Installation Procedure Chevrolet Chevy Express H2500

Door System, Mirror System & Window System 2 illustrations ~258 words

Installation Procedure

  1. Partially install the front door trim plate (1) to the front door trim panel.
  2. Connect the electrical connectors to the switches, if equipped.
  3. Align the retainers on the front door trim plate (1) to the slots in the front door trim panel
  4. Push towards the door panel to engage the front door trim plate (1) retainers. CAUTION: Refer to «FASTENER NOTICE»(/chevrolet/chevy-express-h2500/2003-2003/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) .
  5. Install the screws (2). Tighten Tighten the screw that retains the front door trim plate to 1.9 N.m (17 lb in)
  6. Install the inside door handle bezel. Refer to «Handle Bezel Replacement - Inside - Front»(/chevrolet/chevy-express-h2500/2003-2003/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Install the window regulator handle, if equipped. Refer to «Window Regulator Handle Replacement - Door»(/chevrolet/chevy-express-h2500/2003-2003/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-regulator-handle-replacement-door) .

Scheme 89

Scheme 89: Removal Procedure
Scheme 89: Removal Procedure
  1. Remove the inside door handle bezel. Refer to «Handle Bezel Replacement - Inside - Rear»(/chevrolet/chevy-express-h2500/2003-2003/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the screw (1) from the door trim plate (2).
  3. Partially remove the trim plate (2) from the door trim panel.
  4. Disconnect the electrical connectors from the door lock switch, if equipped.
  5. Remove the front door trim plate (2) from the vehicle.

Scheme 90

Scheme 90: Installation Procedure
Scheme 90: Installation Procedure
  1. Partially install the door trim plate (2) to the door trim panel.
  2. Connect the electrical connector to the door lock switch, if equipped.
  3. Align the door trim plate (2) to the door trim panel CAUTION: Refer to «FASTENER NOTICE»(/chevrolet/chevy-express-h2500/2003-2003/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) .
  4. Install the screw (1). Tighten Tighten the screw that retains the front door trim plate to 1.9 N.m (17 lb in)
  5. Install the inside door handle bezel. Refer to «Handle Bezel Replacement - Inside - Rear»(/chevrolet/chevy-express-h2500/2003-2003/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
