Engine Control System & Fuel System - 4.3l - Introduction (2 of 2) Chevrolet Chevy Express H1500

Temperature Versus Resistance

Temperature Versus Resistance

Altitude Versus Barometric Pressure

Altitude Versus Barometric Pressure

Ignition System Specifications

Ignition System Specifications

Fastener Tightening Specifications

Fastener Tightening Specifications

Emissions Related DTCs

Action Taken When the DTC Sets - Type A

1. The control module illuminates the malfunction indicator lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame/Failure Records.

Action Taken When the DTC Sets - Type B

1. The control module illuminates the malfunction indicator lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

Conditions for Clearing the MIL/DTC - Type A or Type B

1. The control module turns OFF the malfunction indicator lamp (MIL) after 4 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Non-Emissions Related DTCs

Action Taken When the DTC Sets - Type C

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The malfunction indicator lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

Conditions for Clearing the DTC - Type C

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

Conditions for Clearing the DTC - Type X

This DTC is available in the control module software, but has been disabled, or turned OFF. In this case, the diagnostic does not run, no DTCs are stored, and the MIL does not illuminate. Type X DTCs are used primarily for export vehicles that do not require MIL illumination or DTC storing.

Scheme 1

Scheme 2

Scheme 3

Engine Controls Schematic Icons

Engine Controls Schematic Icons Icon Icon Definition IMPORTANT: Twisted-pair wires provide an effective shield that helps protect sensitive electronic components from electrical interference. If the wires were covered with shielding, install new shielding. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown : The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires The outside diameter of the twisted wires must not exceed 6.0 mm (0.25 in)

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Powertrain Control Module (PCM) - C1 Connector & Terminal Parts Information

Powertrain Control Module (PCM) - C1 Terminal Identification

Scheme 25

Powertrain Control Module (PCM) - C2 Connector & Terminal Parts Information

Powertrain Control Module (PCM) - C2 Terminal Identification

Scheme 26

Camshaft Position (CMP) Sensor Connector & Terminal Parts Information

Camshaft Position (CMP) Sensor Terminal Identification

Scheme 27

Central Sequential Fuel Injection (Central SFI) Connector & Terminal Parts Information

Central Sequential Fuel Injection (Central SFI) Terminal Identification

Scheme 28

Crankshaft Position (CKP) Sensor Connector & Terminal Parts Information

Crankshaft Position (CKP) Sensor Terminal Identification

Scheme 29

Engine Coolant Temperature (ECT) Sensor Connector & Terminal Parts Information

Engine Coolant Temperature (ECT) Sensor Terminal Identification

Scheme 30

Evaporative Emission (EVAP) Canister Purge Solenoid Valve Connector & Terminal Parts Information

Evaporative Emission (EVAP) Canister Purge Solenoid Valve Terminal Identification

Scheme 31

Evaporative Emission (EVAP) Canister Vent Solenoid Valve Connector & Terminal Parts Information

Evaporative Emission (EVAP) Canister Vent Solenoid Valve Terminal Identification

Scheme 32

Fuel Pump and Sender Assembly Connector & Terminal Parts Information

Fuel Pump and Sender Assembly Terminal Identification

Scheme 33

Fuel Tank Pressure (FTP) Sensor Connector & Terminal Parts Information

Fuel Tank Pressure (FTP) Sensor Terminal Identification

Scheme 34

Heated Oxygen Sensor (HO2S) Bank 1 Sensor 1 Connector & Terminal Parts Information

Heated Oxygen Sensor (HO2S) Bank 1 Sensor 1 Terminal Identification

Scheme 35

Heated Oxygen Sensor (HO2S) Bank 1 Sensor 2 Connector & Terminal Parts Information

Heated Oxygen Sensor (HO2S) Bank 1 Sensor 2 Terminal Identification

Heated Oxygen Sensor (HO2S) Bank 2 Sensor 1

Heated Oxygen Sensor (HO2S) Bank 2 Sensor 1 Connector & Terminal Parts Information

Heated Oxygen Sensor (HO2S) Bank 2 Sensor 1 Terminal Identification

Heated Oxygen Sensor (HO2S) Bank 2 Sensor 2

Heated Oxygen Sensor (HO2S) Bank 2 Sensor 2 Connector & Terminal Parts Information

Heated Oxygen Sensor (HO2S) Bank 2 Sensor 2 Terminal Identification

Scheme 36

Idle Air Control (IAC) Valve Connector & Terminal Parts Information

Idle Air Control (IAC) Valve Terminal Identification

Scheme 37

Ignition Coil Connector & Terminal Parts Information

Ignition Coil Terminal Identification

Scheme 38

Ignition Control Module (ICM) Connector & Terminal Parts Information

Ignition Control Module (ICM) Terminal Identification

Scheme 39

Knock Sensor (KS) Connector & Terminal Parts Information

Knock Sensor (KS) Terminal Identification

Scheme 40

Manifold Absolute Pressure (MAP) Sensor Connector & Terminal Parts Information

Manifold Absolute Pressure (MAP) Sensor Terminal Identification

Scheme 41

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor Connector & Terminal Parts Information

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor Terminal Identification

Scheme 42

Throttle Position (TP) Sensor Connector & Terminal Parts Information

Throttle Position (TP) Sensor Terminal Identification

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Powertrain Control Module Replacement

Service of the powertrain control module (PCM) should normally consist of either replacement of the PCM or electrically erasable programmable read only memory (EEPROM) programming. If the diagnostic procedures call for the PCM to be replaced, the PCM should be inspected first to see if the correct part is being used. If the correct part is being used, remove the faulty PCM and install the new service PCM.

Note. Turn the ignition OFF when installing or removing the control module connectors and disconnecting or reconnecting the power to the control module (battery cable, powertrain control module (PCM)/engine control module (ECM)/transaxle control module (TCM) pigtail, control module fuse, jumper cables, etc.) in order to prevent internal control module damage. Control module damage may result when the metal case contacts battery voltage. DO NOT contact the control module metal case with battery voltage when servicing a control module, using battery booster cables, or when charging the vehicle battery. In order to prevent any possible electrostatic discharge damage to the control module, do no touch the connector pins or the soldered components on the circuit board. Remove any debris from around the control module connector surfaces before servicing the control module. Inspect the control module connector gaskets when diagnosing or replacing the control module. Ensure that the gaskets are installed correctly. The gaskets prevent contaminant intrusion into the control module. The replacement control module must be programmed.

Removal Procedure

1. Using a scan tool, retrieve the percentage of remaining engine oil. Record the remaining engine oil life.
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/chevy-express-h1500/2003-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
3. Disconnect the PCM harness connectors.
4. Release the spring latch from the PCM.
5. Lift the PCM from the PCM mounting tray.
6. Remove the PCM from the engine compartment.

Installation Procedure

1. Install the PCM to the PCM mounting tray.
2. Secure the spring latch to the PCM.
3. Connect the PCM connectors to the PCM. Tighten: Tighten the PCM connector end fasteners to 8 N.m (71 lb in).
4. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/chevy-express-h1500/2003-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
5. If a new PCM is being installed, program the PCM. Refer to «Control Module References»(/chevrolet/chevy-express-h1500/2003-2012/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) .

Crankshaft Position System Variation Learn

1. Install a scan tool.
2. Monitor the powertrain control module (PCM) for DTCs with a scan tool. If other DTCs are set, except DTC P0315, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-trouble-code-dtc-list) for the applicable DTC.
3. Select the crankshaft position variation learn procedure with a scan tool.
4. The scan tool instructs you to perform the following: Accelerate to wide open throttle (WOT). Release throttle when fuel cut-off occurs. Observe fuel cut-off for applicable engine. Engine should not accelerate beyond calibrated RPM value. Release throttle immediately if value is exceeded. Block drive wheels. Set parking brake. DO NOT apply brake pedal. Cycle ignition from OFF to ON. Apply and hold brake pedal. Start and idle engine. Turn the A/C OFF. Vehicle must remain in Park or Neutral. The scan tool monitors certain component signals to determine if all the conditions are met to continue with the procedure. The scan tool only displays the condition that inhibits the procedure. The scan tool monitors the following components: Crankshaft position (CKP) sensors activity-If there is a CKP sensor condition, refer to the applicable DTC. Camshaft position (CMP) signal activity-If there is a CMP signal condition, refer to the applicable DTC. Engine coolant temperature (ECT)-If the engine coolant temperature is not warm enough, idle the engine until the engine coolant temperature reaches the correct temperature.
5. Enable the CKP system variation learn procedure with the scan tool.
6. Accelerate to WOT.
7. Release throttle when fuel cut-off occurs.
8. The scan tool display reads Test In Progress.
9. The scan tool displays Learn Status: Learned this ignition. If the scan tool indicates that DTC P0315 ran and passed, the CKP variation learn procedure is complete. If the scan tool indicates DTC P0315 failed or did not run, refer to «DTC P0315»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-dtc-p0140-to-dtc-p0506) . If any other DTCs set, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-trouble-code-dtc-list) for the applicable DTC.
10. Turn OFF the ignition for 30 seconds after the learn procedure is completed successfully.
11. The CKP system variation learn procedure is also required when the following service procedures have been performed, regardless of whether or not DTC P0315 is set: An engine replacement A PCM replacement A harmonic balancer replacement A crankshaft replacement A CKP sensor replacement Any engine repairs which disturb the crankshaft to CKP sensor relationship.

Note. Use care when handling the coolant sensor. Damage to the coolant sensor will affect the operation of the fuel control system.

1. Turn OFF the ignition.
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Drain the coolant below the level of the ECT sensor. Refer to «Draining and Filling Cooling System (Static Fill)»(/chevrolet/chevy-express-h1500/2003-2012/remont/cooling-system-mechanical/#engine-cooling-system) or «Draining and Filling Cooling System (Vac N Fill)»(/chevrolet/chevy-express-h1500/2003-2012/remont/cooling-system-mechanical/#engine-cooling-system__draining-and-filling-cooling-system-vac) .
4. Disconnect the electrical connector.
5. Carefully remove the ECT sensor.

Note. Use care when handling the coolant sensor. Damage to the coolant sensor will affect the operation of the fuel control system.

1. Coat the threads with sealer GM P/N 9985253 or equivalent.
2. Install the ECT sensor. Tighten: Tighten the ECT sensor to 20 N.m (15 lb ft).
3. Connect the ECT sensor harness connector to the ECT sensor.
4. Refill the cooling system. Refer to «Draining and Filling Cooling System (Static Fill)»(/chevrolet/chevy-express-h1500/2003-2012/remont/cooling-system-mechanical/#engine-cooling-system) or «Draining and Filling Cooling System (Vac N Fill)»(/chevrolet/chevy-express-h1500/2003-2012/remont/cooling-system-mechanical/#engine-cooling-system__draining-and-filling-cooling-system-vac) .
5. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Turn OFF the ignition.
2. Disconnect the mass air flow (MAF) sensor harness connector.
3. Loosen the clamps (1) on the MAF sensor.
4. Carefully remove the MAF sensor from the air intake ducts (5).

1. Install the MAF sensor (5) into the air intake ducts.
2. Tighten the clamps (1) on the MAF sensor. Tighten: Tighten the clamps to 4 N.m (35 lb in).
3. Connect the MAF sensor harness connector.

Other than checking for a worn grommet and loose electrical connectors, the only service possible is a unit replacement if the diagnosis shows a malfunctioning manifold absolute pressure (MAP) sensor.

1. Turn OFF the ignition.
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Disconnect the MAP sensor harness connector.
4. Remove the MAP sensor by pulling straight up with a slight rocking motion.
5. Remove the MAP sensor grommet.
6. Discard the MAP sensor grommet.

1. Install the new MAP sensor grommet on the MAP sensor.
2. Install the MAP sensor.
3. Connect the MAP sensor harness connector.
4. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

Heated Oxygen Sensor Replacement - Bank 1 Sensor 1

Tools Required

J 39194-B Oxygen Sensor Wrench. See Special Tools .

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the connector (1) for the HO2S.
3. Remove the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .

1. Coat the threads of the oxygen sensor with anti-seize compound GM P/N 5613695, if necessary.
2. Install the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Tighten: Tighten the sensor to 42 N.m (31 lb ft).
3. Connect the HO2S harness connector (1).
4. Lower the vehicle.

Heated Oxygen Sensor Replacement - Bank 1 Sensor 2

Tools Required

J 39194-B Oxygen Sensor Wrench. See Special Tools .

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the connector (1) from the HO2S.
3. Remove the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .

1. Coat the threads of the oxygen sensor with anti-seize compound GM P/N 5613695, if necessary.
2. Install the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Tighten: Tighten the sensor to 42 N.m (31 lb ft).
3. Connect the HO2S harness connector (1).
4. Lower the vehicle.

Heated Oxygen Sensor Replacement - Bank 2 Sensor 1

Tools Required

J 39194-B Oxygen Sensor Wrench. See Special Tools .

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the connector (1) for the HO2S.
3. Remove the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .

1. Coat the threads of the oxygen sensor with anti-seize compound GM P/N 5613695, if necessary.
2. Install the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Tighten: Tighten the sensor to 42 N.m (31 lb ft).
3. Connect the HO2S harness connector (1).
4. Lower the vehicle.

Heated Oxygen Sensor Replacement - Bank 2 Sensor 2

Tools Required

J 39194-B Oxygen Sensor Wrench. See Special Tools .

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the connector (1) for the HO2S.
3. Remove the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .

1. Coat the threads of the oxygen sensor with anti-seize compound GM P/N 5613695, if necessary.
2. Install the HO2S (2) using a J 39194-B . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Tighten: Tighten the sensor to 42 N.m (31 lb ft).
3. Connect the HO2S harness connector (1).
4. Lower the vehicle.

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Remove the throttle position (TP) sensor harness connector.
3. Remove the TP sensor attaching fasteners.
4. Remove the TP sensor from the throttle body assembly.

1. With the throttle valve closed, install the TP sensor on the throttle shaft. Rotate the TP sensor counterclockwise in order to align the mounting holes.
2. Install the TP sensor attaching fasteners. Tighten: Tighten the fasteners to 2 N.m (18 lb in).
3. Install the TP sensor harness connector.
4. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Turn OFF the ignition.
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Disconnect the harness connector from the idle air control (IAC) valve.
4. Remove the IAC valve attaching fasteners.
5. Remove the IAC valve assembly.
6. Remove the O-ring.

Cleaning and Inspection Procedure

1. Clean the IAC valve O-ring sealing surface, the pintle valve seat, and the air passage. Use a carburetor cleaner and a parts cleaning brush in order to remove any carbon deposits. Follow the instructions on the container. Do not use a cleaner that contains methyl ethyl ketone (MEK). MEK is an extremely strong solvent and not necessary for this type of deposit. Shiny spots on the pintle or seat are normal and do not indicate misalignment or a bent pintle shaft. If the air passage has heavy deposits, remove the throttle body for a complete cleaning. Refer to «Throttle Body Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
2. Inspect the IAC valve O-ring for cuts, cracks, or distortion. Replace the O-ring if damaged.

1. Measure the distance between tip of the IAC valve pintle and the mounting flange. If the distance is more than 28 mm (1.10 in), use finger pressure in order to slowly retract the pintle. The force required to retract the pintle of a new valve will not cause damage to the valve.
2. Lubricate the IAC valve O-ring with clean engine oil.
3. Install the IAC valve assembly.
4. Install the attaching fasteners. Tighten: Tighten the IAC valve fasteners to 3 N.m (27 lb in).
5. Connect the IAC harness connector.
6. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
7. Reset the IAC valve pintle position.

IAC Valve Reset Procedure

1. Turn ON the ignition for 20 seconds.
2. Turn OFF the ignition for 10 seconds.
3. Start the engine.
4. Check for the proper idle speed.

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Remove the air cleaner outlet resonator. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
3. Remove the accelerator cable from the throttle lever.
4. Remove the accelerator cable from the engine cable bracket.
5. Remove the accelerator cable from the accelerator pedal (2).
6. Remove the accelerator cable from the bulkhead (1).

1. Install the accelerator cable to the bulkhead (1).
2. Install the accelerator cable to the accelerator pedal (2).
3. Install the accelerator cable to the engine cable bracket.
4. Install the accelerator cable to the throttle lever.
5. Install the air cleaner outlet resonator. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
6. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Lift upward on the accelerator pedal (3) to relieve the tension on the cable (2).
2. Remove the retainer (1) from the pedal lever (4) hole.
3. Remove the cable from the slot in the pedal lever.
4. Remove the accelerator pedal mounting fasteners.
5. Remove the accelerator pedal assembly.

1. Place the accelerator pedal assembly (4) on the mounting surface.
2. Install the mounting bolts. Tighten: Tighten the pedal assembly to 5 N.m (44 lb in).
3. Lift upward on the accelerator pedal (3).
4. Insert the cable (2) through the pedal lever slot.
5. Press the retainer (1) into the lever hole until fully seated.
6. Check the pedal (3) for free movement by pressing down on the pedal.

1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/chevy-express-h1500/2003-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Remove the air cleaner outlet resonator. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
4. Remove the air cleaner outlet adapter stud.
5. Remove the cruise control cable. Refer to «Cruise Control Cable Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/cruise-control-systems/#cruise-control-system) .
6. Remove the accelerator cable. Refer to «Accelerator Control Cable Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
7. Remove the stud and nuts retaining the accelerator control cable bracket and position the bracket aside.
8. Disconnect the idle air control (IAC) valve harness connector.
9. Disconnect the throttle position (TP) sensor harness connector.
10. Remove the throttle body retaining studs.
11. Remove the throttle body assembly.
12. Discard the throttle body seal.

1. Clean the gasket surface on the intake manifold.
2. Install the throttle body assembly with a new seal.
3. Install the throttle body assembly retaining studs. Tighten: Tighten the studs to 9 N.m (80 lb in).
4. Install the adapter stud for the air cleaner outlet resonator. Tighten: Tighten the fasteners to 8 N.m (71 lb in).
5. Connect the TP sensor harness connector.
6. Connect the IAC valve harness connector.
7. Install the accelerator control cable bracket using the mounting fasteners. Tighten: Tighten the fasteners to 12 N.m (106 lb in).
8. Install the accelerator cable.
9. Install the cruise control cable.
10. Install the air cleaner outlet resonator. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
11. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
12. Connect the negative battery cable.
13. Use the following procedure in order to inspect the accelerator pedal operation. Depress the pedal to the floor. Release the accelerator pedal.

Fuel Pressure Relief (With CH 48027)

Tools Required

CH-48027 Digital Pressure Gage

1. Remove the engine cover, if required.
2. Loosen the fuel fill cap in order to relieve the fuel tank vapor pressure.
3. Remove the fuel rail service port cap.
4. Wrap a shop towel around the fuel rail service port.
5. Connect the CH-48027-3 (4) to the fuel rail service port.
6. Connect the CH-48027-2 (2) to the CH-48027-3 (4).
7. Place the hose on the CH-48027-2 (2) into an approved gasoline container.
8. Open the valve on the CH-48027-2 (2) in order to bleed any fuel from the fuel rail.
9. Close the valve on the CH-48027-2 (2).
10. Remove the hose on the CH-48027-2 (2) from the approved gasoline container.
11. Disconnect the CH-48027-2 (2) from the CH-48027-3 (4).
12. Disconnect the CH-48027-3 (4) from the fuel rail service port.
13. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
14. Install the fuel rail service port cap.
15. Install the engine cover, if required.
16. Tighten the fuel fill cap.

Fuel Pressure Relief (Without CH 48027)

1. Loosen the fuel fill cap in order to relieve the fuel tank vapor pressure.
2. Remove the engine cover, if required.
3. Remove the fuel rail service port cap.
4. Wrap a shop towel around the fuel rail service port and using a small flat bladed tool, depress (open) the fuel rail test port valve.
5. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
6. Install the fuel rail service port cap.
7. Install the engine cover, if required.
8. Tighten the fuel fill cap.

Tools Required

CH-48027 Digital Pressure Gage

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
2. Connect the CH-48027-1 (1) to the CH-48027-2 (2).
3. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
4. Perform any tests and/or diagnostics as needed. For the proper usage of the CH-48027 , refer to the manufacture's directions.

1. Relieve the fuel system pressure, if required. Perform the following steps: CAUTION: Wrap a shop towel around the fuel pressure connection in order to reduce the risk of fire and personal injury. The towel will absorb any fuel leakage that occurs during the connection of the fuel pressure gage. Place the towel in an approved container when the connection of the fuel pressure gage is complete. Wrap a shop towel around the fuel rail service port. Place the hose on the CH-48027-2 (2) into an approved gasoline container. Open the valve on the CH-48027-2 (2) in order to bleed any fuel from the fuel rail. Close the valve on the CH-48027-2 (2). Remove the hose on the CH-48027-2 (2) from the approved gasoline container. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
2. Disconnect the CH-48027-1 (1) from the CH-48027-2 (2).
3. Disconnect the CH-48027-2 (2) from the CH-48027-3 (4).
4. Disconnect the CH-48027-3 (4) from the fuel rail service port.
5. Install the fuel rail service port cap.
6. Install the engine cover, if required.
7. Tighten the fuel fill cap.

J 37088-A Fuel Line Quick-Connect Separator. See Special Tools .

1. Relieve the fuel system pressure before servicing any fuel system connection. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
2. Remove the retainer from the quick-connect fitting.
3. Blow dirt out of the fitting using compressed air.
4. Choose the correct tool from J 37088-A tool set for the size of the fitting. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Insert the tool into the female connector, then push inward to release the locking tabs.
5. Pull the connection apart.
6. Using a clean shop towel, wipe off the male pipe end.
7. Inspect both ends of the fitting for dirt and burrs. Clean or replace the components as required.

1. Apply a few drops of clean engine oil to the male pipe end.
2. Push both sides of the fitting together to cause the retaining tabs to snap into place.
3. Once installed, pull on both sides of the fitting to make sure the connection is secure.
4. Install the retainer to the quick-connect fitting.

1. Relieve the fuel system pressure before servicing any fuel system connection. Refer to the «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
2. Using compressed air, blow any dirt out of the quick-connect fitting.
3. Squeeze the plastic retainer release tabs.
4. Pull the connection apart.

1. Apply a few drops of clean engine oil to the male fuel pipe end.
2. Push both sides of the quick-connect fitting together in order to cause the retaining tabs to snap into place.
3. Once installed, pull on both sides of the quick-connect fitting in order to make sure the connection is secure.

Fuel Tank Draining

1. Disconnect the negative battery cable.
2. Use a hand operated pump device in order to remove the fuel through the fuel filler pipe.

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
5. Loosen the fuel fill hose clamp.
6. On cargo van, disconnect the fuel fill hose from the fuel tank.
7. On passenger van, disconnect the fuel fill hose from the fuel tank.
8. On all models, clean all the fuel pipe connections and the surrounding areas before disconnecting the fuel pipes in order to avoid possible contamination of the fuel system.
9. Disconnect the rear fuel return pipe (1) at the chassis fuel return pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
10. Disconnect the rear fuel feed pipe (2) at the chassis fuel feed pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
11. With the aid of an assistant, support the fuel tank.
12. Remove and discard the attaching bolts (1) from the fuel tank strap.
13. Remove the fuel tank straps (2).
14. Carefully lower the fuel tank.
15. Disconnect the fuel sender and the fuel pump electrical connectors.
16. Remove the fuel tank.
17. Place the fuel tank in a suitable work area.
18. Remove the fuel sender assembly (1) and the fuel pipes from the fuel tank. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
19. Remove the evaporative emission (EVAP) hoses from the fuel tank and EVAP canister (2).
20. Remove two tiedown straps from the EVAP canister (2) then remove the canister from the fuel tank. Discard tiedown straps.
21. Remove the fuel fill hose from the fuel tank.
22. Remove the fuel tank from the fuel tank shield (3).

1. Install the fuel tank into the fuel tank shield (3).
2. Install the fuel fill hose to the fuel tank. Tighten: Tighten the fuel fill hose clamp to 2.75 N.m (24 lb in).
3. Place the EVAP canister in position on the EVAP canister bracket, then install two new tiedown straps.
4. Install the EVAP hoses to the fuel tank and EVAP canister (2).
5. Install the fuel sender assembly (1) and the fuel pipes to the fuel tank. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
6. With the aid of an assistant, position and support the fuel tank.
7. Raise the fuel tank slightly.
8. Connect the electrical connectors to the fuel sender and fuel pump.
9. Raise the tank fully.
10. Install the fuel tank straps (2).
11. Install the new attaching bolts (4) to the fuel tank strap. Tighten: Tighten the bolts to 20.5 N.m (15 lb ft).
12. Connect the chassis fuel feed pipe to the rear fuel feed pipe (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
13. Connect the rear fuel return pipe (1) to the chassis fuel return pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
14. On passenger van, connect the fuel fill hose to the fuel tank.
15. On cargo van, connect the fuel fill hose to the fuel tank. Tighten: Tighten the fuel fill hose clamp to 2.75 N.m (24 lb in).
16. On all models, lower the vehicle.
17. Refill the fuel tank.
18. Tighten the fuel filler cap.
19. Connect the negative battery cable.
20. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Disconnect the negative battery cable.
2. Relieve the fuel pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Raise the vehicle.
4. Remove the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
5. Remove the fuel pressure sensor (1).

1. Install the fuel pressure sensor (1).
2. Install the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
3. Refill the fuel tank.
4. Install the fuel filler cap.
5. Connect the negative battery cable.
6. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
5. Remove the fuel sender assembly. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
6. Disconnect the fuel pump electrical connector.
7. Remove the electrical connector retaining clip from the fuel level sensor.
8. Disconnect the electrical connector from the fuel level sensor under the fuel sender cover.
9. Remove the retaining clip from the fuel level sensor.
10. Squeeze the locking tangs and remove the fuel level sensor (1).

1. Install the fuel level sensor (1).
2. Install the retaining clip to the fuel level sensor.
3. Connect the electrical connector to the fuel level sensor.
4. Connect the electrical connector retaining clip to the fuel level sensor.
5. Connect the fuel pump electrical connector.
6. Install the fuel sender assembly. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
7. Install the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
8. Refill the fuel tank.
9. Install the fuel filler cap.
10. Connect the negative battery cable.
11. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
5. Remove the fuel sender assembly. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
6. Support the fuel sender assembly with one hand and grasp the strainer with the other hand.
7. Pull the strainer off the fuel sender. Discard the strainer after inspection.
8. Inspect the strainer. Replace a contaminated strainer and clean the fuel tank.
9. Disconnect the fuel pump electrical connector.
10. Remove the electrical connector retaining clip from the fuel level sensor.
11. Disconnect the electrical connector from the fuel level sensor under the fuel sender cover.
12. Remove the retaining clip from the fuel level sensor.
13. Squeeze the locking tangs and remove the fuel level sensor (1).
14. Remove the fuel pressure sensor (2).

1. Install the fuel pressure sensor (2).
2. Install the fuel level sensor (2).
3. Install the retaining clip to the fuel level sensor.
4. Connect the electrical connector to the fuel level sensor.
5. Connect the electrical connector retaining clip.
6. Connect the fuel pump electrical connector.
7. Install the fuel sender assembly. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
8. Install the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
9. Refill the fuel tank.
10. Tighten the fuel filler cap.
11. Connect the negative battery cable.
12. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Clean all the fuel pipe and hose connections and the surrounding areas before disconnecting in order to avoid contamination of the fuel system.
2. Remove the fuel filler cap.
3. Drain the fuel below the level of the fuel tank fill hose. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the 2 retaining bolts and push-pin that retain the filler neck to the body.
5. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
6. Remove the fuel filler tube ground strap bolt.
7. Loosen the fuel fill hose to fuel fill pipe clamp.
8. Disconnect the fuel fill hose from the fuel fill pipe.
9. Remove the fuel fill pipe assembly.

1. Install the fuel fill pipe to the fuel fill hose.
2. Align the fuel fill pipe to the fuel fill pipe housing. Tighten: Tighten the fuel fill hose clamp to 2.75 N.m (24 lb in).
3. Install the fuel filler tube ground strap bolt. Tighten: Tighten the fuel filler tube ground strap bolt to 8 N.m (70 lb in).
4. Lower the vehicle.
5. Install the fuel fill pipe housing bolts and push-pin. Tighten: Tighten the fuel fill pipe housing bolts to 6 N.m (53 lb in).
6. Refill the fuel tank.
7. Install the fuel filler cap.

1. Clean all the fuel pipe and hose connections and the surrounding areas before disconnecting in order to avoid contamination of the fuel system.
2. Remove the fuel filler cap.
3. Drain the fuel below the level of the fuel tank fill hose. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the 2 retaining bolts and push-pin that retain the filler neck to the body.
5. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
6. Remove the fuel filler tube ground strap bolt.
7. Loosen the fuel fill hose to fuel fill pipe clamp.
8. Disconnect the fuel fill hose from the fuel fill pipe.
9. Remove the fuel fill pipe assembly.

1. Install the fuel fill pipe to the fuel fill hose.
2. Align the fuel fill pipe to the fuel fill pipe housing. Tighten: Tighten the fuel fill hose clamp to 2.75 N.m (24 lb in).
3. Install the fuel filler tube ground strap bolt. Tighten: Tighten the fuel filler tube ground strap bolt to 8 N.m (70 lb in).
4. Lower the vehicle.
5. Install the fuel fill pipe housing bolts and push-pin. Tighten: Tighten the fuel fill pipe housing bolts to 6 N.m (53 lb in).
6. Refill the fuel tank.
7. Install the fuel filler cap.

1. Clean all the fuel pipe and hose connections and the surrounding areas before disconnecting in order to avoid contamination of the fuel system.
2. Remove the fuel filler cap.
3. Drain the fuel below the level of the fuel tank fill hose. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the 2 retaining bolts and push-pin that retain the filler neck to the body.
5. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
6. Remove the fuel filler tube ground strap bolt.
7. Loosen the fuel fill hose to fuel fill pipe clamp.
8. Disconnect the fuel fill hose from the fuel fill pipe.
9. Remove the fuel fill pipe assembly.

1. Install the fuel fill pipe to the fuel fill hose.
2. Align the fuel fill pipe to the fuel fill pipe housing. Tighten: Tighten the fuel fill hose clamp to 2.75 N.m (24 lb in).
3. Install the fuel filler tube ground strap bolt. Tighten: Tighten the fuel filler tube ground strap bolt to 8 N.m (70 lb in).
4. Lower the vehicle.
5. Install the fuel fill pipe housing bolts and push-pin. Tighten: Tighten the fuel fill pipe housing bolts to 6 N.m (53 lb in).
6. Refill the fuel tank.
7. Install the fuel filler cap.

J 45722 Fuel Sender Lock Nut Wrench. See Special Tools .

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
5. Use the J 45722 and a long breaker-bar in order to unlock the fuel sender lock ring. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
6. Remove the fuel sender assembly and the seal. Discard the seal.
7. Clean the fuel sender sealing surfaces.
8. Place the lock ring on a flat surface. Measure the clearance between the lock ring and the flat surface using a feeler gage at 7 points.
9. If warpage is less than 0.41 mm (0.016 in), the lock ring does not require replacement.
10. If warpage is greater than 0.41 mm (0.016 in), the lock ring must be replaced.

1. Install the new seal on the fuel tank.
2. Install the fuel sender assembly into the fuel tank.
3. Use the J 45722 in order to install the fuel sender lock ring. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Turn the fuel sender lock ring in a clockwise direction.
4. Install the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
5. Refill the fuel tank.
6. Tighten the fuel filler cap.
7. Connect the negative battery cable.
8. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
4. Loosen the fuel and evaporative emissions (EVAP) pipe retainer (2) nut at the bellhousing stud.
5. Disconnect the chassis fuel feed and return pipes (3) at the engine compartment fuel feed and return pipes (4).
6. Remove the injector fuel inlet and outlet pipe retainer nuts.
7. Remove the injector fuel inlet and the outlet pipe retainer.
8. Remove the retaining bolt from the rear fuel pipe bracket.
9. Pull straight up on the fuel pipes in order to remove the fuel pipes from the injector assembly.
10. Remove the O-ring seals from both ends of the fuel feed and return pipes.
11. Discard the O-ring seals.

1. Assemble the new O-rings into the inlet and outlet of the fuel injector assembly.
2. Apply a few drops of clean engine oil to the male tube ends.
3. Install the fuel feed and return pipes to the injector assembly.
4. Install the fuel pipe retainer and the attaching nuts.
5. Install the retaining bolt to the rear fuel pipe bracket. Tighten: Tighten the bracket bolt to 6 N.m (53 lb in). Tighten the retainer nuts to 3 N.m (27 lb in).
6. Install the new O-ring seals on the engine fuel feed and the return pipes.
7. Install the chassis fuel feed and return pipes (3) to the engine compartment fuel feed and return pipes (4). Tighten: Tighten the fuel pipe nuts to 27 N.m (20 lb ft).
8. Install the retainer nut to the fuel and EVAP pipe. Tighten: Tighten the retainer nut to 28 N.m (21 lb ft).
9. Tighten the fuel filler cap.
10. Connect the negative battery cable.
11. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.
12. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Disconnect the fuel feed and return pipes from the engine compartment fuel pipes.
4. Remove the fuel pipes from the bellhousing stud retainer clip.
5. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
6. Disconnect the chassis fuel return pipe at the rear fuel return pipe.
7. Remove the fuel pipe retaining clips. Note the location of the retaining clips for installation.
8. Remove the fuel feed and return pipes.

1. Position the fuel feed and return pipes in the vehicle.
2. Install the fuel pipe retaining clips (1). Tighten: Tighten the bolts to 12 N.m (106 lb in).
3. Connect the chassis fuel return pipe to the rear fuel return pipe.
4. Lower the vehicle.
5. Connect the fuel feed and return pipes to the engine compartment fuel pipes. Ensure the O-rings are in place. Tighten: Tighten the fuel pipe fittings to 27 N.m (20 lb ft) using a backup wrench.
6. Install the fuel pipes to the retainer clip. Tighten: Tighten the fuel pipe retainer clip nut to 28 N.m (21 lb ft).
7. Tighten the fuel filler cap.
8. Connect the negative battery cable.
9. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.
10. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Disconnect the front chassis fuel linse.
4. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
5. Disconnect the chassis fuel return pipe at the rear fuel return pipe.
6. Disconnect the chassis fuel feed pipe at the rear fuel feed pipe.
7. Remove the fuel pipe retaining clips (1).
8. Remove the fuel feed and return pipes.

1. Install the fuel feed and return pipes and the fuel pipe retaining clips (1). Tighten: Tighten the bolts to 12 N.m (106 lb in).
2. Connect the chassis fuel return pipe to the rear fuel return pipe.
3. Connect the chassis fuel feed pipe to the rear fuel feed pipe.
4. Lower the vehicle.
5. Connect the front chassis fuel lines.
6. Refill the fuel tank.
7. Connect the negative battery cable.
8. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Disconnect the front chassis fuel lines.
5. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
6. Disconnect the chassis fuel feed and return pipes at the rear fuel feed and return pipes (2).
7. Remove the fuel pipe retaining clips (1).
8. Remove the fuel feed and return pipes.

1. Install the fuel feed and return pipes and the fuel pipe retaining clips (1) to the frame rail. Tighten: Tighten the bolts to 12 N.m (106 lb in).
2. Connect the chassis fuel feed and return pipes to the rear fuel feed and return pipes (2).
3. Connect the chassis fuel return pipe to the rear fuel return pipe (2).
4. Lower the vehicle.
5. Connect the front chassis fuel lines.
6. Refill the fuel tank.
7. Tighten the fuel filler cap.
8. Connect the negative battery cable.
9. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Disconnect the negative battery cable.
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
5. Remove the fuel feed and return pipes (6) from the fuel sender (1).

1. Install the fuel feed and return pipes (6) to the fuel sender (1).
2. Install the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
3. Lower the vehicle.
4. Refill the fuel tank.
5. Tighten the fuel filler cap.
6. Connect the negative battery cable.
7. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

Fuel System Cleaning

1. Disconnect the negative battery cable.
2. Relieve fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Drain fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-tank-draining) .
4. Remove the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
5. Remove the fuel sender assembly. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
6. Inspect the fuel strainer. Replace a contaminated strainer and inspect the fuel pump.
7. Inspect the fuel pump inlet for dirt and debris. Replace the fuel pump if you find dirt or debris in the fuel pump inlet.
8. Flush the fuel tank with hot water.
9. Pour the water out of the fuel sender assembly opening.
10. Rock the tank to ensure that removal of the water from the tank is complete.
11. Inspect the fuel filter for contamination.
12. Replace the fuel filter if the filter is plugged.
13. Clean the fuel lines by applying air pressure in the opposite direction of the fuel flow.
14. Install the fuel sender assembly with a new seal into the fuel tank. Refer to «Fuel Sender Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
15. Install the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
16. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
3. Use a standard valve core tool in order to remove the valve core (2).

1. Use a standard valve core tool in order to install a new valve core (2).
2. Tighten the fuel filler cap.
3. Connect the negative battery cable.
4. Inspect for leaks. Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition for 2 seconds. Inspect for fuel leaks.
5. Install the fuel pressure connection valve cap (3).
6. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

An 8-digit part identification number is on a mylar label affixed to the fuel meter body assembly. Refer to this number if servicing or part replacement is required.

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Disconnect the negative battery cable.
3. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (With CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-with-ch-48027) or «Fuel Pressure Relief (Without CH 48027)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__fuel-pressure-relief-without-ch-48027) .
4. Remove the upper intake manifold assembly. Refer to «Upper Intake Manifold Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/mechanical/#engine-mechanical-43l) .
5. Before removal, clean the fuel meter body assembly with a spray type engine cleaner, GM X-30A or the equivalent, if necessary. Follow the package instructions. Do not soak the fuel meter body assembly in liquid cleaning solvent.
6. Squeeze the poppet nozzle locking tabs together while lifting the nozzle out of the casting socket.
7. Remove the fuel meter body from the bracket by releasing the locking tabs on the bracket.

1. Install the fuel meter body in the intake manifold.
2. Push the fuel meter body into the bracket. Make sure all of the tabs are locked into place.
3. Push the poppet nozzles into the casting sockets.
4. Inspect the poppet nozzles in order to ensure the nozzles are firmly seated and locked in the casting sockets.
5. Install the upper intake manifold assembly. Refer to «Upper Intake Manifold Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/mechanical/#engine-mechanical-43l) .
6. Tighten the fuel filler cap.
7. Connect the negative battery cable.
8. Inspect for leaks: Turn ON the ignition for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition. Inspect for fuel leaks.
9. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Remove the upper intake manifold. Refer to «Upper Intake Manifold Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/mechanical/#engine-mechanical-43l) .
2. Remove the fuel pressure dampener retaining clip (7).
3. Twist and pull the fuel pressure dampener (6) in order to remove the regulator from the housing using a shop towel to catch any spilled fuel.
4. Remove and discard the dampener O-ring seal (5).
5. Cover the fuel pressure dampener housing to prevent contamination from entering the fuel system.

1. Lubricate the NEW O-ring with clean engine oil.
2. Install the fuel pressure dampener O-ring seal (5).
3. Install the fuel pressure dampener (6).
4. Install the fuel pressure dampener retaining clip (7).
5. Install the upper manifold. Refer to «Upper Intake Manifold Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/mechanical/#engine-mechanical-43l) .
6. Tighten the fuel fill cap.
7. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/chevrolet/chevy-express-h1500/2003-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
8. Inspect for leaks. Turn the ignition ON, for 2 seconds. Turn the ignition OFF, for 10 seconds. Turn the ignition ON. Inspect for fuel leaks.

Fuel Injector Cleaning

Tools Required

1. J 44466-12 CSFI Fuel Metering Body Jumper Block. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
2. J 44466-13 Screws. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
3. J 44466-11 IAFM Fuel Transfer Tube Recycling Block. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
4. J 41413 EVAP Pressure and Purge Station. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
5. J 44466-10 Regulator and Hose Assembly. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
6. J 39021 Fuel Injector Coil and Balance Tester. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
7. J 39021-210 Injector Tester Adapter Box. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
8. J 39021-301 V6 Fuel Injector Test Adapter. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
9. J 38500-A Fuel Injector Cleaner. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .

1. Loosen the fuel fill cap to relieve vapor pressure in the fuel tank.
2. Remove the positive crankcase ventilation (PCV) clean air tube from air inlet duct and set aside.
3. Remove the resonator and air inlet duct from throttle body.
4. Remove the brake booster vacuum hose and connector from intake manifold.
5. Remove the electrical connector from the central sequential fuel injection (CSFI) fuel metering body.
6. Remove the spark plug wires from 1, 3 and 5 from the distributor cap.
7. Remove the fuel line bolt (4) at the rear of intake manifold.
8. Relieve the fuel system pressure.
9. Remove the nuts (1) and clamp (2) from the fuel pipe.
10. Remove fuel pipes from the metering body.
11. Install the J 44466-12 (2) and the J 44466-13 (1) to the metering body and tighten. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
12. Install the J 44466-11 (4), clamp (2) and J 44466-13 (1) to the fuel pipe and tighten. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
13. Obtain the J 41413 , close the valve (2) on the tank (3), and remove the regulator assembly. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
14. Install the J 44466-10 (5) to the J 41413 tank (3). See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
15. Connect the J 44466-10 hose (1) to the J 44466-12 (3). See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
16. Install the J 39021 , the J 39021-210 and J 39021-301 (4) to the metering body electrical connector. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
17. Adjust the amperage selector switch on J 39021 to 0. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .5 amps.
18. Open the valve (2) on the tank (3).
19. Open the valve (4) on the J 44466-10 to pressurize the fuel system. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Then close valve (4) before firing injectors. IMPORTANT: The minimum pressure required on the gage (6) is 150 psi. If 150 psi is not obtained, the tank (3) must be refilled prior to performing this procedure.
20. Fire one injector using the J 39021 . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) . Observe a pressure drop on the gage (6) and verify the injector/poppet valve operation. An injector/poppet that is stuck and not operational will have no pressure drop on the gage. If an injector remains stuck, repeat the procedure multiple times (as required) until the injector is operational.
21. Repeat steps 19 and 20 for each individual injector to verify that all injector/poppet valve assemblies are unstuck and functional.
22. Shut off the pressure valve (2) on the tank (3) of the J 41413 . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
23. Bleed off the pressure at the J 44466-10 . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
24. Install the PCV fresh air tube to the air inlet duct.
25. Disconnect and remove the J 44466-10 (1) from the J 44466-12 (3) and the J 41413 . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
26. Remove the J 39021-301 , J 39021-210 and J 39021 from the metering body. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
27. Install the vehicle electrical connector to the metering body.
28. Install brake booster vacuum hose and connector to the intake manifold.
29. Install ignition wires 1, 3, and 5 to the distributor cap.
30. Install the resonator and air intake duct to the throttle body and hand tighten wing nut.
31. Obtain J 38500-A (2). See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
32. Remove the canister top and add top engine cleaner GM P/N 1050002 (Canadian P/N 992872) to the canister.
33. Fill the remainder of the canister with regular unleaded gasoline and install the canister top.
34. Suspend J 38500-A from a convenient underhood location. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
35. Connect the hose from J 38500-A (1) to the service port on the J 44466-12 (3). See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
36. Open valve (3) at the bottom of J 38500-A . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
37. Connect a shop air source to the fitting at the top of J 38500-A and adjust the regulator (1) to 75 psi. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
38. Let the vehicle run at idle until the canister is empty and the vehicle stalls.
39. Remove the shop air supply from J 38500-A . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
40. Depressurize the J 38500-A . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
41. Disconnect the J 38500-A hose from the J 44466-12 . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
42. Remove the PCV clean air tube from the air inlet duct and set aside.
43. Remove the resonator and air inlet duct from the throttle body and set aside.
44. Remove ignition wires 1, 3, and 5 from the distributor cap.
45. Remove brake booster vacuum hose and connector from the intake manifold.
46. Bleed the residual pressure from J 44466-12 . See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
47. Remove J 44466-13 (1) and J 44466-12 (2) from the metering body. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
48. Remove J 44466-13 (1), clamp (2) and J 44466-11 (4) from the fuel pipe (3). See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__special-tools) .
49. Install the fuel pipe (3) to the metering body.
50. Install the clamp (2) and nuts (1). Tighten: Tighten the nuts to 3 N.m (27 lb ft).
51. Apply threadlock GM P/N 12345382 (Canadian P/N 10953489), or equivalent to the threads of the fuel pipe bolt (4).
52. Install the fuel pipe bolt. Tighten: Tighten the bolt to 6 N.m (53 lb ft).
53. Install the brake booster vacuum hose and connector to the intake manifold.
54. Install the resonator and air inlet duct to the throttle body.
55. Install the PCV clean air tube to the inlet duct.
56. Install brake booster vacuum hose and connector to the intake manifold.
57. Install ignition wires 1, 3, and 5 to the distributor cap.
58. Add 1 ounce of port fuel injector cleaner GM P/N 12345104 (Canadian P/N 12345515), or equivalent to the vehicle fuel tank for each gallon of gasoline estimated to be in the tank. IMPORTANT: Instruct the customer to add the remainder of the bottle of port fuel injector cleaner to the vehicle fuel tank at the next fill up.
59. Hand tighten the fuel tank filler cap.
60. Start the vehicle and check for fuel leaks.
61. Using a Tech II scan tool, check for any stored Powertrain DTC codes. Clear codes as required.
62. Disconnect Tech II scan tool. IMPORTANT: Advise the customer to change brands of fuel.

1. Remove the fuel meter body assembly. Refer to «Fuel Meter Body Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
2. Remove the injector assembly retainer (11) and the injector retainer lock nuts (10).
3. While pulling the poppet nozzle tube downward, push with a small tip punch down between the injector terminals until the injector is removed.

1. Lubricate the new injector O-ring seals with clean engine oil.
2. Install the O-rings on the injector assembly (2).
3. Install the fuel injector assembly (12) into the injector socket.
4. Install the injector assembly retainer (11) and the injector retainer lock nuts (10). Tighten: Tighten the lock nuts to 3.0 N.m (27 lb in).
5. Install the fuel meter body assembly. Refer to «Fuel Meter Body Assembly Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Disconnect the evaporative emission (EVAP) purge pipe.
3. Disconnect the purge valve electrical connector.
4. Remove the purge valve mounting nuts.
5. Remove the engine wiring harness bracket from the mounting stud.
6. Remove the purge valve from the intake manifold.

1. Install the purge valve to the intake manifold.
2. Install the engine wiring harness bracket to the mounting stud.
3. Install the purge valve mounting nuts. Tighten: Tighten the nuts to 12 N.m (106 lb in).
4. Connect the purge valve electrical connector.
5. Connect the EVAP purge pipe.
6. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the electrical connector from the EVAP vent valve.
3. Disconnect the canister vent hose.
4. Bend back the tang on the bracket.
5. Slide the EVAP vent valve off the bracket.

1. Slide the EVAP vent valve onto the bracket.
2. Connect the canister vent hose.
3. Connect the electrical connector to the EVAP vent valve.
4. Lower the vehicle.

1. Clean the pipe connections and the surrounding areas before disconnecting in order to avoid possible contamination of the EVAP system.
2. Disconnect the engine compartment EVAP pipe at the EVAP canister purge valve.
3. Disconnect the engine compartment EVAP pipe (1) at the chassis EVAP pipe (2).
4. Remove the EVAP pipe from the engine.
5. Cap the EVAP canister purge valve and the chassis EVAP pipe in order to prevent possible EVAP system contamination.

1. Remove the caps from the EVAP canister purge valve and the chassis EVAP pipe.
2. Install the EVAP pipe on the engine.
3. Connect the engine compartment EVAP pipe (1) to the chassis EVAP pipe (2).
4. Connect the engine compartment EVAP pipe at the EVAP canister purge valve.

1. Remove the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
2. Disconnect the rear EVAP vapor pipe (1) from the fuel sender (2), the fuel tank roll over valve (3), and the fuel tank clips (6).
3. Remove the EVAP vapor pipe from the fuel tank.
4. Cap the fuel sender EVAP pipe and the fuel tank roll over valve.

1. Remove the caps from the fuel sender EVAP pipe and the fuel tank roll over valve.
2. Position the EVAP vapor pipe on the fuel tank.
3. Connect the EVAP vapor pipe (1) to the fuel sender (2), the fuel tank roll over valve (3), and the fuel tank clips (6).
4. Install the fuel tank. Refer to «Fuel Tank Replacement (Passenger/Cargo Van)»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Clean all the EVAP pipe connections and the surrounding areas before disconnecting the pipes in order to avoid possible contamination of the EVAP system.
3. Disconnect the engine compartment EVAP pipe (1) from the chassis EVAP pipe (2).
4. Cap the engine compartment EVAP pipe.
5. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
6. Remove the EVAP pipe from the bellhousing stud clip.
7. Remove the EVAP pipe from the transmission bracket clip.
8. Remove the EVAP pipe from the transfer case bracket clip, AWD drive only.
9. Disconnect the rear EVAP purge pipe (3) from the chassis EVAP purge pipe (2).
10. Cap the rear EVAP purge pipe (3).
11. Note the position of the EVAP pipe for aid in installation.
12. Remove the EVAP pipe from the retaining clips (1).
13. Remove the EVAP pipe.

1. Install the EVAP pipe into the retaining clips (1).
2. Remove the cap from the rear EVAP pipe.
3. Connect the rear EVAP purge pipe (3) to the chassis EVAP purge pipe (2).
4. Install the EVAP pipe into the transfer case bracket clip, AWD drive only.
5. Install the EVAP pipe into the transmission bracket clip.
6. Install the EVAP pipe into the bellhousing stud clip (3).
7. Lower the vehicle.
8. Remove the cap from the engine compartment EVAP pipe.
9. Connect the engine compartment EVAP pipe (1) to the chassis EVAP pipe (2).
10. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the vent hose from the canister.
3. Disconnect the chassis EVAP purge pipe from the EVAP canister.
4. Disconnect the fuel tank EVAP pipe from the canister.
5. Remove the EVAP canister from the EVAP Canister bracket.

1. Connect the fuel tank EVAP pipe to the canister.
2. Connect the chassis EVAP purge pipe to the EVAP canister.
3. Connect the vent hose to the canister.
4. Install the EVAP canister to the EVAP Canister bracket.
5. Install the EVAP canister bracket bolt. Tighten: Tighten the bolt to 12 N.m (106 lb in).
6. Lower the vehicle.

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the vent hose from the canister.
3. Disconnect the chassis EVAP purge pipe from the EVAP canister.
4. Disconnect the fuel tank EVAP pipe from the canister.
5. Remove the EVAP canister from the EVAP canister bracket.

1. Install the EVAP canister to the EVAP canister bracket.
2. Connect the fuel tank EVAP pipe to the canister.
3. Connect the chassis EVAP purge pipe to the EVAP canister.
4. Connect the vent hose to the canister.
5. Lower the vehicle.

Distributor Inspection

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Inspect the cap for cracks, tiny holes or carbon tracks between the cap terminal traces. Diagnose the carbon tracks using the following procedure: Remove the cap. Refer to «Distributor Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) . Place 1 lead from the DMM on a cap terminal. Use the other lead in order to probe all other terminals and the center carbon ball. Move the base lead to the next terminal. Probe all other leads. Continue this procedure until you test all the secondary terminals. If there are any non-infinite readings, replace the cap.
3. Inspect the cap for excess build-up of corrosion on the terminals. Scrape clean the terminals. Replace the cap if the corrosion is excessive. Some buildup is normal
4. Inspect the rotor segment for excess wear. Replace the rotor if excess looseness in the rotor segment is present.
5. Inspect the shaft for shaft-to-bushing looseness: Inspect the housing for cracks or damage. Insert the shaft in the housing. If the shaft wobbles, replace the housing assembly.
6. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

Disassembly Procedure

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Align white paint mark on the bottom stem of the distributor, and the pre-drilled indent hole in the bottom of the gear (2).
3. With the gear in this position, the rotor segment should be positioned as shown for a V6 engine (1). If not, replace the distributor.
4. Remove the two screws from the rotor.
5. Remove the rotor.
6. Note the locating holes that the rotor was removed from: The rotor screw holes (1) The rotor locator pin holes (2)
7. Line up the square-cut hole in the vane wheel with the camshaft position (CMP) sensor.
8. Remove the two screws that hold the camshaft position (CMP) sensor.
9. Discard the screws.
10. Remove the CMP sensor.
11. Note the dimple located below the roll pin hole on one side of the gear. The dimple will be used to properly orient the gear onto the shaft during reassembly.
12. Support the distributor drive gear in a V-block or similar fixture.
13. Drive out the roll pin with a suitable punch.
14. Remove the driven gear from the distributor shaft.
15. Remove the round washer.
16. Remove the tang washer.
17. Remove the shim washer (1).
18. Remove the old oil seal.

Assembly Procedure

1. Line up the square-cut hole in the vane wheel for the camshaft position (CMP) sensor.
2. Insert the sensor into the housing.
3. Install two new screws for the camshaft position (CMP) sensor. Tighten: Tighten the screws to 2.2 N.m (20 lb in).
4. Identify the correct rotor mounting position: At the rotor screw holes (1) At the rotor locator pin holes (2)
5. Install the distributor rotor according to the index marks.
6. Install two rotor hold down screws. Tighten: Tighten the screws to 1.9 N.m (17 lb in).
7. Install the shim washer (1) on the bottom of the distributor shaft.
8. Install the tang washer.
9. Install the round washer.
10. Install the driven gear according to the index marks.
11. Align the rotor segment as shown for a V6 engine (1) or V8 engine (2).
12. Install the gear and align white paint mark on the bottom stem of the distributor, and the pre-drilled indent hole in the bottom of the gear (3).
13. Check to see If the driven gear is installed incorrectly, the dimple will be approximately 180 degrees opposite the rotor segment when it is installed in the distributor.
14. Support the distributor drive gear in a V-block or similar fixture.
15. Install the roll pin with a suitable punch and hammer in order to hold the driven gear in the correct position.
16. Install the new oil seal under the mounting flange of the distributor base.
17. Install the distributor.
18. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

Note. There are two procedures available to install the distributor. Use Installation Procedure 1 when the crankshaft has NOT been rotated from the original position. Use Installation Procedure 2 when any of the following components are removed: The intake manifold The cylinder head The camshaft The timing chain or sprockets The complete engine If the malfunction indicator lamp (MIL) turns on and DTC P1345 sets after installing the distributor, this indicates an incorrectly installed distributor. Engine damage or distributor damage may occur. Use Procedure 2 in order to install the distributor.

1. Turn OFF the ignition.
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Remove the spark plug wires from the distributor cap. Twist each spark plug wire boot 1/2 turn. Pull only on the wire boot in order to remove the wire from the distributor cap.
4. Remove the electrical connector from the base of the distributor.
5. Remove the 2 screws that retain the distributor cap to the housing.
6. Discard the screws.
7. Remove the distributor cap from the housing.
8. Use a grease pencil in order to mark the position of the rotor in relation to the distributor housing (1).
9. Mark the distributor housing and the intake manifold with the grease pencil.
10. As the distributor is being removed from the engine, watch the rotor move in a counter-clockwise direction about 42 degrees. This will appear as slightly more than one clock position.
11. Note the position of the rotor segment.
12. Place a second mark on the base of the distributor (2). This will aid in achieving the proper rotor alignment during the distributor installation.
13. Remove the mounting clamp hold-down bolt.
14. Remove the distributor.

Installation Procedure 1

1. If installing a new distributor assembly, place 2 marks on the new distributor housing in the same location as the marks on the original housing.
2. Remove the new distributor cap, if necessary.
3. Align the rotor with the second mark (2).
4. Guide the distributor into the engine.
5. Align the hole in the distributor hold-down base over the mounting hole in the intake manifold.
6. As the distributor is being installed, observe the rotor moving in a clockwise direction about 42 degrees.
7. Once the distributor is completely seated, the rotor segment should be aligned with the mark on the distributor base (1). If the rotor segment is not aligned with the mark, the driven gear teeth and the camshaft have meshed one or more teeth out of alignment. In order to correct this condition, remove and reinstall the distributor.
8. Install the distributor mounting clamp bolt. Tighten: Tighten the bolt to 25 N.m (18 lb ft).
9. Install the distributor cap.
10. Install the new distributor cap screws. Tighten: Tighten the screws to 2.4 N.m (21 lb in).
11. Install the electrical connector to the distributor.
12. Install the spark plug wires to the distributor cap.
13. Install the ignition coil wire. Note the correct orientation of the wire boot.
14. Refer to Installation Procedure 2 if the malfunction indicator lamp illuminates after installing the distributor.
15. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

Installation Procedure 2

1. Rotate the crankshaft balancer clockwise until the alignment marks on the crankshaft balancer are aligned with the tabs on the engine front cover and the number 1 piston is at TDC of the compression stroke.
2. Align the white paint mark on the bottom stem of the distributor and the pre-drilled indent hole in the bottom of the gear (3).
3. With the gear in this position, the rotor segment should be positioned as shown for a V6 engine (1). The alignment will not be exact. If the driven gear is installed incorrectly, the dimple will be approximately 180 degrees opposite of the rotor segment when installed in the distributor.
4. Use a long screw driver in order to align the oil pump drive shaft to the drive tab of the distributor.
5. Guide the distributor into the engine. Ensure the flat portion of the distributor housing is facing toward the front of the engine.
6. Once the distributor is fully seated, the rotor segment should be aligned with the pointer cast into the distributor base. If the rotor segment does not come within a few degrees of the pointer, repeat the procedure in order to achieve the proper alignment.
7. Install the distributor mounting clamp bolt. Tighten: Tighten the bolt to 25 N.m (18 lb ft).
8. Install the distributor cap.
9. Install the new distributor cap screws. Tighten: Tighten the screws to 2.4 N.m (21 lb in).
10. Install the electrical connector to the distributor.
11. Install the spark plug wires to the distributor cap.
12. Install the ignition coil wire. Note the correct orientation of the wire boot.
13. Repeat Installation Procedure 2 if the malfunction indicator lamp illuminates after installing the distributor.
14. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Remove the air cleaner outlet resonator. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Disconnect the ignition coil electrical connectors.
4. Remove the ignition coil wire to the distributor.
5. Using a suitable tool disconnect the cruse control cable from the throttle body.
6. disconnect the accelerator control cable from the throttle lever.
7. Remove the accelerator cable bracket and position aside.
8. Remove the studs holding the bracket and the ignition coil to the intake manifold.
9. Remove the bracket and the ignition coil.
10. Drill and punch out the two rivets holding the ignition coil to the bracket.
11. Remove the ignition coil from the bracket.

1. Install the ignition coil to the bracket with the 2 screws.
2. Install the ignition coil and the bracket to the intake manifold with studs. Tighten: Tighten the studs to 11 N.m (97 lb in).
3. Install the accelerator control bracket. Tighten: Tighten the accelerator control cable bracket nuts and studs to 12 N.m (106 lb in).
4. Connect the accelerator control cable to the throttle cable.
5. Connect the cruse control cable (2) to the throttle linkage.
6. Install the ignition coil wire. The wire must not touch anything like the dip stick. Rubbing will make a ground or short after time of use.
7. Install the electrical connectors.
8. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
9. Install the air cleaner outlet resonator. Refer to «Air Cleaner Outlet Resonator Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Disconnect the electrical connector (3).
3. Remove the screws (4) holding the ignition control module (2) and the heat sink (1) to the bracket.
4. Remove the ignition control module and the heat sink.

1. Install the ignition control module (2) and the heat sink (1) on the bracket with the screws (4). Tighten: Tighten the screws to 3.5 N.m (31 lb in).
2. Reconnect the electrical connectors (3).
3. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
4. Refer to «Control Module References»(/chevrolet/chevy-express-h1500/2003-2012/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for programming and setup information.

Spark Plug Wire Inspection

Spark plug wire integrity is vital for proper engine operation. A thorough inspection will be necessary to accurately identify conditions that may affect engine operation. Inspect for the following conditions

1. Correct routing of the spark plug wires Incorrect routing may cause cross-firing.
2. Any signs of cracks or splits in the wires.
3. Inspect each boot for the following conditions: Tearing Piercing Arcing Carbon tracking Corroded terminal

If corrosion, carbon tracking or arcing are indicated on a spark plug wire boot or on a terminal, replace the wire and the component connected to the wire.

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Disconnect the spark plug wire at each spark plug. Twist the boots 1/2 turn before removing the boots. Pull only on the boot or use a tool designed for this purpose in order to remove the wire from each spark plug.
3. Disconnect the spark plug wire from the distributor. Twist each spark plug boot 1/2 turn. Pull only on the boot or use a tool designed for this purpose in order to remove the wires from the distributor.

1. Install the spark plug wires at the distributor.
2. Install the spark plug wire to each spark plug.
3. Inspect the wires for proper installation: Push sideways on each boot in order to inspect the seating. Reinstall any loose boot. Wire routings must be kept intact during service and followed exactly when wires have been disconnected or when replacement of the wires is necessary. Failure to route the wires properly can lead to radio ignition noise and crossfiring of the plugs, or shorting of the leads to the ground. Any time the spark plug wires or boots are installed on the spark plugs, new dielectric grease needs to be applied inside the boot.
4. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

Spark Plug Usage

1. Ensure that the correct spark plug is installed. An incorrect spark plug causes driveability conditions. Refer to «Ignition System Specifications»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__ignition-system-specifications) for the correct spark plug.
2. Ensure that the spark plug has the correct heat range. An incorrect heat range causes the following conditions: Spark plug fouling Colder plug Pre-ignition causing spark plug and/or engine damage Hotter plug

Spark Plug Inspection

1. Inspect the terminal post (1) for damage. Inspect for a bent or broken terminal post (1). Test for a loose terminal post (1) by twisting and pulling the post. The terminal post (1) should NOT move.
2. Inspect the insulator (2) for flashover or carbon tracking, soot. This is caused by the electrical charge traveling across the insulator (2) between the terminal post (1) and ground. Inspect for the following conditions: Inspect the spark plug boot for damage. Inspect the spark plug recess area of the cylinder head for moisture, such as oil, coolant, or water. A spark plug boot that is saturated causes arcing to ground.
3. Inspect the insulator (2) for cracks. All or part of the electrical charge may arc through the crack instead of the electrodes (3, 4).
4. Inspect for evidence of improper arcing. Measure the gap between the center electrode (4) and the side electrode (3) terminals. An excessively wide electrode gap can prevent correct spark plug operation. Inspect for the correct spark plug torque. Refer to «Ignition System Specifications»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__ignition-system-specifications) . Insufficient torque can prevent correct spark plug operation. An over torqued spark plug, causes the insulator (2) to crack. Inspect for signs of tracking that occurred near the insulator tip instead of the center electrode (4). Inspect for a broken or worn side electrode (3). Inspect for a broken, worn, or loose center electrode (4) by shaking the spark plug. A rattling sound indicates internal damage. A loose center electrode (4) reduces the spark intensity. Inspect for bridged electrodes (3, 4). Deposits on the electrodes (3, 4) reduce or eliminates the gap. Inspect for worn or missing platinum pads on the electrodes (3, 4), if equipped. Inspect for excessive fouling.
5. Inspect the spark plug recess area of the cylinder head for debris. Dirty or damaged threads can cause the spark plug not to seat correctly during installation.

Spark Plug Visual Inspection

1. Normal operation Brown to grayish-tan with small amounts of white powdery deposits are normal combustion by-products from fuels with additives.
2. Carbon Fouled Dry, fluffy black carbon, or soot caused by the following conditions: Rich fuel mixtures Leaking fuel injectors Excessive fuel pressure Restricted air filter element Incorrect combustion Reduced ignition system voltage output Weak coils Worn ignition wires Incorrect spark plug gap Excessive idling or slow speeds under light loads can keep spark plug temperatures so low that normal combustion deposits may not burn off.
3. Deposit Fouling Oil, coolant, or additives that include substances such as silicone, very white coating, reduces the spark intensity. Most powdery deposits will not effect spark intensity unless they form into a glazing over the electrode.

1. Remove the spark plug wires. Refer to «Spark Plug Wire Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
2. Loosen each spark plug 1 or 2 turns.
3. Brush or air blast away any dirt from around the spark plugs.
4. Remove the spark plugs one at a time. Place each plug in a tray marked with the corresponding cylinder numbers.

1. Inspect each spark plug gap. Adjust each plug as needed. Specification: Spark plug gap: 1.524 mm (0.060 in).
2. Hand start the spark plugs in the corresponding cylinders.
3. Tighten the spark plugs. Tighten: For used heads, tighten the spark plugs to 15 N.m (11 lb ft). For new aluminum heads, tighten the spark plugs to 20 N.m (15 lb ft). For new iron heads, tighten the spark plugs to 30 N.m (22 lb ft).
4. Install the spark plug wires. Refer to «Spark Plug Wire Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .

1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/chevy-express-h1500/2003-2012/remont/hoistjack/#general-information) .
2. Disconnect the CKP sensor harness connector.
3. Remove the CKP sensor mounting bolt.
4. Remove the CKP sensor.

1. Replace the CKP sensor O-ring.
2. Lubricate the O-ring with clean engine oil before installing the CKP sensor.
3. Install the CKP sensor.
4. Install the CKP sensor mounting bolt. Tighten: Tighten the mounting bolt to 8 N.m (71 lb in).
5. Connect the CKP sensor harness connector.
6. Lower the vehicle.
7. Perform the CKP system variation learn procedure. Refer to «Crankshaft Position System Variation Learn»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2__crankshaft-position-system-variation-learn) .

1. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
2. Disconnect the spark plug wires and ignition coil wire from the distributor. Refer to «Spark Plug Wire Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
3. Disconnect the camshaft position (CMP) sensor harness connector from the distributor.
4. Remove the distributor cap screws.
5. Remove the distributor cap.
6. Remove the rotor screws.
7. Remove the rotor.
8. Align the square slot in the reluctor wheel with the CMP sensor.
9. Remove the CMP screws.
10. Remove the CMP sensor.

1. Insert the CMP sensor through the reluctor wheel slot.
2. Install new CMP mounting screws. Tighten: Tighten the bolts to 2.2 N.m (20 lb in).
3. Install the rotor onto the reluctor wheel.
4. Install new rotor screws. Tighten: Tighten the screws to 2 N.m (18 lb in).
5. Install the distributor cap.
6. Install new distributor cap screws. Tighten: Tighten the screws to 2.4 N.m (21 lb in).
7. Connect the CMP sensor harness connector.
8. Connect the spark plug wires and ignition coil wire. Refer to «Spark Plug Wire Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/testing-diagnostics/#engine-control-system-fuel-system-43l-introduction-2-of-2) .
9. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

The knock sensor (KS) is located at the top rear of the engine.

1. Disconnect the negative battery cable.
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Disconnect the KS harness connector (3).
4. Remove the KS bolt (1).
5. Remove the KS (2).

1. Install the knock sensor (2) and bolt (1). Tighten: Tighten the knock sensor bolt to 25 N.m (18 lb ft).
2. Connect the KS harness connector (3).
3. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .

1. Remove the air cleaner assembly end cover clips.
2. Remove the air cleaner cover from the air cleaner assembly (4).
3. Remove the element.

1. Install the element.
2. Install the cover to the air cleaner assembly (4).
3. Install the air cleaner assembly end cover clips.

1. Loosen the duct clamp (1).
2. Remove the air cleaner assembly bolts (3).
3. Remove the air cleaner assembly.

1. Install air cleaner assembly
2. Install the air cleaner assembly bolts (3). Tighten: Tighten the bolts to 18 N.m (13 lb ft).
3. Tighten the duct clamp. Tighten: Tighten the clamp to 2 N.m (18 lb in).

1. Disconnect the negative battery cable.
2. Remove the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
3. Remove the retaining nut (1) from the air cleaner outlet.
4. Remove the air cleaner outlet duct (2) from the throttle body assembly.
5. Disconnect the harness connector of the intake air temperature (IAT) sensor.
6. Loosen the air cleaner outlet duct from the mass air flow (MAF) sensor.
7. Remove the air cleaner outlet duct.

1. Install the air cleaner outlet duct to the MAF sensor.
2. Connect the IAT sensor harness connector.
3. Install the air cleaner outlet duct (2) on the throttle body assembly.
4. Tighten the retaining nut (1). Tighten: Tighten the nut 2 N.m (18 lb in).
5. Install the engine cover. Refer to «Engine Cover Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/exteriorinterior-trim/#interior-trim-and-paneling) .
6. Connect the negative battery cable.

Powertrain

The powertrain has electronic controls to reduce exhaust emissions while maintaining excellent driveability and fuel economy. The powertrain control module (PCM) is the control center of this system. The PCM monitors numerous engine and vehicle functions. The PCM constantly looks at the information from various sensors and other inputs, and controls the systems that affect vehicle performance and emissions. The PCM also performs the diagnostic tests on various parts of the system. The PCM can recognize operational problems and alert the driver via the malfunction indicator lamp (MIL). When the PCM detects a malfunction, the PCM stores a diagnostic trouble code (DTC). The problem area is identified by the particular DTC that is set. The control module supplies a buffered voltage to various sensors and switches. Review the components and wiring diagrams in order to determine which systems are controlled by the PCM.

The following are some of the functions that the PCM controls

1. The engine fueling
2. The ignition control (IC)
3. The knock sensor (KS) system
4. The evaporative emissions (EVAP) system
5. The secondary air injection (AIR) system (if equipped)
6. The exhaust gas recirculation (EGR) system
7. The automatic transmission functions
8. The generator
9. The A/C clutch control
10. The cooling fan control

Powertrain Control Module Function

The powertrain control module (PCM) constantly looks at the information from various sensors and other inputs and controls systems that affect vehicle performance and emissions. The PCM also performs diagnostic tests on various parts of the system. The PCM can recognize operational problems and alert the driver via the malfunction indicator lamp (MIL). When the PCM detects a malfunction, the PCM stores a diagnostic trouble code (DTC). The problem area is identified by the particular DTC that is set. The control module supplies a buffered voltage to various sensors and switches. The input and output devices in the PCM include analog-to-digital converters, signal buffers, counters, and output drivers. The output drivers are electronic switches that complete a ground or voltage circuit when turned on. Most PCM controlled components are operated via output drivers. The PCM monitors these driver circuits for proper operation and, in most cases, can set a DTC corresponding to the controlled device if a problem is detected.

Malfunction Indicator Lamp (MIL) Operation

The malfunction indicator lamp (MIL) is located in the instrument panel cluster. The MIL will display as either SERVICE ENGINE SOON or one of the following symbols when commanded ON

Scheme 43

Scheme 44

The MIL indicates that an emissions related fault has occurred and vehicle service is required.

The following is a list of the modes of operation for the MIL

1. The MIL illuminates when the ignition is turned ON, with the engine OFF. This is a bulb test to ensure the MIL is able to illuminate.
2. The MIL turns OFF after the engine is started if a diagnostic fault is not present.
3. The MIL remains illuminated after the engine is started if the control module detects a fault. A diagnostic trouble code (DTC) is stored any time the control module illuminates the MIL due to an emissions related fault. The MIL turns OFF after three consecutive ignition cycles in which a Test Passed has been reported for the diagnostic test that originally caused the MIL to illuminate.
4. The MIL flashes if the control module detects a misfire condition which could damage the catalytic converter.
5. When the MIL is illuminated and the engine stalls, the MIL will remain illuminated as long as the ignition is ON.
6. When the MIL is not illuminated and the engine stalls, the MIL will not illuminate until the ignition is cycled OFF and then ON.

Trip

A trip is an interval of time during which the diagnostic test runs. A trip may consist of only a key cycle to power up the powertrain control module (PCM), allow the diagnostic to run, then cycle the key off to power down the PCM. A trip may also involve a PCM power up, meeting specific conditions to run the diagnostic test, then powering down the PCM. The definition of a trip depends upon the diagnostic. Some diagnostic tests run only once per trip (i.e., catalyst monitor) while other tests run continuously during each trip (i.e., misfire).

Warm-Up Cycle

The powertrain control module (PCM) uses warm-up cycles to run some diagnostics and to clear any diagnostic trouble codes (DTCs). A warm-up cycle occurs when the engine coolant temperature increases 22°C (40°F) from the start-up temperature. The engine coolant must also achieve a minimum temperature of 71°C (160°F). The PCM counts the number of warm-up cycles in order to clear the malfunction indicator lamp (MIL). The PCM will clear the DTCs when 40 consecutive warm-up cycles occur without a malfunction.

Diagnostic Trouble Codes (DTCs)

The powertrain control module (PCM) is programmed with test routines that test the operation of the various systems the PCM controls. Some tests monitor internal PCM functions. Many tests are run continuously. Other tests run only under specific conditions, referred to as Conditions for Running the DTC. When the vehicle is operating within the conditions for running a particular test, the PCM monitors certain parameters and determines if the values are within an expected range. The parameters and values considered outside the range of normal operation are listed as Conditions for Setting the DTC. When the Conditions for Setting the DTC occur, the PCM executes the Action Taken When the DTC Sets. Some DTCs alert the driver via the malfunction indicator lamp (MIL) or a message. Other DTCs do not trigger a driver warning, but are stored in memory. The PCM also saves data and input parameters when most DTCs are set. This data is stored in the Freeze Frame and/or Failure Records.

The DTCs are categorized by type. The DTC type is determined by the MIL operation and the manner in which the fault data is stored when a particular DTC fails. In some cases there may be exceptions to this structure. Therefore, when diagnosing the system it is important to read the Action Taken When the DTC Sets and the Conditions for Clearing the DTC in the supporting text.

There are different types of DTCs and different actions taken when the DTCs set. Refer to Diagnostic Trouble Code (DTC) Type Definitions for a description of the general characteristics of each DTC type.

DTC Status

When the scan tool displays a DTC, the status of the DTC is also displayed. The following DTC statuses are indicated only when they apply to the DTC that is set.

Fuel System Overview

The fuel system is a returnless on-demand design. The fuel pressure regulator is a part of the fuel sender assembly, eliminating the need for a return pipe from the engine. A returnless fuel system reduces the internal temperature of the fuel tank by not returning hot fuel from the engine to the fuel tank. Reducing the internal temperature of the fuel tank results in lower evaporative emissions.

An electric turbine style fuel pump attaches to the fuel sender assembly inside the fuel tank. The fuel pump supplies high pressure fuel through the fuel filter and the fuel feed pipe to the fuel injection system. The fuel pump provides fuel at a higher rate of flow than is needed by the fuel injection system. The fuel pump also supplies fuel to a venturi pump located on the bottom of the fuel sender assembly. The function of the venturi pump is to fill the fuel sender assembly reservoir. The fuel pressure regulator, a part of the fuel sender assembly, maintains the correct fuel pressure to the fuel injection system. The fuel pump and sender assembly contains a reverse flow check valve. The check valve and the fuel pressure regulator maintain fuel pressure in the fuel feed pipe and the fuel rail in order to prevent long cranking times.

Fuel Tanks

The fuel tank stores the fuel supply. The fuel tank is located on the left side of the vehicle. The fuel tank is held in place by 2 metal straps that attach to the frame. The fuel tank is molded from high density polyethylene.

Fuel Fill Pipe

The fuel fill pipe has a built-in restrictor in order to prevent refueling with leaded fuel. Once the fill vent is obstructed, fuel backs up the fill pipe and trips the dispensing nozzle. The fuel tank vent valves are connected and route to the canister to collect hydrocarbon emissions during operation of the vehicle.

Scheme 45

Scheme 46

The fuel fill pipe has a tethered fuel filler cap. A torque-limiting device prevents the cap from being over tightened. To install the cap, turn the cap clockwise until you hear clicks. This indicates that the cap is correctly torqued and fully seated. A built-in device indicates that the fuel filler cap is fully seated. A fuel filler cap that is not fully seated may cause a malfunction in the emission system.

Scheme 47

The fuel sender assembly consists of the following major components

1. The fuel level sensor
2. The fuel tank pressure (FTP) sensor
3. The fuel tank fuel pump module
4. The fuel strainer
5. The fuel filter

Fuel Level Sensor

The fuel level sensor consists of a float, a wire float arm, and a ceramic resistor cord. The position of the float arm indicates the fuel level. The fuel level sensor contains a variable resistor, which changes resistance in correspondence to the amount of fuel in the fuel tank. The powertrain control module (PCM) sends the fuel level information via the class 2 circuit to the instrument panel cluster (IPC). This information is used for the instrument panel (I/P) fuel gage and the low fuel warning indicator, if applicable. The PCM also monitors the fuel level input for various diagnostics.

Fuel Pump

The fuel pump is mounted in the fuel sender assembly reservoir. The fuel pump is an electric high pressure pump. Fuel is pumped to the fuel rail at a specified flow and pressure. The fuel pump delivers a constant flow of fuel to the engine during low fuel conditions and aggressive vehicle maneuvers. The powertrain control module (PCM) controls the electric fuel pump operation through a fuel pump relay. The fuel pump flex pipe acts to dampen the fuel pulses and noise generated by the fuel pump.

Fuel Strainer

The fuel strainer attaches to the lower end of the fuel sender. The fuel strainer is made of woven plastic. The functions of the fuel strainer are to filter contaminants and to wick fuel. Fuel stoppage at this point indicates that the fuel tank contains an abnormal amount of sediment.

Fuel Filter

The fuel filter is contained in the fuel sender assembly inside the fuel tank. The paper filter element of the fuel filter traps particles in the fuel that may damage the fuel injection system. The fuel filter housing is made to withstand maximum fuel system pressure, exposure to fuel additives, and changes in temperature. There is no service interval for fuel filter replacement.

Nylon Fuel Pipes

Nylon pipes are constructed to withstand maximum fuel system pressure, exposure to fuel additives, and changes in temperature. There are 3 sizes of nylon pipes used

1. 9.5 mm (3/8 in) ID for the fuel supply
2. 7.6 mm (5/16 in) ID for the fuel return
3. 12.7 mm (1/2 in) ID for the vent

Heat resistant rubber hose or corrugated plastic conduit protects the sections of the pipes that are exposed to chafing, to high temperatures, or to vibration.

Nylon fuel pipes are somewhat flexible and can be formed around gradual turns under the vehicle. However, if nylon fuel pipes are forced into sharp bends, the pipes kink and restrict the fuel flow. Also, once exposed to fuel, nylon pipes may become stiffer and are more likely to kink if bent too far. Take special care when working on a vehicle with nylon fuel pipes.

Quick-Connect Fittings

Quick-connect fittings provide a simplified means of installing and connecting fuel system components. The fittings consist of a unique female connector and a compatible male pipe end. O-rings located inside the female connector provide the fuel seal. Integral locking tabs inside the female connector hold the fittings together.

On-Board Refueling Vapor Recovery System (ORVR)

The On-Board Refueling Vapor Recovery System (ORVR) is an on-board vehicle system designed to recover fuel vapors during the vehicle refueling operation. The flow of liquid fuel down the fuel filler pipe provides a liquid seal which prevents vapor from leaving the fuel filler pipe. An evaporative emission (EVAP) pipe transports the fuel vapor to the EVAP canister for use by the engine.

Fuel Pipe O-Rings

O-rings seal the threaded connections in the fuel system. Fuel system O-ring seals are made of special material. Service the O-ring seals with the correct service part.

Scheme 48

The fuel meter assembly attaches to the engine intake manifold. The fuel rail assembly performs the following functions

1. Distributes fuel evenly to the injectors
2. Integrates the fuel dampener into the fuel metering system

Fuel Injectors

The fuel injector assembly is a solenoid device controlled by the powertrain control module (PCM) that meters pressurized fuel to a single engine cylinder. The PCM energizes the injector solenoid to open a normally closed ball valve. This allows the fuel to flow into the top of the injector, past the ball valve, and through a director plate at the injector outlet. The director plate has machined holes that control the fuel flow, generating a spray of finely atomized fuel at the injector tip. Fuel from the injector tip is directed at the intake valve, causing the fuel to become further atomized and vaporized before entering the combustion chamber. This fine atomization improves fuel economy and emissions.

Fuel Pressure Regulator

The fuel pressure regulator is contained in the fuel sender assembly.

Fuel Metering Modes of Operation

The powertrain control module (PCM) monitors voltages from several sensors in order to determine how much fuel to give the engine. The PCM controls the amount of fuel delivered to the engine by changing the fuel injector pulse width. The fuel is delivered under one of several modes.

Starting Mode

When the ignition is first turned ON, the PCM energizes the fuel pump relay for 2 seconds. This allows the fuel pump to build pressure in the fuel system. The PCM calculates the air/fuel ratio based on inputs from the engine coolant temperature (ECT), mass air flow (MAF), manifold absolute pressure (MAP), and throttle position (TP) sensors. The system stays in starting mode until the engine speed reaches a predetermined RPM.

Clear Flood Mode

If the engine floods, clear the engine by pressing the accelerator pedal down to the floor and then crank the engine. When the TP sensor is at wide open throttle (WOT), the PCM reduces the fuel injector pulse width in order to increase the air to fuel ratio. The PCM holds this injector rate as long as the throttle stays wide open and the engine speed is below a predetermined RPM. If the throttle is not held wide open, the PCM returns to the starting mode.

Run Mode

The run mode has 2 conditions called Open Loop and Closed Loop. When the engine is first started and the engine speed is above a predetermined RPM, the system begins Open Loop operation. The PCM ignores the signal from the heated oxygen sensors (HO2S). The PCM calculates the air/fuel ratio based on inputs from the ECT, MAF, MAP, and TP sensors. The system stays in Open Loop until meeting the following conditions

1. Both front HO2S have varying voltage output, showing that both HO2S are hot enough to operate properly.
2. The ECT sensor is above a specified temperature.
3. A specific amount of time has elapsed after starting the engine.

Specific values for the above conditions exist for each different engine, and are stored in the electrically erasable programmable read-only memory (EEPROM). The system begins Closed Loop operation after reaching these values. In Closed Loop, the PCM calculates the air/fuel ratio, injector ON time, based upon the signal from various sensors, but mainly from the HO2S. This allows the air/fuel ratio to stay very close to 14.7:1.

Acceleration Mode

When the driver pushes on the accelerator pedal, air flow into the cylinders increases rapidly. To prevent possible hesitation, the PCM increases the pulse width to the injectors to provide extra fuel during acceleration. This is also known as power enrichment. The PCM determines the amount of fuel required based upon the TP, the ECT, the MAP, the MAF, and the engine speed.

Deceleration Mode

When the driver releases the accelerator pedal, air flow into the engine is reduced. The PCM monitors the corresponding changes in the TP, the MAP, and the MAF. The PCM shuts OFF fuel completely if the deceleration is very rapid, or for long periods, such as long, closed-throttle coast-down. The fuel shuts OFF in order to prevent damage to the catalytic converters.

Battery Voltage Correction Mode

When the battery voltage is low, the PCM compensates for the weak spark delivered by the ignition system in the following ways

1. Increasing the amount of fuel delivered
2. Increasing the idle RPM
3. Increasing the ignition dwell time

Fuel Cutoff Mode

The PCM cuts OFF fuel from the fuel injectors when the following conditions are met in order to protect the powertrain from damage and improve driveability

1. The ignition is OFF. This prevents engine run-on.
2. The ignition is ON, but there is no ignition reference signal. This prevents flooding or backfiring.
3. The engine speed is too high, above red line.
4. The vehicle speed is too high, above rated tire speed.
5. During an extended, high speed, closed throttle coast down-This reduces emissions and increases engine braking.
6. During extended deceleration, in order to prevent damage to the catalytic converters

Fuel Trim

The powertrain control module (PCM) controls the air/fuel metering system in order to provide the best possible combination of driveability, fuel economy, and emission control. The PCM monitors the heated oxygen sensor (HO2S) signal voltage while in Closed Loop and regulates the fuel delivery by adjusting the pulse width of the fuel injectors based on this signal. The ideal fuel trim values are around 0 percent for both short term and long term fuel trim. A positive fuel trim value indicates the PCM is adding fuel in order to compensate for a lean condition by increasing the pulse width. A negative fuel trim value indicates that the PCM is reducing the amount of fuel in order to compensate for a rich condition by decreasing the pulse width. A change made to the fuel delivery changes the short term and long term fuel trim values. The short term fuel trim values change rapidly in response to the HO2S signal voltage. These changes fine tune the engine fueling. The long term fuel trim makes coarse adjustments to the fueling in order to re-center and restore control to short term fuel trim. A scan tool can be used to monitor the short term and long term fuel trim values. The long term fuel trim diagnostic is based on an average of several of the long term speed load learn cells. The PCM selects the cells based on the engine speed and engine load. If the PCM detects an excessive lean or rich condition, the PCM will set a fuel trim DTC.

EVAP System Operation

The evaporative emission (EVAP) control system limits fuel vapors from escaping into the atmosphere. Fuel tank vapors are allowed to move from the fuel tank, due to pressure in the tank, through the vapor pipe, into the EVAP canister. Carbon in the canister absorbs and stores the fuel vapors. Excess pressure is vented through the vent line and EVAP vent solenoid valve to the atmosphere. The EVAP canister stores the fuel vapors until the engine is able to use them. At an appropriate time, the control module will command the EVAP purge solenoid valve ON, allowing engine vacuum to be applied to the EVAP canister. With the EVAP vent solenoid valve OFF, fresh air is drawn through the vent solenoid valve and the vent line to the EVAP canister. Fresh air is drawn through the canister, pulling fuel vapors from the carbon. The air/fuel vapor mixture continues through the EVAP purge pipe and EVAP purge solenoid valve into the intake manifold to be consumed during normal combustion. The control module uses several tests to determine if the EVAP system is leaking.

Large Leak Test

This tests for large leaks and restrictions to the purge path in the evaporative emission (EVAP) system. When the enabling criteria has been met, the control module commands the EVAP vent solenoid valve ON and the EVAP purge solenoid valve ON, allowing vacuum into the EVAP system. The control module monitors the fuel tank pressure (FTP) sensor voltage to verify that the system is able to reach a predetermined level of vacuum within a set amount of time.

Small Leak Test

The engine off natural vacuum (EONV) diagnostic is the small-leak detection diagnostic for the evaporative emission (EVAP) system. While previous leak detection methods were performed with the engine running, the EONV diagnostic monitors the EVAP system pressure or vacuum with the ignition OFF. Because of this, it may be normal for the control module to remain active for up to 40 minutes after the ignition is turned OFF. This is important to remember when performing a parasitic draw test on vehicles equipped with EONV.

The EONV utilizes the temperature changes in the fuel tank immediately following a drive cycle to use the naturally occurring vacuum or pressure in the fuel tank. When the vehicle is driven, the temperature rises in the tank. After the vehicle is parked, the temperature in the tank continues to rise for a period of time, then starts to drop. The EONV diagnostic relies on this temperature change and the corresponding pressure change in a sealed system, to determine if an EVAP system leak is present.

The EONV diagnostic is designed to detect leaks as small as 0.51 mm (0.020 in). The diagnostic can determine if a small leak is present based on vacuum or pressure readings in the EVAP system. When the system is sealed, a finite amount of pressure or vacuum will be observed. When a 0.51 mm (0.020 in) leak is present, often little or no pressure or vacuum is observed. If the test reports a failing value, DTC P0442 will set.

Canister Vent Restriction Test

If the evaporative emission (EVAP) vent system is restricted, fuel vapors will not be properly purged from the EVAP canister. The control module tests this by commanding the EVAP purge solenoid valve ON, commanding the EVAP vent solenoid valve OFF, and monitoring the fuel tank pressure (FTP) sensor for an increase in vacuum. If the vacuum increases more than a calibrated value, DTC P0446 will set.

Purge Solenoid Valve Leak Test

If the evaporative emission (EVAP) purge solenoid valve does not seal properly fuel vapors could enter the engine at an undesired time, causing driveability concerns. The control module tests for this by commanding the EVAP purge solenoid valve OFF and the vent solenoid valve ON, sealing the system, and monitors the fuel tank pressure (FTP) for an increase in vacuum. If the control module detects that the EVAP system vacuum increases above a calibrated value, DTC P0496 will set.

Check Gas Cap Message

The control module sends a class 2 message to the driver information center (DIC) illuminating the Check Gas Cap message when a malfunction in the evaporative emission (EVAP) system and a large leak test fails.

EVAP System Components

The evaporative emission (EVAP) system consists of the following components

EVAP Canister

The canister is filled with carbon pellets used to absorb and store fuel vapors. Fuel vapor is stored in the canister until the control module determines that the vapor can be consumed in the normal combustion process.

EVAP Purge Solenoid Valve

The EVAP purge solenoid valve controls the flow of vapors from the EVAP system to the intake manifold. The purge solenoid valve opens when commanded ON by the control module. This normally closed valve is pulse width modulated (PWM) by the control module to precisely control the flow of fuel vapor to the engine. The valve will also be opened during some portions of the EVAP testing, allowing engine vacuum to enter the EVAP system.

EVAP Vent Solenoid Valve

The EVAP vent solenoid valve controls fresh airflow into the EVAP canister. The valve is normally open. The control module commands the valve ON, closing the valve during some EVAP tests, allowing the system to be tested for leaks.

Fuel Tank Pressure Sensor

The fuel tank pressure (FTP) sensor measures the difference between the pressure or vacuum in the fuel tank and outside air pressure. The control module provides a 5-volt reference and a ground to the FTP sensor. The FTP sensor provides a signal voltage back to the control module that can vary between 0.1-4.9 volts. A high FTP sensor voltage indicates a low fuel tank pressure or vacuum. A low FTP sensor voltage indicates a high fuel tank pressure.

Distributor Ignition (DI) System Description

The distributor ignition (DI) system is responsible for producing and controlling a high energy secondary spark. This spark is used to ignite the compressed air/fuel mixture at precisely the correct time. This provides optimal performance, fuel economy, and control of exhaust emissions. This ignition system consists of a single ignition coil and ignition control module (ICM). Spark energy is delivered via a distributor cap, rotor, and secondary spark plug wires. The driver module within the ICM is commanded to operate the coil by the powertrain control module (PCM), that has complete control over spark timing. The DI system consists of the following components

Crankshaft Position (CKP) Sensor

The CKP sensor is a three wire sensor based on the magneto resistive principle. A magneto resistive sensor uses two magnetic pickups between a permanent magnet. As an element such as a reluctor wheel passes the magnets the resulting change in the magnetic field is used by the sensor electronics to produce a digital output pulse. The PCM supplies a 12-volt, low reference, and signal circuit to the CKP sensor. The sensor returns a digital ON/OFF pulse 3 times per crankshaft revolution for the V6 engine, 4 times for the V8 engine. The CKP sensor reads the crankshaft mounted reluctor wheel to identify pairs of cylinders at top dead center (TDC).

Camshaft Position (CMP) Sensor

The CMP sensor is a hall-effect sensor located in the ignition distributor base, and uses the same type of circuits as the CKP sensor. The CMP sensor signal is a digital ON/OFF pulse, output once per revolution of the camshaft. The CMP sensor information is used by the PCM to determine the position of the valve train relative to the CKP.

Ignition Coil and ICM

The ICM is connected to the PCM by an ignition control (IC) circuit. The ICM also has a ground circuit and shares an ignition 1 voltage supply with the ignition coil. The coil driver in the ICM controls current through the ignition coil based on signal pulses from the PCM. There is no back-up or by-pass function in the ICM.

Secondary Ignition Components

The distributor is only used as a means to operate the CMP sensor and to distribute spark in the correct sequence. Since the distributor has no influence on base timing the distributor is not adjustable on V6 engines. The distributor position can be adjusted on V8 engines because the chance of crossfire between terminals is greater due to the proximity of the terminals. The spark is distributed through conventional carbon core wires to the spark plugs. The plugs are tipped with platinum for long wear and higher efficiency.

Powertrain Control Module (PCM)

The PCM controls all ignition system functions, and constantly corrects the basic spark timing. The PCM monitors information from various sensor inputs that include the following

1. The throttle position (TP) sensor
2. The engine coolant temperature (ECT) sensor
3. The mass airflow (MAF) sensor
4. The intake air temperature (IAT) sensor
5. The vehicle speed sensor (VSS)
6. The transmission gear position or range information sensors
7. The engine knock sensors (KS)

Modes of Operation

There is one normal mode of operation, with the spark under PCM control. If the CKP pulses are lost the engine will not run. The loss of a CMP signal may result in a longer crank time since the PCM cannot determine which stroke the pistons are on. Diagnostic trouble codes are available to accurately diagnose the ignition system with a scan tool.

Purpose

The knock sensor (KS) system enables the control module to control the ignition timing for the best possible performance while protecting the engine from potentially damaging levels of detonation. The control module uses the KS system to test for abnormal engine noise that may indicate detonation, also known as spark knock.

Sensor Description

This KS system uses one or two flat response two-wire sensors. The sensor uses piezo-electric crystal technology that produces an AC voltage signal of varying amplitude and frequency based on the engine vibration or noise level. The amplitude and frequency are dependant upon the level of knock that the KS detects. The control module receives the KS signal through a signal circuit. The KS ground is supplied by the control module through a low reference circuit.

The control module learns a minimum noise level, or background noise, at idle from the KS and uses calibrated values for the rest of the RPM range. The control module uses the minimum noise level to calculate a noise channel. A normal KS signal will ride within the noise channel. As engine speed and load change, the noise channel upper and lower parameters will change to accommodate the normal KS signal, keeping the signal within the channel. In order to determine which cylinders are knocking, the control module only uses KS signal information when each cylinder is near top dead center (TDC) of the firing stroke. If knock is present, the signal will range outside of the noise channel.

If the control module has determined that knock is present, it will retard the ignition timing to attempt to eliminate the knock. The control module will always try to work back to a zero compensation level, or no spark retard. An abnormal KS signal will stay outside of the noise channel or will not be present. KS diagnostics are calibrated to detect faults with the KS circuitry inside the control module, the KS wiring, or the KS voltage output. Some diagnostics are also calibrated to detect constant noise from an outside influence such as a loose/damaged component or excessive engine mechanical noise.

Air Intake System Description

The primary function of the air intake system is to provide filtered air to the engine. The system uses a cleaner element mounted in a housing. The cleaner housing is remotely mounted and uses intake ducts to route the incoming air into the throttle body. The secondary function of the air intake system is to muffle air induction noise. This is achieved through the use of resonators attached to the air intake ducts. the resonators are tuned to the specific powertrain. The mass air flow (MAF) sensor is attached to the outlet of the air cleaner housing. The air cleaner life indicator is located on an intake duct between the air cleaner housing and the throttle plate.

Special Tools

Special Tools and Equipment Illustration Tool Number/Description GE 41415-50 Fuel Tank Cap Adapter J 23738-A Mityvac J 26792 HEI Spark Tester J 34730-1A Fuel Pressure Gage J 34730-375 Harness Test Lamp J 35616 Connector Test Adapter Kit J 37027-1A IAC Motor Driver J 37088-A Fuel Line Disconnect Tool Set J 37287 Fuel Line Shut-Off Adapters J 38500-A Fuel Injector Cleaner J 38522 Variable Signal Generator J 39021 Fuel Injector Coil and Balance Tester J 39021-210 Injector Test Adapter Box J 39021-301 V6 Fuel Injector Test Adapter J 39194-B Heated Oxygen Sensor Wrench J 39765 Fuel Sender Locknut Wrench J 41413 EVAP Pressure and Purge Station J 41413-200 Evaporative Emissions System Tester (EEST) J 41413-SPT High Intensity White Light J 41413-VLV EVAP Service Port Vent Fitting J 41415-40 Fuel Tank Cap Adapter J 44175 Fuel Composition Tester J 44466-10 Regulator and Hose Assembly J 44466-11 IAFM Fuel Transfer Tube Recycling Block J 44466-12 CSFI Fuel Metering Body Jumper Block J 44466-13 Screws J 45722 Fuel Sender Lock Ring Wrench

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

See also:
• DTC P0016
• DTC P0140 or P0160
• DTC P0507
• Battery Negative Cable Disconnection and Connection
• Fastener Notice
• Control Module References
• Diagnostic Trouble Code (DTC) List - Vehicle
• Engine Cover Replacement
• Draining and Filling Cooling System (Static Fill)
• Draining and Filling Cooling System (Vac N Fill)
• COMPONENT FASTENER TIGHTENING NOTICE
• VEHICLE LIFTING CAUTION
• Lifting and Jacking the Vehicle
• HEATED OXYGEN AND OXYGEN SENSOR NOTICE
• EXCESSIVE FORCE AND OXYGEN SENSOR NOTICE
• Cruise Control Cable Replacement
• Gasoline/Gasoline Vapors Caution
• Battery Disconnect Caution
• Upper Intake Manifold Replacement
• Road Test Caution
• Fuel and Evaporative Emission Pipe Caution
• Special Tools
• Throttle Body Assembly Replacement
• Fuel Pressure Relief (With CH 48027)
• Fuel Pressure Relief (Without CH 48027)
• Fuel Tank Draining
• Ignition System Specifications
• Crankshaft Position System Variation Learn
