Scheme 34
Scheme 35
| Callout | Component Name |
|---|---|
| 1 | Tow/Haul Switch |
| 2 | Auxiliary Power Outlet 2 |
| 3 | Inflatable Restraint I/P Module Disable Switch (Heavy Duty) |
| 4 | Blower Motor Switch - Auxiliary (C36) |
| 5 | Cigar Lighter (DT4)/Auxiliary Power Outlet 1 (w/o DT4) |
Scheme 36
| Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: Pins A - E/A Core/Insulation Crimp: Pins C - C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Auxiliary Power Outlet 1 (w/o DT4) Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | RD/WH | 640 | Battery Positive Voltage |
| B | Not Used | ||
| C | BK | 550 | Ground |
Auxiliary Power Outlet 1 (w/o DT4) Terminal Identification
Auxiliary Power Outlet 2
| Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Auxiliary Power Outlet 2 Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | RD/WH | 1040 | Battery Positive Voltage |
| B | Not Used | ||
| C | BK | 550 | Ground |
Auxiliary Power Outlet 2 Terminal Identification
Cigar Lighter (DT4)
| Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: Pins A - E/A Core/Insulation Crimp: Pins C - C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Cigar Lighter (DT4) Connector & Terminal Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | RD/WH | 640 | Battery Positive Voltage |
| B | Not Used | ||
| C | BK | 550 | Ground |
Cigar Lighter (DT4) Terminal Identification
Tools Required
J 42059 Cigar Lighter housing Remover. See Special Tools .
Removal Procedure
- Remove the cigar lighter fuse.
- Remove the cigar lighter element.
- Using J 42059 , perform the following procedure to remove the cigar lighter housing:. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/body-electrical/#accessory-power-socket__special-tools) . Place one side of the T-portion of J 42059 into the tab window in the lighter housing. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/body-electrical/#accessory-power-socket__special-tools) . Rotate the tool into the opposite tab window in the lighter housing. Once J 42059 is engaged in both tabs, pull the lighter housing straight out. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/body-electrical/#accessory-power-socket__special-tools) .
- If J 42059 tool fails to release the lighter socket from the retainer, perform the following alternate method: Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 as directed above to remove the socket. See «Special Tools»(/chevrolet/chevy-express-h1500/2003-2012/remont/body-electrical/#accessory-power-socket__special-tools) .
- Remove the tool from the lighter housing.
- Pull the cigar lighter housing (3) and the cigar lighter retainer (2) out of the trim plate.
- Disconnect the electrical connector (1) from the housing.
- Remove the retainer from the housing.
Installation Procedure
- Install the cigar lighter retainer (2) to the trim plate by pressing the retainer into place until fully seated.
- Connect the electrical connector (1) to the housing.
- Align the housing key to the slot in the retainer ring (2).
- Press the housing into place until the housing is fully seated.
- Install the cigar lighter fuse.
Special Tools
Special Tools Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
