Configurable Customer Control System Chevrolet Chevy Express H1500

Memory Modules 1 illustration ~239 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Steering Wheel Nut41 N.m30 lb ft

Fastener Tightening Specifications

Steering Wheel Control Switch Assembly Replacement

Tools Required

  1. J 1859-A Steering Wheel Puller. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/memory-modules/#configurable-customer-control-system__special-tools) .
  2. J 42578 Steering Wheel Puller Legs. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/memory-modules/#configurable-customer-control-system__special-tools) .

Removal Procedure

  1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/chevrolet/chevy-express-h1500/2003-2012/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  2. Remove the inflator module. Refer to «Inflatable Restraint Steering Wheel Module Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/airbag/#supplemental-inflatable-restraint-system) .
  3. Disconnect the steering wheel control electrical connector.
  4. Remove the steering wheel nut.
  5. Install J 42578 and J 1859-A to the steering wheel. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/memory-modules/#configurable-customer-control-system__special-tools) .
  6. Use J 42578 and J 1859-A in order to remove the steering wheel. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/memory-modules/#configurable-customer-control-system__special-tools) .
  7. Remove J 42578 and J 1859-A from the steering wheel. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/memory-modules/#configurable-customer-control-system__special-tools) .
  8. Remove the controls and the control harness from the steering wheel.

Installation Procedure

  1. Install the controls and the control harness to the steering wheel.
  2. Install the wiring through the steering wheel.
  3. Install the steering wheel.
  4. Connect the steering wheel control electrical connector.
  5. Install the steering wheel nut. Tighten: Tighten the nut to 41 N.m (30 lb ft).
  6. Install the inflator module. Refer to «Inflatable Restraint Steering Wheel Module Replacement»(/chevrolet/chevy-express-h1500/2003-2012/remont/airbag/#supplemental-inflatable-restraint-system) .
  7. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/chevrolet/chevy-express-h1500/2003-2012/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Special Tools

Special Tools Illustration Tool Number/ Description J 1859-A Steering Wheel Puller J 42578 Steering Wheel Puller Legs
