Scheme 12
Scheme 13
Scheme 14
Scheme 15
ENGINE OIL PRESSURE GAUGE (IF EQUIPPED)
Gauge indicates engine oil pressure, not the amount of oil in the engine. However, oil level may affect oil pressure. Under normal operating conditions, gauge should register within NORMAL range. Oil pressure may vary with engine speed, oil viscosity or outside temperature. While engine is warming up, oil pressure will be higher than at normal operating temperature. If gauge registers below NORMAL operating band, stop immediately and check the oil level.
| CAUTION | DO NOT operate vehicle if oil pressure gauge continues to register below NORMAL operating range. |
OIL PRESSURE WARNING LIGHT
Under normal operating conditions, light will come on as a test when ignition is in ON position and go out when the engine is started. Oil pressure warning light may blink on and off when engine is idling at a stop or may come on briefly when a hard stop is made. This is normal. If light illuminates during normal vehicle operation, oil level should be checked immediately.
BRAKE SYSTEM WARNING LIGHT
BRAKE light illumination indicates that either the parking brake is engaged or there is a malfunction of the dual hydraulic brake system. The light should come on briefly when ignition switch is turned to the ON position, and go out after engine is started and the parking brake is released. If light stays on or comes on during vehicle operation, service is required.
ANTI-LOCK BRAKE WARNING LIGHT
If functioning correctly, light comes on when ignition switch is turned to the ON position and goes out after engine is started. If light glows while driving, the anti-lock brake system may be inoperative because of a system malfunction and service is required. If a fault occurs in the anti-lock system, the normal brake function remains operational unless the BRAKE warning light is also illuminated.
EGR WARNING LIGHT
Light indicates a periodic maintenance interval for the Exhaust Gas Recirculation system.
CHARGING SYSTEM WARNING LIGHT
Light is shown as a battery symbol on the instrument cluster. It will illuminate briefly when ignition is turned to ON or START position, and should go out when the engine starts and alternator begins to charge. If light stays on or comes on when the engine is running, the battery is not being charged and the electrical system needs service.
ENGINE COOLANT TEMPERATURE GAUGE
With ignition in RUN position, gauge shows engine coolant temperature. Readings may vary with outside temperature and operating conditions. Readings below the RED warning zone indicate normal operating range. If gauge pointer rises into RED zone, stop vehicle, let engine cool and check the coolant level.
LOW COOLANT WARNING LIGHT
Light will illuminate when ignition switch is in ON position as a system check and will go out after the engine is started. If it fails to illuminate, check fuses and/or electrical system. If light comes on during normal vehicle operation, engine coolant level is too low. Add fluid as necessary.
SERVICE ENGINE SOON/CHECK ENGINE WARNING LIGHT
Light will illuminate briefly when ignition is in ON position as a system check and will go out after the engine is started. If this light glows during vehicle operation it indicates that service to the computerized fuel, ignition or emission control system is required.
