INTRODUCTION

Note. Unless specified otherwise, information for Chevy Express and Savana applies to Cutaway, RV Cutaway, Savana Camper Special and Savana Special.

The Parameter Identification (PID) charts contain all the engine related parameters that are available on the scan tool. The list is arranged in alphabetical order. A parameter may appear in any one of the data lists, and in some cases may appear more than once, or in more than one data list in order to group certain related parameters together. Use the PID charts only after the Diagnostic System Check - Engine Controls has been completed, no DTCs were noted, and you have determined the on-board diagnostics are functioning properly. See DIAGNOSTIC SYSTEM CHECK - ENGINE CONTROLS under SELF-DIAGNOSTIC SYSTEM in appropriate SELF-DIAGNOSTICS article. Scan tool values from a properly running engine may be used for comparison with the engine you are diagnosing. The Typical Scan Data values represent values that would be seen on a normally running engine. Technical Service Bulletins (TSBs) may also be helpful in correcting a hard to diagnose problem.

Note. Do not use a scan tool that displays faulty data. The scan tool concern should be reported to the manufacturer. Use of a faulty scan tool can result in misdiagnosis and in unnecessary parts replacement.

If all the PID values are within the typical range and a symptom still exists, diagnosis by symptom may help find the fault. See appropriate TROUBLE SHOOTING - NO CODES article.

COMPONENT LOCATIONS

The powertrain control module is located in the engine compartment on the left inner fender.

Scheme 1

Scheme 1: COMPONENT LOCATIONS

Scheme 2

Scheme 2: Identifying PCM Connector C1 Terminals

Scheme 3

Scheme 3

Scheme 4

Scheme 4: Identifying PCM Connector C2 Terminals

Scheme 5

Scheme 5

Scheme 6

Scheme 6: Identifying PCM Connector C1 Terminals - Chevy Express & Savana

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9: Identifying PCM Connector C2 Terminals - Chevy Express & Savana

Scheme 10

Scheme 10

Scheme 11

Scheme 11

SCAN TOOL DATA LIST DEFINITIONS

CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

Note. See appropriate PID VALUE chart for vehicle application.

4.3L

The column labeled Data List indicates where a parameter is located on the scan tool. Review the scan tool operating manual for the exact locations of the data lists. The following is a description of each term listed.

  1. ALL The parameter is in all of the data lists indicated below.
  2. Eng 1 Engine Data 1 List
  3. Eng 2 Engine Data 2 List
  4. EE Enhanced EVAP Data
  5. FF/FR Freeze Frame/Failure Records
  6. FT Fuel Trim Data List
  7. MF Misfire Data List

4.8L, 5.3L & 6.0L

The column labeled Data List indicates where a parameter is located on the scan tool. Review the scan tool operating manual for the exact locations of the data lists. The following is a description of each term listed.

  1. All The parameter is in all of the data lists indicated below.
  2. Eng 1 Engine Data 1 List
  3. Eng 2 Engine Data 2 List
  4. EGR Exhaust Gas Recirculation (EGR) Data
  5. EE Enhanced Evaporative Emission (EVAP) Data
  6. FF/FR Freeze Frame/Failure Records
  7. FT Fuel Trim Data List
  8. HO2S HO2S Data List
  9. MF Misfire Data List

PID VALUE CHARTS

Ensure following conditions are met before comparing scan tool data to typical data value found in appropriate PID value chart

  1. Engine is idling unless checking a value at a specified RPM.
  2. Throttle is closed unless checking a value at a specified RPM.
  3. Vehicle is in Park or Neutral.
  4. Vehicle is operating in closed loop.
  5. Vehicle accessories are turned off.

Compare actual PID values on scan tool to PID values found in appropriate PID value chart.

Scheme 12

Scheme 12: PID Values - 4.3L

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15: PID Values - 4.8L, 5.3L & 6.0L

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18
