in the worm shaft to the slot in the valve assembly.
5. Install the thrust support assembly. Refer to «Steering Gear Thrust Support Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__steering-gear-thrust-support-replacement) .

Rack Piston and Worm Shaft Replacement - Off Vehicle (700 Gear)

Tools Required

1. J-21552 Rack Piston Arbor
2. J-8947 Rack Piston Teflon Ring Compressor

Disassembly Procedure

Important: Do not remove the needle bearing when removing the pitman shaft arm and its components.

Scheme 187

Scheme 188

1. Remove the pitman shaft seals and bearing. Refer to «Pitman Shaft Seals and Bearing Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__pitman-shaft-seals-and-bearing-replacement) .
2. Remove the housing end plug. Refer to «Steering Gear Housing End Plug Replacement - Off Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
3. Turn the stub shaft counterclockwise until the rack piston (2) begins to come out of the steering gear housing (3).
4. Remove the rack piston plug (1).
5. Insert J-21552 into the bore of the rack piston (2).
6. Hold J-21552 tightly against the worm shaft while turning the stub shaft counterclockwise. Turning the stub shaft forces the rack piston (2) onto J-21552 . The rack piston balls remain in place.
7. Remove the following items as an assembly from the steering gear housing (9): The rack piston (4) The rack piston screws (8), clamp (7), ball guide (6) and balls (5) J-21552
8. Remove the spool valve assembly. Refer to «Steering Gear Valve Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
9. Remove the worm shaft (14).
10. Remove the thrust bearing (12) and the flat races (11,13). Important: When removing J-21552 , watch for falling piston balls (5) from inside the rack piston (4).
11. Remove J-21552 from the rack piston (4). Remove the rack piston balls (5).
12. Remove the following items from the rack piston (4): The screws (8) The clamp (7) The ball guide (6) The remaining rack piston balls (5) in the ball guide (6)
13. Remove the teflon ring (2).
14. Remove the O-ring seal (3).
15. Clean all of the disassembled parts.
16. Inspect all of the disassembled parts for wear.
17. Replace the parts if necessary.

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

1. Install the O-ring seal (3) and the teflon ring (2).
2. Lubricate both parts with power steering fluid.
3. Install the worm shaft (14) to the rack piston (4) outside of the steering gear housing (9). Fully seat the worm shaft to the rack piston.
4. Align the worm shaft spiral groove with the rack piston ball return guide hole (1). WARNING: Improper rack piston ball installation may result in personal injury. The black rack piston balls are smaller than the silver rack piston balls. Install the black and the silver rack piston balls alternately into the rack piston and the ball guide to maintain the rack piston to the worm shaft preload.
5. Lubricate the rack piston balls with power steering fluid.
6. Insert the rack piston balls through the ball return guide hole (1) while turning worm shaft (2) counterclockwise in order to install the rack piston balls into the rack piston.
7. Install the remaining rack piston balls (3) into the ball guide (1) using grease at each end (2) to retain the rack piston balls (3).
8. Install the ball guide (3) to the rack piston (2).
9. Install the ball guide clamp (4). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
10. Install the screws (5). Tighten Tighten the screws (5) to 6 N.m (53 lb in).
11. Insert J-21552 into the bore of the rack piston while turning the worm shaft counterclockwise. The turning of the worm shaft forces the rack piston onto J-21552 . The rack piston balls remain in place.
12. Install the flat races (2, 4) and the thrust bearing (3) onto the worm shaft (1).
13. Install the worm shaft (4) to the steering gear housing (3). Important: Do not adjust the worm shaft until all components are installed onto the steering gear housing.
14. Install the spool valve. Refer to «Steering Gear Valve Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
15. Install the rack piston (2) to the worm (4) from J-21552 using J-8947 to compress the seals.
16. Hold J-21552 tightly against the worm shaft (4).
17. Turn the stub shaft clockwise until the rack piston (2) is seated on the worm shaft (4).
18. Remove J-21552 from the rack piston (1).
19. Install the rack piston plug (1). Tighten Tighten the rack piston plug to 150 N.m (111 lb ft).
20. Install the housing end plug. Refer to «Steering Gear Housing End Plug Replacement - Off Vehicle»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) . Important: Do not adjust the pitman shaft until all components are installed onto the steering gear housing.
21. Install the pitman shaft seals and bearing. Refer to «Pitman Shaft Seals and Bearing Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__pitman-shaft-seals-and-bearing-replacement) .
22. To adjust the steering gear; refer to one of the following procedures: «Worm Thrust Bearing Preload Adjustment - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__worm-thrust-bearing-preload-adjustment) «Pitman Shaft Over-Center Preload Adjustment - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system)

Pitman Shaft Seals and Bearing Replacement - Off Vehicle (700 Gear)

Tools Required

1. J-6278 Pitman Shaft Bearing Remover and Installer
2. J-4245 Internal Snap Ring Pliers

Scheme 195

Scheme 196

Scheme 197

Scheme 198

1. Remove the pitman shaft and the side cover. Refer to «Steering Gear Pitman Shaft and Housing Cover Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
2. Remove the pitman arm (3) from the steering gear (1).
3. Remove the pitman shaft boot (2).
4. Remove the dust seal (1).
5. Remove the retaining ring using the J-4245 . Important: Use care not to score the steering gear housing bore when prying out the seals and the washers.
6. Use a screwdriver to pry the backup washer (3) and the double lip seal (2) from the steering gear housing (1).
7. Inspect the steering gear housing (1) for burrs.
8. Insert J-6278 through the hole in the top of the steering gear housing (1).
9. Drive out the needle bearing (2).

Scheme 199

Scheme 200

Scheme 201

Scheme 202

1. Install the needle bearing (2) to the steering gear housing (1) using the J-6278
2. Coat the double lip seal (2) and the washer (3) with grease.
3. Install the double lip seal (2).
4. Install the backup washer (3).
5. Install the retaining ring using the J-4245 . Important: Do not install the lock washer and nut until complete installation of the pitman arm and it's components have been installed. Do not adjust the pitman shaft until all components have been installed on the steering gear housing.
6. Install the pitman shaft and the side cover. Refer to «Steering Gear Pitman Shaft and Housing Cover Replacement - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) .
7. Install the dust seal (1).
8. Install the pitman shaft boot (2).
9. Install the pitman arm (3) to the steering gear (1).
10. Install the lock washer (4). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
11. Install the nut (5). Tighten Tighten the pitman arm nut to 250 N.m (184 lb ft).
12. Refer to «Pitman Shaft Over-Center Preload Adjustment - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system) to adjust the pitman shaft.

Steering Gear Check Valve Replacement - Off Vehicle

Scheme 203

Install the check valve (1) using a 9.52 mm inch diameter piece of tubing 100 mm (4 in) long to drive into the steering gear housing.

Scheme 204

Steering Gear Thrust Support Replacement - Off Vehicle (700 Gear)

Tools Required

1. J-42882 Adjuster Nut Socket
2. J-43435 Adjuster Lock Nut Wrench

Scheme 205

Scheme 206

Scheme 207

1. Rotate the stub shaft back and forth in order to drain the power steering fluid.
2. Remove the coupling shield retainer and the lock nut from the steering gear housing using J-43435 and a torque wrench.
3. Remove the adjuster nut assembly (2) from the steering gear housing (1) using J-42882 .
4. Remove the thrust support assembly (2) from the steering gear housing (1).
5. Remove the O-ring seal (3) from the thrust support assembly (2).

Important: Install a new O-ring seal each time the thrust support assembly is removed from the steering gear.

Scheme 208

Scheme 209

Scheme 210

1. Lubricate the new O-ring seal (3).
2. Install the new O-ring seal (3) on the thrust support assembly (2).
3. Install the thrust support assembly (2).
4. Connect the adjuster nut assembly (2) to the steering gear housing (1) using J-42882.
5. Install the coupling shield retainer and the lock nut (1) to the adjuster nut assembly.
6. Refer to «Worm Thrust Bearing Preload Adjustment - Off Vehicle (700 Gear)»(/chevrolet/chevy-express-h2500/2003-2003/remont/manual-power-steering/#power-steering-system__worm-thrust-bearing-preload-adjustment) to adjust the thrust bearing preload.
7. Hold the adjuster nut assembly in position to maintain alignment of the marks. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
8. Tighten the coupling shield retainer and the lock nut using J-43435 and a torque wrench. Tighten Tighten the retainer and the lock nut to 109 N.m (80 lb ft).

The hydraulic power steering pump is a constant displacement vane-type pump that provides hydraulic pressure and flow for the power steering gear. The hydraulic power steering pumps are either belt-driven or direct-drive, cam-driven.

The power steering fluid reservoir holds the power steering fluid and may be integral with the power steering pump or remotely located. The following locations are typical locations for the remote reservoir

1. Mounted to the front of the dash panel
2. Mounted to the inner fender
3. Mounted to a bracket on the engine The 2 basic types of power steering gears are listed below
4. A recirculating ball system
5. A rack and pinion system

In the recirculating ball system, a worm gear converts steering wheel movement to movement of a sector shaft. A pitman arm attached to the bottom of the sector shaft actually moves one tie rod and an intermediate rod move the other tie rod.

In the rack and pinion system, the rack and the pinion are the 2 components that convert steering wheel rotation to lateral movement. The steering shaft is attached to the pinion in the steering gear. The pinion rotates with the steering wheel. Gear teeth on the pinion mesh with the gear teeth on the rack. The rotating pinion moves the rack from side to side. The lateral action of the rack pushes and pulls the tie rods in order to change the direction of the vehicle's front wheels.

The power steering pressure hose connects the power steering pump union fitting to the power steering gear and allows pressurized power steering fluid to flow from the pump to the gear.

The power steering return hose returns fluid from the power steering gear back to the power steering fluid reservoir. The power steering return line may contain an integral fin-type or line-type power steering fluid cooler.

In a typical power steering system, a pump generates hydraulic pressure, causing fluid to flow, via the pressure hose, to the steering gear valve assembly. The steering gear valve assembly regulates the incoming fluid to the right and left chambers in order to assist in right and left turns.

Turning the steering wheel activates the valve assembly, which applies greater fluid pressure and flow to 1 side of the steering gear piston, and lower pressure and flow to the other side of the piston. The pressure assists the movement of the gear piston. Tie rods transfer this force to the front wheels, which turn the vehicle right or left.

Scheme 211

Scheme 212

Scheme 213

Scheme 214

See also:
• ENGINE MECHANICAL - 4.3L
• ENGINE MECHANICAL - 4.8L, 5.3L & 6.0L
• TIRE AND WHEEL REMOVAL AND INSTALLATION
• PITMAN ARM REPLACEMENT
• SPECIFICATIONS
• SYMPTOMS - POWER STEERING SYSTEM
• Power Steering Pulley Replacement
• Rack and Pinion Boot Replacement - On Vehicle
• Tie Rod End Replacement - Outer
• Rack and Pinion Boot and Breather Tube Replacement - Off Vehicle
• Power Steering Gear Replacement (Non-Rack and Pinion)
• Power Steering Gear Replacement (Rack and Pinion)
• Worm Thrust Bearing Preload Adjustment - Off Vehicle (700 Gear)
• Steering Gear Thrust Support Replacement - Off Vehicle (700 Gear)
• Pitman Shaft Seals and Bearing Replacement - Off Vehicle (700 Gear)
