Accessory Power Socket Chevrolet Chevy Express G2500

Body Electrical 4 illustrations ~376 words

Scheme 74

Scheme 74: Cigar Lighter/Auxiliary Outlets Schematics
Scheme 74: Cigar Lighter/Auxiliary Outlets Schematics

Scheme 75

Scheme 75: Power Outlet Component Views
Scheme 75: Power Outlet Component Views
CalloutComponent Name
1Tow/Haul Switch
2Auxiliary Power Outlet 2
3Inflatable Restraint I/P Module Disable Switch (Heavy Duty)
4Blower Motor Switch - Auxiliary (C36)
5Cigar Lighter (DT4)/Auxiliary Power Outlet 1 (w/o DT4)

Power Outlet Connector End Views

Auxiliary Power Outlet 1 (w/o DT4) Connector End Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 640 Battery Positive Voltage B - - Not Used C BK 550 Ground

Auxiliary Power Outlet 2 Connector End Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 1040 Battery Positive Voltage B - - Not Used C BK 550 Ground

Cigar Lighter (DT4) Connector End Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 640 Battery Positive Voltage B - - Not Used C BK 550 Ground

Tools Required

J 42059 Cigar Lighter housing Remover. See Special Tools and Equipment .

Scheme 76

Scheme 76: Removal Procedure
Scheme 76: Removal Procedure

Scheme 77

Scheme 77
Scheme 77
  1. Remove the cigar lighter fuse.
  2. Remove the cigar lighter element.
  3. Using J 42059, perform the following procedure to remove the cigar lighter housing: Place one side of the T-portion of J 42059 into the tab window in the lighter housing. Rotate the tool into the opposite tab window in the lighter housing. Once J 42059 is engaged in both tabs, pull the lighter housing straight out.
  4. If J 42059 tool fails to release the lighter socket from the retainer, perform the following alternate method: Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 as directed above to remove the socket.
  5. Remove the tool from the lighter housing.
  6. Pull the cigar lighter housing (3) and the cigar lighter retainer (2) out of the trim plate.
  7. Disconnect the electrical connector (1) from the housing.
  8. Remove the retainer from the housing.

Installation Procedure

  1. Install the cigar lighter retainer (2) to the trim plate by pressing the retainer into place until fully seated.
  2. Connect the electrical connector (1) to the housing.
  3. Align the housing key to the slot in the retainer ring (2).
  4. Press the housing into place until the housing is fully seated.
  5. Install the cigar lighter fuse.

Special Tools

Special Tools Illustration Tool Number/Description J 42059 Cigar Lighter Socket Remover
